2 Installing the Fiber Optic Module
This guide provides instructions for installing the Bosch VG4-
SFPSCKT Fiber Optic module into a VG4-A-PA1, VG4-A-PA2,
VG4-A-PSU1 or a VG4-A-PSU2 AutoDome power supply box.
2.1 Description
The VG4-SFPSCKT is a unique media converter module for use
with VG4 series AutoDomes incorporating the Ethernet (TCP/
IP) Communications Module. This media converter module is
designed to accept any of the 10/100 Mbps Small Form-factor
Pluggable (SFP) modules described below.
The media converter module along with the SFP module is user
installed directly into the AutoDome's power supply box to
provide an integrated fiber optic solution.
The Fiber Optic module accepts the following SFP modules:
Sub-module Fiber Type Optical Interface
SFP-2 MMF Duplex LC
SFP-3 SMF Duplex LC
SFP-23 SMF Single SC
SFP-24 SMF Single SC
SFP-25 MMF Single SC
SFP-26 MMF Single SC
i
NOTICE! The SFP module is not included with the VG4-
SFPSCKT kit, it must be purchased separately.

6en | Installing the Fiber Optic Module Fiber Optic Media Converter
F.01U.134.924 | 1.0 | 2009.09 Installation Guide Bosch Security Systems, Inc.
2.2 Using an SFP Module
The SFP-23/SFP-24 modules and the SFP-25/SFP-26 modules
are counterparts; if you use one in the VG4-SFPSCKT module
then you must use the other in the CNFE2MC head-end unit. For
example, SFP-25 is used in the VG4-SFPSCKT module installed
into a VG4 power supply. You must use the SFP-26 module in
the CNFE2MC head-end unit.
The following chart lists the compatibility between the SFP
modules:
SFP Sub-module used in
VG4-SFPSCKT
Use this SFP Sub-module
in CNFE2MC
SFP-2 SFP-2
SFP-3 SFP-3
SFP-23 SFP-24
SFP-24 SFP-23
SFP-25 SFP-26
SFP-26 SFP-25
