Safety Symbols
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
This is the safety alert symbol. It
is used to alert you to potential
personal injury hazards. Obey all
safety messages that follow this
symbol to avoid possible injury or
death.
Read manual symbol - Alerts user to
read manual.
WARNING indicates a hazardous
situation which, if not avoided,
could result in death or serious
injury.
GLL25-10 2610050718 04-18.indd 5 4/9/18 8:56 AM

-6-
Read all instructions. Failure to follow all
instructions listed below may result in
hazardous radiation exposure, electric shock, fire and/or serious
injury. The term “tool” in all of the warnings listed below refers to your
mains-operated (corded) tool or battery-operated (cordless) tool.
The following
labels are on your
laser tool for your convenience and
safety. They indicate where the laser
light is emitted by the tool. ALWAYS
BE AWARE of their location when
using the tool.
Do not direct the laser beam at persons or animals
and do not stare into the laser beam yourself. This
tool produces laser class 2 laser radiation and complies
with 21 CFR 1040.10 and 1040.11 except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007. This can lead
to persons being blinded.
DO NOT remove or deface any warning or caution labels.
Removing labels increases the risk of exposure to laser radiation.
Use of controls or adjustments or performance of procedures
other than those specified in this manual, may result in hazardous
radiation exposure.
ALWAYS make sure that any bystanders in the vicinity of use
are made aware of the dangers of looking directly into the laser
tool.
DO NOT place the laser tool in a position that may cause
anyone to stare into the laser beam intentionally or
unintentionally. Serious eye injury could result.
General Safety Rules
GLL25-10 2610050718 04-18.indd 6 4/9/18 8:56 AM

-7-
ALWAYS position the laser tool securely. Damage to the laser
tool and/or serious injury to the user could result if the laser tool fails.
ALWAYS use only the accessories that are recommended by
the manufacturer of your laser tool. Use of accessories that have
been designed for use with other laser tools could result in serious
injury.
DO NOT use this laser tool for any purpose other than those
outlined in this manual. This could result in serious injury.
DO NOT leave the laser tool “ON” unattended in any operating
mode.
DO NOT disassemble the laser tool. There are no user
serviceable parts inside. Do not modify the product in any way.
Modifying the laser tool may result in hazardous laser radiation
exposure.
DO NOT use the laser viewing glasses as safety goggles. The
laser viewing glasses are used for improved visualization of the laser
beam, but they do not protect against laser radiation.
DO NOT use the laser viewing glasses as sun glasses or
in traffic. The laser viewing glasses do not afford complete UV
protection and reduce color perception.
DO NOT use any optical tools such as, but not limited to,
telescopes or transits to view the laser beam. Serious eye injury
could result.
DO NOT stare directly at the laser beam or project the laser
beam directly into the eyes of others. Serious eye injury could
result.
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
GLL25-10 2610050718 04-18.indd 7 4/9/18 8:56 AM

-8-
DO NOT operate the laser tool around children or allow children
to operate the laser tool. Serious eye injury could result.
DO NOT use laser tools, attachments and accessories outdoors
when lightning conditions are present.
Do not operate the measuring tool in explosive environments,
such as in the presence of flammable liquids, gases or dusts.
Sparks can be created in the measuring tool which may ignite the
dust or fumes.
Electrical safety
Batteries can explode or leak, cause injury or
fire. To reduce this risk, always follow all
instructions and warnings on the battery label and package.
DO NOT short any battery terminals.
DO NOT charge alkaline batteries.
DO NOT mix old and new batteries. Replace all of them at the same
time with new batteries of the same brand and type.
DO NOT mix battery chemistries.
Dispose of or recycle batteries per local code.
DO NOT dispose of batteries in fire.
Keep batteries out of reach of children.
Remove batteries if the device will not be used for several months.
Personal safety
If laser radiation strikes your eye, you must deliberately close
your eyes and immediately turn your head away from the beam.
Do not make any modifications to the laser equipment.
GLL25-10 2610050718 04-18.indd 8 4/9/18 8:56 AM

-9-
Stay alert, watch what you are doing and use common sense
when operating a tool. Do not use a tool while you are tired or
under the influence of drugs, alcohol or medication. A moment of
inattention while operating a tool may result in serious personal injury
or incorrect measurement results.
Use safety equipment. Always wear eye protection. Safety
equipment such as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions will reduce personal
injuries.
Use caution when using laser tools in the vicinity of electrical
hazards.
Magnets
Keep the tool, positioning device, and laser target
plate away from cardiac pacemakers. The magnets
of the tool and laser target plate generate a field that can
impair the function of cardiac pacemakers.
Keep the tool, positioning device, and laser target plate away
from magnetic data medium and magnetically-sensitive
equipment. The effect of the magnets of the tool and laser target
plate can lead to irreversible data loss.
Noise Information
The A-weighted sound pressure level of the audio signal at one meter
distance is 80dB(A). Do not hold the measuring tool close to your
ear!
Use and care
Use the correct tool for your application. The correct tool will do
the job better and safer.
GLL25-10 2610050718 04-18.indd 9 4/9/18 8:56 AM

-10-
Do not use the tool if the switch does not turn it on and off. Any
tool that cannot be controlled with the switch is dangerous and must
be repaired.
Store idle tool out of the reach of children and do not allow
persons unfamiliar with the tool or these instructions to operate
the tool. Tools are dangerous in the hands of untrained users.
Maintain tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may
affect the operation. If damaged, tool repaired before use. Many
accidents are caused by poorly maintained tools.
Use the tool, accessories, etc., in accordance with these
instructions and in the manner intended for the particular type
of tool, taking into account the working conditions and the work
to be performed. Use of the tool for operations different from those
intended could result in a hazardous situation.
Service
Have your tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the
tool is maintained.
Develop a periodic maintenance schedule for tool. When
cleaning a tool be careful not to disassemble any portion of the
tool since internal wires may be misplaced or pinched or may
be improperly mounted. Certain cleaning agents such as gasoline,
carbon tetrachloride, ammonia, etc. may damage plastic parts.
SAVE THESE INSTRUCTIONS
GLL25-10 2610050718 04-18.indd 10 4/9/18 8:56 AM

-11-
The numbering of the product features shown refers to the illustration
of the tool on the graphic page.
1On/Off switch
2Laser beam outlet
31/4”-20 mounting thread
4Battery lid
5Laser warning label
6Serial number
7Latch of battery lid
8Tripod*
9Laser viewing glasses*
10 1/4”-20 screw of flexible
mounting device
11 Locking screw of flexible
mounting device
12 Fastening screw of flexible
mounting device
13 Flexible mounting device
*not included.
Features
The tool is intended for determining and checking horizontal and
vertical lines. The measuring tool is suitable exclusively for operation in
enclosed working sites.
Intended Use
GLL25-10 2610050718 04-18.indd 11 4/9/18 8:56 AM

-12-
Model Number ................................GLL25-10
Article number................................3 601 K63 510
Working range ................................... 30 ft (10 m)1)
Leveling Accuracy: ...................±5/16” @ 30 ft (±0.8 mm/m)
Self-leveling range, typically . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±4°
Operating temperature .......................... 41° F to 104° F
(+5° C to +40° C)
Storage temperature .............................-4° F to 158° F
(-20° C to +70° C)
Max. altitude ..................................6560 ft (2000 m)
Relative air humidity, max. ................................ 90%
Pollution degree according IEC 61010.........................22)
Laser class ...............................................2
Laser type ....................................635 nm, <1 mW
Mount threading ......................................1/4”-20
Batteries........................................2 x AAA 1.5V
Operating lifetime, approx. (with 2 lines of alkaline batteries)..... >5 h
Weight ........................................0.6 lb (0.27 kg)
Dimensions ...................................2.6” x 2.6” x 2.6”
(65 x 65 x 65 mm)
The tool can be clearly identified with the serial number on the type plate.
1) The working range can be decreased by unfavorable
environmental conditions (e.g. direct sun exposure).
Technical Data
GLL25-10 2610050718 04-18.indd 12 4/9/18 8:56 AM

-13-
Preparation
Inserting/Replacing the Battery
Use only alkaline batteries.
To open the battery lid 4, press the latch 7in the direction of the arrow
and remove the battery lid. Insert the supplied batteries.
When inserting, pay attention to the correct polarity according to the
representation on the inside of the battery compartment.
When the batteries are low, the laser lines will flash quickly for a few
seconds.
Always replace all batteries at the same time. Only use batteries from
one brand and with the identical capacity.
Remove the batteries from the tool when
not using it for extended periods. When
storing for extended periods, the batteries can corrode and discharge
themselves.
2) Conductive pollution occurs, or dry, non-conductive pollution
occurs which becomes conductive due to condensation which is
expected. In such conditions, equipment is normally protected
against exposure to direct sunlight, precipitation, and full wind
pressure, but neither temperature nor humidity is controlled.
GLL25-10 2610050718 04-18.indd 13 4/9/18 8:56 AM

-14-
Initial Operation
Protect the tool against moisture and direct
sun irradiation.
Do not subject the tool to extreme temperatures or variations
in temperature. As an example, do not leave it in vehicles for longer
periods. In case of large variations in temperature, allow the tool to
adjust to the ambient temperature before operation. In case of extreme
temperatures or variations in temperature the accuracy of the tool can
be impaired.
Avoid heavy impact or falling of the tool. After heavy exterior impact
on the tool, an accuracy check should always be carried out before
continuing to work (see “Leveling Accuracy”).
Switch the tool off during transport. Push the On/Off switch 1
downward to the “Off” position when transporting the measuring tool.
This locks the leveling unit, which can be damaged in case of intense
movement.
Switching On and Off
Do not leave the switched on tool
unattended and switch the tool off after use.
Do not point the laser beam at persons
or animals and do not look into the laser
beam yourself, not even from a large distance.
To switch on the tool, push the On/Off switch 1upward. Immediately
after switching on, the measuring tool sends two laser beams out of the
exit opening 2.
Operation
GLL25-10 2610050718 04-18.indd 14 4/9/18 8:56 AM

-15-
To switch off the measuring tool, push the On/Off switch 1downward
over the laser beam exit opening 2. When switching off, the leveling
unit is locked.
Do not leave the switched on measuring tool unattended and
switch the tool off after use. Other persons could be blinded by the
laser beam.
Application
The measuring tool is used for determining and checking horizontal
and vertical lines.
Automatic Leveling
Working with Automatic Leveling
Position the tool on a level and firm base or to a tripod 8.
After switching on, the leveling function automatically compensates
irregularities within the self-leveling range of ±4º. The leveling is
finished as soon as the laser beams no longer move.
If the measuring tool surface deviates more than 4º from the horizontal
plane, then the automatic leveling function is not possible and the laser
beams will flash. The lines will flash 1 s off 3 s on continually.
In this case, bring the tool to the level position and wait for the self-
leveling to take place. As soon as the tool is within the self-leveling
range of ±4°, then the laser lines will continuously light up.
In case of ground vibrations or position changes during operation, the
tool is automatically level again. To avoid errors, check the position of
the horizontal and vertical laser line with regard to the reference points
upon re-leveling.
GLL25-10 2610050718 04-18.indd 15 4/9/18 8:56 AM

-16-
Always use the center of the laser line for marking. The width of
the laser line changes with the distance.
Attaching with the Flexible Mounting Device
With the flexible mounting device 13, you can fasten the measuring
tool to different objects ranging in thickness between 1/2 and 2-3/8 in
(12 and 60 mm), such as vertical or horizontal boards or pipes.
Loosen the fastening screw 12 of the flexible mounting device, mount
the flexible mounting device to the desired location and tighten the
fastening screw again.
Place the measuring tool via the mounting thread 3onto the 1/4-20
male thread 10 of the flexible mounting device and screw it on applying
moderate force. Do not overtighten the measuring tool, otherwise it can
become damaged.
Roughly adjust the flexible mounting device before switching on the
measuring tool. To do this, loosen the locking screw 11 for the flexible
mounting device and move the measuring tool until horizontally
positioned at the desired height. Retighten the locking screw.
Working with a Tripod (Accessory)
A tripod 8offers a stable, height-adjustable measuring support. Place
the tool via the mounting thread 3onto the 1/4-20 male thread of the
tripod and screw the locking screw of the tripod tight.
Laser Viewing Glasses (Accessory)
The laser viewing glasses 9filter out the ambient light. This makes the
red light of the laser appear brighter to the eyes.
Working Advice
GLL25-10 2610050718 04-18.indd 16 4/9/18 8:56 AM

-17-
Keep the tool clean at all times.
Do not immerse the tool into water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any
cleaning agents or solvents.
Regularly clean the surfaces of the laser beam outlets in
particular, and pay attention to any fluff of fibers.
If the tool should fail despite the care taken in manufacturing and
testing procedures, repair should be carried out by an authorized
after-sales service center for Bosch power tools.
In all correspondence and spare parts orders, please always
include the 10-digit article number given on the type plate of the
tool.
ENVIRONMENT PROTECTION
Recycle raw materials & batteries instead of disposing of
waste. The unit, accessories, packaging & used batteries
should be sorted for environmentally friendly recycling in
accordance with the latest regulations.
Maintenance and Service
Do not use the laser viewing glasses as safety
goggles. The laser viewing glasses are used for
improved visualization of the laser beam, but they do not protect
against laser radiation.
Do not use the laser viewing glasses as
sunglasses or in traffic. The laser viewing
glasses do not provide complete UV protection and reduce color
perception.
GLL25-10 2610050718 04-18.indd 17 4/9/18 8:56 AM

-18-
LIMITED WARRANTY OF BOSCH LASER AND
MEASURING TOOL PRODUCTS
Robert Bosch Tool Corporation (“Seller”) warrants to the original purchaser
only, that all Bosch lasers and measuring tools will be free from defects in
material or workmanship for a period of one (1) year from date of purchase.
Bosch will extend warranty coverage to two (2) years when you register
your product within eight (8) weeks after date of purchase. Product
registration card must be complete and mailed to Bosch (postmarked within
eight weeks after date of purchase), or you may register on-line at
www.boschtools.com/Service/ProductRegistration. If you choose not to
register your product, a one (1) year limited warranty will apply to your
product.
30 Day Money Back Refund or Replacement -
If you are not completely satisfied with the performance of your laser and
measuring tools, for any reason, you can return it to your Bosch dealer
within 30 days of the date of purchase for a full refund or replacement.
To obtain this 30-Day Refund or Replacement, your return must be
accompanied by the original receipt for purchase of the laser or optical
instrument product. A maximum of 2 returns per customer will be permitted.
SELLER’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY under
this Limited Warranty and, to the extent permitted by law, any warranty or
condition implied by law, shall be the repair or replacement of parts, without
charge, which are defective in material or workmanship and which have not
been misused, carelessly handled, or misrepaired by persons other than
Seller or Authorized Service Center. To make a claim under this Limited
Warranty, you must return the complete Bosch laser or measuring tool,
transportation prepaid, to any BOSCH Factory Service Center or Authorized
Service Center. Please include a dated proof of purchase with your tool. For
locations of nearby service centers, please use our on-line service locator or
call 1-877-267-2499.
GLL25-10 2610050718 04-18.indd 18 4/9/18 8:56 AM

-19-
THIS WARRANTY PROGRAM DOES NOT APPLY TO TRIPODS AND
RODS. Robert Bosch Tool Corporation (“Seller”) warrants tripods and
leveling rods for a period of one (1) year from date of purchase.
THIS LIMITED WARRANTY DOES NOT APPLY TO OTHER
ACCESSORY ITEMS AND RELATED ITEMS. THESE ITEMS RECEIVE A
90 DAY LIMITED WARRANTY.
To make a claim under this Limited Warranty, you must return the complete
product, transportation prepaid. For details to make a claim under this
Limited Warranty please visit www.boschtools.com or call 1-877-267-2499.
ANY IMPLIED WARRANTIES SHALL BE LIMITED IN DURATION TO
ONE YEAR FROM DATE OF PURCHASE. SOME STATES IN THE U.S.,
AND SOME CANADIAN PROVINCES DO NOT ALLOW LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
IN NO EVENT SHALL SELLER BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO
LIABILITY FOR LOSS OF PROFITS) ARISING FROM THE SALE OR
USE OF THIS PRODUCT. SOME STATES IN THE U.S., AND SOME
CANADIAN PROVINCES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO
THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM
STATE TO STATE IN THE U.S., OR PROVINCE TO PROVINCE IN
CANADAAND FROM COUNTRY TO COUNTRY.
THIS LIMITED WARRANTY APPLIES ONLY TO PRODUCTS SOLD
WITHIN THE UNITED STATES OF AMERICA, CANADAAND THE
COMMONWEALTH OF PUERTO RICO. FOR WARRANTY COVERAGE
WITHIN OTHER COUNTRIES, CONTACT YOUR LOCAL BOSCH
DEALER OR IMPORTER.
GLL25-10 2610050718 04-18.indd 19 4/9/18 8:56 AM

-20-
Symboles relatifs à la sécurité
Les définitions ci-dessous décrivent le niveau de gravité
pour chaque terme signalant un danger. Veuillez lire le mode
d’emploi et lire la signification de ces symboles.
C’est le symbole d’alerte relatif à la sécurité.
Il est utilisé pour vous avertir de l’existence
possible d’un danger de lésion corporelle.
Obéissez à tous les messages relatifs à la
sécurité qui suivent ce symbole pour éviter
tout risque de blessure ou même de mort.
Symbole de lecture du mode d’emploi
- Alerte l’utilisateur pour lire le mode
d’emploi.
AVERTISSEMENT indique une situation dangereuse qui, si
elle n’est pas évitée, pourrait causer la mort d’une personne
ou une blessure grave.
GLL25-10 2610050718 04-18.indd 20 4/9/18 8:56 AM
