Bosch DINION 7100i IR User manual

DINION 7100i IR
NBE‑7702‑ALX | NBE‑7702‑ALXT | NBE‑7703‑ALX | NBE‑7703‑ALXT |
NBE‑7704‑AL | NBE‑7704‑ALT | NBE‑7704‑ALX
en Installation manual

DINION 7100i IR Table of contents | en 3
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
Table of contents
1Safety 5
1.1 Safety message explanation 5
1.2 Safety precautions 5
1.3 Important safety instructions 5
1.4 Notices 6
2Short information 9
3System overview 10
3.1 Product description 10
3.2 Intended use 10
4Preparing for installation 11
4.1 Unpacking 11
4.2 Parts included 11
4.3 Preparation 12
4.4 In-box configuration 12
4.5 Wiring 12
4.5.1 Network and PoE power - RJ45 13
4.5.2 Network and PoE power - punch down connector 13
4.5.3 10-pin I/O connector 15
4.5.4 Grounding 16
5Hardware installation 17
5.1 Installing the mounting plate 17
5.1.1 Installation steps 17
5.2 Installing the camera base 18
5.2.1 Installation steps 18
5.3 Installing the camera 20
5.3.1 Installation steps 20
5.3.2 Camera positioning and rotation 20
5.4 Other optional accessories 22
5.4.1 Inserting microSD card(s) and Wireless installation dongle 22
5.4.2 Illuminator module/kit 23
5.4.3 Polarizing filter kit 26
5.4.4 Surveillance cabinet (fiber optics) installation 27
5.5 LED status 27
6Commissioning 29
7Connection via the web browser 30
7.1 System requirements 30
7.2 Establishing the connection 30
7.3 Password protection in camera 30
8Troubleshooting 32
8.1 Resolving problems 32
8.2 Testing the network connection 33
8.3 Customer service 33
9Maintenance 34
9.1 Cleaning 34
9.2 Repair 34
9.3 Reset 34
10 Decommissioning 36
10.1 Transfer 36

4en | Table of contents DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
10.2 Disposal 36

DINION 7100i IR Safety | en 5
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
1 Safety
Read, follow, and retain for future reference all of the following safety instructions. Follow
all warnings before operating the device.
1.1 Safety message explanation
In this manual, the following symbols and notations are used to draw attention to special
situations:
Danger!
Indicates a hazardous situation which, if not avoided, will result in death or serious injury.
!
Warning!
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
!
Caution!
Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
i
Notice!
Indicates a situation which, if not avoided, could result in damage to the equipment or
environment, or data loss.
1.2 Safety precautions
!
Caution!
Installation should only be performed by qualified service personnel in accordance with the
National Electrical Code (NEC800 CECSection60) or applicable local codes.
!
Caution!
The product must be supplied only by an external source having an output complying with
PS2 or Annex Q conform to IEC 62368-1 and UL62368-1.
1.3 Important safety instructions
– To clean the device, do not use liquid cleaners or aerosol cleaners.
– Do not install the device near any heat sources such as radiators, heaters, stoves, or
other equipment (including amplifiers) that produce heat.
– Do not spill liquids on the device before installation is completed.
– Take precautions to protect the device from power and lightning surges.
– If powered by a power adapter, the adapter should be properly grounded. The power
cord must be connected to a socket or outlet with a ground connection.
– Use green/yellow (green with yellow stripe) ground wires.
– Adjust only those controls specified in the operating instructions.
– Operate the device only from the type of power source indicated on the label.

6en | Safety DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
– Unless qualified, do not attempt to service a damaged device yourself. Refer all
servicing to qualified service personnel.
– Install in accordance with the manufacturer's instructions in accordance with
applicable local codes.
– Use only attachments/accessories specified by the manufacturer.
– Protect all connection cables from possible damage, particularly at connection points.
1.4 Notices
i
Notice!
Optical elements are sensitive and should be protected at all times. Do not allow objects to
come into contact with glass surfaces and do not touch optical elements with your fingers.
i
Notice!
Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot
be held liable for any damage that results from missing video information.
To minimize the risk of losing information, we recommend multiple, redundant recording
systems, and a procedure to back up all analog and digital information.
i
Notice!
This device is intended for use in public areas only.
U.S. federal law strictly prohibits surreptitious recording of oral communications.
UL Disclaimer
Underwriter Laboratories Inc. ("UL") has not tested the performance or reliability of the
security or signaling aspects of this product. UL has only tested fire, shock and/or casualty
hazards as outlined in Standard(s) for Safety for Information Technology Equipment, UL
62368-1. UL Certification does not cover the performance or reliability of the security or
signaling aspects of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER
REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-
RELATED FUNCTIONS OF THIS PRODUCT.
FCC suppliers Declaration of Conformity
F.01U.390.686 NBE-7702-ALX DINION 7100i IR
F.01U.390.687 NBE-7702-ALXT DINION 7100i IR
F.01U.390.688 NBE-7703-ALX DINION 7100i IR
F.01U.390.689 NBE-7703-ALXT DINION 7100i IR
F.01U.390.690 NBE-7704-AL DINION 7100i IR
F.01U.390.691 NBE-7704-ALT DINION 7100i IR
F.01U.390.692 NBE-7704-ALX DINION 7100i IR
Compliance statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and

DINION 7100i IR Safety | en 7
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
2. This device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Responsible party
Bosch Security Systems Inc
130 Perinton Parkway
14450 Fairport, NY, USA
For more information please contact the nearest Bosch Security Systems location or visit:
www.boschsecurity.us
For use in China: CHINA ROHS DISCLOSURE TABLE
Fixed cameras with lens
Hazardous substance table according to SJ/T 11364-2014
Pb
(Pb)
Hg
(Hg)
Cd
(Cd)
Cr 6+
(Cr 6+)
PBB
(PBB)
PBDE
(PBDE)
Housing & enclosures X O O O O O
PCBA with connectors X O X O O O
Cable assemblies O O O O O O
Image sensor assembly X O X O O O
Lens assembly X O X O O O
This table was created according to the provisions of SJ/T 11364
O: The content of such hazardous substance in all homogeneous materials of such
component is below the limit defined in GB/T 26572
X: The content of such hazardous substance in a certain homogeneous material is above
the limit defined in GB/T 26572
The manufacturing datecodes of the products are explained in:
http://www.boschsecurity.com/datecodes

8en | Safety DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
IC statement (Canada)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Use latest software
Before operating the device for the first time, make sure that you install the latest
applicable release of your software version. For consistent functionality, compatibility,
performance, and security, regularly update the software throughout the operational life of
the device. Follow the instructions in the product documentation regarding software
updates.
The following links provide more information:
– General information: https://www.boschsecurity.com/xc/en/support/product-security/
– Security advisories, that is a list of identified vulnerabilities and proposed solutions:
https://www.boschsecurity.com/xc/en/support/product-security/security-
advisories.html
Bosch assumes no liability whatsoever for any damage caused by operating its products
with outdated software components.
Old electrical and electronic equipment
This product and/or battery must be disposed of separately from household waste.
Dispose such equipment according to local laws and regulations, to allow their
reuse and/or recycling. This will help in conserving resources, and in protecting
human health and the environment.

DINION 7100i IR Short information | en 9
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
2 Short information
This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was correct at the time of publication, however, the content
can change without notice. Bosch Security Systems accepts no liability for damage resulting
directly or indirectly from faults, incompleteness or discrepancies between this manual and
the product described.
Copyright
This manual is the intellectual property of Bosch Security Systems and is protected by
copyright.
All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
More information
For more information please contact the nearest Bosch Security Systems location or visit
www.boschsecurity.com.
https://www.boschsecurity.com/xc/en/product-catalog/

10 en | System overview DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
3 System overview
3.1 Product description
All DINION 7100i IR cameras have a 3-step concept for simple installation.
With the combination of the robust housing, exceptional image quality and the powerful
video analytics, the DINION 7100i IR cameras are the ideal choice for the most demanding
outdoor applications, including traffic monitoring, critical infrastructure, and perimeter
security.
The cameras capture images in exceptional detail, and feature the latest bitrate
management techniques, data security measures and state-of-the art Intelligent Video
Analytics, delivering incredible accuracy in high security applications and interpreting
captured data for smart decision-making that goes beyond security.
Starlight X and HDR X technology combined with powerful smart IR illumination ensure
highly detailed images even in the most challenging situations.
The camera comes with the IVA Pro Buildings and the IVA Pro Perimeter pre-installed and
brings highly reliable deep-learning based detection and tracking of persons and vehicles to
scenes ranging from sterile zones to crowded and congested.
Built-in Intelligent Video Analytics Pro (IVA Pro) enriches full situational awareness and
triggers relevant alerts.
Other optional licenses, such as IVA Pro Traffic are supported.
3.2 Intended use
The camera is designed to be integrated in professional IP video surveillance solutions as a
surveillance camera. Installation, commissioning and operation of the camera shall be
carried out by trained professionals only.
The use of surveillance cameras is restricted by national laws and regulations. Use the
camera accordingly.

DINION 7100i IR Preparing for installation | en 11
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
4 Preparing for installation
4.1 Unpacking
This equipment should be unpacked and handled with care. If an item appears to have been
damaged in shipment, notify the shipper immediately.
Verify that all parts are included. If any items are missing, notify your Bosch Security
Systems sales or customer service representative.
The original packaging is the safest container in which to transport the unit and can be used
if returning the unit for service.
4.2 Parts included
Quantity Component
1 DINION 7100i IR device
1 Mounting plate
1 TR20 key
1 Mini screwdriver
1 Patch cable (in-box configuration)
1 NCA-U-PIG Grommet IP66
1 NCA-U-PIGL Grommet IP67
1 Quick installation guide
1 Safety and security information

12 en | Preparing for installation DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
3 Installer UX labels
4.3 Preparation
Before installation, prepare and plan the installation process and materials needed.
Pre-requisites
Remove the components from the box. Make sure that all parts are included and are not
damaged.
The necessary material and equipment:
– Appropriate size power drill.
– Screwdriver for TR20 bit, or use a torque wrench TR20 hex key.
– microSD card (optional)
Note: Bosch recommends the use of industrial microSD cards with health monitoring.
– Wireless installation dongle for wireless commissioning (optional).
4.4 In-box configuration
In-box configuration of the camera can be done via a wired connection with the camera still
inside the box.
1. Connect a network cable with PoE, and wait 1 minute for the camera to power up.
2. Connect and configure the camera via the wired network by using the web interface ,
the Project Assistant app or the Configuration Manager.
For more detail about the Project Assistant app, refer to Commissioning, page 29.
i
Notice!
The provided patch cable is only intended for in-box configuration. Dispose of the patch
cable after the in-box configuration is successfully completed.
4.5 Wiring
1
2
4
3
6
7
8
5
1 10-pin I/O connector 2 Safety wire anchor
3 Grommet (IP66 or IP67) 4 Punch down network connector

DINION 7100i IR Preparing for installation | en 13
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
5 RJ45 network connector 6 Cable holder / grounding point for
punch down connector
7 Safety plunger 8 PCBA camera connector
i
Notice!
Make sure to pull and hold the safety plunger when removing the camera.
4.5.1 Network and PoE power - RJ45
Connect the camera to a 10/100 Base-T network:
– Use STP Category 5e (or higher) cable with RJ45 connectors.
– Power can be supplied to the camera via the Ethernet cable compliant with the Power-
over-Ethernet standard and/or via the 24VAC / 12-26VDC auxiliary power.
i
Notice!
Use only PoE approved devices.
Power-over-Ethernet (PoE) can be connected at the same time as a 24VAC / 12-26VDC
power supply. If auxiliary power (24VAC / 12-26VDC) and PoE is applied simultaneously,
the camera draws its power from PoE by default, and seamlessly switches to auxiliary input
if PoE power fails.
When PoE power returns, the camera seamlessly switches back to PoE as its default power
source.
4.5.2 Network and PoE power - punch down connector
Connect the camera to a 10/100 Base-T network:
– Use STP Category 5e (or higher) cable with punch down connector.
Note: If needed, test the cable by putting the network cable tester in the RJ45 port.
– Power can be supplied to the camera via the Ethernet cable compliant with the Power-
over-Ethernet standard and/or via the 24VAC / 12-26VDC auxiliary power.
i
Notice!
Use only PoE approved devices.

14 en | Preparing for installation DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
Power-over-Ethernet (PoE) can be connected at the same time as a 24VAC / 12-26VDC
power supply. If auxiliary power (24VAC / 12-26VDC) and PoE is applied simultaneously,
the camera draws its power from PoE by default, and seamlessly switches to auxiliary input
if PoE power fails.
When PoE power returns, the camera seamlessly switches back to PoE as its default power
source.
6
8
2
4
7
1
3
5
4.5.2.1 8-pin T568A
Pin T568A
1 White/Green
2 Green
3 White/Orange
4 Blue
5 White/Blue
6 Orange
7 White/Brown
8 Brown

DINION 7100i IR Preparing for installation | en 15
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
4.5.3 10-pin I/O connector
8
64
2
3 5 7
10
91
Pin Connection
1 +12V OUT
2 GND
3 ALARM IN 2
4 ALARM IN 1
5 GND
6 ALARM OUT
7 ALARM OUT
8 AUDIO OUT
9 GND
10 AUDIO IN
12VDC power output
The 12VDC output can be enabled/disabled via the web interface, and controlled via the
Alarm Task Editor.
Maximum load of 50mA.
Alarm I/O
1. Input:
Use the alarm input to connect external alarm devices such as door contacts or
sensors:
– TTL logic, +5V nominal, +40VDC maximum, DC coupled with 50kOhm pull-up to
+3.3V.
– Configurable as active low or active high.
Use a zero potential make-contact or switch as the actuator (with a bounce-free contact
system).

16 en | Preparing for installation DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
2. Output:
Use the alarm output for switching external devices such as lamps or sirens. The alarm
output switching capability has a maximum voltage of 30VAC or +40VDC; maximum
0.5A continuous, 10VA.
Audio I/O
Connect audio devices to the audio input and audio output connectors.
The unit has full-duplex mono audio for two-way communication between a speaker or door
intercom system. The audio input signal is transmitted in synchronization with the video
signal.
1. Input:
–Line In: Line level input
–Microphone: Microphone level input with 2.5VDC (4mA) supply voltage for external
microphone
2. Output:
Line output level (not suitable for direct speaker connection); impedance 1.5kOhm
minimum; 1Vrms maximum output voltage.
4.5.4 Grounding
The camera does not require a safety earth connection, but grounding is recommended for
outdoor applications.
Grounding provides improved surge protection (up to 1kV, 1 kA to ground (8/20 µs pulse)).
The grounding wire is not included in the box. Bosch recommends the use of a grounding
wire with a ring terminal.
The ring terminal must not have a thickness greater than 2mm (0.01in.).
i
Notice!
Use proper surge protection on cables that are routed outdoors, or close to large inductive
loads or electrical mains supply cables.

DINION 7100i IR Hardware installation | en 17
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
5 Hardware installation
Installation overview
The installation of the camera follows these steps:
1. Installing the mounting plate, page 17
2. Installing the camera base, page 18
3. Installing the camera, page 20
Installation options
The camera can cover various mounting options when combined with the available
accessories. Refer to the Other optional accessories, page 22 chapter for instructions on the
installation of the available accessories.
5.1 Installing the mounting plate
The mounting plate is used to fix the camera to a flat surface. It offers different holes and
slots for a variety of fixing options.
1A
Mounting holes for 4 inch or 4S
electrical box installation. There are
four mounting holes available on the
mounting plate, but you need only
two for the installation.
2B
Mounting holes for standard wall,
ceiling, or pole mount installation. Use
four screws. If required, use plugs (for
concrete walls/ceilings).
3C
Mounting holes for double gang box
installation. Align the mounting plate
with the four screw holes in the
electrical gang box.
5.1.1 Installation steps
1. Remove the mounting plate from the box.
2. Position the mounting plate correctly on the desired installation surface. This is
ensured by having the TOP indicator facing upwards.

18 en | Hardware installation DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
3. Mark the positions of the screw holes on the surface.
Note: For standard installation, use the mounting holes marked with a B on the
mounting plate. For a different installation, for example for an installation on a
surveillance cabinet, use different mounting holes. For more information, refer to
Surveillance cabinet (fiber optics) installation, page 27.
4. Drill the 4 holes with the appropriate diameter drill to support your 5-6mm (0.2inch)
screws.
5. Attach the mounting plate to the surface with 4 screws. Tighten the screws between 4
and 7Nm (3 and 5.2lbfft).
5.2 Installing the camera base
The camera base is used to fix the camera to the mounting plate for easy three-step
installation. All wired connections are established through the camera base before installing
the camera.
5.2.1 Installation steps
1. Remove the device from its packaging.
2. Separate the camera module from the camera base.
3. If necessary, remove the network cable connected to the camera base and pull it
through the selected installation surface.
4. Connect the network cable through the camera base hole.
5. Place the camera base on top of the mounting plate with the camera base hole facing
down.

DINION 7100i IR Hardware installation | en 19
Bosch Security Systems B.V. Installation manual 2023-08 | V02 | DOC
6. Slightly rotate the camera base in a clockwise motion until it makes a clicking sound.
Note: Make sure that the camera base is secured.
7. Insert a grommet to protect the cable:
– For an RJ45 network cable, insert the IP66 grommet tightly around the cable.
– For a network cable to be connected via punch down connector, insert the cable
through the IP67 grommet.
8. Connect the network cable to the camera base (punch down connector or RJ45
connector).
9. Fit the grommet in the camera base hole until firmly closed.

20 en | Hardware installation DINION 7100i IR
2023-08 | V02 | DOC Installation manual Bosch Security Systems B.V.
5.3 Installing the camera
5.3.1 Installation steps
1. Carefully align the camera with the camera base.
2. Connect the safety cable on the camera to the safety hook located on the right side of
the camera base.
i
Notice!
Make sure the safety hook is correctly locked into place.
3. Align the camera with the camera base using the 3 alignment pins located on the
bottom of the camera.
4. Push the alignment pins into the camera base pinholes.
5. Tighten the 3 screws (3 Nm) to fix the camera to the camera base.
Note: Make sure that the camera is secured before releasing it.
5.3.2 Camera positioning and rotation
The device is manually adjustable to accommodate different angles and rotations. This is
helpful for capturing specific scenes.
