bouncepad Utility Line User manual

Sheet Code: BP-IM-076_REV3
Release Date: 22/11/2022
Copyright 2022 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Condential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
Follow instructions-A for
Desk/Wall Mount and
instructions-B for Clamp.
1
Using the Baseplate as
a guide, mark the drill
holes.
A1 Attach the Clamp to the
Baseplate by twisting the
Handle.
Stick the Rubber
Adhesive Pads onto the
Clamp faces.
A3
B1 B2
Drill 4x holes with a 4mm drill bit or a 6mm bit. Then
fasten the Baseplate as detailed using a Screwdriver.
A2
Use the Handle to clamp
the component onto the
surface. B3
In the Boxes
Utility Range - Grip
Assembly Instructions
Tools required for
Desk/Wall Mount:
Attach the upper Clamp
to the Assembly by
twisting the handle.
• Drill with 4mm and 6mm bits
• Screwdriver
• Pencil
* Other components do not require any tools
01 Desk/Wall Mount
Clamp
B
A
* Clamp suitable for surfaces 38mm
Clamp
Desk /Wall Mount complete - Skip
to step 2 to complete assembly.
Desk / Wall Mount
Ø4mm Drillbit
Walls
For surfaces
deeper than
30mm use
the longer
No.8x45mm
screws for added
stability
Twist clockwise
to tighten
Clamp complete - Skip to step
2 to complete assembly.
Desk /Wall Mount
Clamp Dual Arm 400mm
Dual Arm 140mm
03
Tablet Mount
02
Or Or
Solid Surfaces
Ø6mm Drillbit
Attach Baseplate using
Rawlplugs and No.8x25mm
Screws
Attach
Baseplate
using correct
length Screws
Drill 4x holes
Drill 4x
holes
30mm

Clamp the Arm to your
Base as shown. 4
Straigten the Arm using
the Handle at the joint.
23
Attach Retention
Arms to Tablet
Mount as shown. 7
Select the correct
Retention Arm Parts for
your device.
Attach Rubber Pads
to the Retention
Arms.
56Get your Tablet, loosen the
Retention Arms and clamp them
evenly around the Tablet.
10 The device can be adjusted
using the three handles.
Clamp the Tablet
Mount to the Arm.8
Box 2
Clamp
Desk/
Wall Mount Box 3
2 x 90 Degree
Retaining
Arms on the
side
3 x Acute
angled
Retaining
Arms on top/
bottom
9Installation
complete.
Or Or Or
7”-11”
7”-12”
16.5mm max thickness
25.5 mm max thickness
‘Large Tablets’ Bag
‘Standard Tablets’ Bag
