BREE LIGHTING BR-FL10W-07 User manual

< Specifications. > Version:A0
(PIC)
Model No.
Item Power Input Voltage Input Frequency Leds PowerFactor LuminousFlux BeamAngle Weight
BR-FL10W-07(ID:TC) 10W AC100-240V 50/60HZ SMD5630 >0.9 800 Lm 120 0.51 kg
BR-FL20W-07(ID:TC) 20W AC100-240V 50/60HZ SMD5630 >0.9 1600 Lm 120 0.93 kg
BR-FL30W-07(ID:TC) 30W AC100-240V 50/60HZ SMD5630 >0.9 2550Lm 120 1.61 kg
BR-FL50W-07(ID:TC) 50W AC100-240V 50/60HZ SMD5630 >0.9 4250 Lm 120 2.45 kg
Light Source Spec
LEDType
ColorAccuracy(CRI)
Color
Environment Spec.
OperationalTemperatureRange
PreservationTemperatureRange
OperationalHumidityRange
InstallationArea
Lifespan
Dimension Diagram
BR-FL30W-07(ID:TC) BR-FL50W-07(ID:TC)
3Years
Certification standard
BR-FL10W-07(ID:TC) BR-FL20W-07(ID:TC)
-20~50
-40~60
95%Rhorbelow(@-20 C~50 C)
Outdoor:IP65(Roadway, Pathway, Sidewalk,etc)
PhotoelectricSpec
Epistar
CRI>70
WW(3000-3500K)NW(4000-4500K)CW(5000-6500K)
BR-FL10W-07(ID:TC) BR-FL20W-07(ID:TC) BR-FL30W-07(ID:TC) BR-FL50W-07(ID:TC)
www.breelighting.com
www.breegroup.com

Optical Spec
BR-FL50W-07(ID:TC)
BR-FL10W-07(ID:TC)
BR-FL20W-07(ID:TC)
BR-FL30W-07(ID:TC)
Radiation LuxDiagram
Radiation LuxDiagram
Radiation LuxDiagram
Radiation LuxDiagram
www.breegroup.com

Installation and use
Packing Spec
Gross weight Pcs/box Gross weight Pcs/carton
BR-FL10W-07(ID:TC) 0.57 kg 115.2kg 24
BR-FL20W-07(ID:TC) 1kg 117.4kg 16
BR-FL30W-07(ID:TC) 1.8kg 115.8kg 8
BR-FL50W-07(ID:TC) 2.54 kg 116.6kg 6
L305*W260*H95 L540*W325*H315
Through the720H acceleratedaging test,high and lowtemperatureprediction intheratedundertheworking conditionsafter35000H,will providean
average70%opticmaintenance ratio(L70).
Item
Remarks
1.Whitelight series: WW (3000-3500K)NW(4000-4500K)CW(5000-6500K)
2.Luminousfluxtolerancefor ±10%
3.Productsshall besubject toanychangeswithout priornotices.
L205*W170*H75 L430*W360*H335
L253*W220*H85 L460*W275*H375
Measurement（mm）Measurement(mm)
L165*W135*H70 L430*W350*H315
Attention
1.Please turnoff thepowersupplybeforinstallation orchanging assemblyparts.
2.Theinputvoltageand thelampshouldbeadapted. Afterconnecting thepowerline, please make surethewiring section isinsulated.
3.Non-professionals, mustnotinstall ordismantlethelamps.
4.All thefloodlightsduring installation and inuse shouldnotbeputwithglass coververticallyupside.
Box Carton
3.Connect the powerwirefromthe Mainlinetothe powerwireof the lamp,andthen
maketreatment forwaterreistance. Plsnotethat the BrowncolorwireisLivewire,Blue
wireisNull line,the yellowandgreen wireisEarthline.
4.Turnon the powersupplytoensuerthe light isworking,Installed.
1.First,adujust the angleyou need,finallyfasten the floodlightswithscrews 2.Install the LEDFloodlight ontothe wall orground,punchholeon the wall orground,prepare
the expansion screw,andthen fasten the floodlight
360
340
Light attenuationmap
0.86
0.88
0.9
0.92
0.94
0.96
0.98
1
0 90 180 270 360 450 540 630 720 (Hours)
RelativeLuminousFlux
