Botex UP-2RF User manual

User's Manual
MENU
DMX
OUTPUT : 10A Max.
HTP
UNIT PACK RF
UP-2RF
10
8
6
4
2
0

Contents
Features 1
General Instructions 2
1. Overview 3
2. Operation Guide 5
Technical Specifications 10
1.1 Front Panel 3
1.2 Rear Panel 4
2.1 DMX Address Mode 5
2.2 Switch Pack Mode 6
2.3 Dimmer Pack Mode 7

Contents
Features 1
General Instructions 2
1. Overview 3
2. Operation Guide 5
Technical Specifications 10
1.1 Front Panel 3
1.2 Rear Panel 4
2.1 DMX Address Mode 5
2.2 Switch Pack Mode 6
2.3 Dimmer Pack Mode 7

Features
Thank you for your purchase. This product
features include:
Every effort has been made to design dependability, reliability and
comfort into each unit. New products are being designed constantly
to meet the needs of both entertainment and the lighting industry.
We welcome your comments about our product and services.
It is both a privilege and a pleasure serving you.
3-pin standard DMX IN/OUT ports providing dimmer information
Serves as a Switch Pack or Dimmer Pack, depending upon
the current operating mode.
Allows DMX Addressing, Dimmer Preset and Dimmer Limit.
Power failure memory.
4 digits Segment Display shows current activity
and function state.
1
General Instructions
Safe and Efficient Use
Product Care
To prevent fire or shock hazard, do not expose this product to
rain or moisture.
In the event of a malfunction(burning smell, etc.), immediately
stop operation, disconnect the power supply plug, and consult
authorized service personnel.
No user serviceable parts inside, always consult authorized
personnel for repairs.
Take care not to damage the power cord.
Do not make any inflammable liquids, water or metal objects
enter the unit.
This product must be earthed.
Do not dismantle or modify the unit.
Place this unit in a stable location.
Do not use the unit in places subject to excessive humidity,
vibration or bumps.
Unplug the power plug from the sockets when not using the
unit for extended period.
Provide occasional ventilation during use.
This product is intended for indoor use only.
Please read through this operating instructions before installing or using
your new product. After you have finished reading the instructions, put
them away in a safe place for future reference.
2

Features
Thank you for your purchase. This product
features include:
Every effort has been made to design dependability, reliability and
comfort into each unit. New products are being designed constantly
to meet the needs of both entertainment and the lighting industry.
We welcome your comments about our product and services.
It is both a privilege and a pleasure serving you.
3-pin standard DMX IN/OUT ports providing dimmer information
Serves as a Switch Pack or Dimmer Pack, depending upon
the current operating mode.
Allows DMX Addressing, Dimmer Preset and Dimmer Limit.
Power failure memory.
4 digits Segment Display shows current activity
and function state.
1
General Instructions
Safe and Efficient Use
Product Care
To prevent fire or shock hazard, do not expose this product to
rain or moisture.
In the event of a malfunction(burning smell, etc.), immediately
stop operation, disconnect the power supply plug, and consult
authorized service personnel.
No user serviceable parts inside, always consult authorized
personnel for repairs.
Take care not to damage the power cord.
Do not make any inflammable liquids, water or metal objects
enter the unit.
This product must be earthed.
Do not dismantle or modify the unit.
Place this unit in a stable location.
Do not use the unit in places subject to excessive humidity,
vibration or bumps.
Unplug the power plug from the sockets when not using the
unit for extended period.
Provide occasional ventilation during use.
This product is intended for indoor use only.
Please read through this operating instructions before installing or using
your new product. After you have finished reading the instructions, put
them away in a safe place for future reference.
2

MENU
DMX
OUTPUT : 10A Max.
HTP
UNIT PACK RF
UP-2RF
10
8
6
4
2
0
1. Overview
1.1 Front Panel
3
1
2
3
1. Output: 10 A max.
2.
3.
4. Up button: Each tap will increase the value once.
Pressing and holding down will increase quickly.
5. Down button:
6. HTP Slider: This slider adjusts channel lighting intensity and complies
with HTP principle(Highest takes precedence).
7. External Slider: This slider has the same function as that of HTP Slider(6).
Segment Display: Shows current activity or function state.
Menu button: Press to enter next level.
Each tap will decrease the value once.
Pressing and holding down will decrease quickly.
1. Overview
1.2 Rear Panel
1. Power Cord: Plug in the appropriate power outlet.
2. Fuse: F10A 250V 5x20mm
3.
4.
DMX In: 3-pin XLR male socket, used to receive DMX data.
DMX Out: 3-pin XLR female socket, used to send DMX data.
5. Phone jack: Connect to external slider only
4
2 3 4
4
5
67
1
5

MENU
DMX
OUTPUT : 10A Max.
HTP
UNIT PACK RF
UP-2RF
10
8
6
4
2
0
1. Overview
1.1 Front Panel
3
1
2
3
1. Output: 10 A max.
2.
3.
4. Up button: Each tap will increase the value once.
Pressing and holding down will increase quickly.
5. Down button:
6. HTP Slider: This slider adjusts channel lighting intensity and complies
with HTP principle(Highest takes precedence).
7. External Slider: This slider has the same function as that of HTP Slider(6).
Segment Display: Shows current activity or function state.
Menu button: Press to enter next level.
Each tap will decrease the value once.
Pressing and holding down will decrease quickly.
1. Overview
1.2 Rear Panel
1. Power Cord: Plug in the appropriate power outlet.
2. Fuse: F10A 250V 5x20mm
3.
4.
DMX In: 3-pin XLR male socket, used to receive DMX data.
DMX Out: 3-pin XLR female socket, used to send DMX data.
5. Phone jack: Connect to external slider only
4
2 3 4
4
5
67
1
5

2. Operation Guide
2.1 DMX Address Mode
1. The Segment Display shows the DMX address
of last change when powered this unit.
If you've selected DMX address 123 for the last
time, then the Segment Display will read 123.
2. Each tap of the Up or Down button will change
the DMX address once. Pressing and holding
down will change the DMX address quickly.
Once the DMX address is selected, it will be
stored into memory automatically.
5
.8:8:8:8
.8:8:8:8
MENU
MENU
General
Plug in the appropriate power outlet, this unit recovers to the function state of
last time automatically by reasons of power failure memory, and the Segment
Display shows the DMX address of last change.
If the frequency of power is not stable, the Segment Display will show "AC-0",
wait until the power is stable.
This unit serves as a dimmer pack or a switch pack, depending on operating
mode you've selected.
NOTE:
During DMX addressing, output is disabled.
2. Operation Guide
2.2 Switch Pack Mode
1. When DMX address is complete, Press Menu
button to enter next level.
2. Tap the Up or Down button causing the Segment
Display shows "s---".
3. Press Menu button to enter Switch Pack mode.
Switch Pack mode consists of Switch On(S-on)
and Switch Off(S-of).
In the Switch On mode, output is turned on and
the fixture lights regardless of DMX signal.
In the Switch Off mode, output is turned off and
the fixture is controlled by DMX signal. When
DMX level is less than 40%, the fixture goes out;
when DMX level exceeds 40%, the fixture lights.
6
.8:8:8:8
.8:8:8:8
.8:8:8:8
MENU
MENU
MENU
s ---
---

2. Operation Guide
2.1 DMX Address Mode
1. The Segment Display shows the DMX address
of last change when powered this unit.
If you've selected DMX address 123 for the last
time, then the Segment Display will read 123.
2. Each tap of the Up or Down button will change
the DMX address once. Pressing and holding
down will change the DMX address quickly.
Once the DMX address is selected, it will be
stored into memory automatically.
5
.8:8:8:8
.8:8:8:8
MENU
MENU
General
Plug in the appropriate power outlet, this unit recovers to the function state of
last time automatically by reasons of power failure memory, and the Segment
Display shows the DMX address of last change.
If the frequency of power is not stable, the Segment Display will show "AC-0",
wait until the power is stable.
This unit serves as a dimmer pack or a switch pack, depending on operating
mode you've selected.
NOTE:
During DMX addressing, output is disabled.
2. Operation Guide
2.2 Switch Pack Mode
1. When DMX address is complete, Press Menu
button to enter next level.
2. Tap the Up or Down button causing the Segment
Display shows "s---".
3. Press Menu button to enter Switch Pack mode.
Switch Pack mode consists of Switch On(S-on)
and Switch Off(S-of).
In the Switch On mode, output is turned on and
the fixture lights regardless of DMX signal.
In the Switch Off mode, output is turned off and
the fixture is controlled by DMX signal. When
DMX level is less than 40%, the fixture goes out;
when DMX level exceeds 40%, the fixture lights.
6
.8:8:8:8
.8:8:8:8
.8:8:8:8
MENU
MENU
MENU
s ---
---

2. Operation Guide
7
2.2 Switch Pack Mode
2.3 Dimmer Pack Mode
4. Tap the Up or Down button to change between
Switch On and Switch Off.
5. Once the Switch Pack is selected, press Menu
button to return to DMX Address mode.
1. Press Menu button to enter next level.
.8:8:8:8
MENU
MENU
MENU
MENU
8
2. Operation Guide
2.3 Dimmer Pack
2. Tap the Up or Down button causing the Segment
Display shows "d---".
3. Press Menu button to enter Dimmer Limit mode.
5. Press Menu button to enter Dimmer Preset mode.
4. Tap the Up or Down button to change the value
within the range of 10-100. Each tap will change
the value once, pressing and holding down will
change the value quickly.
Once the Dimmer Limit is selected, it will be
stored automatically.
.8:8:8:8
MENU
---
MENU
MENU
