Bosch 11317EVS - Hex Demolition Hammer 3/4 Inch User manual

11317EVS
DEMOLITION HAMMER
Model 0611317739
INDUSTRIAL
April 2001
S-B Power Tool Company Chicago IL 60646-5999
842/8
12mm
42
842/3
842/8
842/5
X
2
113
Y
2
a
113
115
43
125
112
803 15
111
13
114
142
X
38
104
34
57
41
54
103
37
18
39
138
36
105
27
106
821
820
136
75
77
82
140
140
131
9
808
1
7126
6
80
76
5
44/1
White
Black
a
Y
29
55
56 7170
35
103
14
129 840
141
823
124
72
139
127
845 30
86 89
89
784
887
88
90
90
= 898
Brush Spring
Tension 210
842/3
5/1

Service Notes:
103 1610210122 O-Ring{2} 42
104 1610210123 O-Ring 78
105 2 916690007 Lock Washer {4} 65
106 1610508042 Bushing 82
111 3610501500 ThreadedBushing 82
112 3613461500 ThreadedRing 85
113 1610009007 Spacer{2} 82
114 1900210130 O-Ring 78
115 1610508027 Cap 9
124 1610101608 Washer 65
125 2910611047 Screw{4} 89
126 2910611019 Screw 89
127 2914441117 Screw{4} 89
129 2914541008 Screw{4} 89
131 1611110C36 Label"Caution" 9
136 2914551114 Screw{2} 89
138 1610210130 O-Ring 78
139 1610108020 Felt Seal 77
140 2910211247 Screw{4} 89
141 1610290028 Seal 77
142 3613344500 GreaseSlinger 82
784 2602025076 AuxiliaryHandle 9
w/pos. 84, 86, 88, 887
803 1614011074 Armaturew/Fan120V AW
w/pos.13,15,111,114,142
808 1601106999 Nameplate 9
820 1617000850 ToolHolderAssembly 84
w/pos. 34, 36, 37, 39,
106,138,821
821 1617000014 Lock Bolt Assembly 86
823 1617000403 NeedleBearing 56
840 1617000969 ImpactHousingAssembly 72
w/pos. 14, 141, 823
842/3 1 614652004 BrushSpring{2} 27
842/5 1 617014126 Brush Set 26
842/8 2 910611012 Screw{2} 89
845 1617 000 418 GearHousingCoverAssy. 70
w/pos. 30, 127, 139
887 1 617000 188 Clamp Assembly 80
w/pos. 87, 89, 90
898 1617 000 427 ServicePack w/Grease 1
1 1615108091 MotorHousing 71
2 1614220125 Field120V 22
4 1617200048 SwitchOn/Off 15
4/1 2910011088 Screw{2} 89
5 1604460092 Cord 11
5/1 1900452003 TerminalSleeve{2} 11
6 1600703010 StrainRelief 11
7 1 601 302 018 CordClamp 89
9 1611110C35 Label"11317EVS" 9
13 2610909310 BallBearing 60
14 1610 910 089 NeedleBearing 61
15 1616 610 083 Fan 23
18 1 610 119 010 RetainingRing 89
27 2910 141 246 Screw{4} 89
29 1614 621 003 Spring 27
30 1610 210 147 O-Ring 78
34 1610390029 ControlDisc 49
35 1615 806 108 GuideTube 43
36 1610 210 127 O-Ring 78
37 1610 210 128 O-Ring 78
38 1615190093 PlasticSleeve 70
39 1610 283 030 Seal 77
41 1618 710078 Impact Bolt 45
42 1614336036 BrushHolderAssembly 25
w/pos.842/3 - 842/8
43 1615 808 083 MotorHousingCover 70
54 1610190019 ControlDisc 49
55 1 610 420 005 ControlBushing 49
56 1618700064 Piston 47
57 1618 710 062 Striker 44
70 1 612 001 033 ConnectingRod 57
71 1613 101 006 Wrist Pin 47
72 1616 317 045 Eccentric Gear 34
75 1615 132 082 Handle 74
76 1612026049 Switch Actuator 63
77 1612026048 Shift Plate 63
80 1617233027 SpeedControl115V 17
82 1 615 510 000 LightConductor 9
86 2 911011 270 Hex Bolt 89
88 1613 349 017 Knob 63
89 1618040053 ClampHolder{2} 9
90 1610 190018 Catch Disc {2} 9
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
11317EVS DEMOLITION HAMMER
