BOW MX2-N User manual

NSA/CSS Approved
Motor & Manual Operated Hard Drive Destroyer
Model MX2-N
MNSA/CSS Approved for Destruction of 1-inch,
.65-inch, 1.65-inch & Laptop Drives
MExtremely Rugged & Affordable
MDestroys HDD and SSD Drives
MDual Operation – Manual and Motor
M18-Month Factory Warranty
MThe GREEN solution to hard drive destruction
MCompact, Light Weight & Portable – 63 lbs.
MFAST (10 seconds or less), SAFE and
RELIABLE
MRear Output Slide Option Available (increases
throughput by 20%)
MUniversal Mounting Kit Available
MTransport and Storage Case Available
MRackmountable Slide-out Shelf Available
BOW Industries introduces the Model MX2-N Motor & Manual Operated Hard Drive Destroyer. The MX2-N, while motor
driven, still includes the manual feature found on all BOW’s hard drive destroyers, allowing the operator full time
operation whether electrical power is available or not. A feature none of the c ompetition can claim.
Designed with emergency situations in mind where electric power may not be available and quick destruction is a must,
the low cost and versatility make this destroyer perfect for both the government and commercial markets where tight
budgets are an important consideration.
FAST MCOMPACT MPOWERFUL MLIGHT WEIGHT MPORTABLE MVERSATILE
Inserting a hard drive and closing the safety door automatically starts the destruction process, allowing destruction every
10 seconds (12 seconds for 50 Hz units). After destruction the destroyer pushes the hard drive out for easy removal. If
power is ever interrupted the operator has the manual feature to continue. No interruption or setup. Simply turn the easy
to turn handle and continue the operation manually.
Government specifications require that a hard drive needs to be destroyed so that no equipment or persons can spin or
operate the drive. Physical destruction is preferred because it gives clear visible evidence that the hard drive is
inoperable. The MX2-N easily meets these requirements and is an inexpensive alternative to expensive power destroyers
and shredders.
The internal workings of the unit press down on the drive bending it approximately 90 degrees. The bend renders the
drive useless by bending the platters, damaging the heads, motor and circuit board. To keep speed at an optimum the
MX2-N resets automatically. No time is wasted moving the blade back into position or turning the handle backwards.
With years of data from our customers these destroyers have proven they are reliable enough to offer an 18 month
standard factory warranty, more than any of our competitors.
This small heavy-duty destroyer is maintenance free and completely self-contained. No messy fluids or external
components to deal with and no adjustments or calibrations necessary.
Today, with the threat of identity theft and the war on terrorism still raging, it is important to keep information secure and
out of the wrong hands. In emergency situations destruction by rapid and reliable means to insure that the information is
irretrievable is top priority. It is for these situations that the MX2-N is perfectly suited.

UNIVERSAL POWER OPTION (BAT)
MOnly Universally Powered Hard Drive
Destroyer Available
MDestroys 100+ drives under battery power
MInternal Battery & Charger
MExternal Battery Pack Available
MBattery, AC Wall Power & Manual Features
MDestroys HDD and SSD Drives
MIdeal for use in Mobile Units, Embassies,
Military Sites, Commercial Applications, etc.
MCompact, Light Weight & Portable – 67 lbs.
When the BAT Universal Power Option is added to the MX2-N, the user has versatility in all environments by allowing the
MX2-N to operate in three power modes: Battery Power, AC Wall Power, or Manually. The batteries hold a charge
sufficient to destroy more than 100 hard drives. Anytime the MX2-N with BAT is plugged into a standard wall outlet the
batteries are being charged, even while destroying hard drives.
It the battery indicators show low power, the unit can be simply plugged into a standard wall outlet for both standard
operation and quick charging. An optional battery pack can also be plugged in to continue under battery power.
In addition the destroyer includes the manual feature found on all BOW’s hard drive destroyers, allowing the operator full
time operation whether battery or electrical power is available or not. Features not found any place else.
Available Options
(for more details please visit our website)
Laptop Option with Holder (LTH) – Allows the destroyer to process 2.5” Form Factor Laptop Drives. Swapping supports
takes approximately 10 seconds. The holder allows the operator to stow the supports when not in use. The magnetic
mounting enables the holder to simply mount to the back of the unit. When the CASE option is ordered a tool box is
supplied instead of the holder.
Universal Power (BAT) – Allow the MX2-N to operate in three modes: Battery Power, AC Wall Power, or Manually. The
BAT option adds the battery feature to the standard unit.
External Battery Pack (EBP) – Adds an additional external battery pack to the MX2-N with BAT option.
Battery Charger (CHG) – Allows the EBP External Battery Pack to be charged separately from the destroyer’s on board
charger. Allows the operator to have a fully charged battery ready to go at all times.
Rear Output Slide (ROS) - The hard drives typically are removed from the front of the unit. Because of the versatility of
BOW’s destroyers this option also allows for the ejection of the hard drives out the back of the unit, giving the user the
ability to discharge the drive into a disposal bin or container, requiring less operator handling and increasing throughput
by up to 20%.
Rackmountable Slide-out Shelf (EIA) – For mounting in standard 19-inch EIA racks. This option allows the user to
conveniently stow the destroyer when not in use and pull it out when needed, saving all too valuable table-top space. This
option includes the MNT kit (see below).
Remote Control Communication (RCC) – RJ45 connector for operating destroyer with other equipment such as
computers and robotics.
Universal Mount Kit (MNT) – This option allows the customer to mount the destroyer to various surfaces, including
carts, truck floors, racks, etc.
Transport & Storage Case (CASE) – A heavy duty Pelican® case with custom insert made specifically for the destroyer.

SPECIFICATIONS
Model Number MX2-N: NSA/CSS Approved Motor & Manual Operated Hard Drive Destroyer
Media Destroyed
Handles all 3.5-inch Form Factor Drives including .65-inch, 1-inch and 1.65-inch high drives.
Handles 2.5-inch Laptop hard drives with LTH option. Handles SSD (Not NSA Approved for SSD)
drives in 3.5 Form Factor and 2.5 Form Factor with the LTH option.
Available Options
LTH – Laptop Supports with Holder Option (2.5-inch Form Factor Drives)
BAT – Universal Power Option – Adds Battery Feature
EBP – External Battery Pack (for units with BAT option)
CHG – Battery Charger (for units with EBP option)
ROS – Rear Output Option
EIA – Rackmountable Slide-out Shelf Option (for 19” EIA rac ks, 19” to 28” deep)(Includes Slides)
RCC – Remote Control Communication
MNT – Universal Screw Down Mounting Kit
CASE – Transport & Storage Case
Manual Exertion Typical Commercial Drives (3.5”) – Typ. 4 lbs. exertion
Hardened (Heavy Shielded) (3.5”) – Typ. 12 lbs. exertion
Power Supply
MX2-N: 100-240 VAC; Standard Voltages: 115 VAC, 60 Hz; 220 VAC, 60 Hz, 230 VAC, 50 Hz
(specify voltage and frequency when ordering)
MX2-N with BAT Option: 100-240 VAC, 50/60 Hz
Operating Time
60 Hz Units - 10 seconds or less
50 Hz Units – 12 seconds
Operated Manually – 8 seconds (operator dependent)
Dimensions
MX2-N: 7 1/4” W, 11 5/8” D, 21” H (18.4 cm x 29.5 cm x 53.3 cm); 11” wide with handle (28 cm)
MX2-N with BAT Option: 7 ¼” W, 11 5/8” D, 21.5” H (18.4 cm x 29.5 cm x 54.6 cm); 11” wide with
handle (28 cm)
Weight MX2-N: 63 lbs. (28.6 kg)
MX2-N with BAT Option: 67 lbs. (30.4 kg)
Shipping Information
Shipping Wt.: 84-86 lbs. (38-39 kg)
Shipping Dimensions: 33” L x 17” W x 17” H (83.8 cm x 43.2 cm x 43.2 cm)
With CASE Option: 128 lbs (58 kg) (depending on options ordered)
Shipping Dimensions: 33.3” x 24.4” x 18.3” (84.6 cm x 62 cm x 49 cm)
Destruction Method O1 Hardened Steel Blade - Bends platter, damages heads, motor and circuit board
Maintenance Occasional vacuuming of debris drawer and internal housing
Operating Temp. Max. 176º F (80º C) Continuous Duty
Warranty 1 year Parts & Labor; 1-year warranty extension available, Lifetime Warranty on Bender
Cage Code 53468
Patent Patent Pending with U.S.P.T.O.
Manufactured & Sold by
BOW Industries, Incorporated
10349 Balls Ford Road
Manassas, Virginia 20109 U.S.A.
Tel: [phone]
E-mail: [e-mail]
Website: www.bowindustries.com
