Bosch XDK 110 Instruction manual

Connect XDK110 device to your Azure IoT services
1 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
Document Revision
V1.0.0
Document Release Date
12-17-2020
Connect XDK110 device to your Azure IoT services

Connect XDK110 device to your Azure IoT services
2 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
Contents
1Introduction 3
2Before you start 3
3Overview 3
4Steps to follow 3
4.1 Create Azure IoT Central application ..................................................................................................................3
4.2 Create X.509 certificates.....................................................................................................................................3
4.3 Create enrollment group and verify root X.509 certificate ..................................................................................4
4.4 Customize and publish device template .............................................................................................................7
4.5 Update configuration file .....................................................................................................................................8
4.6 Keep the configuration file and credentials in SD card .......................................................................................9
4.7 Flash the application to your device and get connected...................................................................................10
4.8 Additional details: Connecting to IoT Hub.........................................................................................................13
4.9 Additional details: Connecting to Azure IoT Explorer........................................................................................15
5References 15

Connect XDK110 device to your Azure IoT services
3 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
1Introduction
The AzurePlugAndPlay application is aimed at simplifying the development of your IoT solutions. Through this application
you will be able to access the data from all built-in sensors of XDK110 and get the luxury of easy connectivity with Azure
using X.509 certificates. This application will enable you to select which all sensors to be enabled, at what time they needs
to be sampled, at what time the mean value of sampled data should be send to Azure. In addition to these, the application
supports heart beat message operations and reboot command support. This quick start guide is intended for you to make
use of the AzurePlugAndPlay application with Azure IoT Central Application service. You will also be provided with an
additional detail at the end, regarding how to connect with the Azure IoT Hub service as well.
2Before you start
It is mandatory that the firmware of the built-in CC3100 WiFi chip has to be updated before flashing the
AzurePlugAndPlay application to XDK110. This will enable the WiFi chip to handle TLSv1.2. Please refer the 'Wi-Fi
Module Upgrade' documentation for understanding how to update the WiFi chip firmware.
The CC3100 WiFi chip can support certificates of maximum length 2048bytes only.
In order to create an X.509 certificate for the device, you will be needing OpenSSL installed in the system as well.
3Overview
1. Create Azure IoT Central application
2. Create X.509 certificates
3. Create enrollment group and verify root X.509 certificate
4. Customize and publish device template
5. Update configuration file
6. Keep the configuration file and credentials in SD card
7. Flash the application to your device and get connected
8. Additional details : Connecting to IoT Hub
9. Additional details : Connecting to Azure IoT Explorer
4Steps to follow
4.1 Create Azure IoT Central application
Follow the steps discussed in the 'Create An IoT Central Application' for quickly deploying an Azure IoT Central
application.
4.2 Create X.509 certificates
For easy creation of X.509 certificate you can make use of the CACertificates tool provided by Azure. You can either
access this github link to get the tool or else you can go to the location
'AzurePlugAndPlay/SDK/xdk110/Libraries/AzureIotSdkForC/3rd-party/azure-iot-sdk-c/tools/CACertificates' within
the workbench.
The X.509 Certificates created by these scipts MUST NOT be used for production. They contain hard-coded passwords
(“1234”), expire after 30 days, and most importantly are provided for demonstration purposes to help you quickly
understand CA Certificates.
4.2.1 Edit certGen.sh file within the CACertificates tool and change
from key_bits_length="4096" to key_bits_length="2048".This is mandatory as CC3100 WiFi chip can support maximum
key length of 2048bytes.
4.2.2 Open Bash in the folder where certGen.sh is located and run below command to set permission
chmod 700 certGen.sh

Connect XDK110 device to your Azure IoT services
4 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.2.3 Run the command below to create root CA ('azure-iot-test-only.root.ca.cert.pem') and intermediate
certificate within a new subfolder "./certs/".
./certGen.sh create_root_and_intermediate
4.2.4 Replace the <> section with a device name of your choice and run the following command to create X.509 device
certificate and private key pair. This will create the files ./certs/new-device.*that contain the public key and PFX
and ./private/new-device.key.pem that contains the device's private key.
./certGen.sh create_device_certificate <device name of your choice>
For example, ./certGen.sh create_device_certificate myXdk110
4.2.5 Execute the following command to change directory to certs and convert the device certificate to DER format and
rename it to devCert
cd ./certs && openssl x509 -in new-device.cert.pem -inform PEM -out dev
4.2.6 Execute the following command to change directory to private and convert the private key to DER format and rename
it to privKey
cd ../private && openssl rsa -in new-device.key.pem -inform PEM -out pri
Please don't close the bash window yet, we will be in need of it in coming steps.
4.3 Create enrollment group and verify root X.509 certificate
4.3.1 Go to the Azure IoT Central application created during first step 1. You can select and access your central application
from this page : https://apps.azureiotcentral.com/myapps
For example, here we have considered a central application created by the name your _xdk110_central_app
4.3.2 Create new enrollment group
4.3.2.1. Go to 'Administration' and select 'Device connection' option and then select '+ Create enrollment group'
option.
4.3.2.2 Give name of your choice to the enrollment group and follow the steps as shown below to create and new
enrollment group
4.3.3 Upload and verify X.509 root certificate.

Connect XDK110 device to your Azure IoT services
5 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.3.3.1 Once the group details are saved, you will be able to scroll down and select the option 'Manage Primary'. This will
open 'Primary Certificate' pop up screen
4.3.3.2 Click Browse icon and specify the path to X.509 root certificate 'azure-iot-test-
only.root.ca.cert.pem'This file will be available from the create X.509 certificate step.
Once uploaded, the rest of the fields within the popup screen will get auto populated. A warning message will show that the
uploaded certificate 'Needs verification'
4.3.3.3 Copy the auto generated verification code by clicking on the copy to clipboard button.
4.3.3.4 Go to the Bash screen and change directory to the CACertificate tool folder(w.r.t the example
screenshot, Desktop/Azure/CACertificate/ ) and execute the following command. Please replace the <> section with the
copied verification code.
./certGen.sh create_verification_certificate <Paste verification code copied in
previous
This step will create a new verification certificate by the name verification-code.cert.pem in the './certs/'
folder
4.3.3.5 Return to the IoT Central window, click on Verify button and specify the path to generated verification
certificate verification-code.cert.pem in the previous step.
4.3.3.6. Once uploaded the verification will be done and the info will be updated to 'Verified'. Then you can go ahead
and close the window.

Connect XDK110 device to your Azure IoT services
6 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.3.4. Save the changes to the enrollment group by clicking on 'Save'

Connect XDK110 device to your Azure IoT services
7 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.4 Customize and publish device template
With the latest version of IoT Central, you NEED NOT create and publish a device template before connecting the device.
It is capable of automatically creating and publishing a default version of device template upon initial connection of the
device itself. Thus you can skip section 4 and continue with section 5 if needed.
4.4.1 Create a device template
4.4.1.1. Go to the 'Device templates' page and select 'New'.
4.4.1.2. On the 'Select template type' page scroll down the 'Featured device template' list and select XDK110. Then
select 'Next:Customize'
4.4.1.3. On the 'Review' page, select 'Create'.
4.4.1.4. After a few seconds, you can see your new device template
If XDK110 was not on the list, you can also make use of the DCM in the workbench to create a custom template by
selecting 'IoT device' instead of XDK110. Please find the latest DCM at
'https://devicemodels.azure.com/dtmi/bosch/xdk110-1.expanded.json'which can be imported as the device model. The
'Import a model' option will be available to you in the 'Create a model' page which comes up soon after creating.
4.4.2. Visualizing data
4.4.2.1. The quickest way to bring up views is to make use of the tile 'Generate default views' from the 'Views' tab
4.4.2.2. In the following page you can select which all views to be created out of the default
options : Overview,Commands and About
4.4.2.3. Select 'Generate default view(s)' button to create the views.
4.4.2.4. After few seconds, you can see that an Overview and an About view would have generated.
4.4.3. Adding a new 'Settings' form for you to manage the device:
4.4.3.1. Select the 'Views', and then select the 'Editing device and cloud data' tile to add a new view.
4.4.3.2. Change the form name to 'Settings'
4.4.3.3 Select the Telemetry Post Interval.Heartbeat Interval and Sensor Sampling Interval properties from the
'Properties' drop down. Then select 'Add section'.
4.4.3.4 Select 'Save' to save the new Settings form

Connect XDK110 device to your Azure IoT services
8 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.4.4 Publish device template
4.4.4.1. Select the Publish button
4.4.4.2. On the Publish this device template to the application dialog, select Publish.
4.4.4.3. After you publish a device template, it will be visible on the Devices page.
4.5 Update configuration file
In order for you to configure your device, you can make use of config.json file. Please find the example file from the
workbench at location 'AzurePlugAndPlay/resources/config/config.json'. You can play around with different options are
per your requirement. Let's discuss minimum changes that are required to connect the device and visualize data is
discussed here.
4.5.1. Update deviceInfo section
4.5.1.1. Update the value of deviceId with the name used for creating the X.509 device certificate. As example we took
'myXdk110' at step 2.5. This is optional field, without this the device will consider the WLAN MAC ID as the device id.
4.5.1.2. Update the the value of idScope with the ID Scope of the created IoT Central Application. Please find this detail
within the IoT Central Application at 'Administration' → 'Device connection' → 'ID Scope'
Please remember to keep the details within double quotes.

Connect XDK110 device to your Azure IoT services
9 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.5.2. Update wlan section
4.5.2.1. Update the value of ssid with SSID of the WiFi network to be connected to
4.5.2.2. Update the value of password with the password to the WiFi network
Please remember to keep the details within double quotes.
4.5.3. Save the file
4.6 Keep the configuration file and credentials in SD card
You need to provide the XDK with four files through SD card, before turning it on. As part of this step you need to copy the
following files to SD card and insert the card in to your device.
4.6.1. Copy the config.json(which was updated in the section 5) to SD card.
4.6.2. Copy the devCert.der(created at the end of step 2.5.) from the 'CACertificates/certs/' to SD card.
4.6.3. Copy the privKey.der(created at the end of step 2.6.) from the 'CACertificates/private/' to SD card.
4.6.4. Copy the rootCA.der from location 'AzurePlugAndPlay/resources/certificates/' to SD card.
Please keep in mind that rootCA.der file is common for all devices and is different from 'azure-iot-test-
only.root.ca.cert.pem'. The rootCA.der file is used to ensure that it is connecting to Azure endpoint itself.
4.6.5. Insert the SD card to your device.

Connect XDK110 device to your Azure IoT services
10 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.7 Flash the application to your device and get connected
4.7.1. Flash the AzurePlugAndPlay application. Please keep in mind that this step is only needed if your XDK doesn't carry
the AzurePlugAndPlay application already.
4.7.1.1. Open the XDK Workbench
4.7.1.2. Connect your XDK110 device to the Workbench through USB or JLink.
4.7.1.3. Import the 'AzurePlugAndPlay' application from the XDK-Examples
4.7.1.4. Build the project and flash the device
The application is expected to run, soon after flashing your device.
4.7.2. When connected through USB you can listen to the console logs to get the real time execution details of your device.
4.7.3. Explore the Views of your device
4.7.3.1. Go to 'Devices' page within IoT Central application
4.7.3.2. Once the console says 'Plug and Play enabled, running...' you will be able able to see that the device in the
'All devices' list as well as in the 'XDK110' list.
4.7.3.3. Select your device (in this example myXdk110) from the list and explore different views

Connect XDK110 device to your Azure IoT services
11 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.7.3.4. Select the 'Overview' page to view the incoming data from your device. Please keep in mind that at times it might
take few seconds to represent the data as graphs.
4.7.3.5. You use the 'Settings' page to change the intervals at which the sensors has to be sampled, telemetry data to be
posted and the heart beat message has to be posted.
You can set the intervals to Zero to stop the corresponding operations.
4.7.3.6. The 'Command' page will let you reboot your device by selecting the 'Run' button within the 'Command/reboot'
section. You can see the response within the history pane by clicking the command history link

Connect XDK110 device to your Azure IoT services
12 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.7.3.7. The 'About' window will give you the device informations such as the WLAN MAC Address, Software Version
etc.
4.7.3.8. You can make use of the 'Raw Data' page(get generated by default) to checkout the raw data traffic as well.
Once the application runs, the files in the SD card will be copied to internal storage and the original ones will get converted
to *.bkp. From then onward your device need not carry the SD card to function. The SD card is only needed when you
need to modify these files. Then the *.bkp file can be replaced with new *.der file and the SD card can be reinserted to your
device. It will require a reset of your device to take in the new modifications.

Connect XDK110 device to your Azure IoT services
13 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.8 Additional details: Connecting to IoT Hub
For connecting your device with IoT Hub you will need to make use of device provisioning service(DPS) as well.
4.8.1. Follow the steps discussed in the page 'Quickly Setup IoT Hub and DPS' to quickly setup new IoT Hub, DPS service
and link them together.
4.8.2. If already not created, follow the steps in section 2 to create X.509 certificates.
4.8.3. Upload and verify your X.509 certificate with the DPS service
4.8.3.1. Go to created DPS service and from 'Certificates' tab select the '+ Add' button.
4.8.3.2. Give a suitable name for your root certificate(for example your_root_certificate) within the 'Certificate Name' text
box
4.8.3.3. Upload your 'azure-iot-test-only.root.ca.cert.pem', created during section 2, to the
'Certificate .pem or .cer file'
box and save using the 'Save' button.
Once saved, your certificate should be visible in the 'Certificates' page after page refresh.
4.8.3.4. Select the your_root_certificate from the list to get to the side panel and select 'Generate Verification
Code'
button. This will generate a new code in 'Verification Code' box.
4.8.3.5. Copy the verification code using the 'copy to clipboard' button and execute the step 3.3.4 to create new
verification certificateverification-code.cert.pem' in the "CACertificates/certs/"/" folder
4.8.3.6. Upload the verification certificate to 'Verification Certificate .pem or .cer file' box and click on 'Verify' button to
verify.
4.8.4. Add enrollment group in DPS and configure the group to connect to your IoT Hub
4.8.4.1. From the 'Manage enrollments' tab select the 'Add enrollment group' button.
4.8.4.2. Provide a name of your choice in the 'Group name' text box, select 'Certificate' as 'Attestation type'
4.8.4.3. Select the 'IoT Edge Device' to be 'False'
4.8.4.4. Select the 'Certification type' to be 'CA Certificate'.
4.8.4.5. Select the verified certificate, your_root_certificate, from the 'Primary certificate' drop down list.
4.8.4.6. Select the IoT Hub name(for example 'your-iot-hub.azure-devices.net') from the 'Select the IoT hub
this group
can be assigned to' drop down list and save using the 'Save' button

Connect XDK110 device to your Azure IoT services
14 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.8.5. Update the idScope detail in the config.json with ID scope of your DPS service. You can get the ID scope of DPS
from 'Overview' tab. Rest of the details in config.json can be kept as such from section 5.
4.8.6. Load the updated config.json to your device through SD card, turn on your device and get connected to your IoT
Hub. The 'IoT devices' tab of your IoT Hub should reflect your device name(myXdk110)within few seconds.
You can use monitor-events within 'Azure Cloud Shell' commands to monitor the data coming in from your device.

Connect XDK110 device to your Azure IoT services
15 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
4.9 Additional details: Connecting to Azure IoT Explorer
Azure IoT Explorer is a graphical tool for interacting with and devices connected to your IoT hub. Thus please follow the
steps as mentioned in section 8 and then follow the steps mentioned in the link https://docs.microsoft.com/en-us/azure/iot-
pnp/howto-use-iot-explorer#install-azure-iot-explorer to make use of the Azure IoT Explorer with your device.
5References
AzurePlugAndPlay application documentation : https://developer.bosch.com/web/xdk/azureplugandplay
Azure IoT Central documentation : https://docs.microsoft.com/en-us/azure/iot-central/core/
Azure IoT Plug And Play tutorial : https://docs.microsoft.com/en-us/azure/iot-pnp/
Azure IoT Hub tutorial : https://docs.microsoft.com/en-us/azure/iot-hub/
Azure DPS tutorial : https://docs.microsoft.com/en-us/azure/iot-dps/
My nibh euismod tincidunt
ut laor eet dolore magna
aliquam erad minim
veniam, quis nostrud
exerci tation.

Connect XDK110 device to your Azure IoT services
16 | 16
Data subject not change without notice | Printed in Germany | December 2020
BCDS
Bosch Connected Devices and Solutions GmbH
Ludwig-Erhard-Straße 2
72760 Reutlingen
Germany
