Halco ProLED Spa Lamp Operating instructions
Installation and
Operation Guide
Halco ProLED®
White LED Pool
and Spa Lamp
TECHNICAL SUPPORT
Halco ProLED®Pool Customer Service at:
1.800.374.1927
7
®
IMPORTANT SAFETY INSTRUCTIONS
READ, FOLLOW AND SAVE THESE INSTRUCTIONS
Pool Lamp
Spa Lamp
®
Norcross, Georgia
© 2020 Halco Lighting Technologies All rights reserved. ProLED® is a registered trademark of Halco Lighting Technologies.
All registered and trademarked brands and names are the property of their respective companies. JJ16605. REV. 052020
2
HALCO ProLED WHITE LED REPLACEMENT LED POOL & SPA LAMPS
Model #s: LLWP-12-3 LLWP-120-3 LLWS-12-1 LLWS-120-1
Halco ProLED®White LED Pool and Spa lamps oer superior, bright white illumination
for your pool. This owner’s manual contains important information on installing and
using your new Halco ProLED®White LED Pool or Spa lamp. Please read it carefully
and keep it in a safe place for future reference.
WARNING
THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY EXIT FIXTURES
OR EMERGENCY EXIT LIGHTS.
WARNING
PERMANENT DAMAGE TO THE LOW VOLTAGE 12VAC LAMP WILL OCCUR IF
INSTALLED ON A 120VAC CIRCUIT.
Halco ProLED®WhiteLED Pool and spa lamps are available in 12VAC (low voltage) and
120VAC models as indicated on the product packaging. Each lamp has a screw-in
Edison base.
IMPORTANT NOTE:
Halco ProLED®White LED lamps are recommended for installation
by a qualied pool professional.
RATED LAMP LIFE
SAFETY PRECAUTIONS
INSTALLATION
GASKET COMPATIBILITY
The illumination generated by the Halco ProLED®White LED Replacement LED
In-Ground Pool lamp is based on Light Emitting Diode (LED) technology. The
average expected lamp life is rated up to 50,000 elapsed time hours under normal
operating conditions. [Temperature: 33°F to 95°F (1°C to 35°C), Humidity: 0-95%
•
Do not directly expose or immerse the Halco ProLED
®
White LED Pool or
Spa lamp
in water without containing it in a proper, watertight, NRTL
(nationally recognized
testing laboratory) pool light housing and
niche assembly.
• Keep the pool light housing dry.
•
Handle the Halco ProLED
®
White LED Replacement LED Pool lamp
with care.
• Do not open, service or tamper with any internal component of the Halco
ProLED®White LED Pool lamp. Doing so will void the warranty. Follow each
instruction in this owner’s manual and pay careful attention to all
The installation steps in this owner’s manual are intended as guidelines. For specic
instructions onhow toreplacea pool lamp,please refertothe originalmanufacturer’s
pool light installation manual before proceeding.
Halco ProLED®White LED pool and spa lamps must be installed in a compatible
NRTL pool light housing.
POOL AND SPA LIGHT HOUSING COMPATIBILITY
LLWP-12-3 LLWP-120-3 LLWS-12-1 LLWS-120-1
Halco ProLED® White LED Pool and Spa lamps must be installed in a compatible
NRTL pool light housing. Compatible NRTL light housings include:
Pool Light Housings: Hayward®Astrolite™SP058 Series, Pentair®Amerlite 784
Series, SwimQuip™05086 Series, Halco FIWP Series, J&J Electronics TPL-P Series,
Spa Light Housings: Hayward® Astrolite™II SP059 Series, Pentair® SpaBrite™ Series
Hayward®Astrolite™SP058 & SP059 Housing – Use replacement gasket specied
by manufacturer.
Pentair®Amerlite 784 Series & SpaBrite™Series – Requires installation with
included
Halco ProLED®Gasket.
Jacuzzi®Full Moon™– Use replacement gasket specied by manufacturer.
Sta-Rite®SwimQuip™Series 0508 – RUse replacement gasket specied
A socket voltage range of 12.0 –15.0 will achieve optimal brightness. To verify
the voltage, at the lamp socket, measure the open circuit voltage (no lamp in
ATTENTION 12V HALCO ProLED®WHITE LED OWNERS!
DANGER! RISK OF ELECTRICAL SHOCK OR ELECTROCUTION!
Always disconnect power to the pool light at the circuit breaker panel before
attempting to service the lamp. Failure to do so could result in serious injury or death
due to electrical shock. Refer to the original manufacturer’s pool light installation
manual before proceeding. As with any electrical device, installation and service
should always be performed by a qualied individual. This device is not intended for
use in anything other than in-ground pools. THE PRODUCT WARRANTY IS VOIDED IF THE PROPER GASKET IS NOT
INSTALLED. SEE THE“WARRANTY” SECTION AT THE END OF THIS MANUAL
FOR DETAILS.
WARNING
Your Halco ProLED®White LED lamp is not an ordinary light bulb. It is a valuable
electronic device that is not designed to come in direct contact with water. An
improper installation that results in water leakage into the pool light housing
can permanently damage the Halco ProLED®White LED lamp. Please read these
installation steps and the original manufacturer’s pool light installation manual
READ THIS BEFORE ATTEMPTING INSTALLATION.
1
3 4
Figure 2:
Step 1
STEP 1
Remove light housing from niche.
Make sure power to the pool is tuned o at the circuit breaker. Carefully remove
the existing light house from the niche assembly and place it on the pool deck.
There should be enough power cord to do this easily. If there is not enough power
cord to allow the light housing to reach the pool deck surface, call your local pool
STEP 2
Remove old lamp.
Access the old lamp according to the original manufacturer’s pool light installation
manual. Remove the screws and/or loosen the clamp that holds the face plate and
lens in place. Carefully remove the lens from the pool light housing. Take care
not to damage the surface of the light housing body that makes contact with the
rubber gasket.
STEP 3
I
nspect your light housing for signs of wear.
Inspect the rubber grommet where the power cord enters the light for excessive
deterioration. Inspect the light housing, the tensioning clamp, and face ring for
warping, dents and excessive rust. Do not install Halco ProLED®White LED Lamp
into a pool light housing that appears to be worn out.
STEP 4
Dry the light housing and lens.
Make sure the inside of the light housing and glass lens are completely dry by wiping
them down with a clean rag.
STEP 5
Install Halco ProLED®White LED lamp.
Remove the old lamp and discard. Carefully screw the Halco ProLED®White LED
lamp into the socket.
WARNING
Failure to install a new lens gasket could result in water leakage which can
permanently damage the Halco ProLED®White LED lamp and cause serious
injury or death due to electrical shock.
ALWAYS USE A NEW LENS GASKET WHENEVER REASSEMBLING YOUR POOL LIGHT HOUSING.
STEP 6
Reassemble the light housing.
Proceed by cleaning any gasket residue from the light housing body. A clean
surface is necessary for the new gasket to seat properly and prevent leakage. Install
the new gasket onto the glass lens.
The product warranty is voided if the proper gasket is not installed. See the“Gasket
Compatibility” section for details.
Set the lens and faceplate in the light housing and re-assemble according to the
light housing manufacturer’s specication. Tighten the screws or clamp slightly,
allowing the gasket to seal evenly.
Pool Deck Surface To GFCI, Circuit
Breaker and Power
Source
The niche assembly
WARNING
VERIFY THAT YOUR HALCO ProLED
®
WHITE LED LAMP VOLTAGE RATING 120VAC
OR 12VAC MATCHES YOUR ELECTRICAL SYSTEM’S VOLTAGE REQUIREMENTS
BEFORE PROCEEDING WITH INSTALLATION.
Figure 3:
Step 2-4
STEP 7
Submerge assembled light into the water.
Once the screws or clamp are tight, submerge the assembled light
housing in the water and visually check that air bubbles are not escaping
from the gasket area. Should bubbles appear, immediately remove the
light housing from the water and reset the gasket and lens.Once you are
satised that there are no air leaks, complete the installation by wrapping
the cord around the light housing and re-attaching the light housing to the nice
5 6
OPERATION
Use the pool’s current light switch to turn “ON”and“OFF”your new Halco ProLED White LED lamp.
TERMS AND CONDITIONS
This warranty is available to the original purchaser of the product(s) only. This warranty applies only
when products are properly installed in an in-ground pool; any other use voids the warranty. Products
must be used in lighting equipment designed and approved for the application and in environmental
conditions within the normal specied operating range. This warranty does not apply to any abnormal
use of product(s), use in violation of any applicable standard, code or instructions for use in installations
including those contained in the latest National Electrical Code (NEC), the Standards for Safety of
Underwriters Laboratory, Inc. (UL), Standards for the American National Standards Institute (ANSI).
This warranty will not apply in the event of conditions demonstrating abnormal use or stress, freezing,
operating when not fully submerged, under/over voltage/current condition, excessive switching cycles
or operating hours or outside the recommended operation conditions. This warranty does not apply to
color shifts or dimming caused by emissions and/or LED color shifts and dimming that naturally occurs
over time. Warranty conditions: If the product operates for 15 or more hours per day or continuously
for 24 hours per day, the product warranty period stated shall be reduced to half the stated period.
This warranty does not cover damage occurring during shipment, damage or failure resulting from
alteration, accident, acts of God, theft, abuse, negligent installation, improper service, unauthorized
repairs, freezing or where adequate care has not been taken to prevent damage to the product(s).
Tampering with any internal component of this product(s) will void the warranty.
This warranty gives you specic rights. You may have other rights that vary according to the laws of your
state.
LIMITATION OF LIABILITY
THE FOREGOING SHALL CONSTITUTE THE EXCLUSIVE REMEDY OF THE PURCHASER AND IS IN LIEU
OF ALL OTHER WARRANTIES, WHETHER EXPRESS OR IMPLIED, INCLUDING ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND ALL WARRANTIES ARISING FROM
COURSE OF DEALING OR USAGE OR TRADE. THE LIABILITY OF HALCO UNDER THIS WARRANTY SHALL BE
LIMITED TO THE REPLACEMENT, REPAIR OR PRO-RATED CREDIT OF THE PRODUCT(S) AS STATED HEREIN.
HALCO IS NOT RESPONSIBLE FOR SHIPPING OR TRANSPORTATION COSTS RELATED TO OBTAINING
WARRANTY SERVICE. IN NO EVENT SHALL HALCO BE LIABLE FOR ANY OTHER COSTS OR DAMAGES,
INCLUDING LOST PROFITS OR REVENUES, LABOR CHARGES OR FOR ANY INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES.
Halco reserves the right to change the warranty and/or warranty period without prior notice and
without incurring obligation.
To obtain warranty service, retain the failed Product; retain the installation invoice showing product
purchase price and contact Halco ProLED Pool Customer Service at 800.374.1927
HALCO LIGHTING TECHNOLOGIES, 2YEAR LIMITED WARRANTY
Halco Lighting Technologies (Halco) warrants the above-referenced model numbers of Halco ProLED
White LED Pool/Spa Lamp (the “Product”) to be free from defects in material and workmanship, under
normal use, conditions and service, for a period of two (2) year from the original date of purchase,
subject to the terms specied herein. If during the rst (24) months of the warranty period, the Product
fails to operate due to a defect in material or workmanship, Halco will, at its option, repair or replace the
STEP 8
Check for air bubbles when light is turned ON.
Reconnect power to the pool light by resetting the circuit breaker to the “ON”
position. Go back to the light location and check for air bubbles rising to the surface
from the pool light housing for at least 10 minutes. It is important that the lamp
is turned on during this time. If you do not see air bubbles rising to the surface at
any time during the 10-minute inspection process, the housing is holding its water
tight seal and the installation is complete. You are ready to enjoy your new Halco
ProLED®White LED Pool lamp. If you do see air bubbles rising to the surface at any
time during the inspection process, immediately remove the Halco ProLED®White
LED lamp form the housing, dry it completely and reset the gasket and lens. Make
sure that the Halco ProLED®White LED lamp and light housing are completely dry
before reassembling. If the pool light housing continually leaks water after 2 or more
attempts at installation, replacement of the pool light housing may be necessary.
Please read the Halco ProLED®“White LED lamp Quick Start Guide” for further
installation device.
Note on Figures 1-3: All gures are provided for illustration purposes only. Refer to
