11387
DEMOLITION HAMMER
Model 0611387039
INDUSTRIAL
June 2002
S-B Power Tool Company Chicago IL 60646-5999
884
87
86
85
84
895
898
138
Z
135
137
134
7
6
126
5
135
Secure with Loctite
= Pos. 897
Blue Green
White
75
174
81
177
174 178
818
4
Red
131
2
27
172
1
9
808
113
803 15
14
43
13
112
34
111
176
175
803 42
817
811
Black
53
160
142167121
821
154
17
18
835
854
57 162
856
165
171
73
72
116
840
874
69
38
104
145
141
95
150
803
138
Z
0 mm
142 167 121
Pos. 821
Spring Tension
15324
28
16
150 20 166
25 22
143 21

135 1 614 414 016 Cable 10
137 2 916 699 130 Lock Washer 65
138 1 611 015 050 Gasket 79
141 1 610 290 066 Seal 77
142 1 610 290 061 Seal 77
143 2 916 540 017 Spring ing 89
145 1 610 119 012 etaining ing 89
150 1 610 210 127 O- ing 78
153 2 916 540 020 etaining ing 89
154 2 916 660 024 etaining ing 89
160 1 610 210 172 ing 9
162 1 610 210 091 O- ing 78
165 1 610 210 153 O- ing 42
166 1 613 200 015 Pin 66
167 1 610 290 062 Seal 77
171 1 613 435 014 Screw {4} 89
172 1 613 435 013 Screw {4} 89
174 1 613 435 012 Screw {4} 89
175 2 912 401 018 Screw {2} 89
176 1 613 435 012 Screw {2} 89
177 1 603 435 051 Screw {2} 89
178 1 604 412 069 Cable 10
803 1 614 011 090 Armature Assembly AW
w/pos. 13, 14, 15, 95,
111, 112, 141, 145
808 1 611 104 999 Nameplate 9
811 1 617 014 138 Brush Set 26
817 1 614 652 004 Brush Spring {2} 27
818 2 910 011 088 Screw {2} 89
821 1 617 000 835 Bushing Assembly 82
w/pos. 121, 142, 167
835 1 617 000 450 Guide Tube Assembly 43
840 1 617 000 846 Gear Housing Assembly 72
w/pos. 95,104,141,145,150
854 1 617 000 442 Impact Bolt Assembly 45
w/pos. 162, 165
856 1 617 000 836 Piston Assembly 47
w/pos. 165
874 1 617 000 422 Plate 9
884 1 612 025 055 Auxiliary Handle 9
w/pos. 84, 85, 86, 87
895 1 615 430 019 Oil 1
897 1 617 000 447 Service Pack 78
w/pos. 21, 138, 143, 162,
165, 811
898 1 615 437 512 Oil w/pos. 138 1
1 1 615 102 154 Motor Housing 71
2 1 614 220 150 Field 22
4 1 617 200 092 Switch 15
w/pos. 818
5 1 614 461 034 Cord 11
6 1 610 703 053 Strain eleif 11
7 1 601 302 018 Cord Clamp 89
9 1 611 110 C73 Label 9
13 1 610 900 026 Ball Bearing 60
14 1 610 905 028 Ball Bearing 61
15 1 616 610 085 Fan 23
16 1 610 499 053 Sleeve 86
17 1 610 241 000 Washer 65
18 1 614 601 030 etaining ing 89
20 1 618 597 079 Tool Holder 84
21 1 610 508 044 Dust Shield 92
22 1 610 591 034 Sleeve 86
24 1 610 500 020 Disc 86
25 1 613 100 029 Lock Bolt 86
27 1 600 591 032 Air Deflector 24
28 1 614 621 000 Spring 86
34 1 610 516 013 Flange 9
38 1 615 190 088 Cover 9
42 1 614 336 041 Bush Holder 25
w/pos. 811, 817
43 1 615 500 303 Cover 70
53 1 610 102 054 Washer 65
57 1 618 710 079 Striker 44
69 1 610 099 004 Bracket 62
72 1 616 317 062 Eccentric Gear 34
73 1 615 500 312 Gear Housing Cover 70
75 1 615 132 078 Handle 74
81 1 615 132 079 Handle Cover 74
84 1 612 025 050 Auxiliary Handle 9
85 1 618 040 074 Clamp Holder 80
86 1 613 490 002 T-Bolt 80
87 1 611 316 019 Clamping Band 80
95 1 610 210 173 O- ing 78
104 1 610 210 095 O- ing 78
111 1 610 290 064 Bushing 82
112 1 613 300 008 Nut 89
113 1 613 435 009 Screw {2} 89
116 1 610 311 017 Bushing 82
121 1 610 328 018 Bushing 82
126 2 910 211 019 Screw 89
131 1 611 110 C56 Label 9
134 2 910 110 116 Screw 89
Pos. Part Number Description {Qty.} F/C Pos. Part Number Description {Qty.} F/C
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
11387 DEMOLITION HAMMER
Service Notes:
