RESIDENTIAL GAS REPLACEMENT PARTS LIST
Dash Twelve, Thirteen, Fifteen
(-12, -13, -15) Models
Through-The-Wall TTW1
Energy Saver (M-1) Models
Includes Hydrojet®
Total Performance System
Effective: May 12, 2003
ECO 6751
NOTE: BOTH MODEL AND SERIAL
NUMBERS ARE REQUIRED FOR
ORDERING REPLACEMENT PARTS
Dimensions and specifications
subject to change without notice.
Parts Book #238-43737-00B
®

Page 2
Reference Number & Description
1 Blower
2 Blower Gasket
3 Blower Harness
4Temperature Switch
5Transformer
6 Pressure Switch
7Baffle
8 Dip Tube
9 Anode
10 T & P Valve
11 Thermostat
11A Thermostat Protector
12 Thermostat Bracket
13 Hand hole Cover
14 "No" Handle Drain Valve
15 Gas Valve
16 Street Elbow
1
17 Burner Assembly Complete (40 gal)
17A Burner Assembly Complete (50 gal)
18 Pilot Assembly with Tubing
18A Pilot Only
18B Sensor & Igniter Only
19 Pilot tube
20 Gas Feed Line
21 Main Burner Orifice
22 BN Burner Only
22A En Burner Only
23 Cast Iron Burner Assembly Complete
24 Pilot Assembly with Tubing
24A Pilot Only
24B Sensor & Igniter Only
25 Pilot Tube
26 Gas Feed Line
27 Main Burner Orifice
2
28 Washer Spring Crescent
29 Air Shutter
30 Cast Iron Burner Only
31 Inner Door
32 Outer Door
33 Power Cord
34 Tempering Valve
35 Vent Terminal Elbow
36 2" Exhaust Adapter Kit
37 2" Condensate Kit
2

Page 3
Parts Common To MITW(40, 50)L*(BN, EN) (-12, -13, -15) Models
Reference Number and Description Part Number
1Blower 239-41605-00
2Blower Gasket 239-42326-00
3Blower Harness 239-41865-00
4Temperature Switch 233-41831-00
5Transformer 233-41863-00
6Pressure Switch 233-41830-00
7Baffle 243-39998-00
8Cold Water Inlet (Hydrojet) Assembly 229-39625-20
9Hot Water Outlet / Magnesium Anode Assembly 224-32731-89
10 T&P Valve 230-32920-01
11 Thermostat 265-42034-00
11A Thermostat Protector 223-40399-00
12 Thermostat Bracket 239-40765-00
13 Hand Hole Cover 243-36618-02
14Drain Valve 227-42351-01
15 Gas Valve Nat. 222-40762-01
16Street Elbow 239-40779-00
18 Pilot Assembly (Nat) With Pilot Tube 233-40876-02
18A Pilot Only (Nat.) 233-40752-00
18B Flame sensor & Igniter Only (Nat.) 239-40918-00
19 Pilot Tubing 233-40767-03
21 Main Burner Orifice #32 234-41034-32
31 Inner Door 243-36739-02
32 Outer Door 243-41061-00
33 Power Cord 239-39772-00
35 Vent Terminal Elbow 239-39831-00
36 2" Exhaust Adaptor Kit 239-43847-00
37 2" Dia. Condensate Trap Kit 239-43869-00
Optional Parts Reference Number and Description
8Cold Water Inlet (Hydrojet) Assembly (PSDTA) (NC Code) 229-39628-20
9Hot Water Outlet / Aluminum Anode Assembly 224-32999-22
21 High Altitude Orifice 2000 Ft. to 5000 Ft. 234-41034-36
21 High Altitude Orifice 5001 Ft. to 8000 Ft. 234-41034-38
21 High Altitude Orifice Over 8000 Ft. 234-41034-38
34 Tempering Valve 239-43740-01
Parts Unique to MITW40L*(BN, EN) (-12, -13, -15) Models
Reference Number and Description Part Number
17 Complete Burner Assembly Nat. Gas** 265-43992-01-32
20 Feedline Nat. 233-40783-01
22 BN Burner Only Nat. Gas 228-42506-00
22A EN Burner Only Nat. Gas Order item 17
Parts Unique to MITW50L*(BN, EN) (-12, -13, -15) Models
Reference Number and Description Part Number
17A Complete Burner Assembly Nat. Gas** 265-43995-01-32
20 Feedline Nat. 233-41180-00
22 BN Burner Only Nat. Gas 228-42506-00
22A EN Burner Only Nat. Gas Order item 17A
*Applies to all warranties.
** Fits BN and EN Models.
Optional Heat trap components -13 models
8Cold Water Inlet (Hydrojet) HT Assembly (PPDTA) 229-39626-17
8Cold Water Inlet (Hydrojet) HT Assembly (PSDTA) (NC Code) 229-39629-17
9 Hot Water Outlet / Magnesium HT Anode Assembly 224-33871-48
9 Hot Water Outlet / Aluminum HT Anode Assembly 224-33149-11

Page 4
Parts Common To MITW(40,50)L*CX (-12, -13, -15) Models
Reference Number and Description Part Number
1Blower 239-41605-00
2Blower Gasket 239-42326-00
3Blower Harness 239-41865-00
4Temperature Switch 233-41831-00
5Transformer 233-41863-00
6Pressure Switch 233-41830-00
7Baffle 243-39998-00
8Cold Water Inlet (Hydrojet) Assembly 229-39625-20
9Hot Water Outlet / Magnesium Anode Assembly 224-32731-89
10 T&P Valve 230-32920-01
11 Thermostat 265-42034-00
11A Thermostat Protector 223-40399-00
12 Thermostat Bracket 239-40765-00
13 Hand Hole Cover 243-36618-02
14 Drain Valve 227-42351-01
15 Gas Valve L.P. 222-40762-02
16 Street Elbow 239-40779-00
24 Pilot Assembly (LP) With Pilot Tube. 233-40877-02
24A Pilot Only LP. 233-40751-02
24B Flame Sensor & Ignitor Only LP. 239-40918-00
25 Pilot Tube 233-40767-02
27 Main Burner Orifice #50 234-35928-50
28 Washer Spring Crescent 239-40729-00
29 Air Shutter 239-35466-00
30 Cast Iron Burner Only 228-14173-00
31 Inner Door 243-36739-02
32 Outer Door 243-41061-00
33 Power Cord 239-39772-00
35 Vent Terminal Elbow 239-39831-00
36 2" Exhuast Adaptor Kit 239-43847-00
37 2" Dia. Condensate Trap Kit 239-42742-00
Optional Parts Reference Number and Description
8Cold Water Inlet (Hydrojet) Assembly (PSDTA) (NC Code) 229-39628-20
9Hot Water Outlet / Aluminum Anode Assembly 224-32999-22
27 High Altitude Orifice 2000 Ft. to 5000 Ft. 234-35928-51
27 High Altitude Orifice 5000 Ft. to 8000 Ft. 234-35928-52
27 High Altitude Orifice Over 8000 Ft. 234-35928-53
34 Tempering Valve 239-43740-01
Parts Unique to MITW40L*CX (-12, -13, -15) Models
Reference Number and Description Part Number
23 Complete Cast Iron Burner Assembly LP Gas 265-40815-07-50
26 Feedline L.P. 233-40919-01
Parts Unique to MITW50L*CX (-12, -13, -15) Models
Reference Number and Description Part Number
23 Complete Cast Iron Burner Assembly LP Gas 265-40815-08-50
26 Feedline L.P. 233-40919-03
*Applies to all warranties.
Optional Heat trap components -13 models
8Cold Water Inlet (Hydrojet) HT Assembly (PPDTA)
8Cold Water Inlet (Hydrojet) HT Assembly (PSDTA) (NC Code)
9 Hot Water Outlet / Magnesium HT Anode Assembly
9 Hot Water Outlet / Aluminum HT Anode Assembly
229-39626-17
229-39629-17
224-33871-48
224-33149-11
