BOSTONtec CPUTC Guide

1
Thin Client CPU Assembly
Upright Mounting
bostontec.com | 989.496.9510
Part # - CPUTC
#2 Phillips screwdriver
Tool List
11/32" Nut driver or wrench
1
2
3
Separate L brackets (A) by unscrewing 1/4-20
knobs (C) and removing 1/4-20 x 1/2" carriage
bolts (D) (Fig-1)
Apply rubber bumpers (E) in recommended
positions (Fig-1)
Loosen #8-32 kep nuts (G)
and slide upright mounting
brackets (B) apart (Fig-2)
Loosely insert 1/4-20 x 1/2"
carriage bolts (D) and
1/4-20 knobs (C) to secure
L brackets (A) (Fig-4)
Hook upright mounting
brackets (B) into desired
position on slotted upright
(Fig-3)
Secure thin client CPU by
placing between L brackets (A)
and tightening 1/4-20 knobs (C)
For additional security, use
optional strap (I) (Fig-5)
Clamp brackets (B) tight to
upright and tighten #8-32
kep nuts (G) (Fig-3)
4
5
6
7
D
C
A
A
Fig - 4
A
I
C
Fig - 5
B
A
B
Upright
G
Fig - 3
Item
Components*
A
L brackets
Qty
2
Upright mounting brackets
2
C
1/4-20 Knob
2
D
1/4-20 x 1/2" Carriage bolt
2
E
Rubber bumper
F
#8-32 x 1/2" Phillips pan head
machine screw
B
G
#8-32 Kep nut
4
H
M4-0.7 x 8mm Phillips pan
head machine screw
4
10
4
I
Strap
1
*Extra hardware may be included
B
B
G
Fig - 2
A
A
D
C
E
Fig - 1

2
Thin Client CPU Assembly
VESA Plate Mounting
bostontec.com | 989.496.9510
1
2
3
Separate L brackets (A) by unscrewing 1/4-20
knobs (C) and removing 1/4-20 x 1/2" carriage
bolts (D) (Fig-6)
Remove and discard upright mounting brackets (B)
Do not discard #8-32 kep nuts (G) (Fig-6)
Apply rubber bumpers (E) in recommended
positions (Fig-6)
Mount L bracket (A) with bumpers on bottom lip
to VESA plate using #8-32 x 1/2" Phillips pan
head machine screws (F) and #8-32 kep nuts (G)
(Fig-7)
Hook monitor with thin client CPU brackets and
VESA plate assembly onto monitor arm
Secure thin client CPU by
placing between L brackets
(A) and tightening 1/4-20
knobs (C).
For additional security, use
optional strap (I) (Fig-10)
7
8
4
5
Mount L bracket (A) without bumpers on bottom
lip to monitor using M4-0.7 x 8mm Phillips pan
head machine screws (H) (Fig-8)
6
Loosely insert 1/4-20 x
1/2" carriage bolts (D)
and 1/4-20 knobs (C) to
secure L brackets (A)
(Fig-9)
I
C
Fig - 10
D
C
A
Fig - 9
Discard
A
A
D
C
B
Fig - 6
G
G
G
F
Fig - 7
Bumpers
VESA plate
A
Fig - 8
H
No bumpers
A
