BPC Integra Plus EC MVHR Guide
Copyright © 2009 Vent-Axia Limited. All rights reserved.
Integra
Integra Plus EC MVHR
Kinetic
Kinetic Plus E MVHR
Installation & Commissioning
Installation & Commissioning
Stock Ref. N°
437666EC
Integra Plus EC
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.
Warnings & Safety Information
Integra Plus EC MVHR Installation & Commissioning 2
IMPORTANT SAFETY INFORMATION
PLEASE READ THESE
INSTRUCTIONS CAREFULLY
BEFORE COMMENCING
INSTALLATION.
1. Do not install this product in areas where
the following may be present or occur:
• Excessive oil or a grease laden
atmosphere.
• Corrosive or flammable gases, liquids or
vapours.
• Subject to direct water spray from hoses.
• Ambient temperatures higher than 40°C
and lower than -20°C.
• Possible obstructions that may hinder
access to or removal of the unit.
2. All wiring must be in accordance with the
current IEE wiring regulations BS7671, or
appropriate standards of your country.
Installation should be inspected and tested
by a suitably qualified person after
completion.
3. Ensure the mains supply (voltage,
frequency and phase) complies with the
rating label.
4. The power feed to the unit should be
provided with a local double pole fused spur
fitted with a 3A fuse having a contact
separation of at least 3mm.
Depending on the installation, if LS1 and/or
LS2 are used they should also have
isolating switch of similar specification to the
main power feed installed.
5. This unit must be earthed.
6. Precautions must be taken to avoid the
back-flow of gases into the building from the
open flue of gas or other fuel-burning
appliances.
7. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
8. Young children should be supervised to
ensure that they do not play with the
appliance.
INSTALLATION GUIDANCE
1. The installer is responsible for the installation and
electrical connection of the system on site. It is the
responsibility of the installer to ensure that the equipment is
safely and securely installed and left only when
mechanically and electrically safe.
2. All regulations and requirements must be strictly
followed to prevent hazards to life and property, both
during and after installation, and during any subsequent
servicing and maintenance.
3. The unit’s condensate drain must be connected to the
building’s wastewater drainage system.
4. Certain applications may require the installation of sound
attenuation to achieve the sound levels required.
5. The unit must not be connected directly to a tumble
drier.
6. The supply and exhaust valves must be fully opened
prior to commissioning.
7. The supply air must be drawn from the exterior of the
property.
8. The unit should be allowed to stabilise during
commissioning for a minimum period of 5 minutes when
changing between boost and normal speeds.
9. Ensure that the unit’s external grilles are a minimum of
1500mm apart. The exhaust grille should be located at
least 600mm away from any flue outlet. The inlet grille
should be located 2000mm away from any flue outlet.
10. This product and associated duct installation should be
carried out in accordance with the domestic ventilation
compliance guide.
Disposal
This product should not be disposed of with household
waste. Please recycle where facilities exist. Check with
your local authority for recycling advice.
About this Document
Integra Plus EC MVHR Installation & Commissioning 3
Contents
IMPORTANT SAFETY INFORMATION .......................................... 2
INSTALLATION GUIDANCE ........................................................... 2
Product Description.......................................................................... 4
Installation Guidance ....................................................................... 7
Before Installation of the Unit .......................................................... 7
Unit Installation................................................................................. 7
Electrical Installation ...................................................................... 10
Powering Up the Unit ..................................................................... 12
Commissioning Overview .............................................................. 12
Maintenance ................................................................................... 13
Spares ............................................................................................ 14
PRODUCT FICHE ......................................................................... 15
UK Building Regulations (Part F)
Declaration of Conformance
Integra Plus EC conform to the 2010 Building Regulations
(Part F - Means of Ventilation) installed performance of a
ducted mechanical extract fan when installed in
accordance with the instructions in this document and the
domestic ventilation compliance guide.
Product Description
Integra Plus EC MVHR Installation & Commissioning 4
Product Description
The Vent-Axia Integra Plus EC Mechanical Ventilation/Heat Recovery (MVHR) is heat recovery unit
designed for the energy efficient ventilation of houses and similar dwellings, conforming to the latest
requirements of the Building Regulations document F 2010.
The unit is designed for continuous 24 hour exhaust ventilation of stale moist air from bathrooms, toilets and
kitchens. As the stale air is extracted, a heat exchanger within the unit transfers up to 70% of the heat and
transfers it into the supply air entering the bedrooms and lounge.
Air Direction
Supply to
Rooms
Extract from
Rooms
Intake from
Outside
Exhaust to
Outside
Product Description
Integra Plus EC MVHR Installation & Commissioning 5
Exploded View of Fan Unit
Integra Plus EC Dimensions
Ø150
Ø22
Cover
Heat recovery cell
Motor assemblies
Base assembly
Product Description
Integra Plus EC MVHR Installation & Commissioning 6
Performance
Integra Plus EC
Airflow
Maximum, FID, 478 m3/h
Sound levels (@ 3 m)
48.8 dB(A) (70%), 56.8 dB(A) (boost)
Power
AC Voltage Input
220-240 V AC (single phase)
AC Frequency Input
50 Hz nominal
Rated Power
167 W (max.)
Physical
Height (excluding spigots)
304mm
Width (excluding spigots)
540mm
Depth
640mm
Weight
17.7 kg
Spigot diameter
150 mm
Condensate pipe diameter
22 mm
Environmental
IP Rating
IPX2
Operating Temperature
-10C to +45C
Air Intake Temperature
As above
Operating Humidity
0% to 95% RH
Storage Temperature
-10C to +45C
Storage Humidity
0% to 95% RH
For all other technical details, please see the Product Catalogue or our website at www.vent-axia.com
A wide range of sensors are available that can be used to switch the Integra Plus EC from normal to boost speed:
563519
TimeSpan
563506
Air Quality Sensor
563550
Ambient Response Humidity
563532
HumidiSwitch
563502
ThermoSwitch
455213
Normal Boost Switch
435960/446409
Vent Wise
459623
VisionX PIR
Installation
Integra Plus EC MVHR Installation & Commissioning 7
Installation Guidance
The following instructions are intended to help prevent potential hazards and installation should only be carried
out by a qualified electrician and installer.
NOTE: we advise installers to fix all mains and sensor wiring prior to fixing the MVHR unit in position.
Before Installation of the Unit
Inspect the Unit
When taking delivery of the unit, check the items delivered against the enclosed delivery note. Inspect the unit
for damage in transit. If in doubt, contact Customer Services. Each box contains a Integra Plus EC MVHR unit,
Remote Boost Switch and an accessory pack containing condensate drain link pipes, clips, energy rating labels
and product documentation.
Lift and Move the Unit Safely
On page 6 check the weight of the unit that you are installing.
Always use appropriate lifting techniques and appliances when moving heavy equipment.
Check Site Requirements and Safety Notices
Check that the physical and environmental conditions for the site meet, or exceed, the requirements detailed in
the table on page 6.
Read and observe the safety notices listed in Warnings and Safety Information on page 2.
Unit Installation
The Integra Plus EC unit is typically installed on a wall in a utility room, storage cupboard, roof void, or similar.
The wall should have sufficient strength to support the unit.
Take into consideration the position of the electrical services and the condensate drain.
Ensure there is an adequate access for installation, operation and maintenance.
It is recommended that a local isolation switch is installed within 1m of the unit to facilitate future maintenance.
The unit can be mounted on a horizontal or vertical face, care should be taken to ensure the unit is angled
towards the condensate drain.
Installation
Integra Plus EC MVHR Installation & Commissioning 8
Select Unit Orientation
CONDENSATION DRAIN
(THE UNIT SHOULD SLOPE
DOWNWARDS BY 3°- 5° TOWARDS
THE CONDENSATE DRAIN)
CONDENSATION DRAIN
(THE UNIT SHOULD SLOPE
DOWNWARDS BY 3°- 5° TOWARDS
THE CONDENSATE DRAIN)
CONDENSATION DRAIN
(THE UNIT SHOULD SLOPE
DOWNWARDS BY 3°- 5° TOWARDS
THE CONDENSATE DRAIN)
Fig 3a. Mounted on joists
Fig 3b. Ceiling mounted
Fig 3c. Wall mounted
FOR FURTHER INFORMATION ON CONDENSATION WATER TRAP DETAIL, SEE FIG 4
Installation
Integra Plus EC MVHR Installation & Commissioning 9
Fig 4. Water trap details
WATER TRAP
CONDENSATION
DRAIN FROM UNIT
SILICON SEALER
FALL TOWARDS
THE BUILDINGS
DRAINAGE SYSTEM
A
NOTE:
INSTALL THE CONDENSATE DRAINAGE TUBING IN
ACCORDANCE WITH THE DIAGRAM.
ENSURE THE WATER TRAP IS BELOW THE DRAIN
ELBOW OUT LET "A"
To mount the unit on joists:
Place the unit on a suitable platform across joists and attach the appropriate cabling, drainage and ductwork to the unit, with the
Vent-Axia badge facing up. For optimum performance, ensure the ductwork does not turn 90° directly off the spigots. The unit
should, for optimum drainage, be tilted by 3°- 5° towards the drain side. See Fig. 3a.
Ceiling mounted:.
Invert the unit with the Vent-Axia logo facing down and attach the unit securely to the rafters. For optimum performance, ensure
the ductwork does not turn 90° directly off the spigots. The unit should, for optimum drainage, be tilted 3°- 5° towards the drain
side. See Fig. 3b.
Please note - the location and position of installation for the unit must be decided before any drainage knockouts are removed, as
they cannot be refitted.
5. Having decided upon a location and position remove the knock out for the condensate drain, this must be at the lowest point.
Connect the drain of the ventilation unit to the drainage system using suitable ‘U’-bends (see fig 4).
6. Install suitable internal and external grilles/ terminals and connect them to the ventilation unit using suitable 150mm ducting. If
flexible ducting is used, it should be stretched in order to obtain the best performance.
Installation
Integra Plus EC MVHR Installation & Commissioning 10
Electrical Installation
Connect Switches and Sensors
Table 1: Mains Cable Connections
Terminal No.
Name
Cable connection
Description
L
Mains Live
Brown
220-240 V AC, 50 Hz input
N
Mains Neutral
Blue
220-240 V AC, 50 Hz input
EARTH
Mains Earth
Yellow/Green
Earth connector
LS1
Switched Live 1
Black
220-240 V AC, 50 Hz input
LS2
Switched Live 2
Black colour with white stripe
220-240 V AC, 50 Hz input
Main power lead (2m)
Remote boost lead (10m)
Speed adjustment
