Bradford White U1-5036FRN User manual

Residential Ultra Low NOx
Energy Saver Gas Water Heater
The FVIR Eco-Defender Safety System®Models Feature:
■Defender Combustion Chamber—Incorporates the Advanced ScreenLok®
Technology Flame Arrestor and large split-door design to prevent ignition of
flammable vapors outside the water heater.
■Ultra Low NOx Burner with Primary and Secondary Air Distribution
Devices—Ensures proper air to gas ratio for reduction of NOx generated by
the combustion process.
■Digital Thermal Sensor and Resettable Thermal Switch—Coordinates
with self diagnostic control to prevent water heater operation as needed.
■Millivolt Powered Control with Built-in Piezo Igniter—Easy and quick
lighting of the pilot burner by push button.
■Pedestal Base—Rugged and durable base allows easy transport and
positioning, while providing corrosion resistant contact with floor.
■Maintenance Free—No regular cleaning of air inlet openings or flame arrestor
is required under normal conditions.
■Sight Window—Offers a view into the combustion chamber to observe the
operation of the pilot and burner.
■No Electricity Required.
■Factory Installed Hydrojet®Total Performance System—Cold water inlet
sediment reducing device helps prevent sediment build up in tank. Increases
first hour deliveryof hot water while minimizing temperaturebuild up in tank.
■Vitraglas®Lining—BradfordWhite water heater tanks are protected from the
corrosive effects of hot water by an exclusive ceramic porcelain-like coating.
■Self Diagnostic Honeywell Gas Control—Integrated, immersion gas control
learns and monitors the combustion chamber's temperature profile and
prevents water heater operation during upset conditions. Also equipped with
an LED display to aid in start-up and diagnostics.
■1" Non-CFC Foam Insulation—Surrounds the tank surface, saving energy
by retarding loss of heat.
■Water Connections—3⁄4" NPT factory installed true dielectric fittings extend
water heater life and eases installation.
■Factory Installed Heat Traps—Design incorporates a flexible disk that
reduces heat loss in piping and eliminates the potential for noise generation.
■Protective Magnesium Anode Rod—Provides added protection against
corrosion for long trouble-free service.
■3x4 “Snap Lock” Draft Diverter—Allows either 3" or 4" vent connections
with inputs of 40,000 BTU/Hr. or less. Over 40,000 BTU/Hr. has the 4" “Snap
Lock” Draft Diverter.
■T&P Relief Valve—Included.
■Low Restriction Brass Drain Valve—Durable tamper proof design.
■Meets SCAQMD Rule 1121 (10ng/J NOx limit).
■Design Certified by CSA International (formerly AGA and CGA).
6 or 10-Year Limited Tank Warranties / 6 or 10-Year Limited Warranty on Component Parts.
For more information on warranty, please visit www.bradfordwhite.com
For products installed in USA, Canada and Puerto Rico. Some states do not allow limitations on warranties. See complete
copy of the warranty included with the heater.
Photo is of
U1-5036FRN
Identical Dimensions
Same diameter, height and connections
as standard units for ease of installation.
MANUFACTURED UNDER ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,954,492; 5,761,379; 5,943,984; 5,081,696; 5,988,117; 6,142,216; 5,199,385; 5,574,822; 5,372,185; 5,485,879; 5,277,171;
(B1)5,341,770; 5,660,165; 5,596,952; 5,682,666; 4,904,428; 5,023,031; 5,000,893; 4,669,448; 4,829,983; 4,808,356; 5,115,767; 5,092,519; 5,052,346; 4,416,222; 4,628,184; 4,861,968; 4,672,919; Re. 34,534;
7,270,087 B2. OTHER U.S. AND FOREIGN PATENT APPLICATIONS PENDING. CURRENT CANADIAN PATENTS: 1,272,914; 1,280,043; 1,289,832; 2,045,862; 2,112,515; 2,108,186; 2,107,012; 2,092,105; 2,409,271.
Defender Safety System®,ScreenLok®, Vitraglas®and Hydrojet®are registered trademarks of BradfordWhite®Corporation.
112-B-0211-A
FEATURING:

NATURAL GAS
Ultra Low NOx Energy Saver Models Meet or exceed ASHRAE 90.1b (current standard) C.E.C. Listed
Recovery efficiency ranging up to 78%
Model
Number
Approx.
Shipping
Weight
lbs.
A
Floor to
Flue
Conn.
in.
B
Jacket
Dia.
in.
Capacity Recovery at
90°F Rise*
U1-30S6FRN
U1-30T6FRN•
U1-403S6FRN•
U1-40T6FRN•
U1-404T6FRN•
U1-5036FRN•
U1-50L6FRN
U1-504S6FRN•
U1-60T6FRN
U.S.
Gal.
30
30
40
40
40
50
48
50
60
Imp.
Gal.
25
25
33
33
33
42
40
42
50
Nat.
BTU/Hr.
Input
30,000
32,000
40,000
40,000
50,000
40,000
40,000
50,000
40,000
B
6
6
6
Nat.
U.S.
GPH
31
33
42
42
53
42
42
53
42
Nat.
Imp.
GPH
26
28
34
34
44
34
34
44
34
48
3
/ 8
59
1
/ 8
50
59
3
/ 8
60
3
/ 4
59
5
/ 8
49
3
/ 4
58
1
/ 2
60
3
/ 4
110
113
137
130
137
154
163
160
166
18
16
20
18
18
20
22
20
22
H
Floor to
Water
Conn.
in.
46
3
/ 4
57
1
/ 2
48
1
/ 2
57
3
/ 4
58
1
/ 2
58
48
1
/ 4
57
58
1
/ 4
C
Vent
Size
in.
3x4
3x4
3x4
3x4
4
3x4
3x4
4
3x4
E
Floor to
Gas
Conn.
in.
11
5
/ 8
11
5
/ 8
11
5
/ 8
11
5
/ 8
11
5
/ 8
11
5
/ 8
11
5
/ 8
11
5
/ 8
13
D
Floor to
T&P
Conn.
in.
38
3
/ 4
49
3
/ 4 /56
3
/ 8
41 / 47
1
/ 4
50 / 56
5
/ 8
51
1
/ 2 /58
50 / 56
7
/ 8
40
1
/ 2
50 / 55
3
/ 4
50
1
/ 2
Model
Number
Approx.
Shipping
Weight
kg.
A
Floor to
Flue
Conn.
mm.
B
Jacket
Dia.
mm.
Capacity Recovery at
50°C Rise*
U1-30S6FRN
U1-30T6FRN•
U1-403S6FRN•
U1-40T6FRN•
U1-404T6FRN•
U1-5036FRN•
U1-50L6FRN
U1-504S6FRN•
U1-60T6FRN
Liters
114
114
151
151
151
189
182
189
227
Nat.
kW
Input
8.8
9.4
11.7
11.7
14.7
11.7
11.7
14.7
11.7
Nat.
Liters/
Hour
117
125
155
155
201
155
155
201
163
1229
1502
1207
1508
1543
1514
1264
1486
1543
50
51
62
59
62
70
74
73
75
457
406
508
457
457
508
559
508
609
H
Floor to
Water
Conn.
mm.
1187
1461
1232
1467
1486
1473
1226
1448
1480
K
Depth
in.
22
1
/ 4
20
1
/ 4
24
1
/ 4
22
1
/ 4
22
1
/ 4
24
1
/ 4
26
1
/ 4
24
1
/ 4
26
1
/ 2
K
Depth
mm.
565
514
615
565
565
615
666
615
666
C
Vent
Size
mm.
76x102
76x102
76x102
76x102
102
76x102
76x102
102
76x102
E
Floor to
Gas
Conn.
mm.
295
295
295
295
295
295
295
295
330
D
Floor to
T&P
Conn.
mm.
984
1264 / 1432
1041 / 1200
1270 / 1438
1308 / 1473
1270 / 1453
1029
1270 / 1416
1282
Residential Atmospheric Vent Gas Water Heater
Meets NAECA Requirements
General
All gas water heaters are certified at 300 PSI test pressure (2068 kPa) and 150 PSI working pressure (1034 kPa). All water connections are 3⁄4" NPT (19mm)
on 8" (203mm) centers. All Gas Connections are 1/2" (13mm).
All models design certified by CSA International (formerly AGA/CGA), to meet ANSI standard Z-21.10.1 and peak performance rated.
Dimensions and specifications subject to change without notice in accordance with our policy of continuous product improvement.
Suitable for Water (Potable) Heating and Space Heating.
Toxic chemicals, such as those used for boiler treatment, shall NEVER be introduced into this system. This unit may NEVER be connected to any existing
heating system or component(s) previously used with a non-potable water heating appliance.
Available in Natural Gas only.
For 10 year models, change suffix from “6” to “10”.
*Based on manufacturers rated recoveryefficiency.
Note: U1-30S, U1-50L and U1-60T do not have top T&P option.
•Models feature optional top T&P location and must be specified when ordering.
E
K
C
B
8"
A
D
H
●
E
K
C
B
8"
A
D
H
●
•Optional T&P Location Dimension
“D” dimension listed as side/top.
Printed in U.S.A.
112-B-0211-A
©2011, Bradford White Corporation. All rights reserved.
Ambler,PA
For U.S. and Canada field service, contact your professional installer or local BradfordWhite sales representative.
Sales 800-523-2931 ●Fax [phone] / Technical Support800-334-3393 ●Fax [phone] ●Warranty 800-531-2111 ●Fax [phone]
International: Telephone [phone] ●Telefax 215-641-9750 / www.bradfordwhite.com
Sales / Technical Support866-690-0961 /905-238-0100 ●Fax [phone] /www.bradfordwhite.com
All models meet SCAQMD rule 1121 requirement of 10ng/J,
or less, NOx emissions.
