Operator's Manual
Operator's Manual
34407
October 2007
Operator's Manual for:
Public Use Wheelchair Lifts
CJKA-**GB')
CJKA-**GB')
DOT — Public Use Lift
DOT — Public Use Lift
“DOT — Public Use Lift” verifies that this platform lift meets the
“public use lift” requirements of FMVSS No. 403. This lift may be
installed on all vehicles appropriate for the size and weight of the
lift, but must be installed on buses, school buses, and multi-
purpose passenger vehicles other than motor homes with a gross
vehicle weight rating (GVWR) that exceeds 4,536 kg (10,000 lb).
"Providing Access to the World"
International Corporate Hdqrs: P.O. Box 310 Winamac, IN 46996 USA
1-800-THE LIFT®[phone] FAX: [phone]
®
®
www.braunlift.com
31937
Braun UVL SeriesTM
Braun UVL SeriesTM
Under-Vehicle Lift®W
ARNING
Read manual
before operating
lift. Failure to do
so may result in
serious bodily
injury and/or
property damage.
Keep manual in
lift storage pouch.
Oper
ual
Man
ator's

Congratulations
We at The Braun Corporation wish to express our fullest appreciation
on your new purchase. With you in mind, our skilled craftsmen have designed
and assembled the finest lift available.
This manual includes safety precautions, lift operating instructions, man-
ual operating instructions, and instructions for maintenance and lubrication
procedures.
Your lift is built for dependability, and will bring you years of pleasure
and independence, as long as maintenance is performed regularly and the lift
is operated by an instructed person.
Sincerely,
THE BRAUN CORPORATION
Ralph W. Braun
Chief Executive Officer

Page 1
Contents
Warranty/Registration Instructions .................. 2, 3
Lift Terminology
Lift Terminology Illustration ........................................ 4
Introduction ................................................................ 5
Direction .................................................................... 5
Lift Components .................................................... 6, 7
Vehicle and Lift Interlocks ......................................... 7
Lift Actions and Functions .......................................... 8
Lift Operation Safety
Safety Symbols ......................................................... 9
Lift Operation Safety Precautions ...................... 10-14
Operation Notes and Details
Introduction/Lift Access Doors and Interlocks ......... 15
General Safety ......................................................... 16
Control Switches ..................................................... 16
Lift Features
Inner Roll Stop ............................................ 17, 18
Outer Barrier ............................................... 18, 19
Barrier, Handrail and Belt Manual Operation ........... 20
Handrail Operating Instructions ............................... 21
Lift Passengers
Passenger Orientation (Boarding Direction) ..... 22
Standees ........................................................... 22
Yellow Boundaries ...................................... 22, 23
Vehicle (Floor Level) Loading and
Unloading .................................................... 23, 24
Wheelchair-Equipped Occupant Seat Belts ..... 24, 25
Operation Procedure Review ................................. 25
Preventive Maintenance ......................................... 26
Lift Operating Instructions ............................. 27-29
NHTSA Operations Checklist .............................. 30
Manual Operating Instructions ....................... 31-35
Decals and Antiskid ........................................ 36-39
Maintenance and Lubrication ......................... 40-48

Page 2
Warranty and Registration Instructions
Immediately upon receiving your
lift, examine the unit for any
damage. Notify the carrier at
once with any claims.
Two warranty/registration cards
(shown below) are protected in a
clear envelope and attached to
the lift protective shipping wrap.
The sales representative must
process one of the cards. The
consumer must fill out the other
card and mail it to The Braun Cor-
poration. The warranty is provided
on the back cover of this manual.
The warranty cards must be pro-
cessed to activate the warranty.
Two Braun Serial No./Series No.
identification tags are posted on
the lift. One I.D. tag (shown below)
is located on the left platform side
plate (outboard end). A second
I.D. tag is located on the base of
the pump module. This I.D. tag
contains the product identification
information provided on the War-
ranty/Registration card. Record
the information in the space
provided on the next page. This
information must be provided
when filing a warranty claim or
ordering parts.
Sample
Serial No./Series No.
Identification Tag
The Braun Corporation
NUVL855RM24
01-00025
07/09/2007
1-800-THE-LIFT
BRAUNLIFT.COM
TM
MFG DATE
SERIAL NUMBER
TM
DOT Private Use Lift MODEL#
Max. Lifting Capacity - 700Lbs.
OWNER'S WARRANTY REGISTRATION
PURCHASED FROM
DATE INSTALLED
NAME
ADDRESS
CITY
TELEPHONE
TO VALIDATE WARRANTY
REGISTRATION CARDS MUST BE RETURNED TO THE BRAUN CORPORATION.
OWNER
STATE ZIP
NUVL855RM24 01-00025
Sample
Warranty/Registration
Card
Serial No.Model No.
Series No.

Page 3
Model No.
Series No.
Serial No.
Date of Manufacture
Note: This information must
be provided when filing a
warranty claim or ordering
parts. Keep for future use.
Warranty and Registration Instructions

Page 4
JKA
W
ARNING
81823
PushT-handleinfullyand
manuallymoveplatform in
andoutto engage platform
lockbeforedriving vehicle.
Failuretolock platformmay
resultinunintended platform
deployment.Unintended
platformdeploymentmay
resultinseriousbodilyinjury
and/orpropertydamage.
Donot remove!
Lift Mounting
Bracket
Clamps(6)
Hydraulic
Cylinders
Lifting
Arms
Rolling
Horizontal Arms
Outer Barrier
Actuator
Platform Cable-activated
Manual Release System
Inner
Roll Stop
Carriage
Torque
Tube
Platform
Lift Terminology
Illustration
Outboard
RightInboard
Left
Lift Housing
Two-Stage
Outer Barrier
Hand-held Attendants
Control Box
Manual Fold Shield
Handrails with Belt

Page 5
Lift Terminology
Braun NUVL Series lifts are
ADA compliant and comply
fully with National Highway
Traffic Safety Administration
(NHTSA) specifications. The
NUVL855RM24 is commercial
oriented (intended for operation
by an attendant).
Public Use NUVL lift models
provide fully automatic op-
eration of deploy (extend), up,
down and stow (retract) lift
functions. The NUVL855RM24
can be interfaced for fully au-
tomatic operation of the power
door system. Manual operating
procedures are required for the
shield handrails and interlock-
ing belt.
Refer to the Lift Terminology
Illustration for identification of
lift components.
Basic lift operation procedures
are identical for all NUVL Se-
ries lift models. The operating
instructions contained in this
manual address the lift control
switches and the correspond-
ing lift functions. Operating
procedures for the shield
handrails and interlocking belt
are provided. Instructions are
provided for manual operation
of the lift in event of power or
equipment failure.
Terminology: Become familiar
with the terminology that will be
used throughout this manual.
Become familiar with the iden-
tification of lift components and
their functions. Contact your lift
sales representative or call The
Braun Corporation at 1-800-
THE LIFT®if any of this informa-
tion is not fully understood.
Direction: The terms "left,"
"right," "inboard," and "outboard"
will be used throughout this
manual to indicate direction (as
viewed from outside the vehicle
looking directly at the lift). Refer
to the Lift Terminology Illustra-
tion for clarification of direction
terms.
Introduction:

Page 6
Lift TerminologyLift Terminology
regarding the control switches
and their functions are provided in
the Lift Operation section.
Lift Housing: The lift housing
is the metal structure (casing)
mounted under the vehicle which
contains and protects the platform
carriage assembly. The hous-
ing contains all lift components
except the power (pump) module
when the lift is in the stowed posi-
tion.
Platform Carriage Assembly:
The platform carriage assembly
includes the platform assembly,
the lifting arms, the rolling hori-
zontal arms that carry the plat-
form assembly in and out of the
housing and the electrical/hydrau-
lic drive components that power
the lift.
Platform Assembly: The lift
platform assembly consists of the
flat aluminum plate upon which
the wheelchair is positioned, the
outer barriers, the inner roll stop
and shield handrails.
Outer Barrier: The two-stage
outer barrier system consists of a
spring-loaded tall barrier and an
electric actuator-driven short bar-
rier. The two-stage outer barrier
provides a ramp for wheelchair
loading and unloading at ground
level. Photos and further details
are provided in the Operation
Notes and Details section (pages
18-21).
Inner Roll Stop: The NUV-
L855RM24 is equipped with an
automatic inner roll stop that also
serves as the bridge plate. The
Lift Components
Refer to the Lift Terminology Il-
lustration on page 4.
Pump Module: The remote
mounted pump module consists
of the main hydraulic pump, the
manual hand pump, the logic
control board and other electrical
components that power the lift
electric/hydraulic systems.
Hand-held Pendant Con-
trol: The hand-held pendant is
equipped with four push button
switches, (DOOR, STOW, DOWN
and UP). The momentary switch-
es activate the automatic lift
functions. Simply press the switch
labled for the intended function.
The lift function labels illuminate
to identify the function(s). Details

Page 7
Lift Terminology
cannot be stowed if occupied.
The lift platform cannot be raised
or lowered unless the roll stop
and outer barriers are deployed
(up).
Vehicle and Lift Interlocks
Braun Corporation NUVL Series
lifts comply fully with all NHTSA
vehicle and lift interlock speci-
fications. Vehicle movement is
prohibited unless the lift is fully
stowed and the lift will not func-
tion unless the vehicle is parked
and secured.
The NUVL855RM24 features
a visible and audible threshold
warning system that will activate
if the threshold area is occupied
when the platform is one inch or
more below floor level.
The inner roll stop and outer bar-
riers sense weight to prohibit lift
operation. The lift will not function
if the inner roll stop or outer barri-
ers are occupied. The lift platform
inner roll stop bridges the gap
between the lift platform and the
vehicle floor. The inner roll stop
automatically rotates from the
horizontal position to the verti-
cal position as the lift lowers and
raises. Further details regarding
the automatic mechanical inner
roll stop are provided on pages
17 and 18.
Platform Cable-activated Man-
ual Release System: A cable-
activated manual release system
releases the platform carriage
assembly drive chain to allow the
platform carriage assembly to be
manually moved out (extended)
or moved in (retracted), should it
be necessary. Complete details
and operating procedures are
provided on page 32.

Page 8
Lift Terminology
Lift Actions and Functions:
Deploy (Extend): Lift deploy-
ment is the action of the lift plat-
form carriage assembly extend-
ing (moving outward) from the
housing and lowering to ground
level when the DOWN switch is
activated or raising to floor level
when the UP switch is activated.
Stow (Retract): Stow is the
action of the lift platform and car-
riage assembly retracting (moving
inward) into the lift housing. Dur-
ing the stow function, the platform
will automatically raise or lower to
stow level before retracting into
the housing.
DOWN - Platform Lower: Down
is the action of the platform lower-
ing from stow or floor level posi-
tion to fully-lowered (ground level)
position when the DOWN switch
is pressed.
DOWN - Outer Barrier Un-
fold (Down) - When the plat-
form reaches the fully-lowered
(ground) position and the DOWN
switch is continued to be pressed,
the outer barriers rotate down-
ward from vertical position to
ramp position.
UP - Outer Barrier Fold (Raise):
From ground level, the UP func-
tion automatically raises (rotates)
the actuator activated outer bar-
riers to the upright (vertical) posi-
tion before the platform raises.
UP - Platform Raise: Up is the
action of the platform raising from
stow level or ground level to floor
level (fully-raised) position when
the UP switch is pressed. When
the lift is fully lowered, press-
ing the UP switch first raises the
outer barrier.
Note: The lift platform will not
raise if the outer barriers are not
in the upright (vertical) position.
This is a built in safety feature.
Stow Level: Stow level is the
height that the platform and car-
riage assembly moves in and
moves out of the lift housing.
Floor Level: Floor level is the
height that the platfom and car-
riage assembly raises to in order
for the wheelchair passenger to
enter and exit the vehicle (fully
raised position).

Page 9
Safety Symbols
Lift Operation Safety
SAFETY FIRST! Know That....
C
CAUTION
This symbol indicates
important information
regarding how to
avoid a hazardous
situation that could
result in minor per-
sonal injury or prop-
erty damage.
A
supplements (if included), is pro-
vided for your safety. Familiarity
with proper operation instructions
as well as proper maintenance
procedures are necessary to en-
sure safe, troublefree operation.
Safety precautions are provided
to identify potentially hazardous
situations and provide instruction
on how to avoid them.
All information contained
in this manual and B
W
ARNING
This symbol indicates
important safety
information regarding
a potentially hazard-
ous situation that
could result in serious
bodily injury and/or
property damage.
DNote: Additional information provided to help clarify or detail a specific subject.
These symbols will appear throughout this manual as well as on the labels posted on your lift. Recognize
the seriousness of this information.

Page 10
Lift Operation Safety Precautions
W
ARNING
If the lift operating
instructions, manual
operating instructions
and/or lift operation
safety precautions are
not fully understood,
contact The Braun
Corporation immedi-
ately. Failure to do so
may result in serious
bodily injury and/or
property damage.
Read manual and supplement(s) before operating lift. Read
and become familiar with all safety precautions, lift operation
notes and details, operating instructions and manual operat-
ing instructions before operating the lift. Note: Wheelchair
passengers and all transit agency personnel (drivers and
wheelchair lift attendants) must read and become familiar
with the contents of this manual and supplement(s) before
operation.
Load and unload on level surface only.
Engage vehicle parking brake before operating lift.
Provide adequate clearance outside the vehicle to accom-
modate the lift before opening lift door(s) or operating lift.
W
ARNING
Lift Operation Safety
W
ARNING
W
ARNING
W
ARNING
Inspect lift before operation. Do not operate lift if you suspect lift damage, wear or any
abnormal condition.
Keep operator and bystanders clear of area in which the lift operates.
W
ARNING
W
ARNING

Page 11
Whenever a wheelchair passenger (or standee) is on the platform, the:
• Handrail belt must be latched.
• Passenger must be positioned in the center of the platform.
• Wheelchair brakes must be locked
• Inner roll stop and outer barriers must be up (vertical)
• Passenger should grip both handrails (if able).
Load and unload clear of vehicular traffic.
Do not overload or abuse. The load rating applies to both the raising and lowering func-
tions - continuous lifting capacity is 700 lbs.
Discontinue lift use immediately if any lift or vehicle interlock does not operate properly.
Do not operate or board the lift if you or your lift operator are intoxicated.
Do not raise front wheelchair wheels (pull wheelie) when loading (boarding) the platform.
Open lift door(s) fully and secure before operating lift.
Position and secure (buckle, engage, fasten, etc.) the wheelchair-equipped occupant
seat belt (torso restraint) before loading onto the wheelchair lift platform.
Fold outer barrier and handrails down to platform before stowing lift.
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
Lift Operation Safety
W
ARNING

Page 12
Lift Operation Safety
Lift attendants must ensure that lift occupants keep hands,
arms and all other body parts within the lift occupant area
and clear of moving parts.
Platform must be positioned at floor level (bridging position)
when loading or unloading in and out of vehicle.
Do not use platform inner roll stop or outer barriers as a
brake. Stop and brake wheelchair when loading onto the
platform (manually stop and brake manual wheelchairs
— stop powered wheelchairs with the wheelchair controls).
Turn powered (electric) wheelchairs off when on lift platform.
Press the DOWN switch until the entire platform rests on
ground level (lowered fully) and the outer barriers are fully
unfolded (ramp position) before loading or unloading a pas-
senger at ground level.
W
ARNING
Lift Operation Safety Precautions (continued)
W
ARNING
If the lift operating
instructions, manual
operating instructions
and/or lift operation
safety precautions are
not fully understood,
contact The Braun
Corporation immedi-
ately. Failure to do so
may result in serious
bodily injury and/or
property damage.
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
Both outer barriers must be fully unfolded (ramp position) until front and rear wheelchair
wheels cross the barriers when loading or unloading at ground level.

Page 13
Lift Operation Safety
W
ARNING
Accidental activation of control switch(es) may cause unintended operation(s).
After manually releasing platform, stow platform and push manual release T-handle in fully
and move platform in and out to engage platform lock before driving vehicle. Failure to
lock platform may result in unintended platform deployment.
Insert manual relaese T-handle fully before manually lowering or raising platform and
manually move platform in and out to engage platform lock.
Maintenance and lubrication procedures must be performed as specified in this manual by
authorized (certified) service personnel.
Replace missing, worn or illegible decals.
Keep owner’s (operator's) manual in lift vehicle at all times.
Never modify (alter) a Braun Corporation lift.
Do not use accessory devices not authorized by The Braun Corporation.
Do not remove any guards or covers.
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING
W
ARNING

Page 14
Keep clear of any hydraulic leak.
Failure to follow these safety precautions may result in
serious bodily injury and/or property damage.
W
ARNING
W
ARNING
Lift Operation Safety Precautions (continued)
Lift Operation Safety
W
ARNING
If the lift operating
instructions, manual
operating instructions
and/or lift operation
safety precautions are
not fully understood,
contact The Braun
Corporation immedi-
ately. Failure to do so
may result in serious
bodily injury and/or
property damage.

Page 15
Operation Notes and Details
NUVL “Public Use” lift models are
specifically designed to be oper-
ated by an attendant. The Lift
Operating Instructions contained
in this manual and appearing on
the lift operating instructions decal
provide instructions for operation
of the lift only. Read and become
familiar with all lift operation safety
precautions, operation notes and
details, operating instructions and
manual operating instructions
before attempting lift operation
procedures.
Lift Access Doors and Inter-
locks: Attendants must become
familiar with the vehicle lift access
door system and vehicle interlock
system(s). Transit vehicles and
lift access door configurations
vary. Door securement devices
(latches, hooks, cables, etc.) and
procedures to operate them vary.
Instructions for operation of ve-
hicle interlocks and door secure-
ment systems are not addressed
in this manual or on lift-posted op-
erating instructions decals due to
the variety of procedures required
for operating them. Braun Cor-
poration NUVL Series lifts comply
fully with all NHTSA vehicle and lift
interlock specifications (detailed
on pages 18-23). Infringement
of any lift interlock will prohibit lift
operation.
It is the responsibility of the lift
operator (attendant) to properly
open, secure and close the vehicle
lift door(s), to activate the vehicle
interlock(s), to load and unload the
wheelchair passenger (or standee)
on and off the lift platform, and to
properly activate all lift functions.
W
ARNING
Read and become
familiar with all lift
operation safety
precautions, opera-
tion notes and details,
operating instructions
and manual operat-
ing instructions prior
to operating the lift.
If this information is
not fully understood,
contact The Braun
Corporation immedi-
ately. Failure to do so
may result in serious
bodily injury and/or
property damage.

Page 16
Operation Notes and Details
General Safety: The lift operator
(attendant) and bystanders must
keep clear of the area in which
the lift operates and clear of all
moving parts. Lift attendants
must ensure that lift occupants
(passengers) keep hands, arms
and all other body parts within
the lift occupant area and clear of
moving parts.
Control Switches
tions. Simply press the switch
labeled for the intended func-
tion. When there is power to
the lift, the lift function labels
illuminate to identify the func-
tions.
Lift Power ON/OFF Switch:
This switch must be in the ON
position in order to activate the
lift. The green Power Indicator
Light illuminates to signal power
to the lift.
Hand-held Pendant Control:
The hand-held attendent's
pendant control is equipped
with four push button switches
(DOOR, STOW, DOWN and
UP). The momentary switches
activate the automatic lift func-
DOOR STOW
DOWN UP
Hand-held Pendant

Page 17
Fully Deployed
(vertical)
Inner
Roll Stop
The inner roll stop must rest
solidly on the vehicle floor
(minimum 1½" overlap).
Fully Unfolded
(horizontal)
Inner Roll Stop
(bridging position)
Lift Features
Operation Notes and Details
Inner Roll Stop: The NUV-
L855RM24 is equipped with an
automatic inner roll stop that also
serves as a bridge plate. The
spring loaded inner roll stop auto-
matically deploys (rotates) to the
vertical position when the platform
extends from the stow position.
When the UP switch is pressed
and the platform raises to floor
level, this mechanical roll stop is
automatically rotated to the bridg-
ing (horizontal) position to provide
a bridge plate between the plat-
form and the vehicle floor. The
inner roll stop must rest solidly
on the vehicle floor (minimum
1½" overlap). The roll stop auto-
matically deploys (rotates) to the
vertical (roll stop) position as the
platform lowers (DOWN switch is
pressed).
Inner Roll Stop

Page 18
Operation Notes and Details
The inner roll stop automatically
folds down to the platform sur-
face (horizontal) during the stow
function (as platform retracts).
Interlock Feature: The inner roll
stop senses weight (pressure) to
prohibit lift operation. The lift will
not function if the inner roll stop
is occupied.
Discontinue lift operation im-
mediately if the inner roll stop
does not operate properly.
Outer Barrier: The two-stage
outer barrier provides a ramp for
wheelchair loading and unload-
ing at ground level (see photos
on following page). When the
platform lowers fully to ground
level, the electric actuator unfolds
(rotates) the barriers to the ramp
position (fully unfolded).
The tall outer barrier is spring
loaded but driven by the electric
actuator-powered short outer bar-
rier to rotate from the ramp (hori-
zontal) position to the deployed
(vertical) position.
Note: The tall outer barrier must
be manually raised and lowered
W
ARNING
Discontinue lift use
immediately if any
lift component does
not operate prop-
erly. Failure to do so
may result in serious
bodily injury and/or
property damage.
from the platform surface when
extending and retracting the
platform. Details are provided on
pages 20 and 21.
Although the outer barriers are
lift-powered, the activation of the
barriers are controlled by the lift
operator (attendant). Pressing
the DOWN switch unfolds the
barriers. The actuator-powered
two-stage outer barriers fold (ro-
tate) to the vertical position when
the UP swiitch is pressed.
Note: The lift platform will not
raise if the outer barriers are not
fully deployed (up).
Interlock Features: The outer
barriers sense weight to pro-
hibit lift operation. The lift will not
function if the outer barriers are
