BRAVILOR BONAMAT SPRSO User manual

Original document by manufacturer
700.470.010 (Digital manual - English)
ENGLISH MANUAL

Original document by manufacturer
All rights reserved.
No part of this document may be copied and/or published by means of printing, photocopying, microlming or by any other means whatsoever without the prior
written consent of the manufacturer. This also applies to the included drawings and/or diagrams.
The information in this document is based on data that was available at the time the design, the material characteristics and the operating methods were published,
meaning that this document is subject to change.
For this reason, the instructions are merely a guideline for the installation, maintenance and repair of the machine displayed on the front cover.
This document applies to the standard version of this machine.
The manufacturer therefore declines all liability for any damage arising from specications that deviate from the standard version of the machine delivered to you.
This document has been compiled with the utmost care. However, the manufacturer cannot be held liable for any errors it contains or the consequences thereof.

Original document by manufacturer
Table of contents
1. Parts and functions...........................................................1
1.1 Parts ...................................................................... 1
1.2 Optional parts .............................................................. 1
1.2.1 Milk unit ................................................................. 1
1.2.2 Waterlter............................................................... 1
1.3 Controls ................................................................... 2
2. First start ...................................................................3
3. Start up .....................................................................8
4. Standby .....................................................................9
5. Your beverage ............................................................. 10
5.1 Preparing your beverage .................................................... 10
5.2 Personalize your beverage .................................................. 11
5.3 Adjusting the tap height..................................................... 12
6. Cleaning................................................................... 13
6.1 Daily cleaning.............................................................. 13
6.1.1 Drip tray and waste bin ................................................... 13
6.2 Weekly cleaning............................................................ 14
6.2.1 Beverage outlet.......................................................... 14
6.2.2 Water tank .............................................................. 15
6.2.3 CIRCO brewer ........................................................... 16
6.2.4 The housing............................................................. 18
7. Program menu ............................................................. 19
7.1 Maintenance .............................................................. 20
7.1.1 Flushcoeesystem ...................................................... 21
7.1.2 Cleanmilksystem........................................................ 22
7.1.3 Cleancoeesystem ...................................................... 25
7.1.4 Flushmilksystem ........................................................ 29
7.1.5 Descale................................................................. 30
7.1.6 Waterlter.............................................................. 35
7.1.7 Reposition brewer axis ................................................... 39
7.1.8 Counters ............................................................... 42
7.1.9 Error history ............................................................ 44
7.2 Beverages................................................................. 45
7.2.1 Create your own ......................................................... 46
7.2.2 Edit default beverage..................................................... 49
7.2.3 Beverageproles ........................................................ 52
7.3 Machine .................................................................. 53

7.3.1 Milk unit ................................................................ 54
7.3.2 Brewtemperature ....................................................... 55
7.3.3 Altitude................................................................. 56
7.3.4 Automaticswitcho ..................................................... 57
7.3.5 Child lock ............................................................... 58
7.3.6 Brightness screen........................................................ 59
7.3.7 Sounds ................................................................. 60
7.3.8 Languages .............................................................. 62
7.3.9 Units ................................................................... 63
7.3.10 Water hardness ......................................................... 65
7.3.11 Reset to factory settings .................................................. 66
7.3.12 Machineandsoftwareinformation ......................................... 68
7.4 Online help................................................................ 69
8. Special conditions .......................................................... 70
8.1 Brewer(partially)missing(Error10015) ....................................... 70
8.2 Brewermalfunction(Error04104) ............................................ 73
9. Warning and errors messages ............................................... 77
9.1 Warningmessages ......................................................... 77
9.2 Errormessages ............................................................ 79
10. Appendix .................................................................. 81
10.1 Waterhardnessandlterinformation........................................ 81
10.2 Volumeperbeverage(S/M/L) .............................................. 81
10.3 Installawaterlter ......................................................... 82
10.4 Adjustingthecoeegrinder ................................................. 83
10.5 Connectingamilkunit ...................................................... 84
10.6 Installaxedwaterconnection .............................................. 86
10.7 Binfullmessage ........................................................... 87
10.8 Special functions ........................................................... 88

1
1.Parts and functions
1.1 Parts
1. Water tank
2. Lid (bean canister)
3. Bean canister and
Grinding wheel
4. Outlet
5. Driptray(complete)
5a. Waste bin
5b. Front plate
5c. Drip tray plate
5d. Drip tray
5e. Overowdriptray
6. Side/servicepanel
7. Identicationplate
8. CIRCO brewer
1.2 Optional parts
1.2.1 Milk unit
TheSprsoisabean-to-cupespressomachine.AsstandardtheSprsodoesnotoermilk-based
beveragessuchascappuccino.However,youcanconnectamilkunit/coolertotheSprso.Ifyou
connectamilkunittotheSprsoyoucanoerveadditionalbeverages:caelatte,espresso
macchiato,cappuccino,lattemacchiatoandhotmilkfoam.Howtoinstallthemilkunittothe
Sprso is described in section “10.5Connectingamilkunit”onpage84.
1.2.2 Water lter
ThewatertankoftheSprsocanbettedwithawaterlter.Waterltersarepurication
ltersystemsthatremovemineralswhichmakewaterhardandcausescale.Werecommend
customerstouseawaterlter.Awaterlterimprovesthequalityofyourbeverageand
decreaseslimescaletherewithoptimizingtheperformanceoftheSprso.Howtotthewater
lterintotheSprsoisdescribedinsection“10.3Installawaterlter”onpage82.
1
2
3
4
5
6
7
8
5a
5b
5c
5d
5e

2
Thereare4mainbuttonsforthenavigationoftheSprso(seebelow)and4buttonsto
personalize your beverage (see section “5.Yourbeverage”onpage10.)
1.3 Controls
Menu button:
• toentertheprogrammenu(pressandhold)
(see section “7.Programmenu”onpage19)
• to cancel the preparation of a beverage
►The menu button can be used to enter a menu or to ‘go
back’
Start / conrm:
• to start dispensing
• toconrmaselectionintheprogrammenu
Navigation buttons:
• toscrollthroughbeverages,menuoptions,settingsor
change a value
1.3a
1.3b
1.3c

3
Thisdocumentisapplicabletothemodelnumber(s):
• Sprso-0xx
UnpacktheSprsoandinspectfordamage
1. read the safety booklet
2. removethefoilfromthescreen
3. llthewatertank(backside)
4. llthebeancanister(ontop)
5. insert the plug in the power socket (ensure it is earthed),
6. to switch on the Sprso
7. follow the installation procedure shown on-screen
2.First start
Accessoriesinthepackaging:
• safety booklet
• quickstartguide
• brewer cleaning tablets
• sachet Renegite
• water hardness tester
• milkconnector
• milkhose
• milkcleaningtablets

4
Selectvolumeunits:
• press <or > to choose the units to use
• press starttoconrm
Read the safety book!
• press starttoconrmor
• press <to go back to change the language
Selectyourlanguage:
• press <or >to scroll through the available languages
• press starttoconrm
2a
2b
2c
2d
Starttheinstallationprocedure:
• after a few seconds the language selection screen will
appear

5
Fill the bean canister (A)
and the water tank (B)
• press starttoconrm
►The water tank must


Never use warm or hot

2e
Selectyourwaterhardness:
• press <or >to choose one of the 5 settings
• press starttoconrm
►






Waterlter(optional):
• press <or >tochooseno/yes
• press starttoconrm
►
2f
2g
A
B
2h
Beverageproles:
• press start to go to the selection screen
►

6
TheSprsomustbeushed:
• putabigmugunderneaththeoutletoremptythedrip
tray after the installation procedure
• press starttoconrm.
►
►

Fillthemilkunit:
• press starttoconrm
2i
2j
2k
2l
Milkunit:
• press <or >tochooseno/yes
• press starttoconrm
►
Selectaprole:
• press <or >tochoosebetweenthethreeproles
• press starttoconrm
►

7
Therstinstallationprocedurehascompleted.
• emptythedriptrayifyoudidnotuseabigmugto
collecttheushingwater
The Sprso is ready for use.
►


Flushing:
►



►clean milk
system daily

2m
2n

8
TheSprsoushesforashortperiodoftimewhenthe“rststart”iscompletedandeverytime
the Sprso is switched on.
►no
►

3.Start up
The screen blinks orange and
black.
• after a few seconds the
Sprsostartstoush
►±


►clean milk
system daily

The Sprso is ready to use
3c
3b
3a

9
TheSprsodoesnothaveapowerbutton,butyoucanmanuallyputthemachineintostandby
modeatanytime.
Instandbymodeallfunctionsareswitchedoonlythestartbuttonkeepsashingslowly.
Toactivatethemachinepressthestartbutton.
►
4.Standby
Startthe‘standbymode’:
• pressandholdthe‘startbutton’
• thenecessaryusheswillbedonewhenenabled/
required
The screen blinks orange and
black.
• after a few seconds the
Sprsostartstoush
►±


►clean milk
system daily

The“goodbye”screenremainsactiveforafewseconds,
after which only a slowly blinking start button is visible.
►
4a
4b
4c

10
5.Your beverage
5
5.1 Preparing your beverage
Press startandtheSprsopreparesimmediatelytheselectedbeverage.
To cancel a selected beverage press ≡
Thefollowingindicatorsmayappearonthescreenduringthebrewingprocess:
Indicators Meaning
busy preparing your beverage
brewerstillbusy,nextactionisbrewingyourcoee
canceling your beverage
emptywastebin(ME05),seesection9.1
replacewaterlter(ME09),seesection7.1.6
clean brewer (ME08), see section 7.1.3
descalemachine(ME11),seesection7.1.5
►
Press the navigation buttons (<or >) to scroll through the available beverages.
TheSprsohas3beverageprolestochoosefromduringinstallationorselectanotherprole
in section “7.2.3Beverageproles”onpage52.
Theseproleoerthesamebeverages,thougheachprolehasanuniquecombinationof
volumeandstrengthofthebeverages.
Theavailablebeveragesare:
Standard Additional beverages
(connected milk unit)
espresso espressomacchiato
ristretto cappucinno
lungo cappucinno dark
americano lattemacchiato
hot water caèlatte
hotmilkfoam
5.1

11
• press <or > to adjust the
volume
►


beverage
5.2 Personalize your beverage
►
5.2
5.2a
5.2b
• press again to adjust
yourintensesetting:
» disabled or
» enabled
►


• press <or > to adjust your
strength
►

strength
Beverage size
Strength / Intense Strength
Intense

12
• press and hold for your
hot water
►

• Espresso
• Ristretto
• Lungo
• press if you want
2 cups to be prepared
simultaneously
5.2c
5.2d
Hot water (free ow function)
Single / double cup
5.3 Adjusting the tap height
►
80 - 115 mm

13
6.Cleaning
ItisimportanttokeeptheSprsoclean.
TheSprsohastwoushingproceduresthatstartautomatically.
Screenmessagesarealsogeneratedindicatingthataspeciccleaningprocedureshouldbe
started, see “7.1Maintenance”onpage20.
Inaddition,itisrecommendedtomanuallycleancertainparts:
Daily Weekly
drip tray and waste bin beverage outlet
water tank
CIRCO brewer
the outside
►
►
►
Whenthemessage appears on the
display, clean the drip tray parts.
1. pullthecompletedriptrayforward
2. emptyboththedriptrayandwastebin
6.1 Daily cleaning
6
6.1.1 Drip tray and waste bin
6.1.1
6.1.1a
6.1.1b
►

3. detachthefrontplatefromthedriptray
4. clean with 
» the drip tray
» drip tray plate
» waste bin
5. clean with :
» the front plate
» the area where the drip tray slides in
6. dry everything and put it back in place

14
1. removetheplug,bypullingittotheright
►

3
2
1
6.2 Weekly cleaning
6.2
2. press the buttons on both sides
3. removetheoutletbypullingitdownwards
4. clean the outlet parts using 
►no
►
5. dry everything
6.2.1 Beverage outlet
6.2.1
6.2.1a
6.2.1b
6.2.1c
Weeklycleanthefollowingpartsmanually:
• beverage outlet
• water tank
• CIRCO brewer
• the outside

15
1. emptythewatertank
2. removethewaterlter(ifpresent)
3. clean the water tank with hot water and a non-
abrasive brush
4. dry the outside of the water tank with a soft cloth
5. llthewatertankwithfreshcoldnon-carbonated
water and replace
6. return everything to its original position
6.2.2 Water tank
6.2.1d
6.2.2
6.2.2a

16
1. open the service panel
2. turn the lock counter clockwise
3. removetheCIRCObrewer
6.2.3 CIRCO brewer
6.2.3
6.2.3a
6.2.3b
6.2.3c
Inadditiontothexedcleaningprogram(seesection7.1.3 on page 25), you can also
manuallycleantheCIRCObrewerasshownbelow.
4. cleantheinsideoftheservicecompartmentwitha
dampcloth
