DT Research Tablet Mount Cradle Series Assembly instructions

BASIC OPERATION GUIDE
Tablet Mount Cradle
INTRODUCTION
Thank you for acquiring the latest addion to DT Research’s line of tablet accessories – the
Tablet Mount Cradle. Featuring compact, robust design, this cradle provides secure
placement and charging of the tablets whether mounted in vehicles or on the wall. This
innovave cradle provides connecon ports and promotes ergonomic, efficient access and
management of DT Research tablets..
Package Contents
• One (1) Tablet Wall Mount Cradle
• One (1) VESA Conversion Bracket
• Two (2) Keys
• Four (4) Silver Bushes for wall mounng
• Four (4) Black Nuts for VESA mounng
• Eight (8) M4 Screws
signage dtri com
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2019, DT Research, Inc. All Rights Reserved. BOG 03119 WMC ENG
Releasing the Tablet from the Cradle
1. Unlock the Cradle with the key, then slide the latch on the bo�om of the Cradle to
loosen the Top Clasp.
2. Using two hands, hold the Tablet on both sides, pull the tablet up to remove the Tablet
from the Cradle.

Table Mount Cradles for
DT301, DT311 and DT313 Series
Table Mount Cradle for
DT340T
Dimensions
(H x W x D)
263 x 177 x 73 mm (for DT301 series)
277 x 177 x 73 mm (for DT311 series)
300 x 177 x 73 mm (for DT313 series)
318 x 201 x 69 mm
Weight
2.42lbs/ 1080g (for DT301 series)
2.42lbs/ 1080g (for DT311 series)
2.44lbs/ 1130g (for DT313 series)
3.4lbs/ 1540g
Temperature Operaon: 0°C – 40°C
Storage: -20°C – 60°C
Operaon: 0°C – 40°C
Storage: -20°C – 60°C
Humidity 0% – 90% non-condensing 0% – 90% non-condensing
I/O Ports
Ethernet RJ45 connector for Ethernet x 1 RJ45 connector for Ethernet x 1
USB 2.0 4 2
DC-in 1 1
COM 1 1
HDMI-out 1 1

NOTE: The cradle you receive may look slightly different than the one in this picture
based on the exact model ordered.
NOTE: For proper operation, make sure all necessary connections are in place
before powering on the DT Research Tablet.

Keyhole
Top Clasp
OPERATION

The Tablet Mount Cradle supports VESA standard mounng opons (75 mm x 75 mm or
100 mm x 100 mm) so it can be easily a�ached onto a wall, in a vehicle, and on a VESA arm.
2 3

1. Use the key to unlock, and slide the latch on the bo�om of the Cradle to loosen the Top Clasp.
2. Insert the bo�om part of the Tablet into the cradle first with the connector parts
correctly lined up.
NOTE: If using a 100 x 100 VESA stand or arm, the VESA Conversion Bracket is
needed. Please place the VESA Conversion Bracket on the back side of the Cradle,
and apply the four M4 screws.



USB Ports
HDMI Port COM Port
Ethernet Port
DC-in Jack
Latch
USB Ports
HDMI Port COM Port
Ethernet Port
DC-in Jack
Latch
DT301/ DT311/ DT313
Tablet Mount Cradle Bo�om-view
DT301/ DT311/ DT313 Tablet Mount Cradle
DT340T
Tablet Mount Cradle Bo�om-view
DT340T Tablet Mount Cradle

Keyhole
Top Clasp


5
3. When the bo�om of the Tablet is in place, push
the Tablet against the back and into the Cradle.
4. Push down on the Top Clasp, so the top poron
of the cradle slides down and locks into the
locked-down posion.
5. Lock the Cradle with the key.
