  9. BOSS ILLUMINATION NOD User manual

BOSS ILLUMINATION NOD User manual

www.bia.lighting | [email protected]page 1 / 2
PRODUCT MANUAL
COPYRIGHT BIA ©2020 V11.20
WARRANTY STATEMENT This product is covered by a 5 year replacement warranty.
BIA guarantees this product to be free of defects from the date of purchase for the stated period above. If product fails within the warranty period, BIA will x
or replace the product. This excludes any costs associated with the removal or installation of product. This warranty is subject to the terms and conditions stated
on www.bia.lighting. Failure to comply with installation guidelines will automatically void the warranty. Please retain purchase receipt. For more information on
warranty please visit www.bia.lighting/warranty
BIA reserves the right to change specications and other information, modify products and discontinue items without prior notication.
PRODUCT VARIANTS
CCT : 3000K
4000K
5000K
Beam Angle : 15°
25°
40°
Fascia : Recessed
Deep Recessed
Fascia Colour :Black
White
PRODUCT SPECIFICATIONS
Power : 30W
Input Voltage : 240VAC
Operating Temperature : -10 to 40°C
Dimming : Triac
Material : Aluminium
Cutout size : Ø125mm / Ø140mm
NOD
DOWNLIGHT / CEILING LIGHT
Must be installed by
a licensed electrician.
Must be installed
in accordance with
relevant Australian
Standards.
ADDITIONAL INFORMATION
1. BIA recommends using an adaptive phase dimmer with this
product.
2. Module must be installed with designated driver.
3. This product is suitable for indoor and outdoor under cover use.
4. If cleaning maintenance is required, disconnect from mains
supply and allow luminaire to cool. Use a clean microfibre cloth,
slightly dampened with a mild dilution of detergent that is PH
neutral, alcohol free and non-abrasive.
5. Do not use harsh chemicals or solvents. Do not use high
pressure cleaners.
6. Care must be taken during installation and maintenance to
prevent accidental damage to the surface of the luminaire.
These damages may result in corrosion.
PARTS INCLUDED
OPTIONAL COMPATIBLE PARTS sold separately
Recessed
Fascia
Cut Out:
135mm
Deep
Recessed
Fascia
Cut Out:
125mm
Luminaire
with Inbuilt
Driver
IP44
Disclaimer: Please read this product
manual carefully before installing the
product.
Warranty is void if installation
guidelines are disregarded, if the
product has been modied, or if
damage is caused by misuse or
improper installation.
Images, drawings and diagrams are for
illustrative purposes only.
BIA products are manufactured
and certied in accordance with all
mandatory Australian Standards.
Technical data and information subject
to changes. Please visit our website
for latest version.
x1
www.bia.lighting | [email protected]page 2 / 2
PRODUCT MANUAL
COPYRIGHT BIA ©2020 V11.20
INSTALLATION INSTRUCTIONS
A RECESSED
1. Before commencing installation, ensure the main power is
switched off.
2. Measure and cut ceiling hole to size.
3. Twist and lock fascia onto module.
4. Connect plug to 240VAC power socket.
5. Push clips backwards, hold in place and insert luminaire into
prepared ceiling hole. Luminaire clips will spring into place.
6. Turn on main power.
4
5
5
3
DIMENSION DIAGRAM
Fitted with recessed fascia
Cut out size: 135mm
Module Fitted with deep
recessed fascia
Cut out size: 125mm
CLEARANCE TABLE
Scenario 1: Uncovered luminaire
Min. 15mm Min. 15mm
LED Driver
Combustible
Building
Element
Combustible Building Element
Thermal
Insulation
Min. 20mm
145mm 140mm
111mm
95mm
110mm
80mm
