Boss Snowplow MSC13625 User manual

FormNo.MSC13015RevC
Owner'sManual
PlowBox
5.5ftATV/UTV-V
PartNo.MSC13625—SerialNo.400000000andUp
Registeratwww.bossplow.com.
OriginalInstructions(EN)*MSC13015*

ThisproductcomplieswithallrelevantEuropean
directives;fordetails,pleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
BOSSProductslimitedconsumerwarrantyandBOSS
Productscommercialwarrantypoliciesarelocated
atwww.BOSSPlow.com.
Patentwww.ttcopats.com.
Introduction
Note:Thismanualisusedfortheassemblyofall
BOSSATVandUTVV-bladeplows.Illustrationsmay
vary.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactBOSSdirectlyat
www.BOSSPlow.comforproductandaccessory
information,helpndingadealer,ortoregisteryour
product.
Wheneveryouneedservice,genuineBOSSparts,or
additionalinformation,contactanAuthorizedBOSS
DealerorBOSST echnicalService(1-800-286-4155)
andhavethemodelandserialnumbersofyour
productready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethe
numbersinthespaceprovided.
g319521
Figure1
1.Serialnumberdecal
Date
Purchased
ModelNo.
SerialNo.
BladeCrate
SerialNo.
Contents
Safety.......................................................................3
Preparation.........................................................3
Operation............................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................6
InstallingtheCouplerAssembly..........................6
InstallingtheBladeGuides.................................7
MountingthePlowController..............................7
InstallingtheWireHarness.................................8
MountingtheSnowplow......................................9
ProductOverview...................................................10
Controls...........................................................10
Specications..................................................12
Attachments/Accessories.................................12
Operation................................................................13
MountingtheSnowplow....................................13
RemovingtheSnowplow..................................14
AdjustingtheBlades.........................................15
CheckingtheHydraulicFluidLevel...................16
AddingHydraulicFluid......................................17
OperatingTips.................................................17
Maintenance...........................................................18
RecommendedMaintenanceSchedule(s)...........18
CheckingtheHydraulicLinesand
Hoses............................................................19
Storage...................................................................19
StoringthePlow...............................................19
RemovingthePlowfromStorage......................19
Troubleshooting......................................................20
Schematics.............................................................24
©2020—BOSSProducts
P .O.Box787
IronMountain,MI498012
Contactusatwww.bossplow.com.
PrintedintheUSA
AllRightsReserved

Safety
Improperuseormaintenancebytheoperatororowner
canresultininjury.T oreducethepotentialforinjury,
complywiththesesafetyinstructionsandalwayspay
attentiontothesafety-alertsymbol,whichmeans:
Caution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeinstructionmay
resultinpersonalinjuryordeath.
Preparation
•ReadtheOwner’sManualbeforeoperatingor
servicingtheplow.
•Alwaysfollowthevehiclemanufacturer’s
recommendationsrelatingtosnowplow
installation.Forrecommendedvehiclemodels,
refertotheBOSSproductselectortoolat
www.BOSSPlow.com.
•Followalloperatorsafetyinstructionsandage
restrictionsfoundinyourATV/UTVOwner’s
Manual.
•Ensurethatonlytrainedpersonnelinstalland
performmaintenanceontheequipmentand
hydrauliccomponents.
•Keepyourhands,feet,andclothingawayfrom
movingpartsandmountingpoints.
•Ensuretheplowisproperlyattachedtothevehicle
beforemovingit.
•Tocomplywithfederalregulations,donotexceed
thefrontgross-axle-weightrating(FGAWR),
reargross-axle-weightrating(RGAWR),andthe
gross-vehicle-weightrating(GVWR)atanytime.
•Alwayswearappropriatepersonalprotective
equipmentwhenoperatingandservicingthe
machine.Wearsubstantial,slip-resistantfootwear,
andcold-weatherclothing.
•Usea500kg(1/2ton)minimumliftingdeviceto
moveheavyplowcomponents.
•Materialsafetydatasheets(MSDS)areavailable
atwww.BOSSPlow.com.
Operation
•Whentransportingthevehicle,positiontheplow
soasnottoblockyourvision.
•Donotchangethebladepositionwhentraveling.
•WhenoperatingaUTVmountedplow:
–Donotexceed38km/h(24mph)when
transportingtheplow.
–Donotexceed22km/h(14mph)whenplowing.
•WhenoperatinganATVmountedplow:
–Donotexceed8km/h(5mph)when
transportingtheplow.
–Donotexceed8km/h(5mph)whenplowing.
•Alwayslowerthebladewhenthevehicleisnotin
use.
•Neverputanypartofyourbodybetweentheplow
andthevehicle.
•Donotclimborrideontheplow.
•Donotoperateonsteepinclines.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Alwayswearyourseatbelt(ifequipped)while
operatingamotorvehicle.
•Duetothevarietyofequipmentthatyou
caninstallonthevehicle,donotexceedthe
frontgross-axle-weightrating(FGAWR),rear
gross-axle-weightrating(RGAWR),andthe
gross-vehicle-weightrating(GVWR)atanytime.
Thismayrequireweighingthevehicleandadding
ballastasnecessary.Itmayalsolimitthepayload
capacityofthevehicle.
•Thismachinehasanoperatingsoundlevelbelow
70dBA.
•Whentransportingthemachine,ensurethatitis
properlysecured.Instructionsareavailableat
www.BOSSPlow.com.
•TheATV/UTVV-bladeplowisforpersonaluse
only.Usingtheplowinacommercialsettingvoids
theplowwarranty.
3

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decalmsc23037
MSC23037
1.Warning—readtheOwner’sManual.5.Warning—shutofftheengine,removethekey,andreadthe
Owner’sManualbeforeperformingmaintenance.
2.Warning—alloperatorsshouldbetrainedbeforeoperating
themachine.
6.Crushinghazard—donotstandbetweentheplowandvehicle
duringmaintenance.
3.Warning—couplermustbelockedbeforeplowing.7.Warning—donotexceed8km/h(5mph)whenplowing.
4.Warning—couplermustbeunlockedtoremovetheplow.8.Warning—lowertheplowwhenthevehicleisnotinuse.
4

decalmsc13638
MSC13638
1.Important—readthe
Owner’sManual.
3.Fillthehydraulicuidto
thellline.
2.Hydraulicuid
decalmsc13657-1
MSC13657–1
1.ReadtheOwner’s
Manualforinformation
onattachingtheplow.
3.ReadtheOwner’s
Manualforinformation
onremovingtheplow.
2.Couplerspringpin—lock4.Couplerspring
pin—unlock
decalmsc13658-1
MSC13658–1
1.ReadtheOwner’s
Manualforinformation
onremovingtheplow.
3.ReadtheOwner’s
Manualforinformation
onattachingtheplow.
2.Couplerspring
pin—unlock
4.Couplerspringpin—lock
decalmsc13665
MSC13665
1.Warning—thekickstand
mustberaisedbefore
plowing.
2.Warning—thekickstand
mustbeloweredbefore
removingtheplow.
5

Setup
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
InstallingtheCouplerAssembly
1.Laytheleftandrightbladesfacedownsothatthehingebushingsalignandthebladeedgesareeven.
2.Positionthecouplerassemblyontopofbothbladessothatallthebushingsalignandthecentersection
hingebushingisinsertedbetweenthebladehingebushings.
3.Insertthecenterhingepinthroughthebushings.
4.Securethecenterusing1bolt(3/8-16x1inch)and1locknut(3/8inch).
5.Secureeachendofthecylinderstothecylindermountslocatedonthebladesusing2hex-headbolts
(1/2-13x3-1/2inches)and2locknuts(1/2inch).
g318365
Figure2
6

InstallingtheBladeGuides
Attachthebladeguidestotheplowbladeusing4
bolts(5/16x1inch)and4self-lockingnuts.
g212717
Figure3
1.Self-lockingnut(5/16nut)3.Bolt(5/16x1inch)
2.Bladeguide
MountingthePlow
Controller
DANGER
Thecontrollercouldcauseseriousinjuryif
contactedduringacrash.
Mountthecontrollerinalocationthatvehicle
occupantswillnotcontactduringacrash.
MountingtheATVController
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,shutofftheengine,waitforall
movingpartstostop,andremovethekey.
2.Secure1ofthemountingbracketsalongthe
leftsideofthevehiclecontrolclusterusingthe
longU-boltand2self-lockingnuts(1/4inch)as
showninFigure4.
g318451
Figure4
1.LongU-bolt6.Mountingbracket
2.Thumbscrew7.Switchbox
3.Starwasher8.ShortU-bolt
4.Self-lockingnut9.Controllerconector
5.Rubberendcap
3.Securetheothermountingbracketalongthe
rightsideofthevehiclecontrolclusterusingthe
shortU-boltand2self-lockingnuts(1/4inch)
asshowninFigure4.
4.Securetheswitchboxtothemountingbrackets
using4starwashersand2thumbscrewsand
adjustittothedesiredposition(Figure4).
5.Slidethe4rubberendcapsovertheendsofthe
U-bolts(Figure4).
6.Routetheswitchboxwirealongtheexisting
vehiclewiringdownthehandlebarandsteering
stem,andsecureitunderthecentralpartofthe
fenderusingcableties.
MountingtheUTVController
Note:Mountthecontrollerinthecabinadryarea
whereitdoesnotinterferewithvehicleoperationor
visibility.
Important:Donotinstalltheswivelmountwhen
temperaturesarebelow16°C(60°F).
1.Parkthemachineonalevelsurface,shutoffthe
engine,waitforallmovingpartstostop,engage
theparkingbrake,andremovethekeyfromthe
ignitionswitch.
2.Determinethemountinglocationforthe
controller.
3.Cleanthelocationwiththeprovidedalcohol
wipeanddryitwithaclothorpapertowel.
4.Cleanthebackoftheswivelmount(Figure5)
withthealcoholwipeandthendryit.
7

g032942
Figure5
1.Swivelmount2.Mountingtab
5.Removethebackingfrom1sideoftheadhesive
andapplyittothebackoftheswivelmount.
6.Removetheremainingbackingfromthe
swivel-mountadhesiveandpresstheswivel
mounttothecleanareaofthedashboardfor30
seconds.
Important:Oncethemountisplaced,you
cannotremoveitwithoutdestroyingthe
adhesive.
7.Cleanthebackofthecontrollerwiththealcohol
wipeandthendryit.
8.Removethebackingfrom1sideoftheadhesive
andapplyittothebackofthemountingtab
(Figure5).
9.Removetheremainingbackingfromthe
controlleradhesiveandpressthemountingtab
tothecontrollerfor30seconds.
10.Lettheswivelmountrestunusedfor72hours
beforeslidingthecontrollerintothemounting
bracket.
Important:Mountingthecontroller
immediatelymaycausetheadhesivetofail.
InstallingtheWireHarness
DANGER
Vehicleenginescontainmovingpartsandcan
becomeextremelyhot,capableofcausing
severeburnsandseriousbodilyharm.
Shutofftheengineandallowitsufcienttime
tocooldownbeforeinstallingthiskit.
DANGER
Vehiclebatteriescancausedangerous
electricalshocksthatcouldleadtosevere
burnsordeath.
Disconnectyourbatterybeforeinstallingthis
kit.
Note:Applydielectricgreasetoallelectrical
connections.
1.Parkthemachineonalevelsurface,shutoffthe
engine,waitforallmovingpartstostop,engage
theparkingbrake,andremovethekeyfromthe
ignitionswitch.
2.Mountthevehicle-side,wire-harnessplow
connectortotheleftsideofthefrontbumper
usingthecontrol-harnessmounting-bracketand
2capscrewsandself-lockingnuts(Figure6).
Note:Youwillhavetodrill2holesinthefront
bumpertomountthebracket.
3.Mountthepower/groundconnectortothecontrol
harnessmountingbracket(Figure6).
g038426
Figure6
1.Self-lockingnut6.Controlharnessmounting
bracket
2.Power/Groundconnector
bracket
7.Plowconnector
3.Longbolt8.Shortbolt
4.Power/Grounddustcap9.Controlharnessdustcap
5.Power/Groundconnector
4.Securethedustcapstothewireharnessplugs
andmountingbracket.
5.Routethecablesalongthevehicleframetoward
thebatteryandcontrollerconnectorandsecure
themwithcableties.
6.IfyouareinstallingtheplowonanATV,proceed
tostep9.IfyouareinstallingtheplowonaUTV,
proceedtothenextstep.
7.Pulltheplowcontrollerconnectorintothe
vehiclecab(Figure7).
8

g038119
Figure7
1.Self-tappingbolts3.Plowcontrollerconnector
2.Dashbracket
8.Mounttheplowcontrollerconnectortothedash
bracket,andsecurethebrackettotheleftofthe
steeringwheelusing2self-tappingbolts(Figure
7).
9.Plugtheplowcontrollerintotheplowcontroller
connector.
10.Locateakeyed12V+ignitionsourceon
thevehiclewireharnessandidentifythe
correspondingconnectorinyourlooseparts.
11.Slidetheappropriateconnectorontotheendof
theblack/redwireandcrimptheconnectorto
secureit.
12.Connecttheblack/redwiretoakeyed12V+
ignitionsource(Figure8).
Note:Connectingthewiretoasourcethatis
notkeyedcancausethebatterytodrain.
g038427
Figure8
1.Keyed12V+ignition
source
3.Black/Redwire
2.Connector
13.Connecttheblackpower/groundcabletothe
negative(-)batteryterminal(Figure9).
g038428
Figure9
1.Blackpower/groundcable2.Redpower/groundcable
14.Connecttheredpower/groundcabletothe
positive(+)batteryterminal(Figure9).
15.Secureallwiringinapositionthatavoidshotor
movingpartsusingcableties.
MountingtheSnowplow
RefertoMountingtheSnowplow(page13)tomount
theplow.
9

ProductOverview
Controls
Becomefamiliarwithallthecontrolsbeforeyou
operatetheplow.
Couplers
Thecouplerssecuretheplowtothevehiclepush
beam.Turntheleverstowardthecouplertowerto
turnonthespringpins.Turntheleversawayfromthe
couplertowertoturnoffthespringpins.
g038430
Figure10
1.LOCKposition2.UNLOCKposition
SmartTouch2Controller
TheSmartT ouch2controlleroperatesthemovement
ofthesnowplow.
g033007
Figure11
1.Raisebutton6.LeftWingInbutton
2.Lowerbutton7.Angleleft
3.LeftWingOutbutton8.Scoop
4.RightWingOutbutton9.Angleright
5.RightWingInbutton10.V
•On/Offswitch—turnstheplowcontrolleronandoff.
Agreenlightilluminateswhenthecontrollerison.
Note:Turnoffthecontrollerwhennotinuseto
preventaccidentalactivationoftheplow.
•Raisebutton—raisestheplowblade.Pressingthe
buttonquicklytwiceautomaticallyraisestheblade
whenExpressRaisemodeisenabled.
•Lowerbutton—lowerstheplowbladeandactivates
theFLOAT.
FLOAT—doubletappingthebuttonorholdingit
for2secondsautomaticallylowersthebladeand
activatestheFLOATfeature,allowingtheplow
bladetofollowthecontouroftheground.Ared
lightilluminateswhentheFLOATfeatureisactive.
•LeftWingOutbutton—movestheleftwingout
•RightWingOutbutton—movestherightwingout
•LeftWingInbutton—movestheleftwingin
•RightWingInbutton—movestherightwingin
•Sleepmode—Ifyoudonotusethecontrollerfor
20minutes,itenterssleepmodeandthecontroller
lightsashgreenandred.Turnthecontrolleroff
andonagaintodeactivatethesleepmode.
Toperformdifferenttasks,youcanconguretheplow
wingsasfollows:
•Toangletheentireplowbladeright,pressthe
RightWingInandRightWingOutbuttons
simultaneouslyuntilthebladesarefullyangled.
•Toangletheentireplowbladeleft,presstheLeft
WingInandLeftWingOutbuttonssimultaneously
untilthebladesarefullyangled.
•Tomakethescoopshapewiththeplow,press
theLeftWingOutandRightWingOutbuttons
simultaneouslyuntilthebladesarefullyextended.
•Tomakethe“V”shapewiththeplow,presstheLeft
WingInandRightWingInbuttonssimultaneously
untilthebladesarefullyretracted.
10

SwitchBoxController
g318453
Figure12
1.Leftwingin4.Lowerbutton
2.Leftwingout5.Rightwingin
3.Raisebutton6.Rightwingout
Theswitchboxcontrolleroperatesthemovementsof
thesnowplow.
•Leftwinginbutton—movestheleftwingin
•Leftwingoutbutton—movestheleftwingout
•Raisebutton—raisestheplowblade.Pressingthe
buttonquicklytwiceautomaticallyraisestheblade
whenExpressRaisemodeisenabled.
•Lowerbutton—lowerstheplowbladeandactivates
theFLOAT .
•Rightwinginbutton—movestherightwingin
•Rightwingoutbutton—movestherightwingout
11

Toperformdifferenttasks,youcanconguretheplowwingsasfollows:
PositionButtonsFigure
LeftToplowtotheleft,presstheLEFTWINGINbuttonandpressthe
RIGHTWINGOUTbuttonsimultaneouslyuntilthebladesarefully
angled.
RightToplowtotheright,presstheLEFTWINGOUTbuttonandpress
theRIGHTWINGINbuttonsimultaneouslyuntilthebladesare
fullyangled.
“V”Tomakethe“V”shapewiththeplow,presstheLEFTWINGIN
andRIGHTWINGINbuttonssimultaneouslyuntilthebladesare
fullyretracted.
ScoopTomakethescoopshapewiththeplow,presstheLEFTWING
OUTandRIGHTWINGOUTbuttonssimultaneouslyuntiltheblades
arefullyextended
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Bladewidth168cm(5ft6
inchesPowerVXT)
Bladeheight47cm(18-3/8
inches)
Weight111kg(245lb)
Attachments/Accessories
AselectionofBOSSapprovedattachmentsand
accessoriesisavailableforusewiththemachine
toenhanceandexpanditscapabilities.Contact
yourAuthorizedServiceDealerorauthorizedBOSS
distributororgotowww.BOSSPlow.comforalistofall
approvedattachmentsandaccessories.
Toensureoptimumperformanceandcontinuedsafety
certicationofthemachine,useonlygenuineBOSS
replacementpartsandaccessories.Replacement
partsandaccessoriesmadebyothermanufacturers
couldbedangerous,andsuchusecouldvoidthe
productwarranty.
12

Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
MountingtheSnowplow
Note:Thevehiclemustberunningbeforestarting
thisprocedure.
1.ActivatetheFLOATfeatureonyourplow
controller.
2.Lineupthevehiclewiththesnowplowanddrive
forwarduntilthelowerpincontactsthepin
receiver(Figure13).
g318519
Figure13
1.Couplertower3.Wireharness
2.Lowerpin4.Pinreceiver
3.Settheparkingbrake.
Note:Ifyourvehicledoesnothaveaparking
brake,chockthewheels.
4.TurntheleversonthecouplerstotheATTACH
position(Figure14).
g038430
Figure14
1.LOCKposition2.UNLOCKposition
5.Removetheelectrical-plugdust-coversand
connecttheplowwireharnesstothevehicle
wireharness(Figure13).
6.ActivatetheFLOATfeatureonyourplow
controller.
7.Usingthecouplerhandle,pushthecoupler
towerupwarduntilthecouplerspringpinssnap
in(Figure15).
g318517
Figure15
1.Couplerhandle
8.Ensurethatbothcouplerspringpinshavefully
engagedthecoupler(Figure14).
Note:Movethecouplertoweruntilthespring
pinsengagecompletely.
13

RemovingtheSnowplow
Note:Thevehiclemustberunningbeforestarting
thisprocedure.Settheparkingbrake.Ifyourvehicle
doesnothaveaparkingbrake,chockthewheels.
1.ActivatetheFLOATfeatureontheplowcontroller.
g318517
Figure16
1.Couplerhandle
2.Whileputtingupwardpressureonthecoupler
handle,turntheleversonthecouplerstothe
UNLOCKposition(Figure17).
g038430
Figure17
1.LOCKposition2.UNLOCKposition
3.Usingthecouplerhandle,lowerthecoupler
towercompletely(Figure18).
g318518
Figure18
1.Couplertower3.Lowerpin
2.Wireharness4.Pinreceiver
4.Disconnecttheplowwireharnessfrom
thevehiclewireharnessandsecurethe
electrical-plugdust-covers(Figure18).
5.Releasetheparkingbrake(ifequipped)and
slowlybackthevehicleawayfromthesnowplow.
14

AdjustingtheBlades
Usethisproceduretoadjustthebladestolayat
againsttheground.
g318432
Figure19
Addshimstoaligntheblades.
g318434
Figure20
Removeshimstoaligntheblades.
1.Lowertheblades,stopthemachine,setthe
parkingbrake(ifequipped)orchockthewheels,
andremovethekey.
2.Removethetripspringbolts,washers,and
springplatefromthepushframe.
g318435
Figure21
3.Rotatethecentersectionandbladesalltheway
forwardtoasecureposition.
g318433
Figure22
4.Removethebumperstopnutandwasher.
15

g318431
Figure23
5.Addorremoveblade-adjustmentshims;referto
Figure19andFigure20.
6.Installthebumperstopnutandwasher.
7.Rotatethecentersectionandbladesbacktothe
normaloperatingposition.
8.Alignthetripspringeyeboltsthroughthespring
plateandlooselyinstall2tripspringboltsand
washers.
9.Tightenthenutsuntil13mm(1/2inch)ofthe
tripspringboltsextendbeyondthetopofthe
adjustmentnuts.
g318529
Figure24
1.13mm(1/2inch)
10.Attachtheplow;refertoMountingtheSnowplow
(page13).
11.Lowerthebladeallthewaytotheground;refer
toControls(page10).
12.Checktheedgesofthebladestoensurethey
layatagainsttheground.Ifnot,repeatthis
procedureasneeded.
CheckingtheHydraulic
FluidLevel
1.Withtheplowmountedtothevehicle,lowerthe
plowtothegroundandensurethatitisinthe
straightposition.
2.Removethe4plasticrivetssecuringthecoupler
covertothecoupler,andremovethecover
(Figure25).
g318526
Figure25
3.Ensurethattheuidcomesuptothellline
onthesideofthetank(Figure26).Ifitdoes
not,addmorehydraulicuid;refertoAdding
HydraulicFluid(page17).
g318527
Figure26
16

AddingHydraulicFluid
1.Ensurethattheliftcylinderiscompletely
collapsed.
Important:Donotmanuallypullthetower
down.Thiscancauseanairpockettoform
inthehydraulicsystemanduidtospillout
oftheinternalllercap.
2.Cleantheareaaroundthellcap(Figure27).
g261541
Figure27
1.Fillcap2.Fillline
3.Removethellcapfromthehydraulicreservoir
(Figure27).
4.SlowlyllthereservoirwithBOSS
high-performancehydraulicuidtothell
lineontheoutsideofthetank(Figure27).
Note:Thereservoirholdsapproximately0.48
L(1/2USqt)ofhydraulicuid.
5.Installthepreviouslyremovedllcap.
6.Startthevehicleandoperatetheplowinitsfull
rangeofmovement.
7.Stopthevehicle,checkthehydraulic-uidlevel,
andreplenishtheuidifnecessary;referto
AddingHydraulicFluid(page17).
8.Installthepreviouslyremovedcouplercover.
OperatingTips
•Becomefamiliarwiththeareayouareplowing;
hiddenobstructionssuchascurbsandpipescan
damageyourplowormachine.
•Donotletsnowaccumulate;alwaysplowwiththe
storm.
•Lowertheplowwhennotinusetopreventpossible
injury.
•Alwaysplowatasafespeedincaseyouhithidden
obstructions.
•Whentransportingthemachine,donotblockyour
visionwiththeplow.
•Donotchangetheplowpositionwhileplowing.
•Ensurethatthekickstandisraisedbeforeplowing
topreventdamagetotheplowormachine.
•Formoreplowingtips,visitwww.BOSSPlow.com.
17

Maintenance
WARNING
Failingtoproperlymaintainthemachinecouldresultinprematurefailureofmachinesystems,
causingpossibleharmtoyouorbystanders.
Keepthemachinewellmaintainedandingoodworkingorderasindicatedintheseinstructions.
CAUTION
Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheswitchbeforeyouperformanymaintenance.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Beforeeachuseordaily
•Checkthehydrauliclinesandhoses.
•Checkthetorqueofallfasteners,pins,retainers,nuts,andbolts.
•Checkthecuttingedge.
•Checkthewire-harnessconnector.
•Greasethecouplerspringpins.
Beforestorage
•Greasethelift-cylinderrod.
•Applydielectricgreasetothewire-harnessconnectors.
•Greasethecouplerspringpins.
Monthly•Applydielectricgreasetothewire-harnessconnectors.
18

CheckingtheHydraulic
LinesandHoses
ServiceInterval:Beforeeachuseordaily
WARNING
Hydraulicuidescapingunderpressurecan
penetratetheskinandcauseinjury.
•Ensurethatallhydraulicuidhoses
andlinesareingoodconditionandall
hydraulicconnectionsandttingsaretight
beforeapplyingpressuretothehydraulic
system.
•Keepyourbodyandhandsawayfrom
pin-holeleaksornozzlesthateject
high-pressurehydraulicuid.
•Usecardboardorpapertondhydraulic
leaks.
•Safelyrelieveallpressureinthehydraulic
systembeforeperforminganyworkonthe
hydraulicsystem.
•Getimmediatemedicalhelpifuidis
injectedintoskin.
Checkthehydrauliclinesandhosesdailyfor
leaks,kinkedlines,loosemountingsupports,wear,
loosettings,weatherdeterioration,andchemical
deterioration.Makeallnecessaryrepairsbefore
operating.
Storage
StoringthePlow
1.Greaseanyexposedchromeornitrobaronthe
liftcylinders.
2.Drivethesnowplowtoyourstoragelocation
andremovetheplow;refertoRemovingthe
Snowplow(page14).
3.Pullthecouplertowerforwarduntilthelift
cylinderiscompletelycompressed.
4.Applydielectricgreasetoallofthewireharness
connectorsandinstallthedustcaps.
5.Lightlysandandusetouch-uppaintonpainted
areasthatarescratched,chipped,orrusted.
6.Loosenthetrip-returnsprings.
7.Greasethecouplerspringpins.
RemovingthePlowfrom
Storage
1.Checktheplowforcrackedwelds.
2.Checkthetorqueofallfasteners,pins,retainers,
nuts,andbolts;tightenasnecessary.
3.Checkthehydrauliclinesandhosesforcracks
orleaks.
4.Checkthecuttingedgeforwear.
5.Tightenthetrip-returnsprings.
6.Lightlysandandusetouch-uppaintonpainted
areasthatarescratched,chipped,orrusted.
7.Greasethecouplerspringpins.
8.Applydielectricgreasetoallofthewireharness
connectors.
9.Attachtheplowtothevehicle;refertoMounting
theSnowplow(page9).
10.Movetheplowthroughitsrangeofmotionto
checkthehydrauliccylinderrods.
19

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.Thepower/groundcablesorcontrol
cablesarenotconnected.
1.Connectthecables.
2.Thehydraulicpumpmotorhasfailed
orthepumphasseized
2.Checkforvoltageatthehydraulic
pumpmotorwhilethevehicleignition
switchisonandthecontrolswitch
isintheRaiseposition.Ifvoltageis
present,replacethemotororhydraulic
powerunitassembly.
3.Thecablebetweenthebatteryandthe
solenoidisdisconnectedorbroken.
3.Checkforvoltagetothehydraulic
pumpmotorstartsolenoidbytesting
forvoltagebetweenbothlarge
terminalsandground.Ifvoltageis
notpresentbetween1largeterminal
andthegroundcable,thecable
betweenthebatteryandthesolenoid
isdisconnectedorbroken.Connector
replacethecable.
4.Thesolenoidhasfailed.4.Checkforvoltagebetweentheother
largeterminalofthehydraulicpump
motorstartsolenoidandgroundwhile
jumpingthe12V+batterypowertothe
smallterminalwiththewhite/blackwire.
Ifvoltageisnotpresent,thesolenoid
hasfailedorthebrownwirefromthe
smallterminalofthesolenoidtoground
ismaybedisconnectedorbroken.If
voltageispresent,thewhite/blackwire
fromthesmallterminalofthesolenoid
tocontrolmaybedisconnectedor
broken.Connectorreplacethewiring
Thehydraulicpumpmotordoesnotrun.
5.Powerfromtherelayisdisconnected.5.Checkforvoltagetothecontrol
betweentheblackwireandground
atthewhite9-pincontrolconnector
ofthevehiclesideharnesswiththe
vehicleignitionswitchonandtheplow
electricallyconnectedtothevehicle.
Thehydraulicpumpcontinuestorunwhile
theswitchisinneutral.
1.Thesolenoidhasfailedintheclosed
position.
1.Disconnectthecontrollerwhilethe
ignitionison.Ifthehydraulicpump
continuestorun,thepumpmotor
startsolenoidhasfailedintheclosed
position.Quicklyremovethepower
totheplowbydisconnectingthe
power/groundcablestotheplow.
Replacethesolenoid.Ifthehydraulic
pumpstopsrunning,checkthecontrol
wiringforashortbetweentheblack
andwhite/blackwire,orafailedcontrol
switch.Connect,repair,orreplacethe
wiringorswitch.
20
