Bowers & Wilkins PI5 User manual

PI5
Wireless
Headphones

2
ENGLISH
www.bowerswilkins.com
Welcome to Bowers & Wilkins and PI5
Thank you for choosing Bowers & Wilkins. When John Bowers first established
our company, he did so in the belief that imaginative design, innovative
engineering and advanced technology were keys that could unlock the
enjoyment of audio in the home.
The Bowers & Wilkins PI5 are high performance in-ear headphones designed to
deliver the highest quality mobile personal audio experience combined with the
convenience of wireless operation and the serenity of noise-cancellation. This
manual will tell you everything you need to know to get the most from your PI5
headphones.
Your PI5 can play music streamed wirelessly from your mobile phone, tablet or
computer via Bluetooth. PI5 can also be used for wireless telephony.
PI5 Real World Listening features include our latest innovations in Adaptive Noise
Cancellation, Ambient Pass-Through and enhanced Wear Sensing technologies.
Our latest generation noise cancellation feature was designed from the ground
up with intelligent environment sensing capabilities, automatically selecting the
appropriate type of noise cancellation best suited to your surrounding
environment, its only goal is to deliver an uncompromised listening experience.
Ambient Pass-Through enables external sounds, such as conversation or safety
announcements, to be heard clearly without any need to remove the
headphones. The Wear Sensing feature enables PI5 to respond naturally,
pausing and resuming the music simply by lifting either earpiece on or off your
ear. These features can be enabled and further customised via the Bowers &
Wilkins Headphone App available for free on iOS and Android devices.
PI5 incorporates a rechargeable battery pack. When fully charged, depending on
the degree of Bluetooth, Adaptive Noise Cancellation and Ambient Pass-
Through use, the battery pack can provide up to 12 hours of continuous
wireless media streaming with noise cancellation enabled at average playback
volume levels.
ENGLISH
Contents
ENGLISH 2
1. PX7 Carton Contents 3
2. Getting to know your PX7 3
2.1 Switching Headphones On and Off 3
2.2 Headphone Controls 3
2.3 Status Indicator 3
3. Intelligent Features 4
3.1 Adaptive Noise Cancellation 4
3.2 Ambient Pass-Through 4
3.3 Wear Sensors 4
4. Battery Charging and Power Saving 5
4.1 Standby Power Saving 5
5. Wearing Your Headphones 5
6. Bluetooth Connection 6
6.1 Pairing 6
6.2 Multiple Bluetooth Connections 6
6.3 Disconnect from a Device 6
6.4 Setting Up Headphones with the App 6
6.5 Headphone Software Updates 6
7. Auxiliary Connection 7
7.1 Connecting with the 3.5mm Audio Cable7
7.2 Connecting with the USB Cable 7
8. Power Cycle and Reset 7
8.1 Power Cycle 7
8.2 Reset to Default 7
9. Care & Maintenance 7
9.1 Storing Your PX7 7
9.2 Cleaning Your PX7 7
10. Support 7
Specications 8

3
ENGLISH
Function Action
Play or pause Press the Multi-function button
once.
Play to next track Press the Multi-function button
twice in quick succession.
Play previous track Press the Multi-function
button three times in quick
succession.
Phone call functionality:
Function Action
Answer Call Press the Multi-function button
once with incoming call
End Call When incoming call occurs, press
the Multi-function button twice in
quick succession.
Decline an
incoming call
Press the Multi-function button
twice in quick succession with
incoming call.
Diagram 1
Headphone controls
Diagram 2
Headphone controls
1. PI5 Carton Contents
PI5 Headphones with ear tips (M)
Charge Case
USB-C Charging Cable
Ear Tips (S/L)
Literature Pack
2. Getting to know your PI5
2.1 Switching Headphones On and Off
Switching On/OFF
The PI5 does not have a power control and the power
management is automatic. Your PI5 ear buds will charge when
placed into the charging case and will be ready to use when they
are removed from the charing case.
When your ear buds are removed from the charging case they will
enter a power saving mode after 5 minuets of not use. To exit
this low power mode start using the earbuds again, by
connecting your paired device, streaming audio, or placing the
ear buds into your ears.
2.2 Headphone Controls
Each ear bud has a multi-function button located on the flat
round section of the ear bud. The multi-functionally button
controls for:
Media Playback:
Mode Application
On Removes undesired noise from the surrounding
environment.
Off Turns off the noise cancellation feature.
(Please see Diagram 1)
3. Intelligent Features
3.1 Adaptive Noise Cancellation
Noise cancellation is a series of advanced technologies that
aids in removing undesired noise from the surrounding
environment.
PI5 features our latest innovations in adaptive noise
cancellation, this includes noise cancellation and tuning best
suited to your surrounding environment. As your surroundings
change, noise cancellation will auto adapt to complement your
new environment.
The Noise Cancellation can be toggle between On/Off by
long pressing the left earbud for 1 second. (Please see
Diagram 2).

4
ENGLISH
Note: Take care when wearing your headphones; hair or
accessories trapped between your ears and the earpieces,
or wearing glasses that distort the profile of your ears, may
interfere with the performance of the proximity sensors.
4.. Stowing the Ear Buds
When not being worn in the ear, the PI5 ear buds can be stored
and charged inside the charge case. The ear buds will be
magnetically held in the charge case. The ear buds can only be
stowed in one orientation.
Note: Take special care when wearing your earphones, hair
or accessories trapped between your ears and the ear
buds may interfere with proximity sensing.
5. Battery Charging
Your Bowers & Wilkins PI5 ships with the battery partially charged &
may be used immediately. For best practice we recommend to fully
charge the earphones before first use. Please allow up to 3 hours for
full charge.
To charge the PI5 ear buds:
1.
Place the PI5 ear buds int the charge case
2.
Close the charge case lid
To charge the PI5 charge case with cable:
1. Please use the supplied USB charging cable and connect the
USB plug to a USB wall charger or a powered computer USB
socket.
2. Then connect the USB-C end to the charge
case USB-C socket
Diagram 3
Status indicator illuminations
Illumination Operational state
Green (case lid open) Ear bud battery charge > 40%
Yellow (after power on) Ear bud battery charge >20%, <40%
Red (after power on) Ear bud battery charge <20%
Red (blinking) Ear bud factory Reset
Red (Solid) Hardware Reset/ System Crash
Blue blinking Pairing Mode Enabled
Blue (3 sec solid) Pairing successful
5.1 Status Indicator
The status indicator is located on the charge case provide information on the ear
buds when they are located in the case and provide information on the charging
case when the ear buds are removed.
With the Ear buds in the charging case. (Please see Diagram 3).
With the Ear buds in the charging case
With the earbuds removed from the charging case
Illumination Operational state
Green (case lid open) Ear bud battery charge > 40%
Yellow (after power on) Ear bud battery charge >20%, <40%
Red (after power on) Ear bud battery charge <20%
Red (blinking) Factory Reset
Red (Solid) Hardware Reset/ System Crash
Diagram 3
Status indicator illuminations
3.2 Voice Assistance
Voice Assistance can be activated by long pressing the right
earbud for 1 second.
3.3 Ambient Pass-Through
PI5 features ambient pass-through which lets some external
noise from the surrounding environment, such as safety
announcements, conversations or the ability to hear your
surroundings without taking the headphones off.
Ambient pass-through can be enabled/disabled through Bowers
& Wilkins headphone App. The level of ambient pass-through,
High/Low/Off, can be adjusted to suite your needs through the
App.
3.4 Wear Sensors
PI5 incorporates our latest enhanced wear detection sensors in
both earbuds, which will automatically pause the music when you
remove one ear bud from your ear and resuming the audio when
you replace it.
The wear sensors also help battery conservation by entering
standby when removed from the ears. When worn again, PI5
automatically wakes and connects to the last connected
Bluetooth device.
Wear sensor can be turned ON/Off in the Bowers & Wilkins
Headphone App.
Note: During charging, the charge case indicator will blink
green. When fully charged, the indicator will remain solid
green. The charge case can be charge with or without the ear
buds being housed inside the charge case
To charge the PI5 charge case with a wireless charging station:
1.Place the carging case onto a wireless charging station
2.Ensure that the rear of the charging case is on the charging
station (with the case indicator facing up)
Note: During charging, the charge case indicator will blink
green. When fully charged, the indicator will remain solid
green.

5
ENGLISH
(Lid open) Ear bud charge > 40%
(power on) Ear bud charge >20%, <40%
(power on)
(blinking)
Ear bud charge <20%
Ear bud factory Reset
(blinking)
(3 sec solid)
Hardware Reset/System Crash
Pairing Mode Enabled
Pairing successful
(Solid)
Diagram 3
Status indicator illuminations
1.1.
6. Bluetooth Connectivity
6.1 Pairing
Your Bowers & Wilkins PI5 earphones are designed
to stream music wirelessly from Bluetooth audio
devices, such as smartphones, tablets, or
computers. To do so, the earphones & device must
first be paired.
When you receive your PI5 earphones they will be
ready to pair to any Bluetooth audio device.
6.1.1 iOS System/ Android System without
GFP feature Paring
2.
Download the Bowers & Wilkins Headphone
App
3.
Open the charge case lid
4.
The charge case indicator will flash blue
5.
Go to the Bluetooth pairing menu of your
device
6.
Select the “Bowers & Wilkins PI5” from the
device list
7.
The charge case indicator will change to solid
blue to indicate pairing is successful
Open the Bowers & Wilkins Home and add
the headphones into the devices in the app
Note: Your earphones will automatically exit
Bluetooth pairing mode if no device is paired
within 5 minutes. If pairing fails, the indicator
will rapid flash blue, please try pairing again.
1.
1.
To pair to a subsequent device. (Please see Diagram 4)
2.
Open the charge case lid with the ear buds
places inside the charge case
3.
Press and hold the button inside the charge
case for between 1 and 5 seconds
4.
The charge case indicator will flash blue
5.
Go to the Bluetooth pairing menu of your new
device
6.
Select the “Bowers & Wilkins PI5” from the
device list
The charge case indicator will change to solid
blue to indicate pairing is sucessful
Your headphones can remember up to four paired
Bluetooth Devices. Repeat the above steps to pair
more devices.
Note: Your earbuds will automatically exit
Bluetooth pairing mode if no device is paired
within 2 minutes. If pairing fails, the indicator
will rapid flash blue, please try pairing again.
6.2Disconnect from a device
You can quickly disconnect PI5 from a device by putting the earbuds back to the case.
Alternatively, you can manage connection in further detail using the Bowers & Wilkins
Headphones app under Connections.
6.1.2 GFP Pairing (For Android System integrated with GFP Feature)
To add your headphones:
1. Place the Case no further than 10 cm (4 inches) away from Android system cellphone (BT
enabled) and Open the Case Lid.
2. A GFP (Google Fast Pair) notification window would pop up showing “Bowers & Wilkins PI5”
detected” and request to start the pairing process”
3. Press “Notification” button on the window to enable the pairing.
4. Success connection will be shown in GFP window.
5. Once paired
o GFP window would lead user to Google
Play to download/Install B&W
Headphone App.
o L/R Earbud & Case Battery Level can be
seen on the GFP window
6.3Setting Up Headphones with the App
The Bowers & Wilkins Headphones app provides extended setup and adjustments to features
such as Adaptive Noise Cancellation, Ambient Pass-Through, and Wear Sensors. The app
also provides further customisations such as voice prompt, level of ambient pass-through,
connection management and headphone software updates. The app is available as a free
download on iOS and Android devices.
To add your headphones:
1. From your mobile device, download and install the Bowers & Wilkins Headphones app.
2. Launch the app, then read and follow the instructions pertaining app notification and
permissions.
3. After reaching the main screen, simply tap + and following the in-app instructions.

6
ENGLISH
Diagram 4
Bluetooth pairing
1.5s
6.4Headphone Software Update
Bowers & Wilkins will occasionally make available software
updates that refine and optimise the performance of your
headphones or add new features.
The Bowers & Wilkins Headphones app will notify you when a
software update is available. Tap on the notification and the
follow in-app instructions.
a
b
7. Wearing Your Headphones
Wearing your headphones correctly will help ensure you get the
best possible experience, see Diagram 5.
Like many in-ear earphones, the PI5 earpieces are designed to
seal the ear canal in order to perform optimally.
Ear tips come in three sizes (small, medium and large). Finding
the proper size for your ear is critical to obtaining a good seal
and ensure PI5 and the advanced features such as Adaptive
Noise Cancellation performs optimally.
1. Identify the left and right earbud by finding the identification
legends located on the inner side on each earbud.
2. Place the earbuds in your ear so that the tips sit comfortably
at the opening of the ear canal.
3. Ensure the earbuds are sitting comfortably in the ear. Try
another size if they do not fit. Different sized ear tips can be
used to ensure the best possible fit.
Note: To optimize call quality, please ensure the microphone
located underneath the earbud is facing outward, see diagram 5
Diagram 5
Wearing Your Headphones

7
ENGLISH
11. Specifications
True Wireless + techonlogy
Bluetooth 5.0 with AptX technology
ANC
Wireless and USB-C charging
Fast charging support
Technical Features
AptX
AAC
SBC
Bluetooth Codec
Bluetooth Profiles
Frequency Band
RF output power
Bluetooth Codec
Drive Units
Battery Life
A2DP v1.3.1
AVRCP v1.6.1
HFP v1.7.1
HSP v1.2
BLE GATT (Generic Attribute
Profile)
Tx mode: 2402MHz to 2480MHZ, ISM Band, Rx mode: 2402MHz
to 2480MHz, ISM Band
<10.0 dBm
AptX
AAC
SBC
9.2mm Dynamic Drive
Up to 4 hours Bluetooth
Frequency Range
Input Impedance
Distortion (THD)
10Hz to 20kHz
-
<0.3% (1kHz/10mW)
Charging 15 minute charge = 2 hrs Bluetooth
Boxed Accessories 20cm USB-C to USB-C cable
Inputs Bluetooth
Weight 8g for earbuds, 47g for charge case
8. Reset/Troubleshooting
8.1 Factory Reset
You can clear the paired devise history and restore all
setting to their defaults.
To factory reset the earbuds, open the charge case with
the ear buds placed inside. Press and hold the button
on the inside of the charge case for 5 seconds and
release. The indicator on the charge case will turn red to
indicate the reset.
Troubleshooting-
In the case of earbuds are not functioning
properly, please perform a factory reset to resolve
the issue.
8.2 Hardware Reset
To hardware reset the earbuds, open the charge case
with the earbuds placed inside. Press and hold the
button inside the case for 15 seconds until LED
indicator goes off and illuminates in green to indicate
completion of hardware reset process.
Troubleshooting-
For a serious system crash (Solid LED Red Light),
please perform a Hardware Reset to resume the
earbuds.
9. Caring For Your Earphones
Your earphones can be cleaned by a damp cloth and
gently dabbing until clean. Do not use cleaning
detergents, rubbing alcohol, or chemical cleaners/polish,
doing so may damage your earphones.
10. Service / Support
If you need help troubleshooting a specific problem, or
simply have a question you would like answered, please
initially consult the Headphone support section of the
Bowers & Wilkins website:
www.bowerswilkins.com.
