810nm Diode Laser
Model：HL-E810
User Manual

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
Notice
Dear Customer：
Thank you for your choice of the our instrument which designed and
manufactured carefully by our company, in order to better play the
effectiveness of the product, we sincerely recommend：
Before using the instrument, please read this manual and keep it for future
reference.。
Please follow the instructions in the manual for correct installation, use and
operation。
Forbid disassemble this unit and modify any parts。
Except authorized personnel of this company, it is forbidden for others to
open the cover and disassemble the host computer。
Non-professionals are strictly forbidden to carry out repairs or alterations。
In the event of any failure, please contact us。
This product does not belong to medical equipment, do not use
it for disease treatment！

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
Overview
AS50 810nm semiconductor laser hair removal device is a 810nm precision wavelength hair
removal device using the most advanced micro channel laser technology, is currently the
best hair removal device in the beauty market.
Product Advantages
1、Laser: The world's top vertical stack laser
(1) Long service life: the sustainable light 10 million shots;
(2) High peak power: single bar power up to 100W / bar, the market single bar laser power
generally 50W / bar-80W / bar。
2、Efficient and stable cooling system
Laser cooling system with constant temperature cooling, to ensure that the entire system 7 * 24
hours of continuous work. Air-cooled + water-cooled way commonly used on the market can
only work continuously for 2 hours.
3、810nm precision wavelength for hair removal.
(1) The melanin in the hair follicles has the best absorbance to 810nm laser, and the wavelength
of 810nm can be maximize absorbed by melanin in the hair follicles.
(2) To minimize the absorption of hemoglobin or water, reduce the loss of laser energy and
improve the effect of hair removal.
4、Use of contact sapphire cooling system, efficient cooling conduction efficiency, make
comfortable treatment

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
5、Intelligent water temperature control system: effectively protect the life of the laser and the
handle cooling effect.
6、Intelligent water quality monitoring system: effectively protect the water flow of
micro-channel lasers.
7、Unique shape design and color matching, make products more beautiful and stylish.
Functional principle
810nm semiconductor laser hair removal system, using its unique long-pulse laser,
penetrating the epidermis to the hair follicle site, based on the principle of selective light
absorption, the laser energy is preferentially absorbed by the melanin in the hair, and then
lose the regeneration of hair, while the course of treatment
Application
Hair removal: armpit hair, beard, lip hair, hair line, bikini line, limb hair.
Technical Parameters
Laser type: semiconductor laser Laser wavelength：810nm
Working frequency: 1--10Hz adjustable Energy density: 1-88J / C ㎡
Spot size：14×14mm Laser power：300W
input power：1800W Operating language: English
Output mode: pulse output Screen size: 10.4 inch true color touch
Cooling system: Semiconductor cooling + water + air cooling constant temperature

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
cooling
Handle temperature：-10--5℃
Shell material: ABS plastic + metal
Supply voltage: AC220V; AC110V (can be customized)
Instrument composition
1. Screen 2. Emergency switch 3. Power switch 4. Handle 5. Handle bracket
6. Water hole 7. Water filter 8. Main power switch 9. Handle interface
10.Power cord connector 11. Overflow hole 12. Drain hole
Attachment list
1. Handle 1

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
2. Handle bracket 1
3. Water funnel 1
4. Power line 1
1、Instructions 1
Installation operation
（1）Open the box and check
（2）Carefully remove the instrument and accessories from the package and save the
package for future transport or storage. Check attachment by list of accessories.
（3）Check for any mechanical damage
Handle installation
1、Install the handle bracket
Connect the handle to the instrument; then place the handle on the holder。
Note: When the handle is connected, make sure that the blue buttons on the top and
bottom of the connector are completely ejected, otherwise the water flow will not be
easy to flow！
2、Instrument water
（1）Remove the fill funnel and connect to the fill hole on the back of the instrument；
（2）Injecting pure water or distilled water; until the overflow outlet water so far。
Note: Be sure to use pure water or distilled water, tap water or other water shall not be
used。
3、Power on operation

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
（1）Connect the power line and turn on the main switch of the instrument；
（2）Turn on the power switch, emergency switch。
4、Interface introduction
1、Start interface；as shown below：
2、After self-test, click "ENTER" key to enter the gender selection interface, as shown
below：

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
3、Select the appropriate gender interface, click the "ENTER" button to enter the main
operation interface：
1. Skin color choice 2. Water flow monitoring 3. Water quality monitoring 4.
Water temperature monitoring 5. Handle temperature monitoring 6. The number
of shots. 7. Back button 8. Site selection 9. Energy regulation
10. Frequency adjustment 11. Standby 12. Ready 13. Data saved 14. Data reset
Operation Steps
1、Shaved hair
Before the operation, a shaving process, leaving 1-2mm hair on skin, to facilitate the
absorption of light。
2、Apply cold gel
Apply a little cold gel with thickness of the coin on the operating part , should not be too

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
thick, otherwise will reduce the effect。
3、Adjust the treatment parameters
According to the customer's complexion, the degree of rough, and hair location, select the
appropriate treatment parameters, in particular, should be adjusted according to customer
experience。
4、The operation process
（1）Fit the skin, to avoid light leakage, slowly slide the handle probe to operate
（2）Energy adjustment: from the system default energy to start operating, if the operator
feels too much heat, then reduce the energy; if there is a slight sense of thermal expansion,
the melanin is absorbed by the wavelength of 810nm, laser light energy into heat, hair
follicle destruction of melanin, there is the best results.
（3）Operation time：Legs :10-15 minutes, Arms: 5-10 minutes, Armpit: 5 minutes , lip
hair: 3 minutes (for reference only, the specific time should be based on changes in hair,
hair removal site size) , Observed Hair follicles red, raised, slightly curly hair, hair follicles
swell, is the clinical endpoint.
5、Skin cooling
After operation, cooling for 3-5 minutes on treatment location, or natural cooling soothing.
6、Clean the skin
Remove gel, apply moisturizing product or body lotion

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
Operational precautions
1、Forbid look into the glare from the front of the laser handle。
2、Slow sliding handle operation, don’t stay in one place continuous shot light, so as not
to cause customer discomfort。
3、Treatment interval: interval 20-28 days
Attention after treatment
1、7 days after hair removal to avoid overheating hot water bath, suitable for warm water
can be.
2、Avoid eating spicy, alcohol and tobacco, stimulating food
3、To avoid exposure, good sunscreen, wipe sunscreen, Cream
4、After hair removal to avoid pulling hair by hand. Good treatment hair removal
Equipment maintenance precautions
1、it is recommended to replace pure water or distilled water every 1 month;
2、The instrument should be placed at a temperature of 5 - 40 ℃, humidity not exceeding
80%, clean and ventilated room, avoid direct sunlight。
3、During machine working, to ensure that the instrument vents are not blocked, the
instrument at least 5cm around the gap。
4、Do not move the instrument over a long distance. Before shipping, drain all the water in
the instrument, block all the water holes, and use the cushioning packaging provided by
the manufacturer before shipping.

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
Taboo People
1、Heart disease, high blood pressure patients
2、Pregnant women, epilepsy patients
3、Hypertension, diabetes
4、Light allergy customers
5、Long-term work in the glare of the crowd, the recent sunburn skin
6、Short-term skinnable customers
7、Customers who are taking antioxidants or hormonal drugs
Quality assurance
The instrument from the date of purchase (by bill) host warranty for 12 months, the handle
warranty for 3 months, the warranty period of the fault (non-human phenomena) free
repair. Exceed the warranty period can also be responsible for maintenance, in accordance
with the provisions of the company to collect spare parts and consumables costs (shipping
costs borne by the customer). If you need to add or purchase please contact with the
company.
The following user personal reasons for the failure, does not provide free maintenance and
warranty services：
①Disassembly, modification of this product caused by failure；
②Use of non-distribution of the company caused by the failure of hand tools；
③Use careless, beat, drop caused by the failure；
④Failure due to lack of reasonable maintenance；

Shenzhen Bowei tech Co.ltd.
ADD:RM902;ShangMei Times;NO.57;LongGuan RD;Long Hua Dist Shenzhen, China;518000
Tel:[phone] 13148703639
Email:[e-mail] http://www.bowei-ch.com/
⑤Not in accordance with the correct use of instructions caused by the failure。
Warranty Card
Product Name
Customer Name
Model
Tel
Purchase Date
Address
Repair date
Issue Cause
Maintenance Content
Repair Man
