Boss Snowplow Drag Pro 180Z User manual

FormNo.MSC24994RevD
Owner'sManual
PlowBox
DragPro180Z
PartNo.RPL24500—SerialNo.400000000andUp
PartNo.RPL24516—SerialNo.400000000andUp
Registeratwww.bossplow.com.
OriginalInstructions(EN)*MSC24994*

BOSSProductslimitedconsumerwarrantyandBOSS
Productscommercialwarrantypoliciesarelocated
atwww.BOSSPlow.com.
Patentwww.ttcopats.com.
Introduction
Note:Thismanualisusedfortheassembly,
operation,andmaintenanceoftheBOSSexpanding
wingrearmountedplows.Illustrationsmayvary.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.BOSSPlow.comforproductandaccessory
information,helpndingadealer,ortoregisteryour
product.
Wheneveryouneedservice,genuineBOSSparts,or
additionalinformation,contactanAuthorizedBOSS
DealerorBOSST echnicalService(1-800-286-4155)
andhavethemodelandserialnumbersofyour
productready.Figure1andFigure2identifythe
locationsofthemodelandserialnumbersonthe
product.Writethenumbersinthespaceprovided.
g332549
Figure1
1.Serialnumberdecal
g332548
Figure2
1.Serialnumberdecal
Date
Purchased
ModelNo.
SerialNo.
BladeCrate
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure3),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure3
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................3
Preparation.........................................................3
Operation............................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................6
InstallingthePlowWings....................................6
InstallingtheLiftArmandT opLinks....................6
InstallingtheHydraulicCylinders........................7
TorquingtheFasteners.......................................8
InstallingtheHydraulicHoses.............................8
AssemblingtheHitch.........................................11
InstallingtheBladeGuidesandFillingthe
HydraulicReservoir.......................................12
InstallingtheWireHarness...............................12
MountingthePlowController............................14
InstallingtheHitchAssembly............................15
MountingthePlow............................................15
AdjustingtheAngleofAttack............................15
ProductOverview...................................................16
Controls...........................................................16
Specications..................................................17
Attachments/Accessories.................................17
BeforeOperation.................................................17
InstallingtheHitchAssembly............................18
MountingthePlow............................................19
AdjustingtheAngleofAttack............................20
CheckingtheHydraulicFluid............................20
DuringOperation.................................................20
©2021—BOSSProducts
P .O.Box787
IronMountain,MI498012
Contactusatwww.bossplow.com.
PrintedintheUSA
AllRightsReserved

Plowing.............................................................20
ProtectingYourTransmission...........................20
PlowingParkingLots........................................21
OperatingTips..................................................21
AfterOperation....................................................21
RemovingthePlow...........................................21
RemovingtheHitchAssembly..........................22
Maintenance...........................................................23
RecommendedMaintenanceSchedule(s)...........23
ServicingtheHydraulicSystem........................23
Storage...................................................................25
StoringthePlow...............................................25
RemovingthePlowfromStorage......................25
Troubleshooting......................................................26
Schematics.............................................................29
Safety
Preparation
•ReadtheOwner’sManualbeforeoperatingor
servicingtheplow.
•Alwaysfollowthevehiclemanufacturer’s
recommendationsrelatingtosnowplow
installation.Forrecommendedvehiclemodels,
refertotheBOSSproductselectortoolat
www.BOSSPlow.com.
•Ensurethatonlytrainedpersonnelinstalland
performmaintenanceontheequipmentand
hydrauliccomponents.
•Neverdisable,remove,orrelocateanysensorsor
othercomponentsrelatedtotheoperationofthe
airbagsinyourvehicle.
•Keepyourhands,feet,andclothingawayfrom
movingpartsandmountingpoints.
•Ensuretheplowisproperlyattachedtothevehicle
beforemovingit.
•Tocomplywithfederalregulationsandto
assureasafevehicle,donotexceedthe
frontgross-axle-weightrating(FGAWR),rear
gross-axle-weightrating(RGAWR),andthe
gross-vehicle-weightrating(GVWR)atanytime.
•Tocomplywithfederalregulations,ensurethatthe
equipmentdoesnotobstructthetruck’staillight
whentheplowisraised.Ifthetaillightsare
obstructed,auxiliarytaillightsmayberequired.
•Alwayswearappropriatepersonalprotective
equipmentwhenoperatingandservicingthe
machine.Wearsubstantial,slip-resistantfootwear,
andcold-weatherclothing.
•Usea500kg(1/2ton)minimumliftingdeviceto
moveheavyplowcomponents.
•Materialsafetydatasheets(MSDS)areavailable
atwww.BOSSPlow.com.
Operation
•Vehiclesequippedwithairbagsaredesigned
sothattheairbagsactivateinafrontalcollision
equivalenttohittingasolidbarrier(suchasawall)
atapproximately22km/h(14mph)ormore,ora
frontalperpendicularcollisionwithaparkedcar
ortruckofsimilarsizeatapproximately45km/h
(28mph)ormore.Carelessorhigh-speeddriving
whileplowingsnowcandeploytheairbag.
•Donotchangethebladepositionwhentraveling.
•Donotexceed64km/h(40mph)whentransporting
theplow.
•Donotexceed23km/h(14mph)whenplowing.
3

•Alwayslowerthebladewhenthevehicleisnotin
use.
•Neverputanypartofyourbodybetweentheplow
andthevehicle.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Alwayswearyourseatbeltwhileoperatingamotor
vehicle.
•Duetothevarietyofequipmentthatyou
caninstallonthevehicle,donotexceedthe
frontgross-axle-weightrating(FGAWR),rear
gross-axle-weightrating(RGAWR),andthe
gross-vehicle-weightrating(GVWR)atanytime.
Thismayrequireweighingthevehicleandadding
ballastasnecessary.Itmayalsolimitthepayload
capacityofthevehicle.
•Thismachinehasanoperatingsoundlevelbelow
70dBA.
•Whentransportingthemachine,ensurethatitis
properlysecured.Instructionsareavailableat
www.BOSSPlow.com.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decalmsc04603-5
MSC04603-5
1.ReadtheOwner’s
Manualforinformation
onremovingtheplow.
4.ReadtheOwner’s
Manualforinformation
onattachingtheplow.
2.Rotatethereleaselever
clockwiseandpulloutthe
springpinhandletounlock
thecoupler;donotleave
thespringpinpushedin.
5.Rotatethereleaselever
counterclockwiseand
pushinthespringpin
handletolockthecoupler;
donotleavethespringpin
pulledout.
3.Couplerspringpinunlock6.Couplerspringpinlock
decalmsc04604-5
MSC04604-5
1.ReadtheOwner’s
Manualforinformation
onattachingtheplow.
4.ReadtheOwner’s
Manualforinformation
onremovingtheplow.
2.Rotatethereleaselever
clockwiseandpushinthe
springpinhandletolock
thecoupler;donotleave
thespringpinpulledout.
5.Rotatethereleaselever
counterclockwiseandpull
outthespringpinhandle
tounlockthecoupler;do
notleavethespringpin
pushedin.
3.Couplerspringpinlock6.Couplerspringpinunlock
4

decalmsc18131b
MSC18131
1.Crushinghazard—keephandsaway.
decalmsc24730
MSC24730
1.Warning—readthe
Owner’sManual.
6.Crushinghazard—do
notstandbetweenthe
plowandvehicleduring
maintenance.
2.Warning—alloperators
shouldbetrainedbefore
operatingthemachine.
7.Warning—donotexceed
64km/h(40mph)when
transportingtheplow.
3.Warning—attachmentpins
mustbesecuredbefore
plowing.
8.Warning—donotexceed
23km/h(14mph)when
plowing.
4.Warning—attachment
pinsmustbereleasedto
removetheplow.
9.Warning—lowertheplow
whenthevehicleisnotin
use.
5.Warning—donottransport
theplowwiththeblade
wingsextended.
decalmsc24731
MSC24731
1.Attention—readthe
Owner’sManualbefore
attachingtheplow.
6.Retracttheplowwings.
2.Turnontheplowcontroller,
andslowlybackuptoward
theplow.Ensurethe
controllerisnotinFLOAT
mode.
7.Releasetheattachment
pinsandraisethecoupler
assemblyoutofthe
receiver.
3.Connecttheground/power
andplowwireharnesses
andlowerthecoupler
assemblyintothereceiver.
8.Disconnectthe
ground/powerandplow
wireharnesses,andslowly
driveforward.
4.Securetheattachment
pins.
9.Turnofftheplowcontroller.
5.Attention—readthe
Owner’sManualbefore
removingtheplow.
decalmsc24732
MSC24732
1.Attention—readthe
Owner’sManual.
3.Presstheswitchdown
tolowerthecoupler
assembly.
2.Presstheswitchup
toraisethecoupler
assembly.
5

Setup
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Useacranetoholdcomponentsasneeded.
InstallingthePlowWings
1.Interlockthecenterbladeandbothoftheblade
winghinges,ensuringthecuttingedgesare
even.
g332349
Figure4
2.Lockthehingestogetherbyinsertingthehinge
pindownthecenter.
3.Securethehingepintothecenterbladewitha
bolt(1/2x1-1/2inches)andlocknut(1/2inch).
InstallingtheLiftArmand
TopLinks
1.Looselyattachthelowerlinkarmassembliesto
thelowerbracketsonthecenterbladeusing2
bolts(3/4x4inches)and2locknuts(3/4inch).
g332351
Figure5
2.Looselyinstalltheexplateusing6bolts(1/2x
2inches)and6nuts(1/2inch).
g332355
Figure6
6

3.Looselyattachthecouplerassemblytothelink
armassembliesusing2bolts(3/4x4inches)
andlocknuts(3/4inch).
g332356
Figure7
4.Looselyattachthetoplinkstotheupperbrackets
onthecenterbladeusing2bolts(3/4x4inches)
and2locknuts(3/4inch).
g332357
Figure8
5.Looselyattachthetoplinkstotheupperbrackets
onthecouplerassemblyusing2bolts(3/4x4
inches)and2locknuts(3/4inch).
InstallingtheHydraulic
Cylinders
1.Looselyattachtherodendoftheliftcylinderto
thecenterbracketonthecenterbladeusing2
bolts(5/8x4-1/2inches)and2locknuts(5/8
inch).
g332350
Figure9
2.Looselyattachthebodyendsideofthelift
cylindertothecouplerassemblyusing2bolt
(5/8x4-1/2inches)and2locknuts(5/8inch)as
showninFigure9.
3.Looselyattachthebodyendsideofthe2wing
hydrauliccylinderstothecenterbladeusing1
bolt(3/4x4-1/2inches)and1locknut(3/4inch)
asshowninFigure10.
g332359
Figure10
4.Looselyattachtherodendsideofthewing
cylinderstothewingassemblyusing3bolts(3/4
x5-1/2inches),1bolt(3/4x4-1/2inches),6
washers,4locknuts,2camlinks,2armlinks,
and1spacerasshowninFigure11.
7

g332358
Figure11
1.Bolt(3/4x5-1/2inches)5.Bolt(3/4x4-1/2inches)
2.Camlink6.Armlink
3.Washer7.Nut(3/4inch)
4.Spacer
g335520
Figure12
AssembledView
5.Repeattheinstallationforthewinghydraulic
cylindersontheothersideofthecenterblade.
TorquingtheFasteners
Torqueallofthefastenerstothefollowing
specications:
•1/2-inchboltsto76N∙m(56ft-lb)
•5/8-inchboltsto153N∙m(113ft-lb)
•3/4-inchboltsto272N∙m(201ft-lb)
InstallingtheHydraulic
Hoses
1.Securethecouplerpanassemblytothecoupler
assemblyusing4bolts(5/16x3/4inch)and4
nuts(5/16inch).
g332360
Figure13
8

g334868
Figure14
PortOverview
1.Leftrearport;connectthe
25-inchhose
4.Middlefrontport;connect
theredhose
2.Leftfrontport;connectthe
14-inchhose
5.Rightrearport;connect
thebluehose
3.Middlerearport;connect
thewhitehose
6.Rightfrontport;connect
thegrayhose
2.Connectthe14-inchhosefromtheleftfrontport
tothebaseofthecenterhydrauliccylinderas
showninFigure15.
g332761
Figure15
3.Connectthe25inchhosefromtheleftrear
porttothelowerttingonthecenterhydraulic
cylinderasshowninFigure15.
4.Locatethecolortagsonthewinghoses.
5.Routethewhitehosefromthemiddlerearport
totheinnerttingonthelefthydrauliccylinder
asshowninFigure16.
Note:Routethehosesthroughtheaccesshole
onthecenterblade(Figure17).
g332762
Figure16
g332802
Figure17
6.Connecttheredhosefromthemiddlefrontport
totheouterttingonthelefthydrauliccylinder
asshowninFigure16andFigure17.
7.Routethegrayhosefromtherightfrontportto
theouterttingontherighthydrauliccylinder
asshowninFigure18.
Note:Routethehosesthroughtheaccesshole
onthecenterblade(Figure19).
8.Connectthebluehosefromtherightrearportto
theinnerttingontherighthydrauliccylinderas
showninFigure18andFigure19.
9

g337916
Figure18
g332802
Figure19
g337915
Figure20
Overview
10

AssemblingtheHitch
1.Placethehitchdroparmsinthehitchreceiver
assemblies.
Note:Ensurethatthebottomedgesofthehitch
droparmsandthehitchreceiverassembliesare
ush.
g333860
Figure21
2.Placethemidbraceassemblyinbetweenthe
hitchreceiverassemblies.
g333861
Figure22
3.Looselysecurethemidbraceassembly,hitch
droparms,tothehitchreceiversusing8bolts
(5/8x3inches)and8nuts(5/8inch).
g351394
Figure23
4.Placethehitchrailassembliesinsidethehitch
droparms.
g333863
Figure24
5.Placethecrossbraceassemblyinsidethehitch
railassembliesanddroparmassemblies.
g333864
Figure25
6.Looselysecurethecrossbraceassemblyand
hitchrailassembliestothedroparmassemblies
using10bolts(5/8x2-1/2inches),20washers,
and10nuts(5/8inch).
11

g333865
Figure26
InstallingtheBladeGuides
andFillingtheHydraulic
Reservoir
1.Attachthebladeguidestothewingbladeusing
4bolts(5/16x1inch)andlocknuts.
g332361
Figure27
2.Torquetheboltsto19N∙m(14ft-lb).
3.Liftthehoodfromthemanifoldbox,andremove
thellcapfromthehydraulicreservoir(Figure
28).
g332354
Figure28
4.Slowlyllthereservoirwith1.9L(2USqt)of
uid.
5.Runtheplowtollthecylindersandhydraulic
lineswithuid.T opofftheuidasneed;referto
AddingHydraulicFluid(page24).
6.Installthepreviouslyremovedllcapandsecure
themanifoldboxlid.
InstallingtheWireHarness
WARNING
Usingadrillwithoutpropereyeprotection
mayallowdebristoentertheeye,causing
injury.
Whendrilling,alwaysweareyeprotection.
DANGER
Vehicleenginescontainmovingpartsandcan
becomeextremelyhot,capableofcausing
severeburnsandseriousbodilyharm.
Shutofftheengineandallowitsufcienttime
tocooldownbeforeinstallingthiskit.
DANGER
Vehiclebatteriescancausedangerous
electricalshocksthatcouldleadtosevere
burnsordeath.
Disconnectyourbatterybeforeinstallingthis
kit.Removethenegativecablerst,then
removethepositivecable.
Note:Applydielectricgreasetoallelectrical
connections.
1.Ensurethatthevehiclerewallisclearof
obstructions.
12

2.Drilla3cm(1-1/4inch)diameterholethrough
therewallonthedriversideofthevehicle.
Note:Theholeshouldbeinaneasily
accessiblearea.
3.Insertthesplitrubbergrommetintothehole.
4.Pulltheplowcontrollerconnectorandblack/red
wirewithanin-linefuseintothevehiclecab
throughtheholeintherewall(Figure29).
Important:Ensurethatallwiringissecured
inapositionthatavoidshotormovingparts
topreventdamagetothevehicleorplow.
g252336
Figure29
1.Plowcontroller3.Rubbergrommet
2.Controllerconnector4.Black/redwirewithin-line
fuse
5.Mounttheplowcontroller;refertoMountingthe
PlowController(page14).
6.Connecttheblack/redwirewithanin-linefuse
toakeyed12V+ignitionsource.
Note:Connectingthewiretoasourcethatis
notkeyedcancausethebatterytodrain.
7.Mountthepumpsolenoidandpowerdistribution
module(pdm)insidetheenginecompartmentof
thevehicle,ensuringthatitstaysinanupright
positionanddoesnotcontactthebody,hood,or
otherconductivematerialonthevehicle.
8.Connecttheblackandorangewirestothelight
toggleswitch.
9.Determinewhereyouwillmountthelighttoggle
switchandcleantheareathoroughly.
Note:Thelighttoggleswitchcanbefoundin
thehydrauliccomponentbox;refertoServicing
theHydraulicSystem(page23).
Note:Allowtheareatodrycompletelyafter
cleaning.
10.Removetheadhesivebackingandpressthe
toggleswitchtothecleanareaofthedashboard
for30seconds.
11.Plugthecontrollerconnectorintotheplow
controller.
12.Connectthewhite/blackwirefromthewire
harnesstothesmallpostonthepumpsolenoid
(Figure30).
g032928
Figure30
1.White/blackwire4.Solenoid
2.Batterycable5.Brownwirewithsmallring
connector
3.Redpower/groundcable
13.Connectthebrownwirewiththesmallring
connectortotheothersmallpostonthepump
solenoid(Figure30).
Note:Thewiresmaygooneithersmallpost,
butshouldnotshareapost.
14.Connecttheredpower/groundcabletothelarge
postonthepumpsolenoid(Figure30).
15.Connectthebatterycabletotheotherlargepost
onthepumpsolenoid(Figure30).
Note:Thewiresmaygooneitherlargepost,
butshouldnotshareapost.
16.Connecttheblackpower/groundcabletothe
negative(-)batteryterminal(Figure31).
17.Connecttheredwirewiththeringconnector
withthepositive(+)batteryterminal(Figure31).
13

g333870
Figure31
1.Brownwirewithlargering
connector
3.Redwire
2.Blackpower/groundcable4.Batterycable
18.Connectthebrownwirewiththelargering
connectorfromthewireharnesstothenegative
(-)batteryterminal(Figure31).
19.Connectthefreeendofthebatterycabletothe
positive(+)batteryterminal(Figure31).
20.Routetheplowconnectorandpower/ground
connectoralongthevehicleframetotherear
bumper.
21.Mounttheplowconnectorandtheblackandred
power/groundconnectortothelowerpartofthe
rearbumperusingacabletie(Figure32).
g252335
Figure32
1.Power/groundconnector2.Plowconnector
22.Securethewireharnesstothevehicleframe
usingcableties.
Important:Ensurethatallwiringissecured
inapositionthatavoidshotormovingparts
topreventdamagetothevehicleorplow.
MountingthePlow
Controller
Note:Mountthecontrollerinthecabinadryarea
whereitdoesnotinterferewithvehicleoperationor
visibility.
Important:Donotinstalltheswivelmountwhen
temperaturesarebelow16°C(60°F).
DANGER
Thecontrollercouldcauseseriousinjuryif
contactedduringacrash.
Mountthecontrollerinalocationthatvehicle
occupantswillnotcontactduringacrash.
1.Determinethemountinglocationforthe
controller.
2.Cleanthelocationwiththeprovidedalcohol
wipeanddryitwithaclothorpapertowel.
3.Cleanthebackoftheswivelmount(Figure33)
withthealcoholwipeandthendryit.
g032942
Figure33
1.Swivelmount2.Mountingtab
4.Removethebackingfrom1sideoftheadhesive
andapplyittothebackoftheswivelmount.
5.Removetheremainingbackingfromthe
swivel-mountadhesiveandpresstheswivel
mounttothecleanareaofthedashboardfor30
seconds.
Important:Oncethemountisplaced,you
cannotremoveitwithoutdestroyingthe
adhesive.
6.Cleanthebackofthecontrollerwiththealcohol
wipeandthendryit.
7.Removethebackingfrom1sideoftheadhesive
andapplyittothebackofthemountingtab
(Figure33).
8.Removetheremainingbackingfromthe
controlleradhesiveandpressthemountingtab
tothecontrollerfor30seconds.
14

9.Lettheswivelmountrestunusedfor72hours
beforeslidingthecontrollerintothemounting
bracket.
Important:Mountingthecontroller
immediatelymaycausetheadhesivetofail.
10.Continuethewireharnessinstallationfromstep
6ofInstallingtheWireHarness(page12).
InstallingtheHitch
Assembly
RefertoInstallingtheHitchAssembly(page18).
MountingthePlow
RefertoMountingthePlow(page19)tomountthe
plow.
AdjustingtheAngleof
Attack
RefertoAdjustingtheAngleofAttack(page20)to
adjusttheplow.
15

ProductOverview
g333428
Figure34
1.Attachmentpin3.Hydraulicreservoircap
2.Toplink4.Couplerswitch
Controls
Becomefamiliarwithallthecontrolsbeforeyou
operatetheplow.
CouplerSwitch
Thecouplerswitchcontrolsthemovementofthe
couplertowertofacilitateplowattachmentand
removal.Presstheswitchuptoraisethetowerand
downtolowerthetower.
SwitchingtheControlModes
Thiscontrollerisequippedwithtwodifferentsoftware
modesthatwillenableordisablevariousfunctions
dependingonwhichmodelplowisused.The
controllerisfactorysettousewiththeDragPro,and
canbeconguredforusewiththeDragPro180Z
toincludeboth180degreewingrotationandoat
functions.
1.Withthecontrollerturnedoff,pressandholdthe
LOWERbutton.
2.WhilestillpressingtheLOWERbutton,turnthe
controlleron.
Note:Thelight,surroundingtheraiseand
lowerbuttonsonthecontroller,willalternate
ashingredandgreen.
3.ReleasetheLOWERbuttonduringtheappropriate
coloredashforthedesiredsetting.
•Releasethelowerbuttonduringtheredash
toenableDragPromode
•Releasethelowerbuttonduringthegreen
ashtoenabletheDragPro180Zmode.
Note:Thecontrollersavesyoursettinguntilyou
changeitusingtheaboveprocedure.
Controller
•Raisebutton—raisestheplowblade
•Lowerbutton—lowerstheplowblade
•LeftWingOutbutton—movestheleftwingout
•RightWingOutbutton—movestherightwingout
•LeftWingInbutton—movestheleftwingin
•RightWingInbutton—movestherightwingin
g234473
Figure35
1.LeftWingOutbutton4.RightWingInbutton
2.LeftWingInbutton5.RightWingOutbutton
3.Raisebutton6.Lowerbutton
ActivatingFloat
Toactivateoatmode,doubletaporholddownthe
lowerbutton(Figure35)untilthelight,surroundingthe
raiseandlowerbuttononthecontroller,turnsred.
ActivatingDownPressure
Tripletaporholddownthelowerbuttonuntilthe
light,surroundingtheraiseandlowerbuttononthe
controller,turnsorange.
HydraulicFlow-ControlValve
Thehydraulicow-controlvalveadjuststhespeedin
whichtheplowraisesandlowers.RefertoAdjusting
theHydraulicLoweringSpeed(page24).
TopLink
Thetoplinksadjusttheplowangleofattack.Referto
AdjustingtheAngleofAttack(page20).
16

Specications
Wingbladewidth122cm(4ft)
Bladewidth(withwingsretracted)244cm(8ft)
Bladewidth(withwingsextended)4.9m(16ft)
Bladeheight61cm(2ft)
Weight658kg(1450lb)
Attachments/Accessories
AselectionofBOSSapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedBOSS
distributororgotowww.BOSSPlow.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineBOSS
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
Operation
BeforeOperation
•FamiliarizeyourselfwiththeOwner’sManual
beforeoperatingorservicingyoursnowplow.
•Familiarizeyourselfwithlocalsnowplowinglaws
andregulations.
•Carrythefollowingsafetyequipmentanditems
incaseofemergencies:
–reextinguisher
–toolkit
–towstrap
–ashlight
–ares
–rst-aidkit
–fusesforyourvehicle
–jumpercables
–lockdeicer
–icescraper
–washeruid
–shovel
–bagofsaltorsand
Note:Incaseofemergencies,alwayscarryacell
phoneor2-wayradiowhenplowing.
•Wearwarmclotheswhileplowing,including
insulatedboots,insulatedunderwear,awarm
jacket,hat,gloves,andsunglasses.
•Carrythefollowingsnowplowequipmentincase
ofemergencies:
–hydraulicuid
–hydraulichoses
–pumpsolenoid
–cutting-edgebolts
•Ensurethatyourvehiclehasbeenmaintained
accordingtothemanufacturer’srecommendation.
•Consideraddingastrobelightorbackuplightsto
yourvehicleiftheyarenotalreadyequipped.
•Ensurethatyourvehiclecomplieswiththefederal
requirementsforfrontandrearweightdistribution.
Anyballastshouldbeplacedbehindtherearaxle
towardthetailgateandsecuredinplace.
•Ensurethatallsnowplowboltsaretightand
torquedproperly.
•Ensurethatyoursnowplowbladeisnotover-worn
andinneedofreplacing.
•Donotexceed64km/h(40mph)whentransporting
theplow.
17

•Whentransportingtheplow,keeptheplowwings
retractedtoreducethechanceofcatchingacurb,
snowbank,orothervehicles.
•Turnofftheplowcontrollerwhentransportingthe
plowtoandfromajobsite.
•Whentransportingtheplow,donotblockyour
visionwiththeraisedplow.
•Beforeitsnows,inspectthelocationyouwillbe
plowingandlookforobstaclesthatwillbecome
hiddenonceitsnows.Lookforthingssuchas
bumperstops,speedbumps,curbs,shrubs,water
drains,rehydrants,fences,andpipes.T oprevent
damagingtheareabeingplowed,yourplow,or
yourvehicle,markanyobstructionsinawaythat
willbevisibleafteritsnows.
InstallingtheHitch
Assembly
Overviewimage
g351396
Figure36
1.Railassembly4.Sidehitchreceiver
assemblies
2.Droparms5.Hitchreceiverbar
3.Crossbraceassembly6.Midbraceassembly
Note:Useacranetoholdcomponentsasneeded.
1.Installthefthwheelhitchrailsaccordingtothe
instructions(soldseparately).
2.Removethetailgatefromthevehicle.
3.Securethehitchngerstothehitchrail
assembliesusing8bolts(1/2x1-3/4inches)
and8nuts(1/2inch).
g351395
Figure37
1.Standardrailspin2.Hitchngers
g336800
Figure38
1.RailPins3.Hitchreceiverandpin
2.Fifthwheelrails
4.Extendthehitchrailsforvehicleswithlongor
extendedbeds.
5.Installthehitchreceiverbarontothehitch
assembly.
Note:Ensurethattheholesproperlylineup.
Note:Theverticalpositionofthehitchreceiver
barvariesbyvehicle.
18

g337014
Figure39
6.Measurethedistancebetweenthehitch
assemblyandthevehiclebumper.Aminimum
of5.1cm(2inches)isrequired;adjustthehitch
raillengthtoachieveproperclearance.
7.Securethehitchreceiverontothevehicleusing
thehitchpin.
g334867
Figure40
MountingthePlow
Note:Thevehiclemustberunningbeforestarting
thisprocedure.
1.Turnontheplowcontroller.
2.EnsurethatthecontrollerisnotinFLOATmode.
3.Lineupthevehiclewiththesnowplowandslowly
drivebackwarduntilyouarecloseenoughto
connecttheplowwireharnesstothevehicle
wireharness.
4.Removetheelectrical-plugdust-coversand
connecttheplowwireharnesstothevehicle
wireharness.
5.Usethecouplerswitchtoraiseorlowertheplow
tothedesiredheight,thenslowlydrivebackward
untiltheattachmentarmscontacttheslotson
therailmountingkit(Figure41).
6.Lowertheplowontothehitchandipthe
pin-lockingleverstoengagethem(Figure41).
g335629
Figure41
7.Ensurethatthehitchassemblyorplowdoesnot
obstructthetaillightvisibility.
Important:Ifthetaillightsareobstructed
bythehitchassemblyorplow,auxiliary
taillightsmustbeinstalledtocomplywith
federalregulations.
19

AdjustingtheAngleof
Attack
1.Parkthevehicleonalevelsurface,bringthe
plowwingsin,andlowertheplowcompletely.
2.Ensurethattheplowisjustrestingonthe
surface,withoutanydownpressure.
3.EnsurethatthecontrollerisnotinFLOATmode.
4.Loosenthenutonthetoplinks.
g333262
Figure42
1.Toplinks
5.Adjustthewingtipsbyrotatingthetoplinks
untilthereisa1-inchgapbetweentheground
surfaceandthewingbladeedge.
Note:Rotatethetoplinksclockwisetolowerthe
wingtips.Rotatethetoplinkscounterclockwise
toraisethewingtips.
6.Tightenthenutsonthetoplinks.
CheckingtheHydraulic
Fluid
1.Withtheplowmountedtothevehicle,lowerthe
plowtotheground.
2.Cleantheareaaroundthellcap(Figure43).
g332354
Figure43
3.Removethellcapfromthehydraulicreservoir
(Figure43).
4.Ensurethattheuidcoversthepump.Ifitdoes
not,addmorehydraulicuid;refertoServicing
theHydraulicSystem(page23).
5.Installthepreviouslyremovedllcap.
DuringOperation
•Donotexceed22km/h(14mph)whenplowing.
•Alwayswearaseatbeltwhileplowing.
•Neverplowwithyourheadoutthewindow.
•Whenmovinginreverse,turnandlookbehindyou
insteadofrelyingonvehiclemirrors.
•Startdrivingforwardbeforeloweringtheplowfor
apass.
•Asyoucometotheendofapass,liftoffthe
acceleratorwhilestartingtousethebrake.Atthe
sametime,starttoraisethebladetohelpstack
thesnowandtoreducetheloadontheelectrical
systemofyourvehicle.
Plowing
1.Backupthevehicletothelocationyouwillstart
plowingfrom.
2.Extendtheplowwingsifdesired.
3.Lowertheplowbladeandbegintoslowlydrive
forward.
4.Oncetheareahasbeencleared,raisetheplow
andretractthewings,ifextended.
ProtectingYour
Transmission
Transmissiondamageisacommonproblemthat
occurswhileplowing.Thefollowingstepscanhelp
preventtransmissiondamage:
•DonotplowinoverdriveunlesstheOwner’s
Manualforyourvehiclerecommendsit.
•Planyourplowpatternsothatyoudriveforward
asmuchaspossible.
•Cometoacompletestopbeforeshiftingfrom
forwardtoreverse.
•Waituntilthetransmissionengagesbefore
accelerating.
•Accelerateslowly,allowingthetirestogriptheroad
surfaceforbettertraction.Avoidspinningthetires.
•Startdrivingforwardbeforeloweringtheplowfor
apass.
•Wheneverpossible,backintoaclearedarea.
20
