Bosch MIC Series User manual

MIC Series Power Supplies
MIC Series
en Installation Manual

MIC Series Power Supplies Table of Contents | en 3
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
Table of Contents
1Safety 4
1.1 Important safety instructions 4
1.2 Safety precautions 6
1.3 Important notices 7
1.4 Customer Support and Service 14
2 Introduction 16
2.1 Parts List 16
2.2 Preparing the Power Supply Unit 17
2.3 Securing the Power Supply Unit 18
2.4 IP Rating 18
2.5 MIC Shielded Composite Cable Gland Connection 19
3 MIC Non-IR Power Supply Units 20
3.1 Printed Circuit Board Earth Link 20
3.2 Non-IR Power Supply Layout and Connections 22
3.3 Fuse Ratings 23
3.4 Installing a Non-IR Power Supply 24
3.5 Optional Cards and Kits for Non-IR MIC Cameras 29
3.6 Commissioning a MIC Series Camera with Public Address
Speakers 29
3.7 Commissioning a MIC Series Camera with Heater Option 30
4 MIC IR Power Supply Units 32
4.1 Printed Circuit Board Earth Link 33
4.2 Fuse Ratings 34
4.3 MIC IR Power Supply Layout and Connections 35
4.4 Installing a MIC IR Power Supply 36
4.5 Commissioning the IR Lamps 42
5 Technical Specifications 43
5.1 Dimensional Drawings 44

4en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
1Safety
1.1 Important safety instructions
Read, follow, and retain for future reference all of the following
safety instructions. Heed all warnings on the unit and in the
operating instructions before operating the unit.
1. Cleaning - Unplug the unit from the outlet before cleaning.
Follow any instructions provided with the unit. Generally,
using a dry cloth for cleaning is sufficient, but a moist fluff-
free cloth or leather shammy may also be used. Do not use
liquid cleaners or aerosol cleaners.
2. Heat Sources - Do not install the unit near any heat
sources such as radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.
3. Water - Do not use this unit near a bathtub, washbowl, or a
sink.
4. Object and liquid entry - Never push objects of any kind
into this unit through openings as they may touch
dangerous voltage points or short-out parts that could
result in a fire or electrical shock. Never spill liquid of any
kind in the unit. Do not place objects filled with liquids,
such as vases or cups, on the unit.
5. Lightning - For added protection during a lightning storm,
or when leaving this unit unattended and unused for long
periods, unplug the unit from the wall outlet and
disconnect the cable system. This will prevent damage to
the unit from lightning and power line surges.
6. Controls adjustment - Adjust only those controls specified
in the operating instructions. Improper adjustment of
other controls may cause damage to the unit. Use of
controls or adjustments, or performance of procedures
other than those specified, may result in hazardous
radiation exposure.
7. Overloading - Do not overload outlets and extension cords.
This can cause fire or electrical shock.

MIC Series Power Supplies Safety | en 5
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
8. Power supply cord and plug protection - Protect the
power supply cord and plug from foot traffic, being
pinched by items placed upon or against them at electrical
outlets, and its exit from the unit. For units intended to
operate with 230 VAC, 50 Hz, the power supply cord must
comply with the latest versions of IEC 60227. For units
intended to operate with 120 VAC, 60 Hz, the power
supply cord must comply with the latest versions of UL 62
and CSA 22.2 No.49.
9. Power disconnect - Units have power supplied to the unit
whenever the power cord is inserted into the power
source. The power cord is the main power disconnect
device for switching off the voltage for all units.
10. Servicing - Do not attempt to service this unit yourself.
Opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
11. Damage requiring service - Unplug the unit from the main
AC power source and refer servicing to qualified service
personnel when any damage to the equipment has
occurred, such as:
– the power supply cord or plug is damaged;
– exposure to moisture, water, and/or inclement
weather (rain, snow, etc.);
– liquid has been spilled in or on the equipment;
– an object has fallen into the unit;
– unit has been dropped or the unit cabinet is damaged;
– unit exhibits a distinct change in performance;
– unit does not operate normally when the user
correctly follows the operating instructions.
12. Replacement parts - Be sure the service technician uses
replacement parts specified by the manufacturer, or that
have the same characteristics as the original parts.
Unauthorized substitutions may cause fire, electrical
shock, or other hazards.

6en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
13. Safety check - Safety checks should be performed upon
completion of service or repairs to the unit to ensure
proper operating condition.
14. Installation - Install in accordance with the manufacturer's
instructions and in accordance with applicable local codes.
15. Attachments, changes or modifications - Only use
attachments/accessories specified by the manufacturer.
Any change or modification of the equipment, not
expressly approved by Bosch, could void the warranty or,
in the case of an authorization agreement, authority to
operate the equipment.
1.2 Safety precautions
DANGER!
High risk: This symbol indicates an imminently hazardous
situation such as “Dangerous Voltage” inside the product.
This symbol indicates the presence of non-insulated
“dangerous voltage” within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to
persons.
WARNING!
Medium risk: Indicates a potentially hazardous situation.
If not avoided, this could result in minor or moderate bodily
injury.
CAUTION!
Low risk: Indicates a potentially hazardous situation.
If not avoided, this could result in property damage or risk of
damage to the unit.

MIC Series Power Supplies Safety | en 7
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
1.3 Important notices
All-pole power switch - Incorporate an all-pole power switch,
with a contact separation of at least 3 mm in each pole, into the
electrical installation of the building.If it is needed to open the
housing for servicing and/or other activities, use this all-pole
switch as the main disconnect device for switching off the
voltage to the unit.
Coax grounding:
– Ground the cable system if connecting an outside cable
system to the unit.
– Connect outdoor equipment to the unit's inputs only after
this unit has had its grounding plug connected to a
grounded outlet or its ground terminal is properly
connected to a ground source.
– Disconnect the unit's input connectors from outdoor
equipment before disconnecting the grounding plug or
grounding terminal.
– Follow proper safety precautions such as grounding for
any outdoor device connected to this unit.
U.S.A. models only - Section 810 of the National Electrical Code,
ANSI/NFPA No.70, provides information regarding proper
grounding of the mount and supporting structure, grounding of
the coax to a discharge unit, size of grounding conductors,
location of discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
Accessories - Do not place this unit on an unstable stand,
tripod, bracket, or mount. The unit may fall, causing serious
injury and/or serious damage to the unit. Use only with the
cart, stand, tripod, bracket, or table specified by the
manufacturer. When a cart is used, use caution and care
when moving the cart/apparatus combination to avoid injury
from tip-over. Quick stops, excessive force, or uneven
surfaces may cause the cart/unit combination to overturn.
Mount the unit per the manufacturer's instructions.

8en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
Environmental statement - Bosch has a strong commitment
towards the environment. This unit has been designed to
respect the environment as much as possible.
Electrostatic-sensitive device - Use proper CMOS/MOS-FET
handling precautions to avoid electrostatic discharge.
NOTE: Wear required grounded wrist straps and observe proper
ESD safety precautions when handling the electrostatic-
sensitive printed circuit boards.
Fuse rating - For security protection of the device, the branch
circuit protection must be secured with a maximum fuse rating
of 16A. This must be in accordance with NEC800 (CEC Section
60).
Grounding and polarization - This unit may be equipped with a
polarized alternating current line plug (a plug with one blade
wider than the other blade). This safety feature allows the plug
to fit into the power outlet in only one way. If unable to insert
the plug fully into the outlet, contact a locally certified
electrician to replace the obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
Alternately, this unit may be equipped with a 3-pole grounding
plug (a plug with a third pin for earth grounding). This safety
feature allows the plug to fit into a grounded power outlet only.
If unable to insert the plug into the outlet, contact a locally
certified electrician to replace the obsolete outlet. Do not
defeat the safety purpose of the grounding plug.
Disposal - Your Bosch product was developed and manufactured
with high-quality material and components that can be recycled
and reused. This symbol means that electronic and electrical
appliances, which have reached the end of their working life, must
be collected and disposed of separately from household waste
material. Separate collecting systems are usually in place for
disused electronic and electrical products. Please dispose of these
units at an environmentally compatible recycling facility, per
European Directive 2002/96/EC.

MIC Series Power Supplies Safety | en 9
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
Moving - Disconnect the power before moving the unit. Move
the unit with care. Excessive force or shock may damage the
unit and the hard disk drives.
Outdoor signals - The installation for outdoor signals, especially
regarding clearance from power and lightning conductors and
transient protection, must be in accordance with NEC725 and
NEC800 (CEC Rule 16-224 and CEC Section 60).
Permanently connected equipment - Incorporate a readily
accessible disconnect device in the building installation wiring.
Pluggable equipment - Install the socket outlet near the
equipment so it is easily accessible.
Power resupply - If the unit is forced to power down due to
exceeding the specified operating temperatures, disconnect
the power cord, wait for at least 30 seconds, and then
reconnect the power cord.
Power lines - Do not locate the camera near overhead power
lines, power circuits, or electrical lights, nor where it may
contact such power lines, circuits, or lights.
Rack-mount
– Ventilation - Do not place this unit in a built-in installation
or rack without proper ventilation or adhering to the
manufacturer's instructions. The equipment must not
exceed its maximum operating temperature requirements.
– Mechanical loading - Properly mount the equipment in a
rack to prevent a hazardous condition due to uneven
mechanical loading.
Video loss - Video loss is inherent to digital video recording;
therefore, Bosch Security Systems cannot be held liable for any
damage that results from missing video information. To
minimize the risk of lost digital information, Bosch Security
Systems recommends multiple, redundant recording systems,
and a procedure to back up all analog and digital information.
CAUTION!
Connecting System ground to Safety ground may result in
ground loops that can disrupt the CCTV system.

10 en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
FCC & ICES Information
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
– reorient or relocate the receiving antenna;
– increase the separation between the equipment and
receiver;
– connect the equipment into an outlet on a circuit different
from that to which the receiver is connected;
– consult the dealer or an experienced radio/TV technician
for help.
Intentional or unintentional modifications, not expressly
approved by the party responsible for compliance, shall not be
made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult
the dealer or an experienced radio/television technician for
corrective action.
The user may find the following booklet, prepared by the
Federal Communications Commission, helpful: How to Identify
and Resolve Radio-TV Interference Problems. This booklet is
available from the U.S. Government Printing Office,
Washington, DC 20402, Stock No. 004-000-00345-4.
NOTICE!
This is a class B product. In a domestic environment this
product may cause radio interference, in which case the user
may be required to take adequate measures.

MIC Series Power Supplies Safety | en 11
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
INFORMATIONS FCC ET ICES
Suite à différents tests, cet appareil s'est révélé conforme aux
exigences imposées aux appareils numériques de classe B, en
vertu de la section 15 du règlement de la Commission fédérale
des communications des États-Unis (FCC), et en vertu de la
norme ICES-003 d'Industrie Canada. Ces exigences visent à
fournir une protection raisonnable contre les interférences
nuisibles lorsque l'appareil est utilisé dans le cadre d'une
installation résidentielle. Cet appareil génère, utilise et émet
de l'énergie de radiofréquences et peut, en cas d'installation ou
d'utilisation non conforme aux instructions, engendrer des
interférences nuisibles au niveau des radiocommunications.
Toutefois, rien ne garantit l'absence d'interférences dans une
installation particulière. Il est possible de déterminer la
production d'interférences en mettant l'appareil
successivement hors et sous tension, tout en contrôlant la
réception radio ou télévision. L'utilisateur peut parvenir à
éliminer les interférences éventuelles en prenant une ou
plusieurs des mesures suivantes:
– Modifier l'orientation ou l'emplacement de l'antenne
réceptrice;
– Éloigner l'appareil du récepteur;
– Brancher l'appareil sur une prise située sur un circuit
différent de celui du récepteur;
– Consulter le revendeur ou un technicien qualifié en radio/
télévision pour obtenir de l'aide.
Toute modification apportée au produit, non expressément
approuvée par la partie responsable de l'appareil, est
strictement interdite. Une telle modification est susceptible
d'entraîner la révocation du droit d'utilisation de l'appareil.
La brochure suivante, publiée par la Commission fédérale des
communications (FCC), peut s'avérer utile : How to Identify and
Resolve Radio-TV Interference Problems (Comment identifier et
résoudre les problèmes d’interférences de radio et de télévision).
Cette brochure est disponible auprès du U.S. Government
Printing Office, Washington, DC 20402, États-Unis, sous la
référence n° 004-000-00345-4.

12 en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UL's Standard(s) for Safety for Closed
Circuit Television Equipment, UL 2044. UL Certification does not
cover the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UL's Standard(s) for Safety for Information
Technology Equipment, UL 60950-1. UL Certification does not
cover the performance or reliability of the security or signaling
aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR
CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR
SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT.
Notice of Regulatory Compliance
This product complies with the following EC directives:
– EMC Directive (89/336/EC as amended)
– LV Directive (73/23/EC)
– RoHS (Restriction of Hazardous Substances) 2002/95/
ECEMC, CISPRA-B and CTIC
Copyright
This manual is the intellectual property of Bosch Security
Systems and is protected by copyright.
All rights reserved.

MIC Series Power Supplies Safety | en 13
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
Trademarks
All hardware and software product names used in this
document are likely to be registered trademarks and must be
treated accordingly.
NOTE!
This manual has been compiled with great care and the
information it contains has been thoroughly verified. The text
was complete and correct at the time of printing. The ongoing
development of the products may mean that the content of the
user guide can change without notice. Bosch Security Systems
accepts no liability for damage resulting directly or indirectly
from faults, incompleteness or discrepancies between the user
guide and the product described.
More information
For additional information, please contact the Bosch Security
Systems location nearest you or visit our web site at
www.boschsecurity.com

14 en | Safety MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
1.4 Customer Support and Service
If this unit needs service, contact the nearest Bosch Security
Systems Service Center for authorization to return and shipping
instructions.
Service Centers
USA
Repair Center-
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Customer Service
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Technical Support
Telephone: [phone]
Fax: [phone] or 717-735-6560
E-mail: [email protected]
Canada
Telephone: [phone]
Fax: [phone]
Europe, Middle East, Africa Region
Repair Center
Telephone: [phone]
Fax: [phone]
E-mail: [e-mail]
Asia Region
Repair Center
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Customer Service
Telephone: [phone] or
86 (0) 756 7633121
Fax: [phone]
E-mail: [email protected]

MIC Series Power Supplies Safety | en 15
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
Warranty and more information
For additional information and warranty queries, please contact
your Bosch Security Systems representative or visit our website
at www.boschsecurity.com.

16 en | Introduction MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
2 Introduction
The MIC Series power supplies from Bosch Security Systems,
Inc. provide all connections for power, telemetry and video for
the MIC Series range of PTZ cameras. Each power supply has
CE and FCC approval and is rated to IP65. The following table
summarizes the power supplies and their functions:
2.1 Parts List
Each power supply is contained within a cast aluminium
enclosure and comes with the following:
– A weather resistant (IP65) cast aluminium box pre-fitted
with three (3) cable glands.
– A power supply for a MIC Series camera.
– Provision for driving various interface cards mounted
internally to the power supply box, for example an alarm
interface card (Non-IR power supplies only).
– Provision for a signal interface card (BP-3 or BP-4) to
connect telemetry to Bosch Biphase equipment.
– Screw termination of all composite, telemetry and ancillary
cables in the box.
– Earth isolation and termination within the unit to correctly
control video earthing and to prevent earth loop.
MIC-240PSU-UL 240 VAC MIC Power Supply
MIC-IR-240PSU-UL 240 VAC MIC IR only Power Supply
MIC-115PSU-UL 115 VAC MIC Power Supply
MIC-IR-115PSU-UL 115 VAC MIC IR only Power Supply
MIC-24PSU-UL 24 VAC MIC Power Supply
MIC-IR-24PSU-UL 24 VAC MIC IR only Power Supply
NOTICE!
Use the MIC-2M-S, MIC-10M-S, MIC-20M-S and MIC-25M-S
Shielded Composite Cables with the MIC power supplies for
correct EMC protection.

MIC Series Power Supplies Introduction | en 17
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
– Three (3) M12 cable glands for telemetry, video and
ancillary equipment.
– One (1) M16 gland for connection of the screened
composite cable to the MIC camera.
– One (1) 1/2 in. NPT cable gland for the power cable
connection.
– One (1) 1/2 in. NPT and one (1) M12 blanking plug.
2.2 Preparing the Power Supply Unit
– Remove the blanking plug that covers the hole for the
power cable and attach the supplied 1/2 in. NPT cable
gland for the power cable depending upon the installation
requirements.
– Remove the second blanking plug that covers one of the
holes for an M12 cable gland and attach the supplied M12
gland fitted in its place if additional cabling for ancillary
equipment such as alarms or a washer pump is required.
CAUTION!
The PSU enclosures are not EXD rated and must be replaced
with a certified enclosure if installed within a hazardous area.
Please see the MIC Series EXD 440 Camera manual for further
details.

18 en | Introduction MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
2.3 Securing the Power Supply Unit
Secure the power supply unit using four (4) M6 screws or bolts
(not supplied); which secure through the holes in the enclosure
as shown In the figure below.
Figure 2.1 Enclosure mounting and enclosure lid screw holes
2.4 IP Rating
The power supply enclosure is an IP65 weather-resistant cast
aluminium enclosure. To maintain the environmental rating of
this enclosure, install only listed or recognized conduit hubs or
fittings with the same environmental rating as the enclosure in
compliance with the installation instruction of the hub or
fitting.
1 Enclosure mounting screw
2 Enclosure lid screw hole

MIC Series Power Supplies Introduction | en 19
Bosch Security Systems, Inc. Installation Manual F.01U.141.598 | 1.0 | 2009.11
2.5 MIC Shielded Composite Cable Gland
Connection
The MIC power supplies are designed to use the MIC shielded
composite cable. Fit this cable into the M16 nickel plated brass
cable gland as detailed below. It is important that the braided
cable screen engages with the internal clamps of the cable
gland to ensure correct EMC protection.
1. Strip the cable jacket back, leaving 25 mm of braided
shield; then fold the braided shield back over the cable
jacket.
2. Insert the shielded composite cable into the cable gland
until the braided shield reaches the internal clamp position
(approximately 20 mm inside gland)
3. Tighten the dome nut with a wrench to ensure the nut is
fully tightened and securely grips the cable and braided
shield as shown below.
Figure 2.2 Composite cable gland connection

20 en | MIC Non-IR Power Supply Units MIC Series Power Supplies
F.01U.141.598 | 1.0 | 2009.11 Installation Manual Bosch Security Systems, Inc.
3 MIC Non-IR Power Supply Units
Use this chapter to install the following MIC power supply
units:
– MIC-240PSU-UL
– MIC-115PSU-UL
– MIC-24PSU-UL
The MIC power supplies provide power, telemetry and video
connections for a single MIC camera appropriate for the power
supply type.
All non-IR MIC power supplies have the same layout and wiring
procedure; only the input voltages and fusing vary between the
230 VAC, 115 VAC and the 24 VAC power supplies.
3.1 Printed Circuit Board Earth Link
The Printed Circuit Board (PCB) has one link option next to the
add-on card slot, shown in Figure 3.1 below, allowing the power
supply to be set up for different earthing schemes.
The earth link should be broken if there is a separate
connection between the video screen and the earth. This
usually occurs on copper connected systems where all the
copper video coaxial cables are taken back to the control room
DANGER! ELECTRICAL SHOCK HAZARD
Ensure the power is disconnected prior to opening the power
supply enclosure.
Power must be disconnected before replacing any fuse in the
MIC PSU.
The MIC power supplies have a separate internal shield
covering the power cable input head-end (HD1).
Only suitably qualified persons should remove this shield and
connect the mains power cable, the shield MUST be re-fitted
and fully secured prior to connecting the power.
The mains supply cable shall have conductors of a maximum
size of 12 AWG.
A readily accessible disconnect device (circuit breaker) shall be
incorporated externally to the equipment. The recommended
rating is 15 A.
