Bosch IXO Professional User manual

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
2 609 140 837 (2011.11) O / 96 ASIA
IXO Professional
en Original instructions
cn 正本使用说明书
tw 正本使用說明書
ko 사용 설명서 원본
th หนังสือคูมือการใชงานฉบับตนแบบ
id Petunjuk-Petunjuk untuk
Penggunaan Orisinal
vi BΩng hõëng dÿn nguy›n bΩn
OBJ_DOKU-24634-003.fm Page 1 Tuesday, November 8, 2011 2:14 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
2|
English . . . . . . . . . . . . . . . Page 7
中文 . . . . . . . . . . . . . . . . . . . . . . . . . 页21
中文. . . . . . . . . . . . . . . . . . . . . . . . . 頁32
한국어 . . . . . . . . . . . . . . . . . . . . .면 42
ภาษาไทย. . . . . . . . . . . . . . . . . . . . . หนา 53
Bahasa Indonesia. . . . Halaman 68
Tiøng Vi·t . . . . . . . . . . . . . . Trang 81
OBJ_BUCH-1384-003.book Page 2 Tuesday, November 8, 2011 2:15 PM

| 3
Bosch Power Tools 2 609 140 837 | (8.11.11)
A
IXO
11
5
1
2
3
56
10
4
97
8
OBJ_BUCH-1384-003.book Page 3 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
4|
C
B
1
3
2
1
OBJ_BUCH-1384-003.book Page 4 Tuesday, November 8, 2011 2:15 PM

| 5
Bosch Power Tools 2 609 140 837 | (8.11.11)
E
D
14
13
15
12
16
OBJ_BUCH-1384-003.book Page 5 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
6|
F
3
G
11
OBJ_BUCH-1384-003.book Page 6 Tuesday, November 8, 2011 2:15 PM

English | 7
Bosch Power Tools 2 609 140 837 | (8.11.11)
English
Safety Notes
General Power Tool Safety Warnings
Read all safety warnings and all instructions. Fail-
ure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
Work area safety
fKeep work area clean and well lit. Cluttered or dark areas invite acci-
dents.
fDo not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools cre-
ate sparks which may ignite the dust or fumes.
fKeep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
fPower tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
fAvoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
fDo not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
fDo not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges and moving parts. Damaged or entangled cords increase the
risk of electric shock.
WARNING
OBJ_BUCH-1384-003.book Page 7 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
8| English
fWhen operating a power tool outdoors, use an extension cord suit-
able for outdoor use. Use of a cord suitable for outdoor use reduces
the risk of electric shock.
fIf operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD re-
duces the risk of electric shock.
Personal safety
fStay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
fUse personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
fPrevent unintentional starting. Ensure the switch is in the off-po-
sition before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your finger
on the switch or energising power tools that have the switch on invites
accidents.
fRemove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
fDo not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected situations.
fDress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
fIf devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly
used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
fDo not force the power tool. Use the correct power tool for your ap-
plication. The correct power tool will do the job better and safer at the
rate for which it was designed.
OBJ_BUCH-1384-003.book Page 8 Tuesday, November 8, 2011 2:15 PM

English | 9
Bosch Power Tools 2 609 140 837 | (8.11.11)
fDo not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
fDisconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments, chang-
ing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
fStore idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to op-
erate the power tool. Power tools are dangerous in the hands of un-
trained users.
fMaintain power tools. Check for misalignment or binding of mov-
ing parts, breakage of parts and any other condition that may af-
fect the power tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by poorly main-
tained power tools.
fKeep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier to
control.
fUse the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
Battery tool use and care
fRecharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
fUse power tools only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury and fire.
fWhen battery pack is not in use, keep it away from other metal ob-
jects, like paper clips, coins, keys, nails, screws or other small met-
al objects, that can make a connection from one terminal to anoth-
er. Shorting the battery terminals together may cause burns or a fire.
fUnder abusive conditions, liquid may be ejected from the battery;
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
OBJ_BUCH-1384-003.book Page 9 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
10 | English
Service
fHave your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
Safety Warnings for Screwdrivers
fHold power tool by insulated gripping surfaces, when performing
an operation where the fastener may contact hidden wiring. Fas-
teners contacting a “live” wire may make exposed metal parts of the
power tool “live” and could give the operator an electric shock.
fHold the machine with a firm grip. High reaction torque can briefly
occur while driving in and loosening screws.
fAlways wait until the machine has come to a complete stop before
placing it down. The tool insert can jam and lead to loss of control over
the power tool.
fBefore any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational di-
rection switch to the centre position. Unintentional actuation of the
On/Off switch can lead to injuries.
Protect the power tool against heat, e. g., against continu-
ous intense sunlight, fire, water, and moisture. Danger of
explosion.
fIn case of damage and improper use of the battery, vapours may be
emitted. Provide for fresh air and seek medical help in case of
complaints. The vapours can irritate the respiratory system.
Safety Warnings for Battery Chargers
Keep the battery charger away from rain or moisture. Pen-
etration of water in the battery charger increases the risk of an
electric shock.
fOnly charge Bosch lithium ion batteries or batteries installed in
Bosch products with the voltages listed in the technical data. Oth-
erwise there is danger of fire and explosion.
fKeep the battery charger clean. Contamination can lead to danger of
an electric shock.
OBJ_BUCH-1384-003.book Page 10 Tuesday, November 8, 2011 2:15 PM

English | 11
Bosch Power Tools 2 609 140 837 | (8.11.11)
fBefore each use, check the battery charger, cable and plug. If dam-
age is detected, do not use the battery charger. Never open the
battery charger yourself. Have repairs performed only by a quali-
fied technician and only using original spare parts. Damaged bat-
tery chargers, cables and plugs increase the risk of an electric shock.
fDo not operate the battery charger on easily inflammable surfaces
(e. g., paper, textiles, etc.) or surroundings. The heating of the bat-
tery charger during the charging process can pose a fire hazard.
fSupervise children. This will ensure that children do not play with the
charger.
fChildren or persons that owing to their physical, sensory or mental
limitations or to their lack of experience or knowledge, are not ca-
pable of securely operating the charger, may only use this charger
under supervision or after having been instructed by a responsible
person. Otherwise, there is danger of operating errors and injuries.
Products sold in GB only: Your product is fitted with a BS 1363/A ap-
proved electric plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be cut off and an
appropriate plug fitted in its place by an authorised customer service
agent. The replacement plug should have the same fuse rating as the orig-
inal plug.
The severed plug must be disposed of to avoid a possible shock hazard
and should never be inserted into a mains socket elsewhere.
Product Description and Specifications
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and
instructions may result in electric shock,
fire and/or serious injury.
Intended Use
The machine is intended for driving in and loosening screws.
Product Features
The numbering of the product features refers to the illustration of the ma-
chine on the graphics page.
OBJ_BUCH-1384-003.book Page 11 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
12 | English
1Screwdriver bit*
2Tool holder
3Rubber cap
4Indicator for right rotation
5Battery charge-control indicator
6Indicator for left rotation
7On/Off switch
8Rotational direction switch
9“PowerLight”
10 Handle (insulated gripping surface)
11 Battery charger
12 Angle driver head*
13 Torque attachment*
14 Torque presetting ring*
15 Torque-setting mark*
16 Release ring*
*Accessories shown or described are not part of the standard delivery scope of
the product. A complete overview of accessories can be found in our acces-
sories program.
Technical Data
Cordless Screwdriver IXO
Professional
Article number 3 601 J60 2..
Rated voltage V= 3.6
No-load speed min-1 180
Max. torque for hard/soft screwdriving applica-
tion according to ISO 5393 Nm 4/3
Max. screw dia. mm 5
Weight according to EPTA-Procedure 01/2003 kg 0.3
Please observe the article number on the type plate of your machine. The trade names
of the individual machines may vary.
OBJ_BUCH-1384-003.book Page 12 Tuesday, November 8, 2011 2:15 PM

English | 13
Bosch Power Tools 2 609 140 837 | (8.11.11)
Assembly
fBefore any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational di-
rection switch to the centre position. Unintentional actuation of the
On/Off switch can lead to injuries.
Battery Charging (see figure A)
fDo not use other battery chargers. The supplied battery charger is
designed for the Lithium-Ion battery in your machine.
fObserve the mains voltage! The voltage of the power supply must
correspond with the data given on the nameplate of the battery charg-
er. Battery chargers marked with 230 V can also be operated with
220 V.
Note: The battery is supplied partially charged. To ensure full capacity of
the battery, completely charge the battery in the battery charger before
using your power tool for the first time.
The Lithium-Ion battery can be charged at any time without reducing its
service life. Interrupting the charging procedure does not damage the bat-
tery.
The Lithium-Ion battery is protected against deep discharging. When the
battery is discharged, the machine is automatically switched off by a pro-
tective circuit: The inserted tool no longer moves and a slight whistling
noise can be heard.
Battery Li-Ion
Capacity Ah 1.3
Number of battery cells 1
Battery Charger
Article number 2 607 225 093
Charging time h5
Protection class /II
Cordless Screwdriver IXO
Professional
Please observe the article number on the type plate of your machine. The trade names
of the individual machines may vary.
OBJ_BUCH-1384-003.book Page 13 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
14 | English
Do not continue to press the On/Off switch after
the machine has been automatically switched
off. The battery can be damaged.
When the battery charge-control indicator 5lights up red while the
On/Off switch 7is depressed half way, then the battery has less than
30% of its capacity and should be charged.
The charging procedure starts as soon as the main plug of the battery
charger is inserted into the socket and the cordless screwdriver is after-
wards placed on the battery charger 11.
The battery charge-control indicator 5indicates the charging progress.
The indicator lights up green during the charging process. When the bat-
tery charge-control indicator 5is no longer lit, the battery is fully charged.
During the charging procedure, the handle of the machine warms up. This
is normal.
Disconnect the battery charger from the mains supply when not using it
for longer periods.
The power tool cannot be used during the charge procedure; it is not de-
fective when inoperative during the charging procedure.
fProtect the battery charger against moisture!
Observe the notes for disposal.
Changing the Tool (see figure B)
fDo not use double-sided screwdriver blades that are longer than
25 mm.
Insert the screwdriver bit 1directly into the tool holder 2.
Torque Attachment/Angle Driver Head (see figures C –F)
The angle driver head 12 enables screwdriving at hard to reach locations.
With the torque presetting ring 14 on the torque attachment 13, the re-
quested torque can be preset in 10 steps. With the correct setting, the
tool bit is stopped as soon as the screw is driven flush into the material or
when the set torque is reached.
Assembly (see figures C–D)
For assembly of the attachments, pull the rubber cap 3off toward the
front. Afterwards the attachments can be mounted. The attachments can
be mounted offset by 45°.
WARNING
OBJ_BUCH-1384-003.book Page 14 Tuesday, November 8, 2011 2:15 PM

English | 15
Bosch Power Tools 2 609 140 837 | (8.11.11)
Dismounting (see figures E–F)
To dismount the attachments, turn the release ring 16 in rotation direc-
tion nand pull the attachment off toward the front. Afterwards, mount
the rubber cap 3again.
Operation
Starting Operation
Reversing the Rotational Direction
The rotational direction switch 8is used to reverse the rotational direction
of the machine. However, this is not possible with the On/Off switch7ac-
tuated.
Right rotation: For driving in screws, push the rotational direction switch
8left to the stop.
The indicator for right rotation 4lights up when the On/Off
switch 7is actuated and the motor is running.
Left Rotation: For loosening or unscrewing screws, push the rotational
direction switch 8right to the stop.
The indicator for left rotation 6lights up when the On/Off switch
7is actuated and the motor is running.
Switching On and Off
To start the machine, press the On/Off switch 7and keep it pressed.
The power light 9lights up when the On/Off switch 7is slightly or com-
pletely pressed, and allows the work area to be illuminated when lighting
conditions are insufficient.
To switch off the machine, release the On/Off switch 7.
Fully automatic spindle locking (Auto-lock)
The drill spindle is locked when the On/Off switch 7is not pressed.
This enables screws to be screwed in, even when the battery is empty and
allows for the machine to be used as a screwdriver.
fWhen the drilling spindle is locked, do not press the On/Off switch
7 for more than 15 seconds. Otherwise the power tool can be dam-
aged.
OBJ_BUCH-1384-003.book Page 15 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
16 | English
Working Advice
fApply the power tool to the screw only when it is switched off. Ro-
tating tool inserts can slip off.
Up to 13 screwdriver bits can be stored on the side of the battery charger
11. The fixture that holds the screwdriver bits can be removed.
Wall-mounting the Battery Charger (see figure G)
The battery charger 11 can be mounted to a wall. For this, hang the charg-
er via the slots on the side onto two screws.
Maintenance and Service
Maintenance and Cleaning
fBefore any work on the machine (e. g., maintenance, tool change,
etc.) as well as during transport and storage, set the rotational di-
rection switch to the centre position. Unintentional actuation of the
On/Off switch can lead to injuries.
fFor safe and proper working, always keep the machine and venti-
lation slots clean.
When the battery is no longer operative, please refer to an authorised af-
ter-sales service agent for Bosch power tools.
If the replacement of the supply cord is necessary, this has to be done by
Bosch or an authorized Bosch service agent in order to avoid a safety haz-
ard.
If the machine should fail despite the care taken in manufacturing and
testing procedures, repair should be carried out by an after-sales service
centre for Bosch power tools.
In all correspondence and spare parts order, please always include the
10-digit article number given on the type plate of the machine.
OBJ_BUCH-1384-003.book Page 16 Tuesday, November 8, 2011 2:15 PM

English | 17
Bosch Power Tools 2 609 140 837 | (8.11.11)
After-sales Service and Customer Assistance
Our after-sales service responds to your questions concerning mainte-
nance and repair of your product as well as spare parts. Exploded views
and information on spare parts can also be found under:
www.bosch-pt.com
Our customer service representatives can answer your questions con-
cerning possible applications and adjustment of products and accesso-
ries.
People’s Republic of China
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.cn
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.hk
Indonesia
PT. Multi Mayaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No. 2
Jakarta 13930
Indonesia
Tel.: [phone]
Fax: [phone] 23
E-Mail: [e-mail]
www.bosch-pt.co.id
OBJ_BUCH-1384-003.book Page 17 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
18 | English
Philippines
Robert Bosch, Inc.
28th Floor Fort Legend Towers,
3rd Avenue corner 31st Street,
Fort Bonifacio Global City,
1634 Taguig City, Philippines
Tel.: [phone]
Fax: [phone]
[email protected]
www.bosch-pt.com.ph
Bosch Service Center:
9725-27 Kamagong Street
San Antonio Village
Makati City, Philippines
Tel.: [phone]
Fax: [phone]
[email protected]
Malaysia
Robert Bosch (S.E.A.) Pte. Ltd.
No. 8A, Jalan 13/6
G.P.O. Box 10818
46200 Petaling Jaya
Selangor, Malaysia
Tel.: [phone]
Fax: [phone]
[email protected]
Toll-Free: 1800 880 188
www.bosch-pt.com.my
OBJ_BUCH-1384-003.book Page 18 Tuesday, November 8, 2011 2:15 PM

English | 19
Bosch Power Tools 2 609 140 837 | (8.11.11)
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: [phone] – 18 88 (10 lines)
Fax: [phone]
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501, Thailand
Bosch Service – Training Centre
2869-2869/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway)
Prakanong District
10110 Bangkok
Thailand
Tel.: [phone] – 4
Fax: [phone]
Fax: [phone]
Singapore
Robert Bosch (SEA) Pte. Ltd.
11 Bishan Street 21
Singapore 573943
Tel.: [phone]
Fax: [phone]
[email protected]
Toll-Free: 1800 333 8333
www.bosch-pt.com.sg
OBJ_BUCH-1384-003.book Page 19 Tuesday, November 8, 2011 2:15 PM

2 609 140 837 | (8.11.11) Bosch Power Tools
20 | English
Vietnam
Robert Bosch Vietnam Co. Ltd
10/F, 194 Golden Building
473 Dien Bien Phu Street
Ward 25, Binh Thanh District
84 Ho Chi Minh City
Vietnam
Tel.: [phone] ext. 413
Fax: [phone]
[email protected]
www.bosch-pt.com
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: + 61 (01300) 307 045
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
Transport
The contained lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements. The user can transport the batteries by road
without further requirements.
When being transported by third parties (e.g.: air transport or forwarding
agency), special requirements on packaging and labelling must be ob-
served. For preparation of the item being shipped, consulting an expert
for hazardous material is required.
OBJ_BUCH-1384-003.book Page 20 Tuesday, November 8, 2011 2:15 PM
