Compliance Information
1.1 EMC
EC Decalration of Conformity - EMC
Compliance was demonstrated to the following specications listed in the Ocial Journal of the European
Communities: EMC Directive 2014/30/EU.
EN 61326-1:2013. Electrical equipment for measurement, control and laboratory use-
EMC requirements Part 1: General requirements.Safety
1.2 Safety
EC Declaration of Conformity - Low Voltage
Compliance was demonstrated to the following specication as listed in the Ocial Journal of the European
Communities: Low Voltage Directive: 2014/35/EU.
EN 61010-1:2010/AMD:2016. Safety requirements for electrical equipment for measurement,
control and laboratory use - Part 031: General requirements.
EN 61010-031:2015 Ed 2.0. Safety requirements for electrical equipment for measurement,
control and laboratory use - Part 031: Safety requirements for handheld probe assemblies
for electrical measurement and test.
U.S. and Canadian Recognized Agency Certication
The probe is has been certied by TUV Rheinland Taiwan Ltd. (TUV) to conform to the following safety
standard and bears the cTUVus mark.
IEC 61010-031:2015 Ed. 2.0. Safety requirements for electrical equipment for measurement,
control and laboratory use - Part 031: Safety requirements for handheld probe assemblies
for electrical measurement and test.

Compliance Information 4
1.3 IEC Measurement Category & Pollution Degree Denitions
Measurement Category (CAT) - classication of testing and measuring circuits according to the types
of mains circuits to which they are intended to be connected.
Measurement Category other than II, III, or IV : circuits that are not directly connected
to the mains supply.
Measurement Category II (CAT II) : test and measuring circuits connected directly to
ultilzation points (socket outlets and similar prints) of the low-voltage mains installation.
Measurement Category III (CAT III) : test and measuring circuits connected to the
distribution part of a building’s low-voltage mains installation.
Measurement Category IV (CAT IV) : test and measuring circuits connected at the
source of the building’s low-voltage mains installation.
Mains Isolated : is for measurements performed on circuits not directly connected to a
mains supply.
Pollution - addition of foreign matter, solid, liquid, or gaseous (ionized gases) that may produce a
reduction of dielectric strength or surface resistivity.
Pollution Degree 2 (P2) - only non-conductive pollution occurs except that occasionally a
temporary conductivity caused by condensation is expected

Compliance Information 5
1.4 Environmental
Restriction of Hazardous Substances (RoHS 2) The product and its accessories conform to the Directive
2011/65/EU (RoHS 2) on the restriction of the use of certain hazardous substances in electrical and
electronic equipment, inclusive of any modication and addendum to said Directive.
EN ISO 63000:2018 Technical documentation for the assessment of electrical and
electronic products with respect to the restriction of hazardous substances.
China RoHS 2 refers to the Ministry of Industry and Information Technology Order No.
32, eective July 1, 2015. See “Hazardous Substances Disclosure Table” on page 27.
1.5 Product End-of-Life Handling
The equipment may contain substances that could be harmful to the environment or human health if
improperly handled at the product’s end of life. To avoid release of such substances into the environment
and to reduce the use of natural resources, we encourage you to recycle this product to an appropriate
system that will ensure that most of the materials are reused or recycled appropriately.
This product is subject to Directive 2012/19/EU of the European Parliament and the
Council of the European Union on waste electrical and electronic equipment (WEEE), and
in jurisdictions adopting that Directive, is marked as being put on the market after August
13, 2005, and should not be disposed of as unsorted municipal waste. Please utilize your
local WEEE collection facilities in the disposition of this product.

Compliance Information 6
1.6 Terms and Symbols
Terms
A caution statement calls attention to an operating procedure,
practice, or condition, which, if not followed correctly, could result
in damage to or destruction of parts or the entire product.
Une mise en garde attire l’attention sur une procédure, une pratique
ou une condition d’utilisation qui, si elles ne sont pas suivies
correctement, pourraient endommager ou détruire une partie du
produit ou le produit entier.
A warning statement calls attention to an operating procedure,
practice, or condition, which, if not followed correctly, could result
in injury or death to personnel.
Un avertissement attire l’attention sur une procédure, pratique
ou condition de fonctionnement qui, si elles ne sont pas suivies
correctement, pourraient entraîner des blessures, voire la mort de
l’utilisateur.
A note statement calls attention to an operating procedure, practice, or condition,
which, should be noted before proceeding.
Un énoncé de note attire l’attention sur une procédure, une pratique ou une
condition d’exploitation, qui doit être notée avant de continuer. Symbols

Compliance Information 7
Symbols
CAUTION – Statements or instructions that must be consulted in
order to nd out the nature of the potential hazard and any actions
which must be taken.
WARNING - HIGH VOLTAGE - possibility of electric shock.
Earth (ground) TERMINAL - Refer to the instructions accompanying this symbol
in this manual.

Safety Notices
These test probes have been designed and tested in accordance with accepted industry and has been
supplied is a safe condition. Before applying power, verify that the correct safety precautions are taken
(see the following warnings). In addition, note the external markings on the instrument that are described
under “Symbols” .
Throughout this manual and specically in this section, there are warnings, cautions, and notes that you
must follow to ensure safe operation and to maintain the probe in a safe condition.
To avoid personal injury and to prevent re or damage to the probe
and the products connected to it, review and comply with the
following safety Warning and Cautions.
Pour éviter les blessures corporelles et éviter un incendie ou des
dommages à la sonde et aux produits qui y sont connectés, lisez et
respectez les avertissements et mises en garde de sécurité suivants.
Do not use your probe in a manner not specied by the manufacturer.
Be aware, that if used in a manner not specied by the manufacturer,
the protection provided by the probe assembly may be impaired.
N’utilisez pas votre sonde d’une manière non spéciée par le
fabricant. Sachez que s’il est utilisé d’une manière non spéciée par
le fabricant, la protection fournie par l’ensemble de sonde peut être
altérée.
The Probe Must be Grounded.
Before making connections to the input leads of the probe, ensure
that the output BNC connector is attached to the BNC input channel
of the oscilloscope AND the oscilloscope is properly grounded.
La sonde doit être mise à la terre.
Avant d’eectuer les connexions aux ls d’entrée de la sonde,
assurez-vous que le connecteur BNC de sortie est connecté au
canal d’entrée BNC de l’oscilloscope ET que l’oscilloscope est
correctement mis à la terre.

Safety Notices 9
Connect and Disconnect the Probe Properly.
Connect the probe to the oscilloscope before connecting the probe
inputs to the circuit under test. Disconnect the probe inputs from
the circuit under test before disconnecting the probe from the
oscilloscope.
Connectez et déconnectez correctement la sonde.
Connectez la sonde à l’oscilloscope avant de connecter les entrées
de la sonde au circuit à tester. Déconnectez les entrées de la sonde
du circuit à tester avant de déconnecter la sonde de l’oscilloscope.
Observe Maximum Working Voltages.
To avoid injury, do not use the probes above 1000 Vrms in a CAT III
environment between each input lead and earth or between the two
input leads. Do not operate the PR 67 probe above 1000 Vrms mains
isolated (200x attenuation) between the two input leads and above
1000 Vrms mains isolated (both 20x and 200x attenuation) between
each input lead and earth.
Respecter les tensions de fonctionnement maximales. Pour éviter
les blessures, n’utilisez pas les sondes au-dessus de 1000 Vrms
dans un environnement CAT III entre chaque l d’entrée et la terre
ou entre les deux ls d’entrée. Ne pas faire fonctionner la sonde PR
67 au-dessus de 1000 Vrms isolé du secteur (200x atténuation) entre
les deux câbles d’entrée et au-dessus de 1000 Vrms isolé du secteur
(à la fois 20x et 200x atténuation) entre chaque câble d’entrée et la
terre.
Do not attempt internal service or adjustment. Do not install
substitute parts or perform unauthorized modications to the
probe. Service should be carried out by B&K Precision authorized
service personnel. For any service needs, contact B&K Precision
Electronics.
Ne tentez pas d’entretien ou de réglage interne. N’installez pas
de pièces de rechange et n’eectuez pas de modications non
autorisées sur la sonde. Le service doit être eectué par le personnel
de service autorisé par Cal Test. Pour tout besoin de service,
contactez B&K Precision Electronics.

Safety Notices 10
Do Not Operate Without Covers. To avoid electrical shock, or re
hazard, do not operate these probes with cover removed.
Ne pas utiliser sans couvercles. Pour éviter les chocs électriques ou
les risques d’incendie, n’utilisez pas ces sondes avec le couvercle
retiré.
Avoid Exposed Circuit. To avoid injury, remove jewelry such as
rings, watches, and other metallic objects. Do not touch exposed
connections and components when power is present.
Évitez les circuits exposés. Pour éviter les blessures, retirez les
bijoux tels que bagues, montres et autres objets métalliques. Ne
touchez pas les connexions et les composants exposés lorsque
l’alimentation est présente.
Use Proper Power Source. To ensure these probes function well,
use either four fresh AA batteries or the supplied USB power cord.
Utilisez une source d’alimentation appropriée. Pour garantir le bon
fonctionnement de ces sondes, utilisez soit quatre piles AA neuves,
soit le cordon d’alimentation USB fourni.
For Indoor Use Only. To avoid electric shock, injury, or re hazard,
do not operate this probe in wet or damp conditions or in an
explosive atmosphere.
Pour une utilisation en intérieur uniquement. Pour éviter les chocs
électriques, les blessures ou les risques d’incendie, n’utilisez pas
cette sonde dans des conditions humides ou humides ou dans une
atmosphère explosive.

Safety Notices 11
Periodically inspect your probe and probe wires to check for any
damage. Do Not Operate with Visible or Suspected Failures. If
you suspect there is damage, have it inspected by B&K Precision
authorized service personnel.
Inspectez périodiquement votre sonde et ses ls pour vérier qu’ils
ne sont pas endommagés. Ne pas utiliser avec des défaillances
visibles ou suspectées. Si vous pensez qu’il y a des dommages,
faites-le inspecter par le personnel de service autorisé de B&K
Precision.
When it is likely that the ground protection is impaired, you must
make the instrument inoperative and secure it against any unintended
operation.
Lorsqu’il est probable que la protection au sol soit altérée, vous
devez rendre l’instrument inopérant et le sécuriser contre tout
fonctionnement intempestif.
The probe and its cables are sensitive parts and therefore, you
should be careful not to damage them though excessive bending
or pulling. Avoid any mechanical shocks to the probe to guarantee
accurate performance and protection.
La sonde et ses câbles sont des pièces sensibles et, par conséquent,
vous devez faire attention à ne pas les endommager en les pliant ou
en tirant excessivement. Évitez tout choc mécanique sur la sonde
pour garantir des performances et une protection précises.

Introduction
The B&K PrecisionPR65 Series High-Voltage Dierential probes allow conventional earth-grounded
oscilloscopes to be used for oating signal measurements - up to 700 V dierential or common mode
voltage (PR65) and up to 1400 V dierential or common mode voltage (PR 67).
Each model oers user selectable attenuation setting of 10x & 100x (PR65) and 20x & 200x (PR 67),
making both probes highly versatile and usable for a broad range of applications including power supply
measurements and moter controls.
Both probes are compatible with any oscilloscope with a 1 MΩ BNC female input and feature up to 30
MHz of bandwidth. The probes can be powered by any oscilloscope USB port, internal batteries (4 AA
batteries included with the probe), or included mains power adapter. Figure 3.1 shows some key features
of the PR65 Series probe.
Figure 3.1 Probe and Supplies Accessories

Introduction 13
3.1 Key Features
Features Description
Attenuation Selection
Button & LED Indicators
Press the Attenuation selection button to switch between the two ranges.
LED indicator will light green for attenuation selected.
Power Button Press to turn unit on. Press and hold for 5 seconds to turn unit o.
Power and Overload
indicator LED
LED will turn green when the unit is on. LED will turn red when the unit is in
voltage overload condiction. (Dimming of LED may indicate low batteries.)
4 mm Sheathed Banana
Plug Connectors Connects the probe to the DUT using probe hook pair provided wih the probe.
Insulated BNC Male
Output Connector
The probe’s output connect is full insulated and connects directly to an
oscilloscope’s BNC female input channel connector.
USB-C Input Power Port
(on side of probe)
Use USB-C Power Port to connect with USB cable when powering from mains
adapter or oscilloscope’s USB port.
Table 3.1 Key Features

Introduction 14
3.2 Supplied Accessories
Accessory Model No. Quantity
Probe Hook, Pair
(black & red) CT4386 1
Protective Rubber Boot,
Black CT4470-0 1
USB Power Cord
(1 m)(USB-A to USB-C) CT4473-100 1
Power Adapter, N.A. Plugs -
USB Jack Input: 100-240
Vac, 50/60 Hz Output: 5
Vdc, 1 A UL Listed
CT4471 1
EU Plug Converter
(NA to EU Plugs) CT4472 1
Batteries, AA — 4
Table 3.2 Supplied Accessories

Probe Setup
Before connecting the probe for your measurement, read all the
warnings in this section and all of the warnings in the section
“Safety Notices”.
Avant de connecter la sonde pour votre mesure, lisez tous les
avertissements de cette section et tous les avertissements de la
section “Safety Notices”.
4.1 Setup
In order to use the probe follow the steps below:
Step 1. First insert the four AA batteries into the probe as shown in gure 4.1.
Figure 4.1 Insert Batteries
Step 2. OR, connect the USB power cord to the probe (see gure 3.1 for the location of the input jack
on the probe) and a USB port on the oscilloscope or to the Power Adapter plugged into a mains
circuit.
Step 3. Connect the Insulated BNC male output connector to an input channel of the oscilloscope.
The Probe Must be Grounded.
Before making connections to the input leads of the probe, ensure
that the output BNC connector is attached to the BNC input channel
of the oscilloscope AND the oscilloscope is properly grounded.

Probe Setup 16
La sonde doit être mise à la terre. Avant d’eectuer les connexions
aux ls d’entrée de la sonde, assurez-vous que le connecteur BNC
de sortie est connecté au canal d’entrée BNC de l’oscilloscope ET
que l’oscilloscope est correctement mis à la terre.
Step 4. Select the desired attenuation ratio, 10x or 100x (PR 65); 20x or 200x (PR 67), via the attenuation
selection button.
Step 5. Turn o the high voltage source.
Step 6. Press the probe hooks on its matching color 4 mm sheathed banana plug input lead.
Step 7. Connect the probe hooks to the circuit under test.
To protect against electric shock, use only the probe hooks supplied
with this probe.
Pour vous protéger contre les chocs électriques, utilisez uniquement
les crochets de sonde fournis avec cette sonde
Step 8. After conrming that the probe operator is not touching the device under test, turn on the high-
voltage source.
Step 9. Measure the voltage under test and observe the waveform on the oscilloscope.
Remember the actual voltage is the attenuation factor greater than
the oscilloscope waveform.
N’oubliez pas que la tension réelle est le facteur d’atténuation
supérieur à la forme d’onde de l’oscilloscope.
Step 10. Turn o high voltage source.
Step 11. Disconnect the probe inputs from the high-voltage source.

Specications
The probe and oscilloscope should be warmed up for at least 20 minutes before any testing and the
environmental conditions should not exceed the probe’s specied limits.
All entries included in the following tables are characteristics unless otherwise
stated.
Toutes les entrées incluses dans les tableaux suivants sont des caractéristiques,
sauf indication contraire.
5.1 Safety Specications
Parameter Condition
IEC/EN 61010-031:2015 Measurement Category III
Table 5.1 Safety Specications

Specications 18
5.2 Electrical Specications (Not Warranted)
Parameter PR65 PR67
Bandwidth (-3 dB) 30 MHz 30 MHz
Gain Accuracy ±2% ±2%
Attenuation Ratio 10x / 100x 20x / 200x
Rise Time 14 ns 14 ns
Absolute Maximum Rated
Input Voltage
(each side to ground)
1000 V CAT III 1000 V CAT III
Maximum Dierential Input
Voltage (DC + Peak AC)
±70 V at 10x
±700 V at 100x
±140 V at 20x
±1400 V at 200x
Maximum Common Mode
Input Voltage
(DC + Peak AC)
±70 V at 10x
±700 V at 100x
±140 V at 20x
±1400 V at 200x
Input Impedance 5 MΩ, 2 pF (each side to ground) 5 MΩ, 2 pF (each side to ground)
Output Voltage ±7 V (driving 1 MΩ load) ±7 V (driving 1 MΩ load)
Oset (typical) ±20 mV ±20 mV
Noise (typical) 0.7 mVrms 0.7 mVrms
CMRR (typical)
50 Hz: -72 dB
20 kHz: -66 dB
200 kHz: -56 dB
50 Hz: -72 dB
20 kHz: -66 dB
200 kHz: -56 dB
Power Requirements 4 x AA batteries
or USB-C cable
4 x AA batteries
or USB-C cable
Mains Adapter (N.A. Plugs) Input:100-240 V AC, 0.35 A
Output: 5 V DC, 1 A
Input:100-240 V AC, 0.35 A
Output: 5 V DC, 1 A
Table 5.2 Electrical Specications

Specications 19
5.3 Mechanical Specications (same for both versions))
Parameter Characteristic
Input Leads Length (each) 55 cm ±3 cm
BNC Cable Length 95 cm ±3 cm
Dimension (L x W x H) 220 mm, 68 mm, 28 mm (with protective rubber boot)
Weight 488 g (1.08 lb) (with batteries and protective rubber boot)
USB Type C Cable Length 100 cm ±3 cm
Table 5.3 Mechanical Specications
5.4 Environmental Specications (same for both versions)
Parameter Characteristic
Operating Temperature -10°C to 40°C (14°F to 104°F)
Storage Temperature -30°C to 70°C (-22°F to 158°F)
Humidity ≤ 80% RH @ 25°C to 35°C (77°F to 95°F)
Altitude Operating: 2000 m
Non-operating: 15000 m
Pollution Degree P2
Table 5.4 Environmental Specications

Performance Plots
Figure 6.1 Riste Time 10x attenuation, 10%-90%
