Brandt BPG6210 Series Quick start guide

GUIDE D’INSTALLATION ET D’UTILISATION FR
GUIDE FOR INSTALLATION AND USE EN
GUIA DE INSTALAÇÃO E DE UTILIZAÇÃO PT
Table de cuisson
Cooking hob
Placa de cozinha
BPG6210*
BPG6413*

26
Dear Customer,
You have just acquired a BRANDT product and we would like to thank
you.
We have designed and made this product with you, your lifestyle and
your requirements in mind so that it meets your expectations. We
have devoted our know-how, our innovative spirit and the passion that
has been guiding us for over 60 years.
In an effort to ensure that our products meet your requirements in the
best possible way, our Customer Relations department is at your
disposal, to answer all your questions and to listen to all your
suggestions.
Visit our website www.brandt.com where you will find our latest
innovations, as well as useful and complementary information.
BRANDT is delighted to assist you every day and hopes you get the
most out of your purchase.
Important: Before using your appliance, read this user guide
carefully to familiarise yourself more quickly with its operation.
FR 02
EN 26
PT 48

27
• Safety recommendations ________________________________ 28
• Environmental protection ________________________________ 30
• Description of your appliance_____________________________ 31
1 / INSTALLING YOUR APPLIANCE
• Proper positioning______________________________________ 32
• Flush mounting________________________________________ 32
• Tips for flush mounting _________________________________ 33
• Electrical connection____________________________________ 33
• Gas connection ________________________________________ 34
• Changing the gas supply ________________________________ 36
2 / USING YOUR APPLIANCE
• Description of the top___________________________________ 40
• Switching on gas burners________________________________ 41
• Cookware to be used with gas burners _____________________ 42
• Cookware for electric plate_______________________________ 43
• Switching on the electric plate __________________________ 43
3 / DAILY CARE OF YOUR APPLIANCE
• Maintaining your appliance_______________________________ 44
4 / SPECIAL MESSAGES, DIFFICULTIES
• During operation_______________________________________ 45
5 / COOKING CHART
• Gas cooking guide _____________________________________ 46
• Electric cooking guide___________________________________ 46
6 / AFTER-SALES SERVICE _________________________________ 47
ENTABLE OF CONTENTS

28
EN SAFETY RECOMMENDATIONS
— We have designed this
cooking hob for use by private
individuals in their homes.
— This appliance must be
installed in compliance with
currently applicable
regulations and used only in a
well-ventilated location.
Consult this guide before
installing and using your
appliance.
— All cooking should take
place under your surveillance.
— These cooking hobs are
intended exclusively for
cooking beverages and
foodstuffs and do not contain
any asbestos-based materials.
— This appliance is not
connected to a device for
evacuating combustion
products. It must be installed
and connected in compliance
with the regulations in force.
Particular attention must be
given to the guidelines
concerning ventilation.
— Do not store CLEANING
products or FLAMMABLE
products (aerosol cans or
pressurised containers, as
well as papers, cookbooks,
etc.) in the cabinet
underneath your cooking hob.
— If you use a drawer located
under the hob, we
recommend that you avoid
using it to store items that are
heat sensitive (plastic, papers,
aerosol cans, etc.).
— Your hob should be
disconnected from power and
fuel supplies (electricity and
gas) before any repairs.
— When you connect the
power cables of any electrical
appliances plugged in close to
the hob, ensure that they are
not in contact with the
cooking zones.
— It must be possible to
disconnect the appliance from
the power supply, either using
a plug or by fitting a switch on
the fixed wiring system in
accordance with installation
rules.
— The electrical plug must
remain accessible after
installation.
— As a safety measure, do
not forget to close the overall
supply tap for gas distributed
by pipe or the tap of the tank
for butane or propane gas
after use.
— Prior to installation, ensure
that the local distribution
conditions (nature of the gas
and pressure of the gas) and
the setting of the appliance
are compatible.
— The CE mark is affixed to
these hobs.
— Installation should only be
performed by installers and
qualified technicians.
— Do not use a steam cleaner.
— Consult this guide before
installing and using your
appliance.
— This appliance may be used
by children aged 8 years and
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND RETAIN
FOR FUTURE USE.
This user guide is available for download on the brand’s website.

29
SAFETY RECOMMENDATIONS EN
older, and by persons with
impaired physical sensorial or
mental capacities, or without
experience or knowledge, if
they are supervised or have
received prior instructions on
how to use the appliance
safely and have understood
the risks involved. Children
must not be allowed to play
with the appliance. Cleaning
and maintenance operations
must not be carried out by
children without supervision.
— Children must be
supervised to prevent them
from playing with the
appliance.
— This hob is compliant with
standard EN 60335-2-6
relating to the heating of
cabinets and the Class 3
standard with regard to
installation (as per standard
EN 30-1-1).
— We do not recommend
using any hob protection
mechanism.
— This appliance is designed
to be installed on a work
surface only.
— If the power supply lead is
damaged, it must be replaced
by a H05V2V2F cable and
three 1 mm2 conductors.
— WARNING: Fire hazard:
Do not store objects on the
cooking surfaces.
— If a knob is difficult to turn,
call your installer immediately.
— The conditions for setting
this appliance are described
on the label inside the bag or
on the rating plate.
—In order to easily locate the
reference information for your
appliance, we recommend
that you note it on the “After-
Sales Service Department and
Customer Relations” page
(this page also explains where
to find this information on
your appliance).
— WARNING: the appliance
and the accessible parts of it
will become hot during use.
Be careful not to touch the
heated elements. Children
under the age of 8 years must
not be allowed to touch the
appliance, unless they are
supervised continually.
- This appliance’s packing
materials are recyclable.
Recycle them and help to
protect the environment by
disposing of them in the
council receptacles provided
for this purpose.
— CAUTION: The cooking
process must be monitored. A
short cooking process must be
continuously monitored.
— When not monitored,
cooking on a cooking plate
with fat or oil can be
dangerous and may cause a
fire.
— If the power cable is
damaged, it should be
replaced by the manufacturer,
its after-sales service
department or by a similarly
qualified person in order to
avoid danger.
— This unit is not intended to
be operated using an external
timer or a separate remote
control system.
— WARNING: It is
dangerous to cook with oil or

30
EN DESCRIPTION OF YOUR APPLIANCE
• If a crack appears in the
surface of the glass,
disconnect your appliance
from the power supply to
avoid electric shock.
CARING FOR THE
ENVIRONMENT
— This appliance’s packing
materials are recyclable.
Recycle them and play a role
in protecting the environment
by depositing them in local
authority containers provided
for this purpose.
Your appliance also
contains various
recyclable materials. It
is therefore marked
with this logo to
indicate that, in
European Union countries,
used appliances must not be
mixed with other waste.
Appliance recycling organised
by your manufacturer will
thus be carried out in
optimum conditions, in
accordance with European
directive 2002/96/CE relating
to electrical and electronic
equipment waste. Contact
your local council or your
retailer to find out the drop-
off points for used appliances
that are nearest to your
home.
We thank you for your help in
protecting the environment.
fat if the hob is left
unattended, as this may cause
a fire. Do not attempt to
extinguish a fire with water
but switch off the appliance,
then cover the flame with a lid
or a fire blanket.
— WARNING: Risk of fire: do
not use the cooking surfaces
to store things.
— The use of a gas cooking
appliance produces heat and
humidity in the room where it
is located. Ensure that the
kitchen is well-ventilated:
keep mechanical ventilation
orifices open.Intensive and
prolonged use of the
appliance may require
additional ventilation, for
example opening a window,
or more efficient ventilation,
for example by increasing the
power of the mechanical
ventilation if present.
— Do not use recipients that
overhang from the edge of
the cooking hob.
— Never use aluminium foil
for cooking. Never place
products wrapped in
aluminium foil or in aluminium
trays on your hob. The
aluminium will melt and
permanently damage your
appliance.
WARNING : In case of
hotplate glass breakage :
- shut immediately off all
burners and any electrical
heating element and isolate
the appliance from the power
supply.
- do not touch the appliance
surface,
- do not use the appliance.

DESCRIPTION OF YOUR APPLIANCE EN
31
•DESCRIPTION OF YOUR HOB
A
B
Burner covers
Burner head
Injector
C
DSpark plug
Thermocouple
(model with safety
device)
Knob
E
F
G
H
Gasket
Tap
CONSEIL
This Guide to Installation and Use is valid for several models. Minor differences in
details and fittings may emerge between your appliance and the descriptions provided.
D
E
A
B
Pan
support
grid
Hob model: 4 gas
burners
C
F
G
H

•
PROPER POSITIONING
Your appliance shoud be built in the surface
of a support cabinet that is a minimum of
three cm thick, made of a material that
resists heat or that is covered with such a
material.
So as not to disturb movement of cooking
utensils, there should not be to the right or
left or back any obstacle within 30 cm of
the hob.
if a horizontal divider wall is positioned under
the hob, it should be placed between 10 cm
and 15 cm away from the top of the work
top. In any event, do not store aerosol cans
or containers under pressure in any
compartment that may exist under the hob
(See “Safety Recommendations” chapter).
FLUSH MOUNTING
To ensure that the hob and the work top
are leaktight, glue the seal provided in the
front pocket before installing the hob:
Follow the diagram (Fig. 01).
— Remove the pan supports, the burner
covers and burner heads, noting their
positions.
— Turn the hob over and carefully place it
on top of the opening in the cabinet so
asnot to damage the knobs and spark
plugs.
— To ensure a tight seal between the
housing and the work top, glue the foam
seal along the exterior edge of the
housing (Fig. 02).
•
48 cm mini
3 cm mini
30 cm mini
56 cm / 26,5 cm
30 cm mini
5,8 cm mini
70 cm mini
Fig. 01
Fig. 02
Housing
Seal
APPLIANCE
Cut
cabinet
standard
Cut
cabinet
standard
Dimensions
total
above
the work
top
Dimensions
total
below
the work
top
Width
56 cm
26,5 cm
71 cm
31 cm
55,4 cm
26 cm
Depth
49 cm
49 cm
52,2 cm
51 cm
47 cm
47 cm
Thickness
According
to cabinet
According
to cabinet
5 cm
5 cm
5,1 cm
5,1 cm
Model
60 cm
30 cm
60 cm
30 cm
60 cm
30 cm
EN 1/ INSTALLONG YOUR APPLIANCE
32

— Place your hob in the opening of the
support cabinet, carefully pulling the table
toward you.
— Reposition the burner heads, burner
covers and pan supports on the hob.
Connect your hob to the gas supply (See
“Gas Connection” chapter) and to the
power supply (See “Electrical Connection”
chapter).
— If you wish, you can immobilise the hob
using the four mounting brackets delivered
with a screw (Fig. 02) to attach them to the
four corners of the housing. You must use
the holes provided for this purpose,
according to the diagram above (Fig.
01).
—Stop screwing when the mounting
bracket starts to become deformed.
Do not use a screwdriver.
•TIPS FOR FLUSH MOUNTING •ELECTRICAL CONNECTION
The appliance must be plugged in using a
standardized power cable with 3 conductors
each 1 mm² ( 1 ph + 1 N + ground) which
must be connected to the 220~240 Volt
network by means of a standardized IEC
60083 power socket or a single-pole cut-off
device in compliance with installation
regulations. The safety wire (green-yellow) is
connected to the appliance's ground terminal
and must be connected to the installation's
ground lead.
The plug of the electrical outlet must be
accessible after installation.
TIP :Using a gas cooking appliance results in
the generation of heat and humidity in the
location where it is installed. Make sure that
your kitchen is well-ventilated: keep natural
ventilation openings in your home clear or install a
mechanical ventilation device (mechanical ventilation
hood). Intensive, prolonged use of the appliance
may require additional ventilation; you can, for
example, open a window or provide more effective
ventilation by increasing the power of the mechanical
ventilation system, if you have one. (A minimum air
flow of 2 m3/hr per kW of gas power is required).
Exemple : 60 cm - 4 feux gaz
(modèle avec brûleur grand rapide)
Puissance totale : 3,1 + 0,85 + 1,5 + 2,25 = 7,70 kW
7,70 kW x 2 = 15,4 m3/h of
minimum flow.
AA
AA
Fig. 01
Fig. 02
Mounting brackets
Screws
Underside view
of the housing
Mounting brackets
A
Cabinet
CROSS-SECTION OF CABLE TO BE USED
Neutral
(N)
Live
(L)
Ground
Blue wire
H05V2V2F
cable
Black, brown
or red wire
Green/yellow
wire
H05V2V2F cable - T90
Ref. SAV : 77x9060
Cross-section of
conductors in mm2
Fuse
220-240 V~- 50 Hz
3 conductors including
1 ground
1
10 A
Connect the wires to the electricity supply
making sure that the different-coloured wires
are in the right order.
1/ INSTALLING YOUR APPLIANCE EN
33

34
The gas connection must be installed in
compliance with applicable regulations in
the country of installation.
•Gas distributed via natural
gas pipes
For your safety, you must choose from the
three following connection options:
— Connection with a rigid pipe made
from copper and with screw-on mechanical
connectors (G1/2 gas standard mark).
Make the connection directly to the end of
the elbow fitted on the appliance.
— Connection with a wavy metal hose
(stainless steel) with screw-on mechanical
connectors whose service life is unlimited
(Fig. A).
— Connection with a reinforced
flexible rubber hose with screw-on
mechanical connectors whose service
life is 10 years (Fig. B).
WARNING
When connecting your hob’s
gas supply, if you have to change
the direction of the elbow fitted
on the appliance:
- Change the gasket.
Screw on the elbow’s nut,
careful not to exceed a torque of
17 N.m.
GAS CONNECTION
•Preliminary comments
If your hob is installed above an oven or if proximity to other heating elements poses a
threat of overheating the connection, you must insulate the cable in a rigid pipe.
If a hose or soft pipe (in the case of butane gas) is used, it should not come into contact
with a moving part of the cabinet, nor should it pass through a location that may become
blocked.
•
;
;
@
@




;
;
Q
Q


Fig. A Fig. B
EN 1 / INSTALLING YOUR APPLIANCE

35
• Gas supplied by tank or
cylinder (butane/propane)
For your safety, you must choose from the
three following connection options:
— Connection with a rigid pipe made
from copper and with screw-on mechanical
connectors (G1/2 gas standard mark).
Make the connection directly to the end of
the elbow fitted on the appliance.
— Connection with a wavy metal hose
(stainless steel) with screw-on mechanical
connectors whose service life is unlimited
(Fig. 01).
— Connection with a reinforced
flexible rubber hose with screw-on
mechanical connectors whose service
life is 10 years (Fig. 02).
A
B
Sealing washer (not provided)
Adaptor (not supplied)
Clamp (not provided)
C
WARNING
All soft pipes and hoses whose
service life is limited must have a
maximum length of two meters and
must be accessible along their entire
length. They must be replaced before
the end of their service life (indicated
on the pipe). Regardless of the means
of connection chosen, ensure that the
connection is air tight, after
installation, with soapy water.
In an existing system, a soft pipe fitted with
clamps whose service life is five years may
be used. It is necessary in this case to use
an adaptor without forgetting to fit a
sealing washer between the adaptor and
the hob’s elbow. (Fig. 03).
TIP
You can obtain the adaptor and the sealing
washer from your After-Sales ServicE
Department.
WARNING
Screw on the adaptor with a
torque not exceeding 25 N.m.
;
;
@
@




;
;
Q
Q


Fig. 01 Fig. 02 Fig. 03
A
B
C
1 / INSTALLING YOUR APPLIANCE EN

36
EN 1 / INSTALLING YOUR APPLIANCE
CHANGING THE GAS SUPPLY
WARNING
Your appliance is sold pre-set for
natural gas.
The injectors required for adaption to
butane/propane can be found in the
plastic bag containing this guide.
Each time you change the gas supply, you
must complete the following:
— Adapt the gas connection
— Change the injectors
— Adjust the hob connections.
• Adapt the gas connection : Refer to
the
“Gas Connection” section.
• Change the injectors, proceeding as
follows:
— Remove the pan supports, heads and
covers from all burners.
— Using the wrench provided, unscrew the
injectors located under each crucible and
remove them (Fig. 01).
— replace with the corresponding gas
injectors, in compliance with the
positionning of the injectors and the table of
gas properties at the end of this section ; to
do so:
— First screw them in manually until the
injector locks into place.
— Apply the wrench to the injector as far as
it will go.
— Draw a line on the burner plate using a
pencil at the place indicated (Fig. 02).
— Turn the wrench clockwise until the line
appears on the other side(Fig. 03).
Warning
Exceeding this limit may damage
the product.
- Reposition the burner heads, burner
covers and pan supports on the hob.
•TIP
Each time you change the gas supply,
tick the box corresponding to the new gas
level on the label found in the plastic bag.
Refer to the corresponding “Gas
Connection” section.
Fig. 02
Fig. 03
Line
Line
Wrench
Wrench
Fig. 01
Wrench
Injector
Crucible

37
• Adjust the hob connections: they are
located underneath the knobs (Fig. 04).
— Proceed one tap at a time.
— Remove the knobs and the gaskets by
pulling them up.
- Switching from natural gas to
butane/propane gas
- With a small flat-head screwdriver, screw
in all the way the brass (yellow) burner
power screws(Fig. 05), in a clockwise
direction.
- Replace the gaskets and the knobs,
paying careful attention to their direction
and ensuring that the knobs are pushed in
all the way.
- Switching from butane/propane gas to
natural gas
- Unscrew the brass (yellow) burner power
screws (Fig. 05), using a small flat-head
screwdriver, turn twice
counterclockwise.
-Replace the knob.
-Light the burner in maximum heat mode,
then turn down to reduced heat mode.
-Remove the knob again, then turn the
burner power screws clockwise until it
reaches the lowest possible setting that
does not extinguish the flame.
- Replace the gasket and knob.
-Make several attempts to shift from the
maximum flow rate to the minimum: the
flame should not go out; if it does,
unscrew the burner power screw so as to
obtain good flame retention during these
position switches.
- Reposition the burner heads, burner
covers and pan supports on the hob.
Fig. 05
Tap axis
Burner power
adjustment screw
1 / INSTALLING YOUR APPLIANCE EN
Knob
Ring
Gasket
Tap
Fig. 04

38
• Markings on the injectors
The adjacent table shows where the
injectors are positioned on your appliance
according to the type of gas used.
Each number is marked on the injector.
MODELS*
Example:
Injector marking 95
*See “Description of the Top” chapter
95
60cm Hob 3 gas burners + 1 electric plate
60 cm Hob 4 gas burners
30 cm Hob 2 gas burners
Natural Gas
137
94
Butane gas/
Propane
88A
62
Natural Gas
94 1R
137 63
Gaz butane/
Propane
62 7R
88A 45
Natural Gas
1R
137 63
Butane gas/
Propane
7R
88A 45
EN 1 / INSTALLING YOUR APPLIANCE

39
• Gas properties
Appareil destiné à être installé en : Butane Propane Gaz Gaz Butane Propane
FR........................cat : II2E+3+ naturel naturel
GB - PT ......................cat : II2H3+ G30 G31 G20 G25 G30 G31
DK ...............................cat : II2H3B/P
Hourly rate below: 28-30 mbar 37 mbar 20 mbar 25 mbar 30 mbar 30 mbar
at 15°C under 1013 mbar
HIGH-SPEED BURNER
Marking engraved on injector 7R 7R 1R 1R 7R 7R
Nominal heat release rate (kW) 2,15 2,15 2,25 2,25 2,15 1,94
Reduced heat release rate (kW) 0,830 0,870 0,870 0,830
Hourly rate (g/h) 156 154 156 138
Hourly rate (l/h) 214 249
SUPER-FAST BURNER
Marking engraved on injector 88A 88A 137 137 88A 88A
Nominal heat release rate (kW) 3,10 3,10 3,10 3,10 3,10 2,79
Reduced heat release rate (kW) 0,830 0,870 0,870 0,830
Hourly rate (g/h) 225 221 225 199
Hourly rate (l/h) 295 343
SEMI-FAST BURNER
Marking engraved on injector 62 62 94 94 62 62
Nominal heat release rate (kW) 1,50 1,50 1,50 1,50 1,50 1,35
Reduced heat release rate (kW) 0,620 0,615 0,615 0,620
Hourly rate (g/h) 109 107 109 96
Hourly rate (l/h) 143 166
AUXILIARY BURNER
Marking engraved on injector 45 45 63 63 45 45
Nominal heat release rate (kW) 0,70 0,70 0,85 0,85 0,70 0,63
Reduced heat release rate (kW) 0,300 0,350 0,350 0,300
Hourly rate (g/h) 51 50 51 45
Hourly rate (l/h) 81 94
HOB 4 GAS BURNERS
Total heat release rate (kW) 7,45 7,45 7,70 7,70 7,45 6,71
Maximum flow rate (g/h) 541 532 541 478
(l/h) 733 852
HOB 3+1 ELECTRIC PLATE 1500 W
WITH SUPER FAST
Total heat release rate (kW) 5,95 5,95 6,20 6,20 5,95 5,36
Maximum flow rate (g/h) 432 425 432 382
(l/h) 590 686
HOB 2 GAS BURNERS
Total heat release rate (kW) 4,60 4,60 4,60 4,60 4,60 4,14
Maximum flow rate (g/h) 334 328 334 295
(l/h) 438 509
FR - GB -PT FR - GB -
PT - DK FR DK
1 / INSTALLING YOUR APPLIANCE EN

40
DESCRIPTION OF THE TOP
•
(*) Power obtained with natural gas G20
Hob model: 4 gas burners Hob model: 2 gas burners
Model: 3+1 electric
A
B
C
D
E
Semi-fast burner 1.50 kW (*)
Auxiliary burner 0.85 kW (*)
High-speed burner 2.25 kW (*)
Super-fast burner 3.10 kW (*)
Electric plate diameter 145 - 1.5 kW
A
D
D
E D
B
D
A C
B
EN 2 / USING YOUR APPLIANCE

41
SWITCHING ON GAS BURNERS
Each burner is supplied by a tap which can
be opened by pressing it an turning it in a
counterclockwise motion.
The point “●”corresponds to a closed tap.
—Choose the desired burner by using the
symbols located near the knobs (e.g. : right
back burner ).
Your hob is fitted with a burner-lighting
system built into the knobs.
To light a burner :
— Press on the knob and turn it in a
counterclockwise direction to the
maximum setting .
—Continue to press on the knob to
produce a series of sparks until the burner
lights.
The setting for more moderate flame
intensities is between the symbol
and the symbol .
•
WARNING
— Hold the knob completely
pressed down for a few seconds after
the flame appears to trigger the safety
system.
Tip
When a knob becomes difficult to
turn, do not force it. Request an
emergency service call for the installer.
If the flame goes out accidentally, reignite
normally following the starter instructions.
2 / USING YOUR APPLIANCE EN
Fig. 01

42
•COOKWARE TO BE USED WITH GAS BURNERS
• Which burner should you use depending on your cookware?
WARNING
— Adjust the ring of flames so that
they do not extend beyond the edges of
the cookware (Fig. 01).
— Do not use concave or convex
cookware without the appropriate
supports (Fig. 02).
— Do not use cookware that partially
covers the knobs (Fig. 03).
— Do not leave a gas burner operating
with empty cookware.
— Do not use heat regulators, toasters,
steel meat broilers or stewpots that
have feet resting on or touching the
glass worktop
Diameter of the cookware
18 to 28 cm
16 to 22 cm
12 to 20 cm
8 to 14 cm
Diameter of the cookware
High-speed
speed
Semi-fast
Auxiliary
Use
Searing foods
Sauces - Reheating
Gentle simmer
GOOD BAD
CONVEX CONCAVE
Fig. 01
Fig. 02
Fig. 03
EN 2 / USING YOUR APPLIANCE

43
MOST SUITABLE COOKWARE
TO BE USED WITH THE
ELECTRIC PLATE (depending
on model)
Use cookware with flat bottoms that are
perfectly flush with the surface of the
burner:
— in stainless steel with a thick, tri-metal or
“sandwich” bottom,
— in aluminium with a thick (smooth)
bottom,
— in enamelled steel.
SWITCHING ON THE
ELECTRIC PLATE (depending
on the model)
Position the knob on the marking that
corresponds to the desired type of cooking
(Fig. 01) (see cooking guide at the end of
this guide). The cooking zone’s power
indicator lights up.
Upon first use, allow the plate to heat up
with no cookware at maximum power for 3
minutes to harden the coating.
TIP
— Use cookware of an appropriate size:
the diameter of the bottom of the
cookware should be equal to or greater
than the diameter of the electric cooking
plate (Fig. 02).
— When cooking is nearly finished, turn
the knob to the “O” off position to take
advantage of the heat accumulated in the
plate.
— Use a lid on your cookware as often as
possible to reduce the loss of heat by
evaporation.
•
•
Power
indicator
2 / USING YOUR APPLIANCE EN
Fig. 01
WARNING
- Do not operate an electric cooking
plate without cookware (except
during initial use) or with an
empty pot.
- The electric plate will remain hot for
a certain time after the knob has been
turned to the “O” position. Do not
touch this zone because there is a risk
of burning.
YES
NO
Fig. 02

44
PRODUCTS/ACCESSORIES
TO BE USED
. Small, hard-bristled brush.
. Safety pin
. Gentle scrubbing cream
. Cleaning sponge
. Commercially available
restorative product.
- Cleaning sponge.
- Special vitroceramic glass
products (e.g.: Cera-clean).
WARNING
Never clean your appliance while it is in operation. Set all the electric and
gas controls to zero.
TIP
— It is better to clean the parts of the hob by hand rather than in the dishwasher.
— Do not use an abrasive sponge to clean your hob.
— Do not use steam cleaning.
MAINTAINING YOUR APPLIANCE
•
WHAT TO DO
In the event that the spark plugs become
soiled, clean them using a small, hard-
bristled brush (non-metallic).
The gas injector is located in the centre
of the burner in the shape of a dish. Be
careful not to obstruct it during cleaning,
as this will undermine the performance
of your hob. In the event of obstruction,
use a safety pin to unclog the injector.
If tough stains occur, use a non-abrasive
cream, then rinse with clean water.
Carefully wipe each part of the burner
before using your hob again.
- The heating plate is protected by a
black coating, so you should avoid using
any abrasive products. After each use,
wipe it down with a thick cloth.
- If the plate rusts, remove it and restore
the black coating using a commercially
available high-temperature restorative
product.
- Clean with warm water and then wipe.
For tough stains, use products designed
for vitroceramic glass.
MAINTENANCE......
Of the spark
plugs and
injectors
Of the pan
supports and gas
burners
Of the electric
plate
Of the glass
worktop
EN 3 / DAILY CARE OF YOUR APPLIANCE
