Bosch NES 730 UC User manual

Use and Care Manual
Bosch Ceramic Glass Cooktops
Models: NES 730 UC, NES 930 UC with
NES 730 UC
NES 930 UC

Packaged with Cooktop
Use and Care Manual
Installation Instructions
Cooktop Cleaning Creme®
Razor Blade Scraper
Mounting Brackets
Registration Card
Foam Tape Seal
Two mTwisT Magnetic Dials
Table of Contents
Dear Bosch Cooktop Owner
Thank you for selecting the Bosch Ceramic Glass Cooktop with the mTwisTTM magnetic dial.
We recommend that you take time to read this manual prior to using your cooktop for the
first time.
This booklet contains helpful suggestions and instructions for using the featuers on your
cooktop. Keep it handy as it has answers to the questions that may come to mind when you
start to cook.The information in this manual will help you easily operate and care for your
cooktop for years of satisfaction.
If you have any questions, please contact us at 1-800-944-2904. For additional information,
visit our website at www.boschappliances.com or write to us at:
BOSCH
BSH Home Appliances Corp.
5551 McFadden Avenue
Huntington Beach, CA 92649
Sincerely,
BSH Home Appliances
Heat Settings for Radiant
Elements .................................................. 8
Cleaning Guide ....................................... 9
Care Before Use .............................................. 9
mTwisT Dial ...................................................... 9
Recommended Cleaners............................... 9
Avoid These Cleaners.................................... 9
Daily Cleaning Techniques ........................... 9
How to Use a Razor Blade Scraper ............ 9
Special Care Chart ............................ 10
Troubleshooting ................................... 11
Bosch Cooktop Warranty .................. 12
Important Safety Instructions ........... 1-2
Cooktop Models ..................................... 3
Operating Instructions .......................... 4
Before Using Cooktop for First Time ....... 4
Precautions for Long Life and
Good Appearance of the Surface ............ 4
General Operation of Cooktop .................. 4
mTwisT Dial ...................................................... 4
Indicator Lights ................................................ 4
Retained Heat ................................................... 4
The Elements
/ Setting the Controls .... 5
Radiant Elements ............................................. 5
Single Element .................................................. 5
Dual Element .................................................... 5
Temperature Limiters .................................... 5
Turning Elements Off..................................... 5
Power Off .......................................................... 6
Panel Lock .......................................................... 6
Pot Sizing ............................................................ 6
Keep Warm ...................................................... 6
Operation Without a mTwisT Dial ............ 6
Using Proper Cookware ....................... 7
Cookware Characteristics ............................ 7
Testing the Flatness of your Pans ............... 7
Specialty Pans ................................................... 7
Cookware Tips ................................................ 7
Note: The Bosch cooktop referred to thoughout this manual is manufactured by BSH Home Appliance Corp.

NES Cooktop Use and Care Manual
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USINGYOUR COOKTOP
!
WARNING
DO NOT STORE FLAMMABLE
MATERIALS ON OR NEAR THE
COOKTOP.
• When using the cooktop, DO NOT TOUCHTHE
HOT COOKING AREA OR THE IMMEDIATE
SURROUNDING
AREA.Even though dark in color,
these areas may be hot. Areas adjacent to the
elements may become hot enough to cause burns.
Never let clothing, potholders, or other
flammable materials come in contact with a
cooking area until it has cooled.
• For personal safety wear proper apparel.
Loose fitting garments or those with long, loose
sleeves should never be worn while cooking.
Tie long hair so that it doesn't hang loose.
WARNING
TO REDUCE THE RISK OF FIRE,
ELECTRIC
SHOCK, OR INJURY TO
PERSONS,
OBSERVE THE FOLLOWING:
• Use this unit only in the manner intended by the
manufacturer. If you have any questions, contact
the manufacturer.
• Before servicing unit,switch power OFF at service
panel and lock service panel to prevent power from
being switched on accidentally.
• Do not cook on a cooktop in which the glass top
has broken. If the cooktop glass should break, do
not use it or attempt to clean or fix it. Cleaning
solutions and spill overs may penetrate the broken
cooktop and create a risk of electric shock.Turn
off electric circuit to the cooktop and call an
authorized service agency immediately.
• Do not store items of interest to children above
the cooktop or at the back of it. If children climb
onto the cooktop to reach these items,they could
be seriously injured.
• Children and pets should not be left alone or
unattended in an area where appliances are in use.
They should never be allowed to sit or stand on
any part of appliance.
!
!
PAGE 1
Important Safety Instructions
!
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or death.
PERSONAL SAFETY
WARNING — TO REDUCE
THE RISK OF INJURY TO
PERSONS, IN THE EVENT OF
A GREASE FIRE, OBSERVE
THE FOLLOWING:
!
• In the event of a grease fire SMOTHER FLAMES with
a close-fitting lid, cookie sheet, or other metal tray,
then turn off the gas burner. BE CAREFUL TO
PREVENT BURNS. If the flames do not go out
immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
• Donot use water, includingwet dishclothes or towels
on grease fires. A violent steam explosion may result.
• NEVER PICK UP A FLAMING PAN. You may be
burned.
• ALWAYS have a working SMOKE DETECTOR
near the kitchen.
• LEAVE THE HOOD VENTILATOR ON when
flambéing food.
• Use an extinguisher ONLY IF:
• You know you have a Class ABC extinguisher,
and you already know how to operate it.
• The fire is small and contained in the area where
it started.
• The fire department is being called.
• You can fight the fire with your back to an exit.
• SMOTHER FLAMES from other types of food
fires with baking soda. NEVER use water on
cooking fires.

NES Cooktop Use and Care Manual
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using your cooktop
! !
Save These Instructions
• Use only dry potholders. Moist or damp pot
holders on hot surfaces may cause burns from
steam. Do not use a towel or other bulky cloth in
place of potholders. Do not let potholders touch
hot cooking areas.
• This appliance is equipped with one or more
surface units of different sizes. Always use utensils
that have flat bottoms and that are large enough
to cover the whole cooking area. The use of a
utensil smaller than the size of the cooking area
will expose a portion of the heated area to direct
contact with the user which could result in burns.
Proper relationship of utensil to burner will also
improve efficiency.
• Turn handles of utensils inward so that they do
not extend over adjacent work areas, cooking
areas, or the edge of the cooktop. This will help
prevent hot food spills, risk of burns and ignition
of flammable materials, and preventing access by
children.
• The cooktop is for cooking. Never use it to warm
or heat a room.
Be sure your appliance is properly installed
and grounded by a qualified servicer in
accordance with the Installation
Instructions provided with the cooktop.
Do not repair or replace any part of the
appliance unless specifically recommended
in this manual.
All other servicing should
be referred to a qualified servicer.
• Always use cookware and utensils appropriate for
the type and amount of food being prepared.
• Do not place any hot cookware on the control
panel area.
• Use high heat settings on the cooktop only when
necessary. Use low to medium settings to heat oil
slowly.
• Never move a pan of hot oil, especially a deep fat
fryer. Wait until it is cool.
• Never leave the cooktop unattended when using
high heat settings. Boilovers can cause smoke and
possibly damage the cooktop.
• Hold the handle of the pan to prevent movement
of the utensil when stirring or turning food.
• Other than the use of metal pans,only certain types
of glass, heatproof glass ceramic, ceramic,
earthenware, or other glazed utensils are suitable
for cooktop use.These types of utensils may break
with sudden temperature changes.Use only on low
or medium heat settings according to the utensil
manufacturer’s directions.
• Clean the cooktop with caution. If the soil must
be removed while the cooktop is hot, clean the
hot top with the metal razor blade scraper only.
Do not use a wet sponge or cloth while it is hot.
Some cleaners produce noxious fumes if applied
to a hot surface.
• Clean the ventilation system above or behind the
cooktop frequently so that grease from the
cooking vapors does not accumulate on the filters,
fan, intake, or hood.
• For people who wear electronic implants such
as a pacemaker or insulin pump, it is possible that
some implants may be affected by magnetic fields.
You should not carry the control knob (mTwisT
dial) in your pockets. The control knob is highly
magnetic and persons wearing electronic implants
should keep the control knob at least four inches
from the implant.
PAGE 2
Important Safety Instructions

NES Cooktop Use and Care Manual
PAGE 3
Cooktop Models
NES 730 UC - 30"
NES 930 UC - 36"
NO. TYPE SIZE WATTAGE
1 Dual 5-1/2" / 9" (140 / 230 mm) 1100 / 2500
2. Single 5-1/2" (140 mm) 1200
3 Dual 5" / 7" (120 / 180 mm) 700 / 1700
4 Single 6" (160 mm) 1500
5 Dual 5" / 8" (120 / 195 mm) 800 / 1900
6 Dual Element ON Indicator Lights (indicates inner and outer elements are on)
7 Heating Elements Selector Pads
8 mTwisT Dial Location
9 Function Pads (See Page 6)
10 POWER OFF Pad (See Page 6)
Cooktop Models
1
3
10
7
4
2
8
6
1
9
3
10
7
4
2
8
6
5
9
)
)
)
)

NES Cooktop Use and Care Manual
• Remove all packing materials and literature from
the cooktop surface.
• While cool, wipe with a clean, damp sponge and
dry.
• Apply the Cooktop Cleaning Creme®packaged
with the cooktop. Buff with a clean cloth. (See
Page 9 for daily care instructions.)
• There may be a slight odor during the first several
uses; this is normal and will disappear.
• Optimum cooking results depend on the proper
cookware being selected and used. (See Page 7.)
• The cooking surface will hold the heat and remain
hot up to 25 or 30 minutes after the elements
have been turned off.
• Read all safety precautions and Use and Care
Manual information prior to operating.
Precautions for Long Life and Good Appearance of
the Surface
• Regular, daily care using the Cooktop Cleaning
Creme will protect the surface and make it easier
to remove food soil and water spots.
• The ceramic glass cooking surface is a durable
material resistant to impact but not unbreakable
if a pan or other object is dropped on it.
• Do not use aluminum foil directly on the glass; it
will melt and damage the glass surface.
• Do not allow plastic, paper, or cloth to come in
contact with the hot glass surface; these items can
melt or burn and damage the glass surface.
• Do not allow pans to boil dry. This can damage
the pan, element and/or the cooktop.
• Never cook food directly on the glass.
• Avoid placing a wok support ring, trivet or other
metal stand on the glass surface.
• Do not use the glass surface as a cutting board.
• Do not slide cookware across the cooking surface;
it may scratch the glass.
• Do not place wet pans on the glass surface.
BEFORE USING THE COOKTOP
FOR THE FIRST TIME
Cooktop Operating Instructions
Cooktop Operating Instructions
PAGE 4
Retained Heat
The glass cooking surface retains heat and stays hot
after the element(s) have been turned off. The retained
heat may be used to hold foods at serving temperatures
for a short time.
General Operation of Cooktop
The cooktop uses touch pads and a magnetic dial to
operate the cooktop.When touching the glass of a touch
pad, such as an element or function pad, use the flat
part of the finger and touch the center of the pad. A
beep will sound when touching any of these pads.
mTwisT Dial
The cooktop uses a mTwisT magnetic dial to select
the desired heat setting. The mTwisT dial is held onto
the cooktop by a strong magnet and automatically
positions itself in the center of the dial location when
placed on the cooktop.
Note: If the dial is removed from the cooktop when
in use, all elements will be turned off. The cooktop is
locked and the Panel Lock light comes on. (See Setting
Panel Lock on Page 6.)
Element‘ON’ Indicator Light
The area above the element touch pad being used
will show the cook setting when the element is on.
When the element is turned off, the hot surface
indicator comes on in this area. (See Hot Surface
Indicator Light below).
Hot Surface Indicator Light
Each element features a hot indicator light to show
when the cooking surface is too hot to touch. A
letter Hwill appear above the element touch pad.
The light remains on until the cooking area has cooled to a
safe-to-touch temperature.
If a hot surface light is on, use caution when working or
cleaning around the cooktop as the cooktop is still hot.

NES Cooktop Use and Care Manual Cooktop Operating Instructions
The Elements / Setting the Controls
PAGE 5
Radiant Elements
Bosch UltraSpeedTM radiant elements use a wire
ribbon located under the ceramic glass surface to
provide the heat for cooking.These radiant elements
will cycle on and off by design (see Temperature
Limiters, below.) There are 9 heat setting positions
from 9 (high) to 1 (low) and a special setting for keep
warm.
Dual Element
The dual element consists of two radiant ribbon
elements within the same heating area. Either the small
inner element or both the inner and outer elements
may be selected for use, depending on the size of
cookware. (See page 7.)
Temperature Limiters
Each UltraSpeed heating element has its own sensor
to protect the glass cooking surface from extreme
high temperatures. The limiters will operate
automatically by cycling the element on and off
regardless of the cook setting.
Although cycling is normal, any one of the following
conditions can activate the limiter and cause it to
cycle on and off more than usual:
• The base of the pan is not making full contact
with the heating surface (due to a warped or
uneven base).
• The pan is too small for the size of the element.
• The pan has boiled dry.
• The material or shape of the pan is slow to
transfer the heat.
Setting the Controls (dual element)
1. Place pan on element.
2. Touch element pad for desired element. Display
will show a 0.
3.Touch POT SIZING pad. Control defaults to large
size (inner and outer) element. Touch the POT
SIZING element pad again for smaller element.
Touching the POT SIZING pad repeatedly alternates
the element size. The dual element light comes on
above element pad when using large element.
4.Turn the mTwisT dial to the desired setting.
To the right (clockwise) starts with heat setting
1(low).
To the left (counterclockwise) starts with heat
setting 9(high).
Turn the dial until the desired heat setting is
displayed.
Setting the Controls (single element)
1. Follow steps 1, 2 and 4 above.
Changing Heat SettingWhile Cooking
1. Touch element pad for element desired. Display
will show 0.
2. Turn dial. The first turn of the mTwisT dial will
display the current cook setting.
3.Turn dial left or right to new cook setting. The new
cook setting is displayed.
Change Pot Size when Cooking (for dual only)
See Pot Sizing (Page 6 ).
To Turn Off One Surface Element
1. Touch element pad for desired element.
2. Display shows 0. After 5 seconds the element
shuts off.
Or
touch element pad twice.
Or
touch element pad once. After five seconds,
the element turns off.
To Turn Off All Elements at the Same Time
1.Touch POWER OFF pad.
Or
Remove mTwisT dial from cooktop. Once
removed, the cooktop controls are locked. Replace
mTwisT dial then touch and hold PANEL LOCK pad
for three seconds to unlock control.

Setting the Controls
Cooktop Function Pads
Power Off
Turns off all elements at the same time.The indicator light
above the POWER OFF pad is lit when at least one element
is on.The light will turn off when the POWER OFF pad is
touched or all elements are turned off.
Panel Lock
The panel lock is selected to prevent the cooktop from
being turned on, such as for cleaning. The elements will
not function when turned on.
Setting Panel Lock
1.Touch and hold PANEL LOCK pad for three seconds.A
light above the pad stays lit when the panel is locked.
2. To unlock Touch the PANEL LOCK pad and hold for
three seconds. The light above the pad will disappear.
The cooktop cannot be locked when a surface element is
operating. It is recommended to lock the cooktop
before cleaning.
Pot Sizing
Use this pad to choose the pot size on dual elements.
1.Touch element pad for dual element. Control defaults to
larger element. Dual element light comes on above element
pad indicating large size is selected.
2. Touch POT SIZING pad to change to smaller element.
Dual element light will turn off.
3.Turn mTwisTdial to desired heat setting.
To change element size for different size cooking pot when
the element is on:
1.Touch element pad. Display will show 0.
NES Cooktop Use and Care Manual Cooktop Operating Instructions
PAGE 6
Operation Without mTwisT Dial
The cooktop can be operated without the mTwisT dial.
1.Turn off Panel Lock (see below).
2.Touch element pad for desired element. Display shows 0.
3. Choose the POT SIZING pad (if using dual element).
4.Touch element pad repeatedly until desired heat settting
is displayed.
Change Heat Setting
1. Select element pad for desired element.
2. Each touch of the element pad changes setting.
Continue touching repeadedly until desired heat setting
is displayed.
Change Pot Size - (for dual elements only)
1. Select element pad for desired element.
2.Touch Pot Sizing pad for desired pad.
3.Touch element pad until desired heat setting is displayed.
Turn Off Element
1.Touch element pad.
2.Touch element pad until 0is displayed.
Or
for several elements, select POWER OFF pad.
2.Touch POT SIZING pad to change element size chosen,
element turns off.
3.Turn mTwisT dial to desired heat setting.
KeepWarm
Each element has a keep warm setting to keep hot, cooked
foods at serving temperatures.
To set Keep Warm feature:
1.Touch element pad for desired element.
2.Touch KEEP WARM pad. Lis displayed above selected
element and element comes on.
Keep Warm Guidelines
Use pans/utensils with flat bases. Plates and casseroles
with shallow ridges around the base can be used provided
they are made of heat-safe materials.
Keep dish covered to keep foods hot.
Choose pans and cookware that may be safely used on a
hot surface. Example: Use CorningWare® "Safe for
Rangetop" rather than Pyrex® which is not recommended
for cooktop use.
Use a trivet or steamer inside a pan when necessary to
raise food off bottom of pan.

NES Cooktop Use and Care Manual
Cookware Characteristics
The choice of pans directly affects the cooking speed
and uniformity. For best results select pans with the
following features:
1. Flat Bases - When a pan is hot, the base (pan
bottom) should rest evenly on the surface without
wobbling (rocking). Flat, medium to heavy-weight
pans are best.
To test the flatness of your pans
Turn the pan upside down on the countertop and place
a ruler flat against the bottom of the pan. The bottom
of the pan and the straight edge of the ruler should be
flush against each other.
Another simple test to determine even heat
distribution across the cookware bottom is to place
1” of water in the pan. Bring the water to a boil and
observe the location of the bubbles as the water starts
to boil. Good, flat cookware will have an even
distribution of bubbles over the bottom surface area.
2. Diameter – The base of the pan should cover or
match the diameter of the element being used.
Pans may overhang the element area by 1" all
around.
3.Tight Fitting Lid – A lid shortens cooking time by
holding the heat inside the pan.
Specialty pans
Specialty pans, such as griddles, roasters, pressure
cookers, woks, water bath canners and pressure
canners must have the same features as described
above. Use only a flat-bottom wok. Never place a
support ring, such as a wok ring or trivet, on the
cooking surface.
PAGE 7
Cooktop Operating Instructions
Using Proper Cookware
CAUTION
•Foods packaged in aluminum foil should not
be placed directly on the glass ceramic surface for
cooking; aluminum foil can melt and cause perma-
nent damage.
•Plastic, paper and cloth can melt or burn
when in contact with a hot surface. Do not let
these items come in contact with the hot glass
ceramic surface.
•Do not allow pans to boil dry. This can
permanently damage the pan, the element and
the cooktop glass.
Cookware Tips
• Use of pots and pans with rounded (either
concave or convex) warped or dented bottoms
should be avoided. See drawings above.
• Make sure the bottom of the pot or pan being
used is clean and dry.
• Use pots and pans with thick, smooth metal
bottoms.
• Do not slide metal pots across the cooktop.Pans
may leave marks. (See Page 9 for cleaning.)
• Do not use glass pans as they may scratch the
surface.

NES Cooktop Use and Care Manual
All these settings are recommended without the element being preheated. Use this chart as a guide.
Cooktop Operating Instructions
Heat Settings for Radiant Elements
A range of heat settings are listed because the actual
setting depends on:
1) type and quality of pan
2) type, quantity and temperature of the food
3) element used
4) the cook’s preference.
208/240 Volt Connection: The Heat Settings
recommended on this page are based on a 240 volt
power source. If your cooktop is connected to 208
volts, the same heat settings apply but foods may take
a little longer to finish cooking.
Melting butter/chocolate 1
Delicate sauces
Finishing rice 1-3
Simmering sauces with
butter and egg yolk
Bacon
Cooking vegetables, fish,
broths
Eggs, fried or scrambled
Finishing cereals, pasta 4-6
Milk
Pancakes
Pudding
Simmering meats
Steaming vegetables,
fish, broths
Pan frying
Spaghetti sauces
Sauteed vegetables
Stewing meat, soups
Braising meat
Pan frying meat, fish,
Stir frying 6-8
Quickly brown or
sear meats
Hold rapid boil
Boiling water for
vegetables, pasta, 9
rice, etc.
Type of Food HEAT SETTINGS
PAGE 8
