Boss Snowplow MSC23345 User manual

FormNo.MSC23351RevB
Owner'sManual
StraightBladePlow
forGroundsmaster®3200or3300SeriesTractionUnit
PartNo.MSC23345—SerialNo.400000000andUp
PartNo.STB13567B—SerialNo.400000000andUp
Registeratwww.bossplow.com.
OriginalInstructions(EN)*MSC23351*B

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
BOSSProductslimitedconsumerwarrantyandBOSS
Productscommercialwarrantypoliciesarelocatedat
www.bossplow.com.
Patentswww.ttcopats.com.
Introduction
Note:ThisplowattachestotheGroundsmaster3200
or3300.
Thestraight-bladeplowisintendedtobeusedona
Tororide-on,multi-purposemachine.Thebladeis
designedtohydraulicallychangeitsangleasneeded
forsnowremoval.Usingthisproductforpurposes
otherthanitsintendedusecouldprovedangerousto
youandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.bossplow.comforproductsafetyand
operationtrainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineBOSSparts,or
additionalinformation,contactanAuthorizedBOSS
DealerorBOSST echnicalService(1-800-286-4155)
andhavethemodelandserialnumbersofyour
productready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethe
numbersinthespaceprovided.
g297810
Figure1
1.Modelandserialnumberlocation
Date
Purchased
ModelNo.
SerialNo.
BladeCrate
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Safety.......................................................................3
Preparation.........................................................3
Operation............................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................5
PreparingtheMachine........................................5
InstallingtheRequiredKits.................................6
InstallingthePlowontheMachine......................6
InstallingthePushFrame...................................7
InstallingtheHydraulicHoses.............................8
ProductOverview.....................................................9
Controls.............................................................9
Specications....................................................9
Operation................................................................10
OperatingthePlow...........................................10
OperatingTips.................................................10
Maintenance............................................................11
RecommendedMaintenanceSchedule(s)............11
..........................................................................11
Maintenance.........................................................11
Storage....................................................................11
StoringthePlow................................................11
RemovingthePlowfromStorage.......................11
Troubleshooting......................................................12
©2020—BOSSProducts
P .O.Box787
IronMountain,MI498012
Contactusatwww.bossplow.com.
PrintedintheUSA
AllRightsReserved

Safety
Improperuseormaintenancebytheoperatoror
ownercanresultininjury.Toreducethepotential
forinjury,complywiththesesafetyinstructions
andalwayspayattentiontothesafety-alert
symbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failureto
complywiththeinstructionmayresultinpersonal
injuryordeath.
Preparation
•ReadtheOwner’sManualbeforeoperatingor
servicingtheplow.
•Alwaysfollowthevehiclemanufacturer’s
recommendationsrelatingtosysteminstallation.
•Ensurethatonlytrainedpersonnelinstallsand
performsmaintenanceontheequipmentand
hydrauliccomponents.
•Alwayswearappropriatepersonalprotective
equipmentwhenloading,unloading,andservicing
theplow.Wearsubstantial,slip-resistantfootwear
andeyeprotection.
Operation
•Usea500kg(1/2ton)minimumliftingdeviceto
moveheavyplowcomponents.
•Neverputanypartofyourbodybetweentheplow
andthevehicle.
•Whentransportingtheplow,ensurethatitis
properlysecured.Instructionsareavailableat
www.bossplow.com.
•Whentransportingthevehicle,positiontheplow
soasnottoblockyourvisionorheadlights.
•Donotchangethebladepositionwhentraveling.
•Donotexceed16km/h(10mph)while
transporting.
•Alwayslowerthebladewhenthevehicleisnotin
use.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Alwaysfollowthevehiclemanufacturer’s
recommendationsforproperparkingprocedures.
•Overloadingtheplowcouldresultinanaccident
ordamage.Neverexceedtheratedoperating
capacityforthevehicle.
•Ensurethatyoudonotexceedthe
gross-vehicle-weightrating(GAWR)atany
time.
•Turnthevehicleandplowoffbeforelling,
servicing,orcleaningit.
•Donotclimbintoorrideontheplow.
•Keepyourhands,feet,andclothingawayfrom
movingpartsandmountingpoints.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotoperatetheplowwithin8m(25ft)of
bystanders.
3

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decalmsc23037
MSC23037
1.Warning—readtheOwner’sManual.5.Warning—shutofftheengine,removethekey,andreadthe
Owner’sManualbeforeperformingmaintenance.
2.Warning—alloperatorsshouldbetrainedbeforeoperating
themachine.
6.Crushinghazard—donotstandbetweentheplowandvehicle
duringmaintenance.
3.Warning—couplermustbelockedbeforeplowing.7.Warning—donotexceed8km/h(5mph)whentransporting
orplowing.
4.Warning—couplermustbeunlockedtoremovetheplow.8.Warning—lowertheplowwhenthevehicleisnotinuse.
4

Setup
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
PreparingtheMachine
RemovetheDeckfromthe
Machine(ifrequired)
RefertothedeckInstallationInstructions.
RemovethePTOShaftfromthe
Machine
Removethe6boltsfromthePTOshaftandremove
theshaft.
g317217
Figure3
RemovingtheShoulderBoltfrom
theLiftArms
Usetheremovaltooltoremovetheshoulderboltfrom
theliftarms.
g317026
Figure4
RemovingtheManifoldOrice
1.Locatetheliftmanifoldfromunderthemachine
(Figure5).
g299920
Figure5
5

2.Removethehoseconnectionfromthettingin
portC1(Figure6).
g316862
Figure6
1.Fitting2.Hoseconnection
3.Removethettingfromthemanifold.
4.Useapicktoremovetheoricediscfromthe
manifold.
Note:Donotdiscardtheoricedisc.Itis
requiredforinstallingotherGroundsmaster
attachments.
5.InstallthettingontotheC1portonthemanifold.
6.Securethehosetothetting.
7.Torquethettingto47to53N∙m(35to39ft-lb).
8.Torquethehoseconnectionto41to45N∙m(30
to33ft-lb).
AdjustingtheWeightTransferof
theAttachment
RefertothemachineOperator’sManual.
InstallingtheRequiredKits
Installthefollowingkits:
•AuxiliaryHydraulicKit(31966)
•AccessoryControlKit(31994)
InstallingthePlowonthe
Machine
1.Installtheclevispinsthroughtheliftarm
bushings.
g317027
Figure7
2.Installthecotterpins.
6

g317028
Figure8
3.Installthebrackets.
g317029
Figure9
4.Torquetheboltsto48N∙m(35ft-lb).
InstallingthePushFrame
1.Looselysecurethe2mountingbracketstothe
plowusing2bolts(5/8inch)andnuts(Figure
10).
g297803
Figure10
1.Bolt(5/8inch)3.Nut(5/8inch)
2.Mountingbracket
2.Looselysecurethepushframetotheplowand
mountingbracketsusing2bolts(5/8inch)and
nuts(Figure11).
7

g322158
Figure11
1.Bolt(5/8inch)3.Nut(5/8inch)
2.Pushframe
3.Torqueall4boltsto153N∙m(113ft-lb).
Note:Donotovertightenthefasteners;ensure
thatthepushframecanpivotfreely.
4.Hookthe2tripspringsthroughtheholesonthe
pushframe(Figure12).
g316202
Figure12
1.Washer(1/2inch)3.Eyebolt
2.Nylonlocknut(1/2inch)4.Tripspring
5.Hooktheotherendsofthetripspringsto2
eyebolts(Figure12).
6.Insertthethreadedendoftheeyeboltsthrough
theholesontheplowbladeandsecurethem
using2washers(1/2inch)andnylonlocknuts
(Figure12).
7.Tightenthenylonlocknutsuntilthereisagapof
0.8mm(1/32inch)betweenthetripspringcoils.
InstallingtheHydraulic
Hoses
InstallthehosestothemanifoldasshowninFigure
13.
g317030
Figure13
8

ProductOverview
g316207
Figure14
1.Tripsprings3.Attachmentplate
2.Hydraulichosequick
couplers
Controls
Pushtheupperswitch,onthesteeringcolumn,left
orrighttoangletheplow.
g317219
Figure15
1.Angleswitch
Pushthelowerswitch,onthesideconsole,upor
downtoraiseorlowertheplow.
g317814
Figure16
1.Raise/lowertheplow
Specications
BladeWidthBladeHeightWeight
1.52m(5ft)55.8cm(22inches)104kg(229lb)
9

Operation
OperatingthePlow
RefertoyourmachineOperator’sManualfor
instructionsonoperatingattachments.
OperatingTips
•Becomefamiliarwiththeareayouareplowing;
hiddenobstructionssuchascurbsandpipescan
damageyourplowormachine.
•Donotletsnowaccumulate;alwaysplowwiththe
storm.
•Lowertheplowwhennotinusetopreventpossible
injury.
•Alwaysplowatasafespeedincaseyouhithidden
obstructions.
•Whentransportingthemachine,donotblockyour
visionwiththeplow.
•Donotchangetheplowpositionwhileplowing.
•Formoreplowingtips,visitwww.bossplow.com.
10

Maintenance
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst2hours•Tightenallhardware.
Beforeeachuseordaily
•Checkthehydrauliccylinders.
•Checkthehydrauliclinesandhoses.
•Checkallfasteners,pins,retainers,nuts,andbolts.
•Checkthecuttingedgeforwear.
Beforestorage
•Lightlysandandusetouch-uppaintonpaintedareasthatarescratched,chipped,
orrusted.
•Greasethehydrauliccylinderrods.
•Lightlysandandusetouch-uppaintonpaintedareasthatarescratched,chipped,
orrusted.
Maintenance
•Checkthehydrauliclinesandhosesdailyfor
leaks,kinkedlines,loosemountingsupports,wear,
loosettings,weatherdeterioration,andchemical
deterioration.Makeallnecessaryrepairsbefore
operating.
•Checkthehydrauliccylindersdailyforleaks,rust,
orpittingontherods.Makeallnecessaryrepairs
beforeoperating.
•Checkthecuttingedgedailyforwear.Ifthecutting
edgeisworndowneitheriporreplaceit.
•Checkallfasteners,pins,retainers,nuts,andbolts
dailytoensurethattheyaresecure.Torquethem
totheappropriatevalueiftheyareloose.
Storage
StoringthePlow
1.Drivetheplowtoyourstoragelocationand
removetheplow;refertoyourmachine
Operator’sManual.
2.Greaseanyexposedmetalonthehydraulic
cylinderrods.
3.Lightlysandandusetouch-uppaintonpainted
areasthatarescratched,chipped,orrusted.
4.Loosenthetripsprings.
RemovingthePlowfrom
Storage
1.Checkthetorqueofallfasteners;tightenas
necessary.
2.Checkthehydrauliclinesandhosesforcracks
orleaks.
3.Checkthecuttingedgeforwear.
4.Tightenthetripsprings.
5.Lightlysandandusetouch-uppaintonpainted
areasthatarescratched,chipped,orrusted.
6.Attachtheplowtothemachine;refertoyour
machineOperator’sManual.
7.Movetheplowthroughitsrangeofmotionto
checkthehydrauliccylinderrods.
11

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.Thehoseisbad.1.Checkthehoseforleaks.Applythread
lockingcompoundtotheconnectionor
replacethehose.
2.Thecylinderisbad.2.Replacethecylinder.
Oilleaksfromthehydrauliccylinders.
3.Thecylinderrodispitted.3.Polishtherodwithsteelwool.
Thebladetripstooeasily.1.Thetripspringsarelooseordamaged.1.Tightenthespringsorreplacethemif
theyaredamaged.
12
