Braecrest Design Skye View Post Mount Bird Feeder Kit User manual

Skye View Post Mount Bird Feeder Kit
Copyright © 2007 Braecrest Design FDR-001 -03 Assemb y, Rev. 01
These instructions are for the assembly of the Skye View Post Mount bird feeder (FDR-001-03-xx).
PARTS
(8) #8 x 3/4 Brass Screws
(2) Metal Supports
(1) RoofAssembly
(1) FloorAssembly
TOOLS REQUIRED
• #2 Robertson (square) screwdriver
• Ruler or Tape Measure
STEP 1. UNPACKING
Unpack the Bird Feeder kit and locate each part listed in the
PARTS list. See Figure 1 .
STEP 2. LOCATING METAL SUPPORTS
Place the FloorAssembly upright. Position a Metal Support
against the end of the FloorAssembly and centered between
the sides of the FloorAssembly. See Figure 2.
STEP 3. INSTALL BRASS SCREWS
Using the #2 square screwdriver, install two Brass Screws
through the holes in the Metal Support and into the Floor
Assembly. See Figure 3. Repeat STEP 2 and STEP 3 to install
the second Metal Support on the opposite end of the Floor
Assembly.
Figure 3
STEP 4. LOCATING ROOF ASSEMBLY
Turn the RoofAssembly upside down. Take the Floor and Metal
Support subassembly and turn upside down on the Roof
Assemby. Slide the subassembly sideways until centered on the
RoofAssembly. See Figure 4.
Figure 4
Figure 1
Figure 2
PAGE 1 OF 2
Continued on Page 2 of 2
Assembly Instructions

Copyright © 2007 Braecrest Design FDR-001 -03 Assemb y, Rev. 01
Page 2 of 2
STEP 5. INSTALL BRASS SCREWS
Using the #2 square screwdriver, install two Brass Screws
through the outside holes in the Metal Support and into the Roof
Assembly. See Figure 5. Repeat this step for the other Metal
Support. Turn the bird feeder sitting right side up. The Bird
Feeder is now complete and ready to use. See Figure 6.
Figure 5
Figure 6
