-9-
Laser Receiver ................................................LR8
Article number .......................................3601 K69 J11
Working range1) .................................... 15’-165’ (5-50 m)
Receiving angle ................................................ 90°
Measuring accuracy2)
– “Fine” adjustment ..................................±1/32” (±1 mm)
– “Coarse” adjustment .................................±1/8” (±3 mm)
Operating temperature ................14°F....+122 °F (–10 °C...+50 °C)
Storage temperature .................. -4°F...+158 °F (–20 °C...+70 °C)
Max. altitude...................................................6560 ft (2000 m)
Relative air humidity, max....................................................90%
Pollution degree according IEC 610103) ..........................................3
Batteries ..........................................2x1.5V LR6 (AA)
Operating time, approx. .........................................30h
Weight .......................................... .0.33 lb (0.150 kg)
Degree of protection ...............IP54(dust and splash water protected)
Dimensions (length x width x height) . . . 2.9” x 1.1” x 5.4” (73 x 28 x 137 mm)
1) The working range can be decreased by unfavorable environmental
conditions (e.g. direct sun exposure).
2) The angular accuracy between the 45° laser line and the 90° laser line is
max. ±5/32 @ 30 ft (+/-0.4 mm/m).
3) Conductive pollution occurs, or dry, non-conductive pollution occurs
which becomes conductive due to condensation which is expected. In such
conditions, equipment is normally protected against exposure to direct
sunlight, precipitation, and full wind pressure, but neither temperature nor
humidity is controlled.
Please observe the article number on the type plate of your tool.
The trade names of the individual tools may vary.
The tool can be clearly identified with the serial number 14 on the type plate.
