BREL BPE User manual

Pagina 1
Manual Brel Bi-directional electronic radio motor
Type BPE
Read the manual before you begin the installation. If these instructions are not followed
this may lead to defects and injury in which warranty can’t be claimed.
Warning:
Children cannot recognise the dangers of this electrical equipment and should therefore not work with it.
It is important to follow this manual carefully for your own safety.
1. Do not work with the motor in humid environments.
2. The motor must be installed correctly.
3. eep the antenna in good condition and do not shorten it.
The antenna must not come into contact with other
metal parts otherwise the operation will be reduced.
4. The motor must be protected against direct moisture.
5. BREL-Motors declares that this motor has been manufactured
according to the guidelines of the CE standard 1999/5/EC.
_______________________________________________________________________________
Functions remote control Changing batteries
DD-2702H
Works with all BREL transmitters:
Visit our website www.BREL-HOME.com
for more manuals and information
__________________________________________________________________________________
Technical data of the motor BLE25-1.5 BLEQ28-2
 Motor voltage: DC 100-240V DC 100-240V
 Power: 13 W 18 W
 Torque: 1.5 Nm 2 Nm
 Speed: 32 rpm 28 rpm
 Amperage: 0.15 A 0.5 A
 Moisture and dust: IP20 IP20
 Storage capacity is up to 20 channels:
 Working temperature of the motor:
o Heavy use: -10℃ tot +40℃
o Normal use: -20℃ tot +70℃
Scan the QR code here for the manual
to download and view instructional videos

Page 2
______________________________________________________________________________
Reach L1 = 100 meter L2 = 25 meter
_______________________________________________________________________________
Functions Wiring
BPE25
Antenna------
Micro-USB---------
P1 ------------------ BPE25
ON/OFF --------
BPEQ28
Charging plug ------ Antenna --------
BPE28
P1 -----------
_______________________________________________________________________________
Installing the motor
Attach the crown and wheel to the motor and place the clip on the shaft of the motor so that the wheel
is fixed to the motor.
Install the motor with the motorbracket on the product and take care that it is secured.
Place the motor in the tube of the roller/shutter.(These assemblies are usually already done in the factory)
During programming the motor; the following must be done within 10sec. After 10 sec. the motor will quit the
programming mode.
EMERGENCY CONTROL: If a transmitter has been paired and the end positions determined in the motor,
you can use the P1 key as the control key.
_______________________________________________________________________________
Step 1 Setting up the first remote/channel
P1 until 



 STOP until 2x 




OK
Hold down the P1 button until the Press and hold the STOP button until the product Transmitter/channel
product moves up and down. The motor beeps. moves 2x up and down and beeps 3x. has been set.
If NO end positions are set the product will move in the pulse / step operation. Go then to STEP 2.
I end positions are set, the product will continue to its end position. Go then to STEP 4.
WARNING: It is possible that the correct end positions have not been set. Go then to OPTION A.

Page 3
______________________________________________________________________________
Step 2 Adjusting the direction of rotation(Only if the direction of rotation is not correct)
Only possible i no end positions are set, otherwise irst option B (Delete end positions), a ter that, Step 2.
▲+▼ until 1x 




OK
Press UP and DOWN button The direction of rotation of
Simultaneously, until the product moves. the motor is OK.
_______________________________________________________________________________
Step 3 Setting the end limits
1. Set the desired top position.


 ▲+ STOP 2x 




OK
Use the OPERATING- buttons to Press UP and STOP simultaneously, The desired top
move the product to the desired top position. until the product moves 2x and beeps 3x. position is set.
1. Set the desired bottom position.


 STOP+▼ 2x




OK
Use the OPERATING- buttons to move Press DOWN and STOP simultaneously, The desired bottom
the product to the desired bottom position. until the product moves 2x and beeps 3x. position is set.
_______________________________________________________________________________
Step 4 Setting the desired third limit position (If desired)


 1x P2 1x 



 1x STOP 1x 



 1x STOP 2x 




OK
Set the desired Press 1x P2. Press 1x STOP button. Press 1x STOP button.
Third limit The product moves 1x The product moves 1x The product moves 2x up
position. up and down and beeps. up and down and beeps. and down and beeps 3x for confirmation.
Press and hold STOP or 3 seconds to move to the set limit position.
______________________________________________________________________________
Additional settings
____________________________________________________________________________
Option A Adjusting the top position
If adjustment is not possible go to Option B then to Step 3.


 STOP +▲ until 



 

 STOP +▲ until 2x 




Go to the already Press at the same time Go to the new Press at the same time
set top position, STOP and UP until the top position. STOP and UP button, until
motor moves and beeps 1x. the motor 2x moves and 3x beeps.

Page 4
___________________________________________________________________________
Adjusting the down position
If adjustment is not possible go to Option B then to Step 3.


 STOP +▼ until 



 

 STOP +▼ until 2x 




Go to the already Press at the same time Go to the new Press at the same time
set bottom position, STOP and DOWN until bottom position. STOP and DOWN button, until
the motor moves and beeps 1x. the motor 2x moves and 3x beeps.
______________________________________________________________________________
Option B Deleting the end limits
1x P2 1x 



 1x ▼ 1x 



 1x P2 2x 




OK
Press 1x P2. The product Press the DOWN button. Press P2. The product The end positions
moves up down and beeps 1x. The product moves 1x moves 2x up and down are now deleted
up and down and beeps 1x. and beeps 1x. from the memory.
_______________________________________________________________________________
Option C Deleting the third limit position
1x P2 1x 



 1x STOP 1x 



 1x STOP 1x 




OK
Press 1x P2. Press 1x STOP button. Press 1x STOP button.
The product moves 1x up The product moves 1x up The product moves 1x up and
and down and beeps 1x. and down and beeps 1x. down and beeps 1x for confirmation.
_______________________________________________________________________________
Option D Learn new transmitter/channel while maintaining end limits.
Only possible when end limits are set.
= Already existing transmitter = New transmitter
Method 1
P2 a until 



 P2 a until 



 STOP b until 2x 




OK
Press P2 of a. The product Press P2 of a. The product Press STOP of b. The product The transmitter b
moves 1x up and down moves 1x up and down moves 2x up and down has been added.
and beeps 1x. and beeps 1x. and beeps 3x.
Method 2(also sun- and windmeter)
P2 a until 



 P2 a until 



 P2 b until 2x 




OK
Press P2 of a. The product Press P2 of a. The product Press P2 of b. The product The transmitter b
moves 1x up and down moves 1x up and down moves 2x up and down has been added.
and beeps 1x. and beeps 1x. and beeps 3x.
Repeating the above will remove the new transmitter/channel.

Page 5
Method 3 (in case the old transmitter is lost or broken)
P1 until 



 STOP b until 2x 




OK
Press P1 of a. The product moves 1x Press 1x STOP of b. The product The transmitter b
up and down and beeps 2x. moves 2x up and down and beeps 3x. has been added.
_______________________________________________________________________________
Option E Pulse / jog control
1x 



 beeps 1x
▲+▼ until 1x 



 1x STOP
Pulse / jog on
Pulse / jog off
Press and hold UP and DOWN button, Press 1x STOP button.
until the product moves up and down.
2x 



 beeps 3x
______________________________________________________________________________
Option F Speed control
1x 

 A 1x 

 A
1x P2 A until 



 O
Press 1x up of A. Press 1x up of A. The motor speed
has been increased
1x 

 A 1x 

 A
O
Press P2 of a. The product Press 1x down of A. Press 1x down of A. The motor speed
moves 1x up and down. toets A in. toets A in. has been reduced.
I the motor does NOT react a ter this action, it is already at the highest or lowest speed.
There are 3 di erent speeds; Namely: 24 rpm 

 1x



 - 28 rpm 

 2x



 - 32 rpm 

 3x



.
______________________________________________________________________________
Option G Sun and wind meter ( DD-116H )
_______________________________________________________________________________
Add / remove
1x P2a 1x 



 1x P2a 1x 



 1x P2b 2x 




The sun and wind meter has been added.
Press P2 of a. The product Press P2 of a. The Press P2 of b. The
moves 1x up and down and product moves 1x up product moves 2x up
beeps 1x. and down and beeps 1x. and down and beeps 3x.
By repeating the above, you can remove the sun and wind meter again.

Page 6
_______________________________________________________________________________
On / off sun function ( Factory setting = on)
1x P2 1x 



 1x P2 1x 



 1x ▲ 




ON: The product moves up and down once and beeps once long.
OFF: The product moves up and down 2x and beeps 3x long.
Press 1x P2. The product Press 1x P2. The Press 1x UP.
moves 1x up and down and product moves 1x up
beeps 1x. and down and beeps 1x.
By repeating the above, you can switch the sun unction on or o again.
_______________________________________________________________________________
Additional settings P1 button Can be used without a transmitter as an operating button
1x P1
The product moves up stops or goes down when pressed P1
Press 1x P1 on the motor.
_______________________________________________________________________________
Switching off the receiver
P1 (6 sec.) until 2th x 




OK
Press and hold P1 until the product moves The Receiver switched off.
up and down for the 2th time and beeps 2x.
To reactivate the receiver, brie ly press P1 once.
______________________________________________________________________________
Changing the direction of rotation
P1 (10 sec.) until 3th x 




OK
Press and hold P1 until the product moves The direction of rotation has changed.
up and down for the 3th time and beeps 3x.
_______________________________________________________________________________
Resetting to factory settings
P1 (14 sec.) until 4th x 




OK
Press and hold P1 until the product moves Resets to factory settings
up and down for the 4th time and beeps 4x.
