Bosch axt rapid 2000 User manual

Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-garden.com
F 016 L81 414
AXT
Rapid 2000 | Rapid 2200
en Original instructions
OBJ_DOKU-43506-003.fm Page 1 Thursday, March 1, 2018 3:36 PM
(2018.04) O / 21

2 | English
F 016 L81 414 | (1.3.18) Bosch Power Tools
English
Safety Notes
Warning! Read these instructions
carefully, be familiar with the con-
trols and the proper use of the ma-
chine. Please keep the instructions
safe for later use!
Explanation of symbols on the
machine
General hazard safety alert.
Read instruction manual.
Before dismantling any part of
the machine, switch off and re-
move the plug from the mains
supply. If the cable is damaged or cut
through while working, do not touch
the cable but immediately remove the
plug from the mains supply. Never use
the machine with a damaged cable.
Wear protective gloves, sturdy
shoes and long trousers.
Danger – rotating blade. Keep
hands and feet out of openings
while the machine is running.
Pay attention that bystanders
are not injured through foreign
objects thrown from the ma-
chine.
Warning: Keep a safe distance
from the machine when operat-
ing.
Wait until all machine compo-
nents have completely stopped
before touching them.
Wear eye protection.
Always wear ear protection.
Do not use the machine in the
rain or leave it outdoors when it
is raining.
Operation
During operation, do not reach into
the chute assembly. The machine
runs on for a few seconds after be-
ing switched off.
Never allow children or people unfa-
miliar with these instructions to use
the machine. Local regulations may
restrict the age of the operator. When
not in use, store the machine out of
reach of children.
This machine is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction con-
cerning use of the machine by a per-
son responsible for their safety.
Children should be supervised to en-
sure that they do not play with the
machine.
Never work while people, especially
children, or pets are nearby.
Before switching on, the machine
must be assembled according to the
enclosed instructions.
OBJ_BUCH-2380-003.book Page 2 Thursday, March 1, 2018 3:38 PM

English | 3
Bosch Power Tools F 016 L81 414 | (1.3.18)
For increased electrical safety use a
Residual Current Device (RCD) with a
tripping current of not more than
30 mA. Always check your RCD every
time you use it.
Use only extension cables that are in-
tended for outdoor use and are pro-
tected against splashes of water.
Do not touch the plug or socket with
wet hands.
Do not run over, crush or pull the
power supply cord or extension cord,
otherwise it may be damaged. Pro-
tect the cable from heat, oil and sharp
edges.
Keep other persons and animals at a
distance of 3 metres or more when
the machine is being used.
Always use original Bosch accesso-
ries and spares. We cannot be re-
sponsible for damage or malfunction
when other such items are used.
Become familiar with the instruction
manual before attempting to operate
this machine.
Avoid wearing loose-fitting clothing,
hanging cords or ties.
Only operate the machine in open
space (e. g. not too close to a wall or
other fixed objects) and on a firm,
level surface.
Before starting the machine, check
that all screws, nuts, bolts and other
fasteners are properly secured and
that guards and screens are in place.
Replace damaged or unreadable
warning and operating labels.
Before starting the machine, make
certain that the chute assembly is
empty.
Keep your face and body away from
the chute assembly.
Do not allow hands or any other part
of the body or clothing inside the
chute assembly, discharge chute or
near any moving part.
Keep proper balance and footing at
all times. Do not overreach. Never
stand at a higher level than the base
of the machine when feeding materi-
al.
Always stand clear of the discharge
zone when operating the machine.
When feeding material into the ma-
chine be extremely careful that piec-
es of metal, rocks, bottles, cans or
other foreign objects are not includ-
ed.
If the cutting mechanism strikes any
foreign object or if the machine
should start making any unusual
noise or vibration, immediately
switch off and allow the cutter to
stop. Remove the plug from the
mains supply and take the following
steps:
– Inspect for damage.
– Replace or repair any damaged
parts.
– Check for and tighten any loose
parts.
Do not attempt to repair the machine
unless you are qualified to do so.
Do not allow processed material to
build up in the discharge zone; this
may prevent proper discharge which
can result in kickback of material
through the chute assembly.
OBJ_BUCH-2380-003.book Page 3 Thursday, March 1, 2018 3:38 PM
English | 3
Bosch Power Tools F 016 L81 414 | (1.3.18)
 For increased electrical safety use a
Residual Current Device (RCD) with a
tripping current of not more than
30 mA. Always check your RCD every
time you use it.
Use only extension cables that are in-
tended for outdoor use and are pro-
tected against splashes of water.
Do not touch the plug or socket with
wet hands.
Do not run over, crush or pull the
power supply cord or extension cord,
otherwise it may be damaged. Pro-
tect the cable from heat, oil and sharp
edges.
Keep other persons and animals at a
distance of 3 metres or more when
the machine is being used.
Always use original Bosch accesso-
ries and spares. We cannot be re-
sponsible for damage or malfunction
when other such items are used.
Become familiar with the instruction
manual before attempting to operate
this machine.
Avoid wearing loose-fitting clothing,
hanging cords or ties.
Only operate the machine in open
space (e. g. not too close to a wall or
other fixed objects) and on a firm,
level surface.
Before starting the machine, check
that all screws, nuts, bolts and other
fasteners are properly secured and
that guards and screens are in place.
Replace damaged or unreadable
warning and operating labels.
Before starting the machine, make
certain that the chute assembly is
empty.
Keep your face and body away from
the chute assembly.
Do not allow hands or any other part
of the body or clothing inside the
chute assembly, discharge chute or
near any moving part.
Keep proper balance and footing at
all times. Do not overreach. Never
stand at a higher level than the base
of the machine when feeding materi-
al.
Always stand clear of the discharge
zone when operating the machine.
When feeding material into the ma-
chine be extremely careful that piec-
es of metal, rocks, bottles, cans or
other foreign objects are not includ-
ed.
If the cutting mechanism strikes any
foreign object or if the machine
should start making any unusual
noise or vibration, immediately
switch off and allow the cutter to
stop. Remove the plug from the
mains supply and take the following
steps:
– Inspect for damage.
– Replace or repair any damaged
parts.
– Check for and tighten any loose
parts.
Do not attempt to repair the machine
unless you are qualified to do so.
Do not allow processed material to
build up in the discharge zone; this
may prevent proper discharge which
can result in kickback of material
through the chute assembly.
OBJ_BUCH-2380-003.book Page 3 Thursday, March 1, 2018 3:38 PM
6 | English
F 016 L81 436 | (20.11.15) Bosch Power Tools
 It is recommended for increased
electrical safety to use a Residual
Current Device (RCD) with a tripping
current of not more than 30 mA. Al-
ways check your RCD every time you
use it.
Use only extension cables that are in-
tended for outdoor use and are pro-
tected against splashes of water.
Do not touch the plug or socket with
wet hands.
Do not run over, crush or pull the
power supply cable or extension
lead, otherwise it may be damaged.
Protect the cable from heat, oil and
sharp edges.
Other persons and animals should re-
main at a distance of 3 metres or
more when the machine is being
used. The operator is responsible for
third persons in the working area.
Bosch can assure flawless function-
ing of the machine only when original
accessories are used.
Become familiar with the instruction
manual before attempting to operate
this machine.
Avoid wearing loose-fitting clothing,
hanging cords or ties.
Only operate the machine in open
space (e. g. not too close to a wall or
other fixed objects) and on a firm,
level surface.
Do not operate the machine on paved
or gravel surface where ejected mate-
rial could cause injury.
Before starting the machine, check
that all screws, nuts, bolts and other
fasteners are properly secured and
that guards and screens are in place.
Replace damaged or unreadable
warning and operating labels.
Before starting the machine, make
certain that the chute assembly is
empty.
Keep your face and body away from
the chute assembly.
Do not allow hands or any other part
of the body or clothing inside the
chute assembly, discharge chute or
near any moving part.
Keep proper balance and footing at
all times. Do not overreach. Never
stand at a higher level than the base
of the machine when feeding materi-
al.
Always stand clear of the discharge
zone when operating the machine.
When feeding material into the ma-
chine be extremely careful that piec-
es of metal, rocks, bottles, cans or
other foreign objects are not includ-
ed.
If the cutting mechanism strikes any
foreign object or if the machine
should start making any unusual
noise or vibration, immediately
switch off and allow the cutter to
stop. Remove the plug from the
mains supply and take the following
steps:
– Inspect for damage.
– Replace or repair any damaged
parts.
– Check for and tighten any loose
parts.
Do not attempt to repair the machine
unless you are qualified to do so.
Do not allow processed material to
build up in the discharge zone; this
OBJ_BUCH-920-005.book Page 6 Friday, November 20, 2015 1:23 PM
English | 3
Bosch Power Tools F 016 L81 414 | (1.3.18)
 For increased electrical safety use a
Residual Current Device (RCD) with a
tripping current of not more than
30 mA. Always check your RCD every
time you use it.
Use only extension cables that are in-
tended for outdoor use and are pro-
tected against splashes of water.
Do not touch the plug or socket with
wet hands.
Do not run over, crush or pull the
power supply cord or extension cord,
otherwise it may be damaged. Pro-
tect the cable from heat, oil and sharp
edges.
Keep other persons and animals at a
distance of 3 metres or more when
the machine is being used.
Always use original Bosch accesso-
ries and spares. We cannot be re-
sponsible for damage or malfunction
when other such items are used.
Become familiar with the instruction
manual before attempting to operate
this machine.
Avoid wearing loose-fitting clothing,
hanging cords or ties.
Only operate the machine in open
space (e. g. not too close to a wall or
other fixed objects) and on a firm,
level surface.
Before starting the machine, check
that all screws, nuts, bolts and other
fasteners are properly secured and
that guards and screens are in place.
Replace damaged or unreadable
warning and operating labels.
Before starting the machine, make
certain that the chute assembly is
empty.
Keep your face and body away from
the chute assembly.
Do not allow hands or any other part
of the body or clothing inside the
chute assembly, discharge chute or
near any moving part.
Keep proper balance and footing at
all times. Do not overreach. Never
stand at a higher level than the base
of the machine when feeding materi-
al.
Always stand clear of the discharge
zone when operating the machine.
When feeding material into the ma-
chine be extremely careful that piec-
es of metal, rocks, bottles, cans or
other foreign objects are not includ-
ed.
If the cutting mechanism strikes any
foreign object or if the machine
should start making any unusual
noise or vibration, immediately
switch off and allow the cutter to
stop. Remove the plug from the
mains supply and take the following
steps:
– Inspect for damage.
– Replace or repair any damaged
parts.
– Check for and tighten any loose
parts.
Do not attempt to repair the machine
unless you are qualified to do so.
Do not allow processed material to
build up in the discharge zone; this
may prevent proper discharge which
can result in kickback of material
through the chute assembly.
OBJ_BUCH-2380-003.book Page 3 Thursday, March 1, 2018 3:38 PM

4 | English
F 016 L81 414 | (1.3.18) Bosch Power Tools
If the machine becomes clogged,
switch off and allow the cutter to
stop. Remove the plug from the
mains supply before clearing debris.
Check if guards and protective devic-
es are undamaged and properly
mounted. Before using, carry out any
necessary maintenance and repairs.
Clean the cooling air outlet grid from
outside, using a vacuum cleaner to
clear the dust and debris which inevi-
tably builds up there. The filter mesh
cannot be removed.
Never pick up or carry the machine
while the motor is running.
Whenever you leave the work area,
switch off, allow the cutter to stop,
and remove plug from the mains sup-
ply.
Do not tilt the machine while it is run-
ning.
Do not expose the machine to rain.
Only store the machine in a dry place.
When using an aggregator then it
needs to be an Automatic Voltage
Regulation (AVR) version avoiding
damages caused by overvoltage
spikes. Aggregator minimum power
need to be 4 kW.
Maintenance and Storage
When the machine is stopped for ser-
vicing, inspection, or storage, or to
change an accessory, switch off and
remove the plug from the mains sup-
ply and allow the machine to cool.
Make sure that all moving parts have
come to a complete stop before mak-
ing any inspections, adjustments,
etc.
Maintain the machine with care and
keep it clean.
Examine the machine and replace
worn or damaged parts to maintain
its safety.
Ensure replacement parts fitted are
Bosch-approved.
If an extension cord is used with the
machine, see paragraph “Electrical
Safety”.
When servicing the cutter (e. g. turn-
ing over the blade, or replacing it), be
aware that there is no brake on the
motor and so the blade can be moved
by hand and could trap fingers, etc..
Never attempt to override the inter-
lock feature of the hopper.
Electrical Safety
Warning! Switch off, remove
plug from mains before ad-
justing, cleaning or if cable is
cut, damaged or entangled.
Your machine is double insulated for
safety and requires no earth connec-
tion. The operating voltage is 230 V AC,
50 Hz (for some non-EU countries
220 V, 240 V as applicable).
For increased electrical safety use a Re-
sidual Current Device (RCD) with a trip-
ping current of not more than 30 mA.
Always check your RCD every time you
use it.
Supply cord. If your appliance is in-
tended for use in the UK, it may have a
ready-fitted supply cord, fitted with a
UK 3-pin plug approved to BS1363/A
(this has a 13A fuse fitted). Inspect the
cord regularly for damage. If damaged,
OBJ_BUCH-2380-003.book Page 4 Thursday, March 1, 2018 3:38 PM

English | 5
Bosch Power Tools F 016 L81 414 | (1.3.18)
get it replaced by a Bosch Service Cen-
tre; it cannot be safely replaced by any-
one else.
If the plug is not suitable for your socket
outlet, get a Bosch service agent to re-
place the plug. Dispose of the severed
plug immediately; never insert any plug
with severed flex into a mains socket,
even if the socket is switched off, as it
poses a risk of electric shock from the
exposed flex, which could be made live.
Extension leads. If your appliance is
intended for use outside the UK, it will
be fitted with a special “Schuko” plug
built into the appliance; this called an
appliance inlet. You will need an exten-
sion lead, or reel, fitted with a mating
‘Schuko’ socket at one end and a plug
suitable for your local supply system at
the other. This is not supplied with the
product.
If you have a UK appliance with a fitted
plug, you can use an extension lead, or
reel, with it.
Warning! Inadequate exten-
sion cables can be dangerous.
The following advice applies to
ALL extension leads for all products.
– Extension leads used should comply
with EN 60884-2-7, and be intended
for outdoor use.
– Extension reels should comply with
EN 61242/IEC 61242.
– Follow the instructions supplied with
any lead or reel, and any local wiring
regulations.
– There should be an earth core within
the cable.
– Always ensure that leads are not
damaged, for instance by dragging
across rough ground, or being caught
on obstructions. Do not let the cable
or any connections stand in water.
– Inspect the lead regularly for damage,
and repair or replace if damaged.
– Any couplings between extension
leads should be of rubber, and be
protected against splashed water,
preferably by an IP55 approval.
– Maximum length: for use with this
product, the maximum total length of
cable should be 30 m for extension
leads, or up to 60 m for a cable reel, if
an RCD (with rated residual current of
30 mA) is incorporated into the reel.
– Minimum size: for use with this prod-
uct, the minimum nominal conductor
cross-sectional area of the cable
must be 1.25 mm2 (UK) or 1.5 mm2
(outside UK).
non-UK product: with appliance inlet
can still be used in the UK, with the ap-
propriate extension lead, which must,
of course, be fitted with a 13A UK plug.
Symbols
The following symbols are important for reading and under-
standing the operating instructions especally the diagrams.
Please take note of the symbols and their meaning. The cor-
rect interpretation of the symbols will help you to use the gar-
den product in a better and safer manner.
Symbol Meaning
Wear protective gloves
Movement direction
Reaction direction
Weight
OBJ_BUCH-2380-003.book Page 5 Thursday, March 1, 2018 3:38 PM

6 | English
F 016 L81 414 | (1.3.18) Bosch Power Tools
Intended Use
This corded, electrically driven, shredder is intended for the
purpose of shredding leafy, green garden waste such as
hedge cuttings. It is not intended for heavy duty use or as a
rental tool.
Technical Data
Noise/Vibration Information
Sound emission values determined according to EN 50434.
Mounting and Operation To run the machine
Starting
To start your shredder, rotate the ON/Off knob from position
“0” to position “I”. Then move it to “II” for a second or so and
release it so that it moves back automatically to “I”. The ma-
chine should start.
The shredder will not start if the knob is pushed in while start-
ing. Let it spring back out. Return the knob to “0” and start
again.
If you hold the knob too long in position “II”, the shredder will
stop. Return the knob back to “0” and start again.
As a safety feature, the shredder will not start unless the hop-
per securing knob is fully tightened. (Item X in picture 8)
Stopping
To stop the machine, turn the ON/OFF knob anti-clockwise to
“0”. Alternatively, and in an emergency, simply press the
knob inwards. You will then have to turn the knob to “0” be-
fore you can restart the machine.
Switching On
Switching Off
Accessories/Spare Parts
Symbol Meaning
Rapid Shredder AXT Rapid 2000 AXT Rapid 2200
Article number 3 600 H53 5.. 3 600 H53 6..
Power consumption, (P40)1) W 2000 2200
No-load speed rpm 3650 3650
Throughput, max. kg/h 802) 902)
Branch diameter, max. mm 352) 402)
Weight (excluding optional accessories) kg 11.9 12.1
Electrical safety class /II /II
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
1)P40 indicates that the appliance has been tested and approved for a cycling usage of 40 seconds fully-loaded, followed by 60 seconds idling. The
appliance can therefore be allowed to run continuously, but with regular breaks from heavy loading. Continuous heavy loading will cause the thermal
trip to operate.
2)Depending on the hardness of the wood.
3 600 ... H53 5.. H53 6..
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Wear hearing protection!
dB(A)
dB(A)
dB
89
103
=3
90
103
=4
Action Figure Page
Delivery Scope 19
Mounting wheels and undercarriage 29
Mounting the collecting bag and storing
the base unit 310
Connecting the extension lead 410
Starting 511
Working Advice 611
Stopping 712
Blade Maintenance 812
Maintenance, Cleaning and Storage 913
Selecting Accessories 10 13
OBJ_BUCH-2380-003.book Page 6 Thursday, March 1, 2018 3:38 PM

English | 7
Bosch Power Tools F 016 L81 414 | (1.3.18)
Restarting Protection
A mains failure causes machine to switch off. The machine
cannot restart on its own when the power returns.
Overload Protection
Overloading (e. g. clogging up of the cutter) can lead to a
standstill of the machine after a few seconds. After a short pe-
riod, the machine can be switched on again.
If the shredder clogs up again, turn it off, pull out the mains
plug, and clear the blockage. Continuous overloading and
blocking up of the motor outlet vents can cause the motor
thermal overload cutout to trip. Clean the outlet mesh and
turn the shredder off for several minutes to allow it to cool.
The trip will reset automatically, but the shredder will not, of
course, start again until you turn the ON/OFF knob back to
“0” and repeat the start sequence.
Advice on Shredding
Branches become harder to shred depending on the type, age
and dryness of the wood.
For best results, shred fresh branches soon after they have
been cut.
Soft garden waste should be shredded in smaller loads, par-
ticularly when wet. Any blockages can be avoided by intermit-
tently shredding branches.
Blade Maintenance
Stop and remove plug from the power supply.
The blade has a double-sided cutting edge.
When the cutting edges become blunt, the blade can be
turned over.
The blade bolt can be reused. Ensure it is tightened very firm-
ly when replacing the cutter disc. When both sides are blunt,
replace the blade. A new blade is available as a spare; use the
new bolt which is supplied with it.
Troubleshooting
The following chart lists problem symptoms, possible causes and corrective action, if your garden product does not operate
properly. If these do not identify and correct the problem, contact your service agent.
Warning! Switch off, remove plug from mains before adjusting, cleaning or if cable is cut, damaged or entangled.
Problem Possible Cause Corrective Action
Machine fails to operate Switch fails to operate Do not push On/Off switch while it is being rotated
Securing knob has not been fully tightened Tighten hopper securing knob
Power turned off Turn power on
Mains socket faulty Use another socket
Extension cable damaged Inspect cable, replace if damaged
Fuse faulty/blown Replace/restart
Motor protector has activated Follow “Overload Protection” procedure
Power supply interrupted Follow “Overload Protection” procedure
On/Off switch returns to position “0” Allow machine to cool then follow “Overload Protec-
tion” procedure
Undervoltage protection Restart machine. Check extension cable is as re-
quired in instructions (lower quality extension cable
can cause error). When powered by aggregator,
check its performance.
Machine functions
intermittently Extension cable damaged Check mains cable and have it replaced, if required
Internal wiring of machine damaged Contact Service Agent
Motor protector has activated Follow “Overload Protection” procedure
On/Off switch returns to position “0” Allow machine to cool then follow “Overload Protec-
tion” procedure
Poor cutting performance Cutting blade blunt Rotate blade to unused side. If both sides are blunt
then replace blade.
Cutting blade dirty Remove Blade and Clean. Rotate blade if necessary
Feed intake or discharge chute blocked Clean machine and empty collecting bag
Cutting blade not rotating Cutting blade obstructed Clear obstruction
Blade nut/bolt loose Tighten blade nut/bolt
Excessive vibrations/noise Blade nut/bolt loose Tighten blade nut/bolt
Cutting blade damaged Replace blade
Machine damaged internally Contact Service Agent
