Bosch LP1-BC10E-1 Installation and operation manual

Bidirectional Sound Projector
LP1-BC10E-1
en Installation note

Installation
This document describes the installation procedure of the LP1-BC10E-1 Bidirectional Sound
Projector.
1
Bidirectional Sound Projector Installation | en 3
Bosch Security Systems B.V. Installation note 2016.12 | V1.02 |

5
6
3
2
1
4
7
LP1-BC10E-1
12
Black
3x
4en | Installation Bidirectional Sound Projector
2016.12 | V1.02 | Installation note Bosch Security Systems B.V.

Technical data
Electrical*
Maximum power 15 W
Rated power 10 / 5 / 2.5 / 1.25 W
Sound pressure level
at 10 W / 1 W (1kHz, 1 m)
90 dB / 80 dB (SPL)
Sound pressure level
at 10 W / 1 W (1 kHz, 4 m)
85 dB / 76 dB (SPL)
Opening angle
at 1 kHz / 4 kHz (-6 dB)
165° / 60°
Effective frequency range (-10 dB) 75 Hz to 20 kHz
Rated voltage
Rated impedance
100 V
10 W 1000 Ohm
5 W 2000 Ohm
2.5 W 4000 Ohm
1.25 W 8000 Ohm
Connector 3‑pole screw terminal
* Technical performance data according to IEC 60268‑5
Mechanical
Dimensions (D x L) 185 x 297 mm (7.3 x 11.7 in)
Weight 3 kg (6.6 lb)
Color White (RAL 9010)
Material ABS
Environmental
Operating temperature -25 ºC to +55 ºC
(-13 ºF to +131 ºF)
Storage and transport temperature -40 ºC to +70 ºC
(-40 ºF to +158 ºF)
Relative humidity <95%
Note:
– The specification data is measured in an anechoic chamber, free field
– The reference axis is perpendicular to the center point of the front grille
– The reference plane is perpendicular to the center of the reference axis
– The horizontal plane is perpendicular to the center of the reference plane
2
Bidirectional Sound Projector Technical data | en 5
Bosch Security Systems B.V. Installation note 2016.12 | V1.02 |

40
27
138
120°
109
14
23
11
6
Ø185
300
Ø144
Ø185
34
118
300
303
Ø144
(7.28)
(11.81)
41
(1.61)
(7.28)
(5.67) (5.67)
(1.34)
(11.81)
(1.06)
(1.57)
(5.43)
(4.29)
(0.43)
(0.90)
(0.55)
(0.24)
(11.93)
(4.65)
Dimensions in mm / (inch)
10W
5W
2.5W
0
1.25W
Circuit diagram
6en | Technical data Bidirectional Sound Projector
2016.12 | V1.02 | Installation note Bosch Security Systems B.V.

Frequency response
Polar diagram (measured with pink noise)
CE label
Bidirectional Sound Projector Technical data | en 7
Bosch Security Systems B.V. Installation note 2016.12 | V1.02 |
