Bosch Rexroth EFC 3600 Instructions for use

Easy Start Guide
This guide is intended to compliment the user manual provided by the manufacturer.
It is provided as a basic introduction to the product for Inverter Drive Supermarket customers.
It should not be used as a replacement for the manual issued by the manufacturer.
Issue 2
20140924
This product is not a safety device. All safety considerations including but not
limited to Emergency Stop provision should be assessed separately and are
outside the scope of this guide.
Bosch Rexroth
EFC 3600 Frequency Inverter
available from Rexroth.InverterDrive.com
(+)

Easy Start Guide
Page 1
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Page 11
Page 12
Page 13
Contents
Power and Motor Connections (Single Phase)
Power and Motor Connections (Three Phase)
Motor Connections - Star and Delta
Parameters - Overview
Parameters to set before use
How to Operate the Inverter from the keypad
How to connect and configure a Potentiometer
for remote speed control
How to connect and configure a Run Forward or
Run Reverse switch
Brake Resistor Connection
How to Reset the Inverter to Factory Defaults
How to set a Parameter value
How to connect and configure a Run/Stop switch
with Forward/Reverse selection
How to configure “3-Wire” control with Run/Stop
pushbuttons and Forward/Reverse selection
Contents
Bosch Rexroth EFC 3600 Series Inverter

Easy Start Guide
1. Power and Motor Connections (Single Phase)
Page 2
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Notes:
The illustration above is based on the frame
size B model (0.75kW). The terminal layout for
sizes A, C and D (0.37kW, 1.5kW and 2.2kW is
similar.
The order of the three phases determines the
direction the motor turns.
Important:
Use screened SY cable between the Inverter
and Motor to minimise electromagnetic
interference.
Ensure the motor cable screen is earthed at
the motor end.
Before commencing, confirm that the Inverter and
all cables are completely isolated from the power
supply, have been isolated for at least 5 minutes
and that the motor is not turning.
Bosch Rexroth EFC 3600 Series Inverter
(+)
MotorPower
Phase
Phase
Phase
Earth
Live
Neutral
Earth

Easy Start Guide
2. Power and Motor Connections (Three Phase)
Page 3
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Notes:
The illustration above is based on the frame
size B model (0.75kW). The terminal layout for
other frame sizes is similar.
The order of the three motor phases
determines the direction the motor turns.
The order of the three power phases is
unimportant.
Important:
Use screened SY cable between the Inverter
and Motor to minimise electromagnetic
interference.
Ensure the motor cable screen is earthed at
the motor end.
Before commencing, confirm that the Inverter and
all cables are completely isolated from the power
supply, have been isolated for at least 5 minutes
and that the motor is not turning.
Bosch Rexroth EFC 3600 Series Inverter
(+)
MotorPower
Phase
Phase
Phase
Earth
Phase
Phase
Phase
Earth

Easy Start Guide
3. Motor Connections - Star and Delta
Page 4
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
3.2 Motor connected in DELTA:
The link configuration is shown in the
illustration opposite and is sometimes referred
to as “three-a-breast”.
The order of the three phases determines the
direction the motor turns.
Note that the cable screen and earth are
connected together at the earth terminal.
Phase
Phase
Phase
Earth
Screen
3.1 Motor connected in STAR (or Wye):
For safety purposes, Star (shown opposite) is
the default configuration for new motors and is
sometimes known as “two at one side”.
Only two links are required for Star. Double-up
the links if changing from Delta to allow the
motor to be changed to back in future.
The order of the three phases determines the
direction the motor turns.
Note that the cable screen and earth are
connected together at the earth terminal.
Phase
Phase
Phase
Earth
Screen
Dual voltage induction motors typically include
terminal boxes with six points. The points can
be connected together with links in one of two
ways to suit one of the two rated voltages.
The two ways of connecting the links are
shown below. These are known as “Star” (the
higher voltage) or “Delta” (the lower voltage).
Link
The selection of Star or Delta is not optional
and must match the supply voltage.
Dual voltage motor nameplates include
symbols to represent voltage and full load
current in each configuration.
Delta is represented by a triangle and star by a
Y (Wye).
DELTA
STAR
Link
Bosch Rexroth EFC 3600 Series Inverter

Easy Start Guide
Page 5
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
4. Parameters - overview
Parameter
Description
How to set
b0.02
Access to additional parameters
Set at to enable Extended Parameters ( .2Default is 0 for Basic Parameters)
b1.05
Maximum Frequency
Maximum frequency of the . Set to for most applications.Inverter 50.00
b1.06
Upper Frequency
Maximum frequency of .speed reference (eg. keypad dial) Set to for most applications.50.00
b1.07
Minimum Frequency
Set to for most applications (Default is 00.00).05.00
b1.08
Lower frequency mode
Set to to enable Minimum Frequency.1
b1.20
Acceleration ramp in seconds
Default is . Increase or decrease if required.5
b1.21
Deceleration ramp in seconds
Default is . Increase or decrease if required.5
S0.00
V/F curve mode
Default is . Set to 1 if the motor is driving a Fan or Pump.0
S2.00
Rated motor frequency in Hz
Default is 50.00. Change to 60.00 for 60Hz motor only - otherwise set at 50.00
S2.01
Rated motor speed in rpm
Set to match motor nameplate - eg. 1380
S2.02
Rated motor power in kW
Set to match motor nameplate - eg. 0.8 (for 0.75kW)
S2.03
Rated motor voltage
Set to match motor nameplate - eg. 230
S2.04
Rated motor current in A
Set to match motor nameplate - eg. 3.34
The Inverter contains a number of settings
which can be changed to tailor it for use in a
wide range of applications. These settings are
known as parameters.
Parameters are typically referred to by code or
number (eg. s2.04 = Rated Motor Current) with
a description available in the manual.
The parameters contain critical information
essential to the correct operation of the
Inverter. Therefore, they should at least be
checked by the user before the Inverter is
operated for the first time.
The parameters listed in section 5 are intended
to provide a starting point to allow for basic
operation of the EFC 3600 Inverter.
5. Parameters to set before use
See section 6 to learn how to set a parameter value.
Set the following parameters to allow the EFC
3600 to control a motor with Run, Stop and
Speed Control from the keypad.
If any of the parameters have been changed
previously, follow the procedure in section 13
to reset the Inverter to Factory Defaults.
5.1 Parameters to check and values to set
Bosch Rexroth EFC 3600 Series Inverter

Easy Start Guide
6. How to set a Parameter value
Page 6
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Bosch Rexroth EFC 3600 Series Inverter
6.1 Find Parameter Groups.
This example demonstrates the steps required to set
parameter b1.05 which is Maximum Frequency.
Press the “Func” key repeatedly until the display shows
“-b0-” (shown in the illustration opposite).
6.2 Find a Parameter Group eg. b1
There are a total of 12 parameter groups when
“Advanced Parameters” are enabled:-
Some parameter groups may be hidden when “Advanced
Parameters” are not enabled. Press “Set” to select “-b1-”.
6.3 Find a Parameter eg. b1.05
The display will show “b1.00" to indicate parameter 00
within group b1.
Use the up and down keys to navigate to parameter
b1.05. Press the “Set” key to modify the parameter value.
Note that in some cases, the value of a parameter can be
restricted by the value of another parameter.
6.4 Change a Parameter value.
Use the up and down keys to increase or decrease the
value. Press and hold the up or down key to change the
value more quickly.
Press the “Set” key to save changes. The display will
show the next available parameter.
Press “Func” twice to exit.

Easy Start Guide
7. How to operate the Inverter from the keypad
Page 7
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
7.1 Use the dial to set the required speed.
The display will change to show the current speed
reference in Hz.
The minimum speed reference is defined by parameter
b1.07 and the maximum reference by b1.06.
7.2 Press the green “Run” button to start the motor.
Press the green button firmly to start the motor. The motor
will accelerate to the speed set in 7.1 (above) in the time
defined by parameter b1.20.
Motor speed can be changed whilst the motor is running by
rotating the dial clockwise (faster) or anti-clockwise
(slower). When the motor is running, the “Run” lamp will be
illuminated.
7.3 Press the red “Stop” button to stop the motor.
The red button will stop the motor.
The time taken (in seconds) to stop the motor is determined
by parameter b1.21.
Bosch Rexroth EFC 3600 Series Inverter

Easy Start Guide
Page 8
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Bosch Rexroth EFC 3600 Series Inverter
8. How to connect and configure a Potentiometer
for remote speed control
Parameter
Description
How to set
b0.02
Access to additional parameters
Default is 0 for Basic Parameters. Set at to enable Extended Parameters.2
b1.00
Frequency Setting Source
Set to to enable 0-10V via 10kOhm Potentiometer2
E0.22
Potentiometer Min Speed Hz
Set to for most applications.05.00
E0.24
Potentiometer Max Speed Hz
Set to for most applications.50.00
8.1 Parameters to change for remote Potentiometer speed control
If the integrated dial on the keypad is
unsuitable for the application, a remote
Potentiometer can be used instead.
This provides the benefit of allowing motor
speed to be controlled from a more convenient
location such as a cabinet door (if the EFC
3600 is cabinet-mounted) or on the machine
itself.
A Potentiometer of rating should be
used.
The number of turns depends on the
application but both single turn and ten turn
Potentiometers are available from The Inverter
Drive Supermarket at InverterDrive.com.
10kOhm
8.2 Connecting the Potentiometer
A wiring diagram is shown in the illustration
opposite. The most important connection at
the Potentiometer end is the centre terminal or
“wiper”.
The wiper will output a variable voltage
between 0 and 10 volts and should be
connected to the Vr1 terminal at the Inverter
end. It is this voltage which provides the speed
signal with 0V being slowest and 10V fastest.
The default output frequency at 0V is 0Hz. To
change this, edit Parameter E0.22. The default
output frequency at 10V is 50Hz. To change
this, edit Parameter E0.24.
If the rotation of the Potentiometer is the
opposite to that required (ie. turn anti-
clockwise to increase speed instead of
clockwise) reverse connections +10V and
GND.
Use shielded SY cable between Potentiometer
and Inverter and ensure that the cable screen
is connected to the earth IO terminal.
2
1
3
10kOhm
Potentiometer
[Order Code 21302]
Screened
“SY” Cable
1
3
2
Screen to
Earth Terminal
GND
+10VVr1
EFC 3600
I/O Terminal Blocks

Easy Start Guide
Page 9
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Bosch Rexroth EFC 3600 Series Inverter
9. How to connect and configure a Run Forward or
Run Reverse switch
Parameter
Description
How to set
b0.02
Access to additional parameters
Default is 0 for Basic Parameters. Set at to enable Extended Parameters.2
b1.02
First RUN Command Source
Set to for IO Terminals on the Inverter1
E0.00
2-wire / 3-wire control
Set to for 2-wire control with Run/Forward or Run/Reverse0
E0.01
Terminal X1 program
Set to for run forward command on X123
E0.02
Terminal X2 program
Set to for run reverse command on X224
9.1 Parameters to change for remote Run/Stop
The parameters described in Section 5 enable
Run/Stop operation via the red and green
buttons on the Inverter.
If this is unsuitable for the application, a remote
switch can be used instead.
This section explains how to enable 2-wire
control with Run Forward / Stop / Run Reverse
commands via a single selector switch.
Note that once this procedure is complete, the
Run/Stop buttons on the Inverter can no longer
be used.
9.2 Connecting the Switch
A wiring diagram is shown in the illustration
opposite.
The SC terminal is a common connection for
terminals X1-X5 and has no other function.
A suitable 3 position NO ( )
switch should be installed between terminals
SC, X1 and X2. The centre position should
remain open circuit.
When a connection is made between terminals
SC and X1, the motor will run forward. When
terminals SC and X2 are connected, the motor
will run in reverse.
Care should be taken to ensure that terminals
X1 and X2 cannot be connected to SC at the
same time or to each other.
Normally Open
EFC 3600
I/O Terminal Blocks
21
1
X1 SCX2
FR
3
23
Switch, 3 Position
Normally Open
“Run Forward / Stop / Run Reverse”

Easy Start Guide
Page 10
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Bosch Rexroth EFC 3600 Series Inverter
10. How to connect and configure a Run/Stop switch
with Forward/Reverse selection
The parameters described in Section 5 enable
Run/Stop operation via the red and green
buttons on the Inverter.
If this is unsuitable for the application, remote
switches can be used instead.
This section explains how to enable 2-wire
control with Run/Stop and Forward/Reverse
commands via separate selector switches.
Note that once this procedure is complete, the
Run/Stop buttons on the Inverter can no longer
be used.
Parameter
Description
How to set
b0.02
Access to additional parameters
Default is 0 for Basic Parameters. Set at to enable Extended Parameters.2
b1.02
First RUN Command Source
Set to for IO Terminals on the Inverter1
E0.00
2-wire / 3-wire control
Set to for 2-wire control with Run/Stop and Forward/Reverse1
E0.01
Terminal X1 program
Set to for run forward command on X123
E0.02
Terminal X2 program
Set to for run reverse command on X224
10.1 Parameters to change for remote Run/Stop
10.2 Connecting the Switch
A wiring diagram is shown in the illustration
opposite.
The SC terminal is a common connection for
terminals X1-X5 and has no other function.
Two suitable 2 position NO ( )
switches should be installed: One between
terminals SC and X1 (Run/Stop) and the other
between terminals SC and X2
(Forward/Reverse).
Note that the Forward/Reverse switch only
selects the direction of rotation - it will not start
or stop the motor.
If the application only requires the motor to turn
in one direction, the Forward/Reverse switch
can be omitted.
Normally Open
EFC 3600
I/O Terminal
Blocks
13
X1 SCX2
12
R
32 1
Switch, 2 Position
Normally Open
“Forward / Reverse”
Switch, 2 Position
Normally Open
“Run / Stop”

Easy Start Guide
Page 11
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Bosch Rexroth EFC 3600 Series Inverter
11. How to configure “3-Wire” control with Run/Stop
pushbuttons and Forward/Reverse selection
The parameters described in Section 5 enable
Run/Stop operation via the red and green
buttons on the Inverter.
If this is unsuitable for the application, remote
switches can be used instead.
This section explains how to enable 3-wire
control with Run and Stop commands via
separate pushbuttons and Forward/Reverse
selection via a selector switch. Note that once
this procedure is complete, the Run/Stop
buttons on the Inverter can no longer be used.
Parameter
Description
How to set
b0.02
Access to additional parameters
Default is 0 for Basic Parameters. Set at to enable Extended Parameters.2
b1.02
First RUN Command Source
Set to for IO Terminals on the Inverter1
E0.03
Terminal X3 program
Set to for 3-wire running control on X37
E0.00
2-wire / 3-wire control
Set to for 3-wire control with Forward/Reverse selection2
E0.01
Terminal X1 program
Set to for run forward command on X123
E0.02
Terminal X2 program
Set to for run reverse command on X224
11.1 Parameters to change for remote 3-wire control
11.2 Connecting the Switches
A wiring diagram is shown in the illustration
opposite. The SC terminal is a common
connection for terminals X1-X5 and has no
other function.
For “Run” and “Stop”, two suitable
pushbuttons should be installed. The “Run”
pushbutton should include a Normally Open
contact between terminals SC and X1 and the
“Stop” a Normally Closed contact between
terminals SC and X3.
For “Forward/Reverse” a suitable 2 position
NO ( ) switch should be installed
between terminals SC and X2.
A momentary connection between SC and X1
will start the motor. It will continue to run until
the connection between SC and X3 is broken.
If the application only
requires the motor to turn in one direction, the
Forward/Reverse switch can be omitted.
Normally Open
Note that the Forward/Reverse switch only
selects the direction of rotation - it will not start
or stop the motor.
EFC 3600
I/O Terminal
Blocks
12
X1 SCX2
14
Pushbutton
Normally Open
“Run”
R
Pushbutton
Normally Closed
“Stop”
Switch, 2 Position
Normally Open
“Forward / Reverse”
13
X3
2134

Easy Start Guide
12. Brake Resistor Connection
Page 12
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
Before commencing, confirm that the Inverter and
all cables are completely isolated from the power
supply, have been isolated for at least 5 minutes
and that the motor is not turning.
Bosch Rexroth EFC 3600 Series Inverter
(+)
Parameter
Description
How to set
b0.02
Access to additional parameters
Default is 0 for Basic Parameters. Set at to enable Extended Parameters.2
E4.01
Overvoltage prevention setting
Set to for Stall protection disabled, braking enabled.2
12.1 Parameters to change for Dynamic Braking
12.2 Connecting the Resistor
A wiring diagram is shown in the illustration
opposite. Connect the brake resistor to the B
and (+) Terminals on the Inverter. The order of
the connections is unimportant.
The braking resistor may get hot during
operation. Ensure that it is mounted in a
suitable position at least 10cm away from other
items.
It is important that a resistor of the correct
rating is used. Consult the manufacturer’s
manual or product listing on InverterDrive.com
for further information.
B (+)
High inertia loads can cause overvoltage trips
during deceleration and lead to “OE-3" error
messages. In many cases, the solution is to
increase the deceleration time to compensate.
However, if the application requires it, dynamic
braking can be enabled to maintain or reduce
deceleration times by absorbing the energy
generated by such loads.
A Brake Resistor is first installed to absorb
braking energy and dissipate it as heat. The
resistor be correctly sized for both the
Inverter and application.
Then, the “brake chopper” within the Inverter is
enabled. This detects excessive braking
energy and redirects it to the resistor when
required.
must
Heat Resistant
Cable

Easy Start Guide
13. How to reset the Inverter to Factory Defaults
Page 13
This guide has been produced by The Inverter Drive Supermarket Ltd.
All content, including but not limited to graphics, text and procedures copyright The Inverter
Drive Supermarket and must not be reproduced or altered without prior written permission.
©
13.1 Select the b0 Parameter Group
With the motor stopped, press the “Func” button
repeatedly until the display shows “-b0-” (do not press
and hold the “Func” button).
13.2 Select Parameter b0.05.
Press the “Set” button to select the b0 Parameter group
then use the up button to locate parameter b0.05.
13.3 Change value of b0.05 from 0 to 1.
Press the “Set” button to edit the value of b0.05 and use
the up button to change this from 0 to 1.
Press the “Set” button again to save the changes.
13.4 Finished
The display will show the next parameter for editing
(b0.06).
Press the “Function” button twice to exit from the
parameter menu.
Optional: repeat the process and change b0.05 from 0 to
2 to clear recent fault messages if required.
Bosch Rexroth EFC 3600 Series Inverter
