Oriental motor CVK Series User manual

1
Introduction
Before use
Only qualied personnel of electrical and mechanical engineering should
work with the product.
Use the product correctly after thoroughly reading the "Safety precautions."
In addition, be sure to observe the contents described in warning, caution,
and note in this manual.
The product described in this manual has been designed and manufactured
to be incorporated in general industrial equipment. Do not use for any other
purpose. Oriental Motor Co., Ltd. is not responsible for any damage caused
through failure to observe this warning.
Overview of the product
This product is a motor and driver package consisting of a board type
microstepping driver equipped with the smooth drive function and a
stepping motor designed for high-torque and low-vibration.
Operating Manuals for the CVK Series
Operating manuals for the CVK Series are listed below. Use the product
properly after carefully reading the operating manual.
•Motor
y2-phase Stepping Motor PKP Series OPERATING MANUAL
y5-phase Stepping Motor PKP Series OPERATING MANUAL
•Driver
y2-phase and 5-phase Stepping Motor and Driver Package CVK Series
OPERATING MANUAL Driver (this document)
Safety precautions
The precautions described below are intended to prevent danger or injury
to the user and other personnel through safe, correct use of the product.
Use the product only after carefully reading and fully understanding these
instructions.
Description of signs
Handling the product without observing the instructions
that accompany a "Warning" symbol may result in serious
injury or death.
Handling the product without observing the instructions
that accompany a“Caution”symbol may result in injury
or property damage.
The items under this heading contain important handling
instructions that the user should observe to ensure safe
use of the product.
HM-60119-7
OPERATING MANUAL Thank you for purchasing an Oriental Motor product.
This Manual describes product handling procedures and safety precautions.
yPlease read it thoroughly to ensure safe operation.
yAlways keep the manual where it is readily available.
2-phase and 5-phase Stepping Motor and Driver Package
CVK Series Driver MSIP-REM-OMC-075
MSIP-REM-OMC-076
Description of graphic symbols
Indicates "prohibited" actions that must not be performed.
Indicates "compulsory" actions that must be performed.
yDo not use the product in explosive or corrosive environments, in
the presence of ammable gases, locations subjected to splashing
water, or near combustibles.
This may cause re or injury.
yDo not forcibly bend, pull or pinch the cable.
This may cause re.
yDo not turn the AWO input to ON while the motor is operating.
This may cause injury or damage to equipment.
yDo not disassemble or modify the product.
This may cause injury.
yAssign qualied personnel the task of installing, wiring, operating/
controlling, inspecting and troubleshooting the product.
Failure to do so my result in re or injury.
yIf this product is used in a vertical application, be sure to provide a
measure for the position retention of moving parts.
Failure to do so may result in injury or damage to equipment.
yWhen the driver generates an alarm (any of the driver's protective
functions is triggered), rst remove the cause and then clear the
alarm (protective function).
Continuing the operation without removing the cause of the
problem may cause malfunction of the driver, leading to injury or
damage to equipment.
yInstall the product in an enclosure.
Failure to do so may result in injury.
yKeep the driver’s input-power voltage within the specied range.
Failure to do so may result in re.
yFor the driver power supply use a DC power supply with reinforced
insulation on its primary and secondary sides.
Failure to do so may result in electric shock.
yConnect the cables securely according to the wiring diagram.
Failure to do so may result in re.
yTurn o the driver power in the event of a power failure.
Failure to do so may result in injury or damage to equipment.
Introduction .................................................1
Safety precautions ......................................1
Precautions for use......................................2
General specications ................................2
Regulations and standards........................2
Preparation...................................................2
Installation....................................................3
Connection ...................................................4
Setting .........................................................10
Inspection ...................................................11
Alarms..........................................................11
Accessories..................................................12

2
yDo not use the product beyond its specications.
This may cause injury or damage to equipment.
yKeep your ngers and objects out of the openings in the product.
Failure to do so may result in re or injury.
yDo not touch the product while operating or immediately after
stopping.
This may cause a skin burn(s).
yDo not forcibly bend or pull the cable that was connected to the
driver.
Doing so may cause damage.
yKeep the area around the product free of combustible materials.
Failure to do so may result in re or a skin burn(s).
yLeave nothing around the product that would obstruct ventilation.
Failure to do so may result in damage to equipment.
yDo not touch the rotating part (output shaft) while operating the
motor.
Doing so may result in injury.
yUse a motor and driver only in the specied combination.
Failure to do so may result in re.
yProvide an emergency stop device or emergency stop circuit
external to the equipment so that the entire equipment will
operate safely in the event of a system failure or malfunction.
Failure to do so may result in injury.
yBefore supplying power to the driver, turn all input signals to the
driver to OFF.
Failure to do so may result in injury or damage to equipment.
yBefore moving the motor directly with the hands, conrm that the
AWO input turns ON.
Failure to do so may result in injury.
yWhen an abnormal condition has occurred, immediately stop
operation and turn o the driver power.
Failure to do so may result in re or injury.
yDispose the product correctly in accordance with laws and
regulations, or instructions of local governments.
Precautions for use
•When conducting the insulation resistance measurement and
the dielectric strength test, be sure to separate the connection
between the motor and the driver.
Conducting the insulation resistance test or dielectric strength test with the
motor and driver connected may result in damage to the product.
•Regeneration
When a large load inertia is operated at a high speed, the power supply
voltage may increase by the regenerated energy generated, causing an
alarm of overvoltage to generate. This may result in damage to the driver, so
reconsider the operating condition so as not to generate the regenerative
voltage.
General specications
Operation
environment
Ambient
temperature
0 to +50 °C (+32 to +122 °F)
(non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 1000 m (3300 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Storage
environment,
Shipping
environment
Ambient
temperature
−25 to +70 °C (−13 to +158 °F)
(non-freezing)
Humidity 85% or less (non-condensing)
Altitude Up to 3000 m (10000 ft.) above sea level
Surrounding
atmosphere No corrosive gas, dust, water or oil
Regulations and standards
CE Marking
zLow Voltage Directive
Although this product is exempt from the Low Voltage Directive since
the input power supply voltage is 24 VDC, perform the installation and
connection as follows.
yThis product is designed and manufactured to be incorporated in
equipment. Be sure to install the product in an enclosure.
yFor the driver power supply, use a DC power supply with reinforced
insulation on its primary and secondary sides.
zEMC Directive
This product is conducted EMC testing under the conditions specied in
"Example of motor and driver installation and wiring" on p.10. The conformance
of your mechanical equipment with the EMC Directive will vary depending
on such factors as the conguration, wiring, and layout for other control
system devices and electrical parts used with this product. It therefore must
be veried through conducting EMC measures in a state where all parts
including this product have been installed in the equipment.
Applicable Standards
EMI EN 61000-6-4, EN 55011 group 1 class A
EMS EN 61000-6-2
This equipment is not intended for use in residential
environments nor for use on a low-voltage public network
supplied in residential premises, and it may not provide
adequate protection to radio reception interference in
such environments.
Republic of Korea, Radio Waves Act
This product is axed the KC Mark under the Republic of Korea, Radio Waves
Act.
RoHS Directive
The products do not contain the substances exceeding the restriction values
of RoHS Directive (2011/65/EU).
Preparation
Checking the product
Verify that the items listed below are included. Report any missing or
damaged items to the branch or sales oce from which you purchased the
product.
yDriver................................................................. 1 unit
yOPERATING MANUAL .................................. 1 copy (this document)
yConnector housing/contact ..................... 1 set
(Packed in a bag; see table below.)
Application Housing (Molex) Contact (Molex)
For power supply (CN1) 1 pc. 51103-0200 (2-poles)
19 pcs.
50351-8100
For motor (CN2) 1 pc. 51103-0500 (5-poles)
For I/O signals (CN3) 1 pc. 51103-1200 (12-poles)
When removing the driver from the ESD protection bag, make sure
your hands are not charged with static electricity. This is to prevent
damage to the driver due to static electricity.

3
Combinations of motors and drivers
in the model names indicates A(single shaft) or B(double shaft).
z2-phase motor
•Standard type
Model Motor model Driver model
CVK213KPKP213D05CVD205-K
CVK223KPKP223D152 CVD215-K
CVK225KPKP225D152 CVD215-K
CVK233KPKP233D23CVD223-K
CVK235KPKP235D23CVD223-K
CVK243KPKP243D23CVD223-K
CVK244KPKP244D23CVD223-K
CVK245KPKP245D23CVD223-K
CVK246KPKP246D23CVD223-K
CVK264KPKP264D28CVD228-K
CVK266KPKP266D28CVD228-K
CVK268KPKP268D28CVD228-K
z5-phase motor
•Standard type
Model Motor model Driver model
CVK523KPKP523N12CVD512-K
CVK525KPKP525N12CVD512-K
CVK544KPKP544N18CVD518-K
CVK546KPKP546N18CVD518-K
CVK564FKPKP564FN24W CVD524-K
CVK566FKPKP566FN24W CVD524-K
CVK569FKPKP569FN24W CVD524-K
•High-resolution type
Model Motor model Driver model
CVK544MKPKP544MN18CVD518-K
CVK546MKPKP546MN18CVD518-K
CVK564FMKPKP564FMN24CVD524-K
CVK566FMKPKP566FMN24CVD524-K
CVK569FMKPKP569FMN24CVD524-K
Names of parts
STEP switch
(step angle)
No.1: 1P/2P switch (pulse input mode)
No.2: OFF/SD switch (smooth drive function)
No.3: R2/R1 switch (resolution)
No.4: STOP switch (standstill current rate)
No.5: OFF/FIL switch (command lter)
No.6: Not used.
RUN switch
(operating current rate)
PWR/ALM LED
CN1 connec
tor
(power supply)
Mounting hole
(4 places)
CN2 connector
(motor)
CN3 connector
(I/O signal)
Installation
Location for installation
The driver has been designed and manufactured to be incorporated in
equipment. Install it in a well-ventilated location that provides easy access for
inspection.
The location must also satisfy the following conditions:
yInside an enclosure that is installed indoors (provide vent holes)
yOperating ambient temperature 0 to +50 °C (+32 to +122 °F) (non-freezing)
yOperating ambient humidity 85% or less (non-condensing)
yArea that is free of explosive atmosphere or toxic gas (such as sulfuric gas)
or liquid
yArea not exposed to direct sun
yArea free of excessive amount of dust, iron particles or the like
yArea not subject to splashing water (rain, water droplets), oil (oil droplets)
or other liquids
yArea free of excessive salt
yArea not subject to continuous vibration or excessive shocks
yArea free of excessive electromagnetic noise (from welders, power
machinery, etc.)
yArea free of radioactive materials, magnetic elds or vacuum
y1000 m (3300 ft.) or lower above sea level
Installation direction
Install the driver on a metal plate having excellent vibration resistance in
vertically or horizontally. If the driver is installed under conditions other than
vertical or horizontal position, its heat radiation eect will deteriorate.
The items shown below are necessary in order to install the driver. The items
are not included and must be provided by the customer.
Torque the mounting screw to 0.5 N·m (71 oz-in).
yM3 screw........................................................... 4 pcs.
yM3 spring washer.......................................... 4 pcs.
yM3 nut ............................................................... 4 pcs. *
ySpacer [5 mm (0.2 in.) or larger] ............... 4 pcs.
* Not necessary if screw holes are provided in the enclosure.
There must be clearances of at least 25 mm (0.98 in.) and 50 mm (1.97 in.)
in the horizontal and vertical directions respectively, between the driver
and enclosure or other equipment within the enclosure. When two or more
drivers are to be installed side by side, provide clearances in the horizontal
and vertical directions as shown in the gure.
yInstall the driver in an enclosure.
yDo not install any equipment that generates a large amount of heat
or noise near the driver.
yIf the ambient temperature of the driver exceeds 50 °C (122 °F),
improve the ventilation condition.
•Horizontal installation
20 mm (0.79 in.) or more
50 mm (1.97 in.) or more

4
•Vertical installation
40 mm (1.57 in.) or more
50 mm (1.97 in.) or more
Installation method
•Horizontal installation
M3 screw
Spring washer
Spacer
Metal plate
•Vertical installation
M3 screw
Spring washer
Spacer
Metal plate
In the case of a vertical installation, the driver can be installed in any
direction.
Connection
Connecting the motor
Connector pin assignments vary depending on the motor. Refer to the
following table.
The pin number is shown in the gure.
“Color” in the table represents the color of the lead wire for the connection
cable (supplied or sold accessory).
•When 2-phase stepping motor is connected
The motors of the model A and model B are dierent in pin
assignments. Wrong connection will not cause the motor to operate
properly.
Model AModel BModel C
51 1 6
Pin No. →
Driver
CN2 Pin No.
Model A Model B Model C
Pin No. Color Pin No. Color Color
1 4 Blue 1 Blue Blue
2 5 Red 3 Red Red
3 − − −
4 2 Green 6 Green Green
5 1 Black 4 Black Black
•When 5-phase stepping motor is connected
The motors of the model A and model B are dierent in pin
assignments. Wrong connection will not cause the motor to operate
properly.
Model AModel BModel C
51 1 5
Pin No. →
Driver
CN2 Pin No.
Model A Model B Model C
Pin No. Color Pin No. Color Color
1 5 Blue 1 Blue Blue
2 4 Red 2 Red Red
3 3 Orange 3 Orange Orange
4 2 Green 4 Green Green
5 1 Black 5 Black Black

5
Connection example
zWhen using the voltage of input signals at 5 VDC (Refer to p.6 for when connecting 24 VDC.)
•When pulse input is of line driver type
Driver
R0
0 V
0 V
0 V
0 V
GND
24 VDC±10%
PLS (CW)
DIR (CCW)
AWO
ALM
CN3
CN3
CN3
CN1
Red
Blue
Motor lead wire *1
Twisted pair cable
Green
Black 5
4
3
2
1
4
3
2
1
10
9
R0
TIM
12
11
6
5
-
+
Orange*2
CN2
100 Ω
Current sink output circuitCurrent source output circuit
Controller
100 Ω
100 Ω
100 Ω
470 Ω
2.2 kΩ
2.2 kΩ
2.2 kΩ
2.2 kΩ
1 kΩ
CS
8
7
470 Ω
1 kΩ
0 V
30 VDC or less
30 VDC or less
Output saturated voltage
0.5 V max.
5 VDC
5 VDC
*2
10 mA or less
*1 Connector pin assignments vary depending on the motor. For details, refer to "Connecting the motor" on p.4.
*2 This orange lead wire is for 5-phase stepping motor. For 2-phase stepping motor, do not connect anything to the pin No.3 since there is no orange lead wire.
Use output signals at 30 VDC, 10 mA or less. If the current exceeds 10 mA, connect an external resistor R0 so that the current becomes 10 mA or less.
•When pulse input is of open-collector type
Driver
0 V
0 V
PLS (CW)
CN3
2
1
100 Ω
Current sink output circuit
Twisted pair cable
Current source output circuit
Controller
100 Ω
100 Ω
100 Ω
2.2 kΩ
2.2 kΩ
2.2 kΩ
2.2 kΩ
DIR (CCW)
4
3
5 VDC
5 VDC

6
zWhen using the voltage of input signals at 24 VDC
•When pulse input is of open-collector type
Driver
1.5 to 2.2 kΩ
0.5 W or more
1.5 to 2.2 kΩ
0.5 W or more
1.5 to 2.2 kΩ
0.5 W or more
0 V
0 V
PLS (CW)
CN3
2
1
100 Ω
Twisted pair cable
Controller
100 Ω
100 Ω
100 Ω
2.2 kΩ
2.2 kΩ
2.2 kΩ
2.2 kΩ
1.5 to 2.2 kΩ
0.5 W or more
DIR (CCW)
4
3
24 VDC
R2
R2
R1
R1
R1
R1
24 VDC
R0
0 V
0 V
0 V
GND
24 VDC±10%
AWO
ALM
CN3
CN3
CN1
Motor lead wire *1
5
4
3
2
1
10
9
R0
TIM
12
11
6
5
-
+
CN2
Current sink output circuitCurrent source output circuit
470 Ω
1 kΩ
CS
8
7
470 Ω
1 kΩ
0 V
30 VDC or less
30 VDC or less
Output saturated
voltage
0.5 V max.
24 VDC
24 VDC
*2
1.5 to 2.2 kΩ
0.5 W or more
1.5 to 2.2 kΩ
0.5 W or more
10 mA or less
Red
Blue
Green
Black
Orange*2
*1 Connector pin assignments vary depending on the motor. For details, refer to "Connecting the motor" on p.4.
*2 This orange lead wire is for 5-phase stepping motor. For 2-phase stepping motor, do not connect anything to the pin No.3 since there is no orange lead wire.
yThe input voltage specication for the CW input and CCW input is 5 VDC. If the voltage exceeding 5 VDC is applied, connect an external resistor R1 so
that the input current becomes 7 to 20 mA.
Example) When the 24 VDC is connected: R1 = 1.5 to 2.2 kΩ, 0.5 W or more
yThe input voltage specication for the AWO input and CS input is 5 VDC. If the voltage exceeding 5 VDC is applied, connect an external resistor R2 so
that the input current becomes 5 to 15 mA.
Example) When the 24 VDC is connected: R2 = 1.5 to 2.2 kΩ, 0.5 W or more
yUse output signals at 30 VDC, 10 mA or less. If the current exceeds 10 mA, connect an external resistor R0 so that the current becomes 10 mA or less.

7
Connector pin assignment
123 • • • • • •
CN3
121110 12 +
- 3 4 5
CN2 CN1
zCN1 (power supply)
Pin No. Direction Signal name Description
+IN POWER +24 VDC
− GND
zCN2 (motor)
Pin No. Direction Signal name Description
1
OUT MOTOR
Blue motor lead wire
2 Red motor lead wire
3 Orange motor lead wire *
4 Green motor lead wire
5 Black motor lead wire
* This orange lead wire is for 5-phase stepping motor. For 2-phase stepping motor,
do not connect anything to the pin No.3 since there is no orange lead wire.
Connector pin assignments vary depending on the motor. For details,
refer to "Connecting the motor" on p.4.
zCN3 (I/O signals)
Pin No. Direction Signal name Description
1
IN
PLS (CW) +Pulse (CW pulse) input *
2 −
3DIR (CCW) +Rotation direction (CCW
pulse) input *
4 −
5AWO +All windings o input
6 −
7CS +Step angle switching input
8 −
9
OUT
ALM +Alarm output
10 −
11 TIM +Timing output
12 −
* These inputs serve as the pulse input (PLS) and rotation direction input (DIR) in
the 1-pulse input mode, or CW pulse input (CW) and CCW pulse input (CCW) in
the 2-pulse input mode.
Applicable connector
Type Application Model
Connector housing
For power supply (CN1) 51103-0200 (Molex)
For motor (CN2) 51103-0500 (Molex)
For I/O signals (CN3) 51103-1200 (Molex)
Contact − 50351-8100 (Molex)
Applicable crimping tool − 63811-8100 (Molex)
Type Application
Applicable lead wire
yFor power supply (CN1)
AWG22 (0.3 mm2)
Outer sheath diameter:
ø1.15 to 1.8 mm (ø0.045 to 0.071 in.)
Strip length of the insulation cover:
2.3 to 2.8 mm (0.091 to 0.11 in.)
yFor motor (CN2), for I/O signals (CN3)
AWG24 to AWG22 (0.2 to 0.3 mm2) *
Outer sheath diameter:
ø1.15 to 1.8 mm (ø0.045 to 0.071 in.)
Strip length of the insulation cover:
2.3 to 2.8 mm (0.091 to 0.11 in.)
* About the connector for motor (CN2) of the
CVD228 and CVD524, use lead wires of AWG22
(0.3 mm2).
yFor the I/O signals cable, use a twisted pair cable.
yKeep the wiring distance as short as possible [less than 2 m (6.6 ft.)] to
suppress the eect of noise.
For the motor of the frame size 20 mm (0.79 in.) [PKP213 type], since
the wire diameter of the motor cable is AWG26 (0.14 mm2), it is too
thin to t in the supplied connector for motor. Provide the cable of
AWG24 to AWG22 (0.2 to 0.3 mm2) yourself, and connect by using it.
Cable of AWG24 to AWG22
PKP213
Driver
Connecting the power supply
Use a power supply that can supply the following current capacity.
When the power is turned on, the PWR/ALM LED will be lit in green.
Driver model Input power supply
voltage
Power supply
current capacity
CVD205
+24 VDC±10%
0.5 A or more
CVD215 1.3 A or more
CVD223 2.0 A or more
CVD228 3.0 A or more
CVD512 1.7 A or more
CVD518 2.8 A or more
CVD524 2.7 A or more
yWhen connecting, pay attention to the polarity of the power supply.
Reverse-polarity connection may cause damage to the driver.
yHave the connector plugged in securely. Insecure connection may
cause malfunction or damage to the driver.
yWhen unplugging the connector, do so while spreading the latches
on the connector a little.
yWhen cycling the power or plugging/unplugging the connector,
turn o the power and wait for the PWR/ALM LED to turn o.
ySeparate I/O signals cable at least 100 mm (3.94 in.) from
electromagnetic relays and other than inductance loads.
Additionally, route I/O signals cable perpendicular to power supply
cable and motor cable, rather than in a parallel fashion.
yDo not route the power supply cable in the same conduits as other
power supply lines and motor cable.
yIf the motor cable or power supply cable generates an undesirable
amount of noise depending on the wiring or conguration, shield
the cable or install a ferrite core.

8
Explanation of I/O signals
zInput signals
The signal input state represents "ON: Carrying current" or "OFF: Not carrying
current" state of the internal photocoupler.
The interval for switching the motor direction represents the response time of
the circuit. Set this interval to an appropriate time after which the motor will
respond.
•PLS (CW) input, DIR (CCW) input
Set a desired pulse input mode of the driver according to the pulse output
mode of the controller used with the driver.
Maximum input pulse frequency (duty cycle is 50%)
yWhen the controller is of line driver type: 1 MHz
yWhen the controller is of open-collector type: 250 kHz
1-pulse input mode
When the PLS input is turned from OFF to ON while the DIR input is ON, the
motor will rotate by one step in CW direction.
When the PLS input is turned from OFF to ON while the DIR input is OFF, the
motor will rotate by one step in CCW direction.
2-pulse input mode
When the CW input is turned from OFF to ON, the motor will rotate by one
step in CW direction.
When the CCW input is turned from OFF to ON, the motor will rotate by one
step in CCW direction.
yWhen the motor is at standstill, be sure to keep the photocoupler in
OFF state.
yDo not input the CW pulse and CCW pulse simultaneously. If the
other pulse is input while one of the pulse is ON, the motor cannot
operate normally.
Pulse signal
Pulses with sharp rising and falling edges should be input as shown in the
gure below. The gure shows the voltage levels of pulse signals.
90%
10%
0.4 µs or more 0.4 µs or more
1 µs or more
2 µs or less 2 µs or less
ON
OFF
•AWO (all windings o) input
When the AWO input is turned ON, the motor current will be cut o and the
motor will lose its holding torque. The motor output shaft can be turned
manually.
When the AWO input is turned OFF, current will be supplied and the holding
torque will be restored.
•CS (step angle switching) input
When the CS input is turned ON, the motor rotates at a basic step angle.
When the CS input is turned OFF, the motor rotates at the step angle set by
the driver switch.
yDo not change the CS input while operating. The motor may lose its
synchronism, causing position deviation or standstill of the motor.
yWhen changing the step angle using the CS input, do so while the
TIM output is ON.
zOutput signals
The driver outputs signals are photocoupler/open-collector output. The
signal output state represents "ON: Carrying current" or "OFF: Not carrying
current" state of the internal photocoupler.
•ALM (alarm) output
The ALM output is normally closed. When an alarm generates, the ALM
output will turn OFF and the motor current will be cut o.
At the same time, the PWR/ALM LED of the driver will blink in red.
•TIM (timing) output
Every time the motor output shaft rotates by 7.2° (3.6° for high-resolution
type), the motor excitation state becomes the initial setting state (step 0), and
the TIM output turns ON. If an AND circuit is congured with signals of the
home sensor and TIM output when the home position in the equipment is
detected, the tolerance for the motor stop positions in a detection range of
the home sensor can be reduced and the further accurate home position can
be detected.
Example of the TIM output when the step angle is 0.72°(resolution
500 P/R)
Pulse input
Motor output shaft
rotates by 7.2º.
123 • • •1020
ON
OFF
TIM output
ON
OFF
Mot
or operation
Motor type Number of divisions TIM output
1 10
Standard Base step angle 1.8°/step 1.8° 0.18° every 7.2°
Base step angle 0.72°/step 0.72° 0.072°
High-
resolution Base step angle 0.36°/step 0.36° 0.036° every 3.6°
yWhen using the TIM output, keep the input pulse frequency to be
500 Hz or less.
yWhen using the TIM output, set the pulse or step angle so that the
motor output shaft stops at an integral multiple of 7.2°.

9
Timing chart
*3
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
CW input
DIR input
CCW input
PLS input
AWO input
Motor operation
Power supply input
ON
OFF
ALM output
Excitation
Non-excitation
Motor excitation
5 µs or more
*1
0.1 s or more
0.1 s or less 0.2 s or less0.2 s or less0.2 s or less
0.2 s or less
10 s or less
5 µs or more5 µs or more
*2
CS input Base step angle Step angle set by the driver switch
2-pulse input
mode
1-pulse input
mode
5 ms or more
*1
*1
CW
CCW CCW
0.2 s or more
*1 The interval for switching the motor direction represents the response time of the circuit. Set this interval to an appropriate time after which the motor will respond.
*2 It varies depending on the moment of load inertia, load torque, starting frequency, and so on.
*3 When cycling the power, turn o the power and wait for the PWR/ALM LED to turn o.
Noise measures
The electrical noise is of two types: One is a noise to invade into the driver
from the outside and cause the driver malfunction, and the other is a noise to
emit from the driver and cause peripheral equipments malfunction.
For the noise that is invaded from the outside, take measures to prevent the
driver malfunction. It is needed to take adequate measures because signal
lines are very likely to be aected by the noise.
For the noise that is emitted from the driver, take measures to suppress it.
zMeasures against electrical noise
There are the following three methods mainly to take measures against the
electrical noise.
•Noise suppression
yWhen relays or electromagnetic switches are used together with the
system, use noise lters and CR circuits to suppress surges generated by
them.
yCover the driver by a metal plate such as aluminum. This is eective in
shielding the electrical noise emitted from the driver.
•Prevention of noise propagation
yPlace the power lines, such as the motor and power supply cables, keeping
a distance of 100 mm (3.94 in.) or more from the signal lines, and also do
not bundle them or wire them in parallel. If the power cables and signal
cables have to cross, cross them at a right angle.
yUse shielded twisted pair cables of AWG22 (0.3 mm2) for power lines and
AWG24 to 22 (0.2 to 0.3 mm2) for signal lines.
yKeep cables as short as possible without coiling and bundling extra lengths.
yTo ground a shielded cable, use a metal cable clamp that will maintain
contact with the entire circumference of the cable. Ground the cable clamp
near the product.
Cable clamp
Shielded cable
yWhen grounding PE terminals of multiple drivers to a grounding point,
it becomes more eective to block the electrical noise since impedance
on the grounding point is decreased. However, ground them so that a
potential dierence does not occur among the grounding points. An
accessory connection cable (for signal) that includes a ground wire is
provided. Refer to p.12 for details.
•Suppression of eect by noise propagation
yLoop the noise propagated cable around a ferrite core. Doing so will
prevent the propagated noise invades into the driver or emits from the
driver. The frequency band in which an eect by the ferrite core can be
seen is generally 1 MHz or more. Check the frequency characteristics of the
ferrite core used. To increase the eect of noise attenuation by the ferrite
core, loop the cable a lot.
yUse the line driver type, which is less likely to be aected by electrical noise,
for the output circuit of pulse signals. If the pulse signal of the controller is
of the open collector type, use an accessory pulse signal converter for noise
immunity. Refer to p.12 for details.

10
zNoise suppression parts (accessories)
Refer to p.12 for accessories.
•Connection cable (for signal)
This cable is a shielded twisted pair cable for good noise immunity to connect
the driver and controller. The ground wires useful to grounding are provided
at both ends of the cable. The EMC measures are conducted using the
Oriental Motor connection cable.
•Pulse signal converter for noise immunity
This is a noise lter for pulse signal lines. It eliminates the noise of the pulse
signal, and converts the pulse signal to the line driver type.
•Surge suppressor
This product is eective to suppress the surge which occurs in a relay contact
part. Connect it when using a relay or electromagnetic switch. CR circuit for
surge suppression and CR circuit module are provided.
Conformity to the EMC Directive
Eective measures must be taken against the EMI that the motor and driver
may give to adjacent control-system equipment, as well as the EMS of the
motor and driver itself, in order to prevent a serious functional impediment in
the machinery. The use of the following installation and wiring methods will
enable the motor and driver to be compliant with the EMC directive. Refer to
p.2 for the applicable standards.
Oriental Motor conducts EMC measurements on its motors and drivers in
accordance with the following "Example of motor and driver installation and
wiring."
The user is responsible for ensuring the machine's compliance with the EMC
Directive, based on the installation and wiring explained below.
•Power supply
The CVK Series is a product of DC power input. Use a DC power supply
(switched-mode power supply etc.) that conforms to the EMC Directive.
•Connecting the signal cable
Refer to "Prevention of noise propagation" on p.9.
•How to ground
yThe cable used to ground the motor and driver must be as thick and short
as possible so that no potential dierence is generated.
yChoose a large, thick and uniformly conductive surface for the grounding
point.
yInstall the motor to the grounded metal plate.
•Example of motor and driver installation and wiring
Motor
Driver
DC power
supply Cable
clamp
Grounded panel
Motor cable
Controller
Power supply
cable
Signal cable
(connection cable)
Grounding
is a shield box.
Grounding
Grounding
Grounding
Grounding
Grounding
Grounding
Grounding
The driver uses parts that are sensitive to electrostatic charge. Take
measures against static electricity since static electricity may cause
the driver to malfunction or suer damage.
Setting
No.5: OFF/FIL switch
(command lter)
No.6: Not used.
STEP switch
(step angle)
No.1: 1P/2P switch
(pulse input mode)
No.2: OFF/SD switch
(smooth drive func
tion)
No.3: R2/R1 switch
(resolution)
No.4: STOP switch
(standstill current rate)
RUN switch
(operating
current rate)
The STEP switch, 1P/2P switch, and R2/R1 switch are enabled after the
power is cycled.
Step angle
Set the motor step angle using the R2/R1 switch and STEP switch. See the
following tables for the step angles that can be set.
Factory setting
R2/R1 switch: ON side (R1) for 5-phase stepping motor
OFF side (R2) for 2-phase stepping motor
STEP switch: 0
•When the R2/R1 switch
is set to ON side (R1).
•When the R2/R1 switch
is set to OFF side (R2).
STEP switch Resolution
(P/R) Step angle Resolution
(P/R) Step angle
0 500 0.72° 200 1.8°
1 1000 0.36° 400 0.9°
2 1250 0.288° 800 0.45°
3 2000 0.18° 1000 0.36°
4 2500 0.144° 1600 0.225°
5 4000 0.09° 2000 0.18°
6 5000 0.072° 3200 0.1125°
7 10000 0.036° 5000 0.072°
8 12500 0.0288° 6400 0.05625°
9 20000 0.018° 10000 0.036°
A 25000 0.0144° 12800 0.028125°
B 40000 0.009° 20000 0.018°
C 50000 0.0072° 25000 0.0144°
D 62500 0.00576° 25600 0.0140625°
E 100,000 0.0036° 50000 0.0072°
F 125,000 0.00288° 51200 0.00703125°
yStep angles are theoretical values.
yDo not change the CS input or switches while operating. Doing so
may cause loss of synchronism of the motor, resulting in the motor
standstill.
yFor the high-resolution type, in comparison with the standard type
the resolution is twice and the step angle is one-half.
Example: When the R2/R1 switch is set to the ON side (R1) and the
STEP switch is set to "0"
Resolution of the high-resolution type: 500 × 2 = 1000
Step angle of the high-resolution type: 0.72°/2 = 0.36°
Pulse input mode
Set a desired pulse input mode of the driver according to the pulse output
mode of the controller used with the driver. Set a desired mode using the
1P/2P switch. The factory setting of the pulse input mode depends on the
destination country.

11
Smooth drive function
The smooth drive is a function to achieve lower vibration and noise at low
speeds operation without changing the step angle setting.
This function divides the step angle automatically in response to the pulse
signals. It is no need to change the setting of the pulse signals (speed, number
of pulses) on the controller side.
Set the smooth drive function with the OFF/SD switch.
Factory setting ON side (SD) [smooth drive function is enabled.]
Operating current
If the operating current rate is set with the RUN switch, the motor current for
when inputting pulses (operating current) can be changed.
If the load is small and there is an ample allowance for torque, motor
temperature rise can be suppressed by setting a lower operating current rate.
The operating current is a value in which the operating current rate is
multiplied by the rated current (100%).
Operating current = Motor rated current × Operating current rate
Factory setting F (operating current rate 100%)
RUN switch Operating
current rate RUN switch Operating
current rate
0 25% 8 65%
1 30% 9 70%
2 35% A 75%
3 40% B 80%
4 45% C 85%
5 50% D 90%
6 55% E 95%
7 60% F 100%
Standstill current
When the motor stops, the current cutback function will be actuated to lower
the motor current to the standstill current.
The driver standstill current rate can be switched between 25% and 50%
using the STOP switch. When setting the switch to the OFF side, the standstill
current rate will be set to 25%. When setting the switch to the ON side, the
standstill current rate will be set to 50%.
The standstill current is a value in which the standstill current rate is
multiplied by the operating current.
Standstill current = Operating current set with the RUN switch × Standstill
current rate
Factory setting ON side (standstill current rate 50%)
Pulse input
100 to 400 ms *
ON
OFF
Standstill current
Operating current
* The specic time varies depending on the load or operating pattern.
Command lter
The motor response corresponding to input pulses can be adjusted with the
OFF/FIL switch. When the switch is set to the ON side, starting/stopping of the
motor becomes smooth. Note, however, that synchronization performance in
response to the commands is decreased.
Set an appropriate value according to the specic load and purpose.
Factory setting OFF side (command lter is not used)
Command speed
Motor speed
• When the command
lter is not used
Command speed
Motor speed
• When the command
lter is used
5.5 ms5.5 ms
Inspection
It is recommended that periodic inspections are conducted for the items
listed below after each operation of the motor. If an abnormal condition is
noted, discontinue any use and contact your nearest Oriental Motor sales
oce.
During inspection
yAre any of the mounting screws or connection parts of the driver loose?
yIs there attachment of dust, etc., on the driver?
yAre there any strange smells or appearances within the driver?
The driver uses semiconductor elements, so be extremely careful
when handling them. Static electricity may damage the driver.
Alarms
When the driver's protective function triggers and an alarm generates, the
ALM output is turned OFF and the motor current is cut o.
At the same time, the PWR/ALM LED will blink in red. The cause of the alarm
can be checked by counting the number of times the PWR/ALM LED blinks.
zAlarm list
Number of
LED blinks Alarm type Cause and remedial action
2 Overheat
[Cause]
The temperature of the driver circuit board
reached 85 °C (185 °F).
[Remedial action]
Review the ventilation condition.
3 Overvoltage
[Cause]
A voltage exceeding the specication value
was applied.
[Remedial action]
Check the input voltage of the power supply.
[Cause]
A large inertial load was stopped abruptly.
Elevating drive of a large inertia load was
performed.
[Remedial action]
If this alarm generates during operation,
reduce the load or increase the acceleration/
deceleration.
5 Overcurrent
[Cause]
Excessive current was owed through the
driver output circuit for motor.
[Remedial action]
Turn o the power and check that the motor,
cable and driver are not damaged.

12
yUnauthorized reproduction or copying of all or part of this manual is prohibited.
yOriental Motor shall not be liable whatsoever for any problems relating to
industrial property rights arising from use of any information, circuit, equipment
or device provided or referenced in this manual.
yCharacteristics, specications and dimensions are subject to change without
notice.
yWhile we make every eort to oer accurate information in the manual, we
welcome your input. Should you nd unclear descriptions, errors or omissions,
please contact the nearest oce.
yis a registered trademark or trademark of Oriental Motor Co., Ltd.,
in Japan and other countries.
© Copyright ORIENTAL MOTOR CO., LTD. 2013
Published in February 2018
T
echnical Support Tel:[phone]
8:30
A.M. to 5:00 P.M., P.S.T. (M-F)
7:30
A.M. to 5:00 P.M., C.S.T. (M-F)
www
.orientalmotor.com
Schiessstraße 44, 40549 Düsseldor
f, Germany
T
echnical Support Tel:[phone]
www
.orientalmotor.de
T
el:01256-347090
www
.oriental-motor.co.uk
T
el:01 47 86 97 50
www
.orientalmotor.fr
T
el:02-93906346
www
.orientalmotor.it
T
el:[phone]
www
.orientalmotor.com.br
• Please contact your nearest Oriental Motor oce for further information.
4-8-1Higashiueno
,Taito-ku,Tokyo 110-8536
Japan
T
el:03-6744-0361
www
.orientalmotor.co.jp
Tel:[phone]
www.orientalmotor.com.tw
Singapore
Tel:[phone]
www.orientalmotor.com.sg
Tel:[phone]
www.orientalmotor.com.my
Korea
Tel:[phone]
www.inaom.co.kr
Tel:[phone]
www.orientalmotor.co.th
Tel:[phone]
www.orientalmotor.com.cn
Tel:[phone]
www.orientalmotor.co.in
Hong Kong Branch
Tel:[phone]
Number of
LED blinks Alarm type Cause and remedial action
9 EEPROM error
[Cause]
The stored data in the driver was damaged.
[Remedial action]
Contact your nearest Oriental Motor sales
oce.
Lit CPU error
[Cause]
CPU malfunctioned.
[Remedial action]
Cycle the power.
zAlarm reset
When the power is cycled, the alarm will be reset. Before resetting an alarm,
always remove the cause of the alarm and ensure safety.
Accessories
Connection cable set
For the connection cable set, a set of three cables for the power supply,
motor, and input/output signals is provided.
Model Applicable driver Length [m (ft.)] Conductor
LCS01CVK2
CVD205-K
CVD215-K
CVD223-K
CVD228-K 0.6 (2) AWG22 (0.3 mm2)
LCS04SD5
CVD512-K
CVD518-K
CVD524-K
Connection cable (for signal)
This is a shielded twisted pair cable for the driver control I/O signals (12 pins)
that has good noise immunity. The ground wires useful to grounding are
provided at both ends of the cable.
Model Length [m (ft.)] Conductor
CC12D005-2 0.5 (1.6)
AWG24 (0.2 mm2)
CC12D010-2 1 (3.3)
CC12D015-2 1.5 (4.9)
CC12D020-2 2 (6.6)
Pulse signal converter for noise immunity
This product eliminates the noise of the pulse signal, and converts the pulse
signal to the line driver type.
Model: VCS06
CR circuit for surge suppression
This product is eective to suppress the surge which occurs in a relay contact
part. Use it to protect the contacts of the relay or switch.
Model: EPCR1201-2
CR circuit module
This product is eective to suppress the surge which occurs in a relay contact
part. Use this product to protect the contacts of the relay or switch.
4 pieces of CR circuit for surge suppression are mounted on the compact
circuit, and this product can be installed to the DIN rail. This product can
make the wiring easily and securely since it also supports terminal block
connection.
Model: VCS02
