Briggs & Stratton 30467 User manual

&
®
rator's I
8
This generator is rated in accordance with CSA(Canadian Standards
Association) standard C22.2 No. 100-04 (motors and generators).
BRIGGS& STRATTONPOWERPRODUCTSGROUP,LLC
MILWAUKEE,WISCONSIN,U.S.A.
Manual No. 312491GS RevisionB

Thankyou for purchasingthis quality-built Briggs & Stratton@generator. We are pleasedthat you've placedyour confidence
in the Briggs & Stratton brand. When operatedand maintainedaccording to the instructions in this manual,your Briggs &
Stratton generatorwill provide many years of dependableservice.
This manual containssafety information to makeyou awareof the hazardsand risks associatedwith generatorproducts and
how to avoidthem. Thisgenerator is designed and intendedonly for supplying electrical powerfor operatingcompatible
electrical lighting, appliances,tools and motor loads, and is not intendedfor any other purpose, it is important that you read
and understand these instructions thoroughly before attempting to start or operatethis equipment. Save this originalmanual
for future reference.
This generator requiresfinal assemblybeforeuse. Referto the Assembly section of this manualfor instructions on final
assembly procedures. Followthe instructions completely.
Whereto FindUs
You never haveto look far to find Briggs & Stratton support and servicefor your generator.Consultyour Yellow Pages.There
are over 30,000 Briggs & Stratton authorized service dealersworldwide who provide quality service. You canalso contact
Briggs & Stratton Customer Service by phone at [phone], or on the Internet at BRIGGSandSTRATTON.COM.
Generator
Engine
Model Number
Revision
Serial Number
Model Number
Type Number
Code Number
Date Purchased
Copyright © 2011. Briggs & Stratton PowerProducts Group, LLC
Milwaukee, WI, USA.All rights reserved.
BRIGGS& STRATTONPOWERPRODUCTSis a registered
trademark of Briggs & Stratton Corporation
Milwaukee, WI, USA
2 BRIGGSandSTRATTON.COM

Tableof Contents
Operator Safety ................................. 4
Equipment Description......................................... 4
important Safetyinformation.................................... 4
Assembly ..................................... 7
UnpackGenerator ............................................ 7
Shipment Contents ........................................... 7
InstallWheel Kit.............................................. 7
Add Engine Oil............................................... 8
Add Fuel.................................................... 8
System Ground .............................................. 9
Connectingto a Building's ElectricalSystem........................ 9
GeneratorLocation ........................................... 9
Featuresand Controls............................ 10
Cord Sets and Receptacles.................................... 11
Operation .................................... 12
Starting the Engine ......................................... ............12
ConnectingElectrical Loads............ ............... 3
Storage ................... . . .. ........................ 19
Troubleshooting ....... 21
Schematic .... :.'. ".;.'. :.'. ".;.'. :.'.'. ;.'. :.'. 22
Warranties...................... 24
Emissions trranty ............................. 24
Generator .................................... 26
Specifications. .!:.. ............................ 28
Product Specifications........................................ 28
Common Service Parts ....................................... 28
Frangais Espa_ol
(Z}

OperatorSafety
EquipmentDescription
Readthis manual carefullyand become familiar
with yourgenerator. Knowitsapplications, its
limitationsand any hazardsinvolved.
Thegenerator is an engine-driven, revolving field, alternating
current (AC) generator. It was designedto supply electrical
power for operating compatible electrical lighting,
appliances,tools and motor loads. Thegenerator's revolving
field is driven at about 3,600 rpm by a single-cylinder
engine.
NOT/CE Exceedinggeneratorswattage/amperagecapacity
could damagegeneratorand/orelectrical devicesconnected
to it.
important Safety information
Themanufacturer cannot possibly anticipateevery possible
circumstance that might involve a hazard.Thewarnings in
this manual, and the tags and decals affixedto the unit are,
therefore, not all-inclusive, if you usea procedure,work
method or operatingtechnique that the manufacturer does
not specifically recommend, you must satisfy yourself that it
is safe for you and others. You must also makesure that the
procedure, work method or operating technique that you
choose does not renderthe generator unsafe.
Safety Symbols and Meanings
ToxicFumes Kickback ElectricalShock
*DO NOTexceedthe generator's wattage/amperage capacity. See
Don't OverloadGeneratorin the Operationsection.
Everyeffort hasbeen madeto ensurethat the information in Fire Iosion Operator'sManual
this manualis both accurateand current. However,the
manufacturer reservesthe right to change alter or otherwise .....
improve the generatorand this documentation at anytime .......... ..........
without prior notice.
The EmissionControl System for this generator is warranted ............ MovingRaff_ FlyingObjects HotSurface
for standardsset by the Environmental ProtectionAgency .....
and the California Air Resources Board. ......................_t, The symbol indicatesa potential personal
A signalword (DANGER,WARNING,or
usedwith the alert symbol to designatea
....... levelof hazardseriousness.A safety symbol may
.... usedto representthetype of hazard.Thesignal word
....._OTICE is usedto address practicesnot relatedto personal
injury.
,& BANGERindicatesa hazardwhich, if not avoided, will
result in deathor serious injury.
A WARNINGindicatesa hazardwhich, if not avoided,
could result in death or serious injury.
A, CAUTIONindicates a hazardwhich, if not avoided, could
result in minor or moderate injury.
NOT/CEaddresspractices not relatedto personal injury.
4 BRIGGSandSTRATTON.COIVl

Using a generator indoors CAN KiLL YOU iN MINUTES,
Generator exhaust contains carbon monoxide, This is
apoison you cannot see or smell,
V
NEVER use inside ahome
or garage, EVEN iF doors
and windows are open,
[]
Only use OUTSIDE and
far away from windows,
doors, and vents,
,& WARNING Runningengine gives off carbon
monoxide, an odorless, colorless, poison gas.
_ Breathingcarbon monoxide could result in death,
serious injury, headache,fatigue,dizziness,
vomiting, confusion, seizures,nauseaor fainting.
•Operatethis productONLYoutdoors.
• Installa batteryoperatedcarbonmonoxidealarmnearthe
bedrooms.
• Keep exhaustgas from entering a confined areathrough
windows, doors, ventilation intakes,or other openings.
•DO NOToperatethis product insideany building, carport,
porch, mobile equipment, marineapplications, or enclosu[e
evenif windows and doors areopen.
,& WARNING The engine exhaustfrom this p_od_ct
contains chemicals known to the State o_Gali_oihia_6 .........
causecancer, birth defects,or other reproducti_ _rm.
_ikWARNING Certain components in this product and
relatedaccessoriescontain chemicals known to the
of Californiato causecancer, birth defects
reproductive harm. Wash hands after handling.
A WARNING
• This generator does not meetU. S. CoastG_ # Regulation
33CFR-183and should not be used on marine _pplications.
• Failureto usethe appropriate U.S. CoastGuard approved
generator could result in deathor serious injury and/or property
damage.
,& WARNING Starter cord kickback(rapid retraction)will
pull hand and armtoward engine fasterthan you
can letgo which could causebroken bones,
fractures, bruises, or sprains resulting in
serious injury.
• Whenstartingengine,pullcordslowlyuntilresistanceisfelt
andthenpull rapidlytoavoidkickback.
• NEVERstartor stopenginewith electricaldevicespluggedin
andturnedon.
,& WARNING Fuel and its vapors are extremely
flammable and explosive which could
cause burns, fire or explosion resulting
in death, serious injury and/or property
damage.
WHENADDING OR DRAiNiNG FUEL
•Turn generator engineOFFand letit cool at least2 minutes
before removing fuel cap. Loosen capslowly to relievepressure
in tank.
• Fill or drain fuel tank outdoors.
• DONOToverfill tank. Allow spacefor fuel expansion.
i! !uel spills, wait until it e_ape_atesbefore starting engine.
fuel awayfrom spai_ open flames, pilot lights, heat,and
ignition ....
_heckfuel lin#_ fittings frequently for cracks or
ieaks. Replacdii n_e_sary.
• DONOT ii_Nte or smoke.
WHEN
s_Fk, plug,muffler, fuel cap,andair cleanerare in
crank enginewith spark plug removed.
dENOPERATINGEQUIPMENT
NOToperatethis product inside any building, carport,
porch, mobile equipment, marineapplications, or enclosure.
• DONOTtip engine or equipmentat anglewhich causesfuel to
spill.
• DONOTstop engineby moving choke control to "Choke"
position (1'*,1).
WHEN TRANSPORTING, MOVING OR REPAiRiNGEQUIPMENT
•Transport/move/repair with fuel tank EMPTYor with fuel shutoff
valveOFF.
•DONOTtip engine or equipment at anglewhich causesfuel to
spill.
•Disconnectspark plug wire.
WHEN STORING FUEL OR EQUIPMENT WITH FUEL INTANK
• Store awayfrom furnaces, stoves, water heaters,clothes
dryers, or other appliancesthat havepilot light or other ignition
source becausethey could ignite fuel vapors.

AWARNING Generator voltage could cause electrical
_)dh| shock or burn resulting in death or serious
mjury.
•Use approvedtransfer equipment to preventbackfeed by
isolating generator from electric utility workers.
•When using generator for backup power, notify utility company.
•Use a ground fault circuit interrupter (GFCI)in any damp or
highly conductive area,such as metal deckingor steel work.
•DO NOTtouch bare wires or receptacles.
•DO NOTuse generatorwith electrical cords which areworn,
frayed, bareor otherwise damaged.
•DO NOToperate generator in the rain or wet weather.
•DO NOThandle generator or electrical cords while standing in
water, while barefoot,or while hands or feet are wet.
•DO NOTallow unqualified personsor children to operate or
servicegenerator.
_1_WARNING Exhaust heat/gases could ignite
_ ombustibles, structures or damage fuel
tank causing a fire, resulting in death,
-serious injury and/or property damage.
Contact with muffler area could cause burns resulting in
serious injury.
•DO NOTtouch hot parts andAVOID hot exhaust gases.
•Allow equipmentto cool beforetouching.
•Keepat least5 feet (1.5 m) of clearanceon all sidesof
generator including overhead.
•It is a violation of California Public Resource Code,S_
4442, to use or operate the engineon any
brush-covered, or grass-covered land unlessthe e_h_
system is equipped with aspark arrester
4442, maintained in effective working order.
federal jurisdictions may have similar laws.
Contactthe original equipment manufacturer, retailer, or deal!
to obtain a sparkarrester designed for the exhaust
installed on this engine.
•Replacement parts must bethe sameand installed
position asthe original parts. ....
...... __
AWARNING Unintentional sparking fire or
electric shock resulting iRdeath or
_.¢ serious injury.
WHENADJUSTINGORMAKINGREPAIRSTOYOURGENERATOR
•Disconnectthe spark plug wire from the spark plug and place
the wire where it cannot contact spark plug.
WHENTESTINGFORENGINESPARK
•Use approved spark plug tester.
•DO NOTcheckfor spark with spark plug removed.
A WARNING Starter and other rotating parts could
entangle hands, hair, clothing, or accessoriesresulting in serious injury.
•NEVERoperate generator without protective housing or covers.
•DO NOTwear looseclothing, jewelry or anything that could be
caught in the starter or other rotating parts.
•Tie up long hair and removejewelry.
A, CAUTION Excessively high operating speeds could
result in minor injury and/or generator damage.
Excessively low speeds impose a heavy load.
•DO NOTtamper with governor spring, links or other partsto
increase enginespeed. Generatorsupplies correct rated
frequency and voltage when running at governed speed.
•DO NOTmodify generator in any way.
NOTICE Exceeding generators wattage/amperage capacity
could damage generator and/or electrical devices connected
to it.
•DO NOTexceedthe generator's wattage/amperage capacity. See
Don't OverloadGeneratorin the Operationsection.
•Start generator and letengine stabilize beforeconnecting
electrical loads.
•Connectelectrical loads in OFFposition, then turn ONfor
operation.
•Turn electricalloads OFFanddisconnect from generator before
stopping generator.
Improper t_i_ of generator couId damageit
;hortenits fife, .............
Usegenerate[_:_[_i:8#jniendeduses.
•If youhave_u_st:ioRdaboutintendeduse,askdealeror contact
localse_i_ cen_#r.
....._pe_:gteg_grator onlyonlevelsurfaces.
.B_:N_Te_ose generatorto excessivemoisture,dust,dirt, or
;orr_ivevapors.
insertanyobjectsthroughcoofingslots.
devicesoverheat,turnthemoff anddisconnectthem
fromgenerator.
•Shutoffgeneratorif:
-electricaloutputislost;
-equipmentsparks,smokes,or emitsflames;
-unitvibratesexcessively.
6 BRIGGSandSTRATTON.COIVl

Assembly
Your generator requiressome assembly and isreadyfor use
after it hasbeen properly servicedwith the recommendedoil
and fuel.
If you haveany problemswith the assemblyof your generator,
pleasecallthe generatorhelplineat 1-800-743-4115. If calling
for assistance,pleasehavethe model, revision,and serial
numberfrom the identificationlabel available.SeeGenerator
Controlsand Featuresfor identification labellocation.
UnpackGenerator
1. Setthe carton on a rigid, fiat surface.
2. Removeeverything from carton exceptgenerator.
3. Opencarton completely by cutting eachcorner from
top to bottom.
4. Leavegeneratoron carton to install wheel kit.
Shipment Contents
The generator is suppliedwith:
3. insert retaining pin (B) through hole on axlestud.
4. Slide a wheel (C) over axlestud.
NOTICE Besure to install wheelwith raised hub inboard.
5. Attach wheelto axlestud with a washer (D), lock
washer (E) and nut (F). Tighten with a 18 mm socket
wrench and 18 mm wrench.
6. Placehub cap (G) into center of wheel and push until it
snaps into place.
7. Repeatsteps 2 through 6 to secure secondwheel.
8. Line up holes in support leg (H) with holes in generator
frame.
•Engineoil bottle
•Operator's manual
•Wheelkit
.......... 9. Attach SU_Q[t leg using 4 capscrews(,!) and 4 hexInstall Wheel Kit nuts (Ki Tigfi_ with a 10 mm socket wrench and
NOTICE Wheelkit is not intendedfor over-the-road 8_e 13 m_ w[e_bh.
You will needthe following tools to install thes_ .............. to normal operating position (resting
components: ..............
• 13 mm and 18 mm wrench
• Socketwrench with 10 mm and 18 mm sockets
InstalJthewheelkitas follows:
1. Tip generator sothat engine side is down. ..................................................
2. Slide axlestud (A)through mounting .....
threadedend facing out.

Add Engine Oil
1. Placegeneratoron a fiat, levelsurface.
2. Cleanarea around oil fill and removeyellow oil fill cap.
3. Using oil funnel (optional), slowly pour contents of
provided oil bottle into oil fill opening.
NOTICE improper treatment of generator could damage it
and shorten its life.
•DO NOTattempt to crank or start the engine beforeit has been
properly servicedwith the recommended oil. This could result in
an enginefailure.
4. Replaceoil fill cap and fully tighten.
AddFuel
Fuel mustmeet these requirements:
•Clean,fresh, unleadedgasoline.
•A minimum of 87 octane/87AKI (91 RON).Forhigh
altitude use, seeHigh Altitude.
•Gasolinewith up to 10% ethanol (gasohol) or up to
15% MTBE(methyl tertiary butyl ether) is acceptable.
AWARNING Fueland its vapors areextremelyflammable
and explosivewhich could causeburns,
fire or explosionresulting in death,
serious injury and/orproperty damage.
WHENADDINGFUEL
*Turn generator engineOFFand letit cool at least2 minutes
before removing fuel cap. Loosen capslowly to relievepressure
in tank.
,. Fill fuel tank outdoors.
*DONOToverfill tank. Allow spacefor fuel expansion.
* iffuel spills, wait until it evaporatesbefore starting engine.
*Keepfuel awayfrom sparks, open flames, pilot lights,heat,and
other ignition sources.
*Checkfuel lines,tank, cap and fittings frequently for cracks or
leaks.Replaceif necessary.
*DONOTlighta cigaretteor smoke.
1. Clean area around fuel fill cap, remove cap.
2. Slowly add unleaded fuel to fuel tank. Be careful not to
fill above the red fuel level indicator (A). This allows
adequate space for fuel expansion.
NOTICE Avoid generatordamage.
Failureto follow Operator's Manualfor fuel .........
recommendations voids warranty.
•DONOTuseunapprovedgasolinesuchasE85.
•DONOTmixoil in gasoline. ........
•DONOTmodifyengineto runonalternatefuels. ..............................
To protect the fuel system from gum formaiie_ _i :::ina fuel
stabilizerwhen adding fuel. SeeStorage.All fu_l:is not the
capand let anyspilled fuel evaporatebefore
engine.
same. if you experiencestarting or performanceproblems :::::_i_h Altitude
after usng fue sw tch to a dfferent fue prov der or chang_ .... At Itit ,4_o_v_r _ ,_,_,_P_t '1_24 m_Pr°' _ minim m
..... ,. . . a uu_u _ ,_vvv _ t ,J _j a u
oranas In s eng ne s cer_Tedto operateon paso ..... t n AKi R N lin i t I T
•..... 85oca e/85 (89 0 )paso e saccepabe, o
emis.s!on..con!rolsystem for this engine is EM ...... remainemissions compliant, high altitude adjustment is
MooTcat ons). ..... required.Operationwithout this adjustment will cause
.... .................. decreasedperformance, increasedfuel consumption, and
....... increasedemissions. Seean authorized dealerfor high
............ altitude adjustment information. Operationof the engine at
altitudes below 2,500 feet (762 meters) with the high altitude
kit is not recommended.
8 BRIGGSandSTRATTON.COM

SystemGround
Thegenerator hasa system ground that connects the
generatorframe components to the ground terminals on the
ACoutput receptacles.Thesystem ground is connectedto
the ACneutral wire (the neutral is bondedto the generator
frame).
Special Requirements
Theremay be Federalor StateOccupationalSafety and
Health Administration (OSHA)regulations, local codes, or
ordinances that applyto the intended useof the generator.
Pleaseconsult a qualified electrician, electrical inspector, or
the local agency havingjurisdiction:
+ In some areas,generators are requiredto be registered
with local utility companies.
+ If the generator is usedat a construction site, there
may be additional regulations which must be observed.
Connectingto aBuiiding'sElectricalSystem
Connectionsfor standby powerto a building's electrical
system must be made by a qualified electrician. The
connection must isolate the generator powerfrom utility
power or other alternativepower sources and must comply
with all applicablelaws and electrical codes.
AWARNING Generatorvoltage could cause
)dill .shockor burn resulting in deathor serious
mjury.
+ Useapprovedtransferequipmentto
isolatinggeneratorfromelectricutility
usinggeneratorfor backuppower,notify:_i!itYcompany.
When
®
+ Useagroundfaultcircuitinterrupter(GFCI)in anydampor
highlyconductivearea,suchasmetaldeckingor steelwork.
+ DONOTtouchbarewiresor receptacles.
+ DONOTusegeneratorwithelectricalcordswhicha
frayed,bareor otherwisedamaged.
+ DONOToperategeneratorintherainor
+ DONOThandlegeneratoror electrical
water,whilebarefoot,or whilehandsorfeet_e wet.
e
ig in
DO NOTallow unqualified personsor children to operate or
servicegenerator.
GeneratorLocation
Clearancesand Air Movement
,i_ WARNING Exhaustheat/gases could ignite
combustibles, structuresor damagefueltank
causing afire, resultingin death,serious injury
and/or property damage.
+ Keepatleast5 ft. (1.5m)clearanceonall sidesof generator
includingoverhead.
Placegeneratoroutdoors in an areathat will not accumulate
deadlyexhaust gas. DONOTplacegeneratorwhere exhaust
gas (A) could accumulate and enter inside or be drawn into
a potentially occupied building. Ensureexhaustgas is kept
awayfrom any windows, doors, ventilation intakes, or other
openingsthat canallow exhaustgasto collect in a confined
area.Prevailingwinds and air currents should betaken into
consideration when positioning generator.
UsingageneratorindoorsCANKILL YOU iN MINUTES,
Generatorexhaustcontai_;_carbon monoxide,This is
youcannot mell.
|

FeaturesandControls
Readthis Operator's Manual and safetyrulesbefore operating yourgenerator.
Comparethe illustrations with your generator,to familiarize yourself with the locations of various controls and
adjustments. Savethis manual for future reference.
A- Hour Meter -- Displays and records how _By :hour_ J _Spa[k A_[ester Muffler -- Exhaustmuffler lowers engine
your generator hasrun (up to 9,999.9) ........ is equippedwith a spark arrester screen.
B- RockerSwitch Circuit Breaker- The AC ................ -- Protects engine byfiltering dust and
30A locking receptacleis provided with a rocker ................: d_bris out of intake air.
sw tch c rcut breakerto protect the generatoraga nst Choke Lever Usedwhen starting a col n in
• .... .................. d e g e.
e ectr ca over cad. M- Recoil Starter -- Usedto start the engine manually.
C-lb_O/fe4d0tVoe_tuAC[3e0ecAtmcPaLO_;g N-Engine RockerSwitch- Setthis switch to ONor,
PPY P P_
_._,^. oar, ,,^,_^,. o,, ^m_ i,_ ..... before us ng reco starter Set sw tch to OFFor 0 to
.... ....... 5WILUII UH _HLJIH_
electrical, hghbng,appl,ance,tool and mg;_erleads. P Fuel Valve Usedto turn fuel supply on andoff to
D- CircuitBreakers(AC)-- The 120 Voli G_20A duplex ". --
receptaclesare provided with "pushto reset"circuit engine.
breakersto protect the generatoragainst electrical
overload.
E-120 Volt AC, 20 Amp, Duplex Receptacle -- May be
usedto supply electrical powerfor the operation of
120 Volt AC,20 Amp, single phase,60 Hz electrical,
lighting, appliance,tool and motor loads.
F-Oil Drain Plug-- Drainengine oil here.
G- Oil Fill Cap-- Checkand add engineoil here.
H-Grounding Fastener -- Consultyour local agency having
jurisdiction for grounding requirements in your area.
R-FuelTank-- Capacityof five (5) U.S.gallons (18.9 I) for
5,000 and 5,500 Watt generator. Capacityof seven (7)
U.S.gallons (26.5 I) for 6000 Watt generator.
Items Not Shown:
Engineidentification-- Provides model, type and code of
engine. Pleasehavethese readilyavailableif calling for
assistance.
Identification Label-- Provides model and serial number of
generator. Pleasehavethese readilyavailableif calling for
assistance.
10 BRIGGSandSTRATTON.COIVl

Cord Sets and Receptacles
Use only high quality, well-insulated, grounded extension
cords with the generator's receptacles.Inspect extension
cords before eachuse.
Checkthe ratings of all extensioncords beforeyou use
them. Extensioncord sets usedshould be ratedfor AC loads
20 Amps or greater. Checkoperator's manuals of devicesto
be poweredfor the manufacturer's recommendations.
Keepextension cords asshort aspossible to minimize
voltage drop.
,& WARNING Damagedor overloadedelectrical cords
could overheat,arc, and burn resulting in death,
serious injury, and/or property damage.
*ONLYuse cords ratedfor your loads.
*Follow all safeties on electricalcords.
* Inspect cord sets before each use.
120/240 Volt AC, 30 Amp, LockingReceptacle
Use a NEMAL14-30 plug with this receptacle.Connecta
4-wire cord set ratedfor 250 Volt AC loadsat 30 Amps (or
greater). You can usethe same4-wire cord if you planto run
a 120 Volt load.
4-Wire CordSet
Y(Hot) /
NEiViAL14o30 7)-z
This receptaclepowers 120/240 Volt AC,6-0-_-Hz,single phase
loads requiring up to 6,000 watts of power (6:0 kW) at
25 Amps for 240 Volts or two independent120 Volt loads at
25 Amps each.The outlet is protected by a 2 pole rocker
switch circuit breaker.
120 Volt AC, 20 Amp, DuplexReceptacles
Theduplex receptaclesare protected against overload by
push-to-reset circuit breakers.
Useeachreceptacleto operate120 Volt AC, single-phase,
60 Hz electricalloads requiring up to 2,400 watts (2.4 kW) at
20 Amps of current. Usecord setsthat are ratedfor 125 Volt
ACloads at 20 Amps (or gre_er).
NOTICE Receptacles may be marked with rating value
greater than generator output capacity.
• NEVERattempt to power adevice requiring more amperagethan
generator or receptaclecan supply.
• DONOToverloadthe generator.SeeDon'tOverloadGenerator.
11

Operation
Startingthe Engine
Disconnect all electrical loads from the generator. Usethe
following start instructions:
1. Make sure unit is on a levelsurface.
NOTICE Failureto start and operatethe unit on a level
surfacewill causethe unit not to start or shut down during
operation.
2. Turnthe fuel valve (A)to the "On" position.
3. Push choke leverto "Choke" position (l_,l).
4. Push engine rocker switch (B)to ONor I _Osi_ian.
5. Grasp recoil handleand pull slowly until siigh
resistanceis felt. Then pull rapidlyone
start engine.
• If engine starts, proceedto
•If engine fails to start, proceedto _ap 6.
A WARNING Starter cord kickback(rapid retraction)will
pull hand and armtoward enginefasterthan you
,_ can letgo which could cause brokenbones,
fractures, bruises, or sprains resulting in
serious injury.
•Whenstartingengine,pullcordslowlyuntilresistanceisfelt
andthenpullrapidlytoavoidkickback.
•NEVERstartor stopenginewith electricaldevicespluggedin
andturnedon.
6. Move choke leverto "Half" choke position, and pull
recoil handletwice.
• Ifengine fails to start, repeatsteps 5 thru 7.
7. Slowly move choke leverto "Run" position (l+l).If
engine falters, move choke leverto "Half" choke
position until engine runs smoothly, andthen to "Run"
position (I_I).
NOTICE If engine floods, placechoke lever in "Run"
position (1+1)and crank until engine starts.
NOTICE If engine starts after 3 pulls but fails to run, or if
unit shuts down during operation, makesure unit is on a
levelsurfaceand check for proper oil level in crankcase.This
unit may be equipped with a low oil protection device. If so,
oil must be at proper levelfor engine to start.
A WARNING Exhaustheat/gases could ignite
combustibles, structuresor damagefuel
tank causinga fire, resulting in death,
serious injury and/or property damage.
Contact with muffler area could cause burns resulting in
serious injury.
•DONOTtouchhotpartsandAVOIDhotexhaustgases.
........iow equipmentto coolb_foi__ouching.
atleast5 feet onall sidesof
includin iia PublicResourceCode,Section
engineonanyforest-covered,
landunlesstheexhaust
,edwith asparkarrester,asdefinedinSection
in effectiveworkingorder.Otherstatesor
mayhavesimilarlaws.
theoriginalequipmentmanufacturer,retailer,or dealer
asparkarresterdesignedfor theexhaustsystem
installed onthis engine.
Replacementpartsmustbethesameandinstalledinthesame
positionastheoriginalparts.
12 BRIGGSandSTRATTON.COIVl

Connecting Electrical Loads
1. Let engine stabilizeand warm up for a few minutes
after starting.
2. Ensurecircuit breakeron control panel is in "On"
position.
3. Plug in andturn on the desired 120 and/or 240 Volt
AC,single phase,60 Hz electrical loads.
NOTICE When plugging into the 120 Volt receptacles,plug
items to be powered in sequenceasshown below.
o
NOTICE
•DONOTconnect24OVoltloadstothe120Volt ....
receptacles.
•DONOTconnect 3-phaseloads to the generator.
•DONOTconnect 50 Hzloads to the generator:: ..........
DONOTOVERLOADTHEGENERATOR.SeeDQnt ....
OverloadGenerator.
NOTICE Exceedinggeneratorswattage/amperagecapacity
could damagegeneratorand/orelectrical devicesconnectc
to it.
• DONOTexceedthegenerator'swattage/amperage
Don'tOverloadGeneratorintheOperationsection.
•Startgeneratorandletenginestabilizebefore
electricalloads.
• Connectelectricalloadsin OFFposition,
operation. ....
• TurnelectricalloadsOFFanddisconnectfrom generatorbefore
stoppinggenerator.
Stopping the Engine
1. Turn OFFand unplug aiI electrical loads from generator
panel receptacles.NEVERstart or stop enginewith
electrical devicesplugged in and turned ON.
2. Let engine run at no-load for several minutes to
stabilize internaltemperatures of engine and generator.
3. Push engine rocker switch to OFFor 0 position.
AWARNING Fueland its vapors areextremelyflammable
and explosivewhich could causeburns,
fire or explosionresulting in death,
serious injury and/orproperty damage.
*DONOTstopenginebymovingchokecontrolto"Choke"
position(IXl).
4. Move fuel valve to "Off" position.
WarmWeatherOperation
This generatorengine is equippedwith WeatherGuard,an
innovativefeature to preventcarburetor icing in cold weather
conditions. WeatherGuardhas beenengineeredto operatein
aii weather conditions. However,product performancecan be
increasedwhen operatingt)e generator solely in warm
weather by removing the _eat_[Guard shield (A).
/
Removethe two nuts(B) and loosenthe fastener(C) as
shown. Store shield andfasteners for future coldweather
operation.
13

Don't OverloadGenerator
Capacity
You must make sureyour generator cansupply enough
rated (running) and surge (starting) watts for the items you
will power at the same time. Followthese simple steps:
1. Selectthe itemsyou will power at the same time.
2. Total the rated(running) watts of these items. This is
the amount of power your generator must produce to
keepyour items running. Seethe table on the right.
3. Estimatehow many surge (starting) watts you will need.
Surge wattageis the short burst of power neededto
start electric motor-driven tools or appliancessuch asa
circular saw or refrigerator. Becausenot all motors start
atthe sametime, total surgewatts can be estimatedby
adding only the item(s) with the highest additionalsurge
watts to the total ratedwatts from step 2.
Example:
Tool or Appliance
WaterWell Pump
Refrigerator
FurnaceFan
Television
Light (75 Watts)
Running (Rated)
Watts
1200
700
8O0
5O0
75
3275 Total
Running Watts
Total Rated (Running) Watts
HighestAdditional Surge Watts
Total GeneratorOutput Required
Additional Starting
(Surge) Watts
21O0
2200
2350
2350 H:ighesi
Sta_i_g _a_
= 32_5
235
= 5625
Power Management
To prolong the lifeof your generatorand
is importantto take carewhen adding eleG$fiea! y6_r
generator. Thereshould be nothing cona_cted&Q$5_........
generator outlets before starting itsengine:: he Correctand
safe way to managegeneratorpower isto s_uentially add
loads asfollows:
1. With nothing connectedto the generator,start the
engine asdescribed in this manual.
2. Plug in andturn on the first load, preferablythe largest
load you have.
3. Permit the generatoroutput to stabilize (engine runs
smoothly and attacheddeviceoperates properly).
4. Plug in andturn on the next load.
5. Again, permit the generatorto stabilize.
6. Repeatsteps 4 and 5 for eachadditional load.
WattageReference Guide
Running*
Tool or Appliance
Essentials
Light Bulb - 75 watt
FurnaceFanBlower- 1/2 HP
Sump Pump- 1/3 HP
Refrigerator/Freezer
Water Well Pump - 1/2 HP
Heating/Cooling
Window AC- 10,000 BTU
Humidifier- 13 Gal
CentralAC- 24,000 BTU
Kitchen
Microwave Oven- 1000 Watt
CoffeeMaker
Electric Stove- 8" Elemen_ :.....
Room ..... ......
BvD/CD ........
VCR .....
Stereo
0e 0__ele_iSion- 27 in
w/17 in
(Rated)
Watts
75
800
800
700
1000
1200
175
3800
1000
1000
21O0
850
100
100
450
500
800
Additional
Starting
(Surge)
Watts
E
2350
1300
2200
2100
3600
11400
E
E
E
E
E
E
E
E
E
a her
Security System 500 --
AM/FM Clock Radio 100 --
GarageDoor Opener- 1/2 HP 875 2350
ElectricWater Heater 4700 11700
DIY/Jab Site
Quartz HalogenWork Light 1000 =
Airless Sprayer- 1/3 HP 600 1200
Reciprocating Saw 960 --
Electric Drill- 1/2 HP,5.4 Amps 600 900
Circular Saw - 7-1/4 in 1400 2300
Miter Saw- 10 in 1800 1800
Table Planer- 6 in 1800 1800
Table Saw/RadialArm Saw- 10 in 2000 2000
Air Compressor - 1 HP 1600 4500
NEVERadd more loadsthan the generatorcapacity.Take
special careto consider surge loads in generator capacity,as
described above.
* Wattageslisted are approximate only. Checktool or
appliancefor actual wattage.
14 BRIGGSandSTRATTON.COIVl

Maintenance
MaintenanceSchedule
Follow the hourly or calendarintervals, whichever occurs
first. More frequent serviceis required when operating in
adverseconditions noted below.
• Changeengine oil
Cleandebris
Checkengineoil level
•Service engineair cleaner1
Changeengine oiP
Servicefuel valve
Service spark plug
Inspect muffler and spark arrester
Cleancooling system1
• Checkvalve clearance
1 Service more often under dirty or dusty conditions.
General Recommendations
Regular maintenancewill improve the performance ant
extendthe life of the generator.Seeany authorized
service.
Thegenerator's warranty doesnot coveEi_m '
been subjectedto operator abuseor negiigen_ Te receive
full valuefrom the warranty, the operator _st maintainthe
generator asinstructed in this manual.
Someadjustments will needto be made periodically to
properly maintain your generator.
All serviceand adjustments should be made at least once
eachseason.Follow the requirementsin the Maintenance
Schedulechart above.
NOTICE Oncea year you should cleanor replacethe spark
plug and replacethe air filter. New spark plugs and cleanair
filter assure proper fuel-air mixture and help your engine run
better and last longer.
EmissionsControl
Maintenance, replacement, or repair of the emissions
controldevices and systems may be performed byany
non-road engine repair establishment or individual.
However,to obtain "no charge" emissions control service,
the work must be performed by a factory authorized dealer.
Seethe Emissions Warranty.
GeneratorMaintenance
Generatormaintenanceconsists of keepingthe unit clean
and dry. Operateand store the unit in a clean dry
environment where it will not be exposedto excessivedust,
dirt, moisture, or any corrosive vapors. Coolingair slots in
the generator must not become cloggedwith snow, leaves,
or any other foreign material.
NOTICE DONOTusewater or other liquids to clean
generator. Liquids canenter engine fuel system, causing
poor performance and/or failure to occur, in addition, if
liquid enters generator through cooling air slots, some of the
liquid will be retainedin voids andcracks of the rotor and
stator winding insulation. Liquid and dirt buildup on the
generator internalwindings will eventuallydecreasethe
insu ation resistanceof the_ _indings.
and underneaththe
fil or fuel leaks.Cleanaccumulated
from outside the generator. Keepthe
other engine controls clean. Keepthe
the muffler free from any
Inspect cooling air slots and openings
_.Theseopenings must be kept cleanand
jine parts should be kept cleanto reducethe risk of
_rheatingand ignition of accumulateddebris:
•Use a damp cloth to wipe exterior surfaces clean.
NOTICE improper treatment of generator could damage it
and shorten its life.
• DO NOTexposegenerator to excessivemoisture, dust, dirt, or
corrosive vapors.
• DONOTinsert any objects through cooling slots.
• Use a soft bristle brush to loosen cakedon dirt or oil.
•Use a vacuum cleanerto pick up loose dirt and debris.
15

FuelValve Maintenance
Thefuel valve is equippedwith a fuel sediment cup, screen,
and o-ring that needto be cleaned.
1. Move fuel valve to "Off" position•
2. Removesediment cup (A) from fuel valve. Remove
o-ring (B) and screen (C)from fuel valve.
3. Wash sediment cup, o-ring, and screen ina
nonflammablesolvent. Drythem thoroughly.
4. Place screen and o-ring intofuelvalve, installsediment
cup and tighten securely.
5. Movefuelvalveto "On"position,and check for leaks.
Replacefuel valve if there is anyleakage.
EngineMaintenance
,& WARNING Unintentionalsparking could cause
'_.l|ll electric shock resulting in death
£W serious injury......
HENADJUSTI,GoRMAKI,GREPAIRSTo
W
--Disconnectthesparkplugwirefromthe
thewirewhereit cannotcontactsparkplug•
WHENTESTINGFORENGINESPARK
*Useapprovedsparkplugtester•
* DONOTcheckfor sparkwithsparkplugremoved•
Oil
Oil Recommendations
We recommendthe useof Briggs &
Certified oils for best performance•Otherhigh-quality
detergent oils are acceptableif classified for serviceSF,SG,
SH, SJ or higher• DONOTuse specialadditives•
Outdoor temperatures determine the proper oil viscosity for
the engine•Usethe chart to selectthe best viscosity for the
outdoor temperature rangeexpected•
oFoC
86 -_ _ _ 30
68 _' _ _ 20
o
50 _ 10
32 __ _n -- 0
14 __ A-10
-4 I--J_L---- -20
-22 _-30
* Below40°F(4°C)theuseofSAE30 will resultin hardstarting.
** Above 80°F (27°C) the useof 10W30 may cause increasedoil
consumption• Checkoil level more frequently.
OOTICE Synthetic oil meeting iLSACGF-2,APi
certification mark and API servicesymbol with
"SJ/CF ENERGYCONSERVING"or higher, is an
_ cceptableoil at all temperatures• Useof synthetic
oil does not alter required oil change intervals•
CheckingOil Level
should be
hours ofope
Make sure
2. Clean
3. Veri
each useor at least
oil levelmaintained•
on a levelsurface•
oil fill and remove oil fill cap.
point of overflowing at oil fill
tighten oil fill cap.
ine Oil
• Make sure generatoris on a levelsurface•
Checkoil levelas described in Checking OilLevel
3. If needed,slowly pour oil into oil fill opening to the
point of overflowing at oil fill.
4. Replaceand tighten oil fill cap.
18 BRIGGSandSTRATTON.COIVl

ChangingEngineOil
if you are usingyour generator under extremely dirty or
dusty conditions, or in extremely hot weather, changethe oil
more often.
ACAUTION Avoid prolonged or repeated skin contact
with used motor oil.
• Used motor oil has beenshown to cause skin cancer in certain
laboratory animals.
• Thoroughly wash exposed areaswith soap andwater.
KEEPOUTOFREACHOFCHILDREN.DON'T
POLLUTE.CONSERVERESOURCES.RETURN
USEDOIL TOCOLLECTIONCENTERS.
To service the air cleaner, follow thesesteps:
1. Loosen screws (D) and remove air cleanercover (E).
Changethe oil while the engineis still warm from
running,as follows:
1. Make sure unit is on a levelsurface.
.
3.
Disconnectthe spark plug wire from the spark plug and
placethe wire where it cannot contact spark plug.
Cleanarea aroundoil drain plug (A). Theoil drain plug
is locatedat baseof engine,opposite carburetor.
4. Removeoil drain plug anddrain oil completely
suitable container.
5. Reinstall oil drain plug andtighten securely.
fill cap.
6. Slowly pour oil (about 28 oz.)
the point of overflowing (C) at oil DONOT
overfill.
7. Reinstall oil fill cap. Fingertighten cap securely.
8. Wipe up any spilled oil.
tO
Service Air Cleaner
Your enginewill not run properly and may be damaged if
you run it with a dirty air cleaner.Cleanor replacemore
often if operating under dusty or dirty conditions.
2. Carefully removecartridge (F) from base(G).
3. Install clean(or new)air cleanerassembly inside cover.
Disposeof old filter properly.
4. Assembleair cleanerco_eronto baseand tighten
P ug
gingthe helpyourengineto starteasier
run .....
1. Clean_rea aound spark plug.
a. and inspect spark plug.
gapwith wire feeler gauge and reset
plug gap to recommended gap if necessary(see
secifications).
4. Replacespark plug if electrodesare pitted, burned or
porcelain is cracked. Usethe recommended
replacementspark plug. SeeSpecifications.
5. Install spark plug and tighten firmly.
17

inspectMuffler and SparkArrester
Inspect the muffler for cracks, corrosion, or other damage.
Removethe spark arrester, if equipped,and inspectfor
damageor carbon blockage, if replacementparts are
required, make sureto useonly original equipment
replacementparts.
_1_WARNING Exhaust heat/gases could ignite
combustibles, structures or damage fuel
tank causing a fire, resulting in death,
serious injury and/or property damage.
Contact with muffler area could cause burns resulting in
serious injury.
•DO NOTtouch hot parts andAVOID hot exhaust gases.
•Allow equipmentto cool beforetouching.
•Keepat least5 feet (1.5 m) of clearanceon all sidesof
generator including overhead.
•It is a violation of California Public Resource Code,Section
4442, to use or operate the engineon anyforest-covered,
brush-covered, or grass-covered land unlessthe exhaust
system is equipped with a spark arrester, as defined in Section
4442, maintained in effective working order. Other states or
federal jurisdictions may have similar laws.
Contactthe original equipment manufacturer, retailer, or dealer
Clean Cooling System
Overtime debris may accumulatein cylinder cooling fins and
cannot be observedwithout partial engine disassembly. For
this reason,we recommendyou havea Briggs & Stratton
authorized dealercleanthe cooling system (D) per
recommendedintervals (seeMaintenanceSchedulein the
Maintenancesection). Equallyimportant is to keeptop of
engine freefrom debris. Also see Cleaning.
•Replacementpartsmustbethesameandinstalledinthe
positionastheoriginalparts.
Clean and inspectthe sparkarresteras fellows:
1. To remove muffler heatshield (A) from
removefour screws that connect gu_
bracket.
CheckValve Clearance
liar valve clearance adjustment will improve
to obtaina sparkarresterdesignedfor theexhaustsystem
installedonthis engine, and extend _n_iBelife. This procedure cannot
_newithout _a[ti_! engine disassemblyand the useof
iiaitools, we recommendthat you have
authorized Se_iGe _ealer check and adjust valve
clearanceat [_co_mended intervals (seeMaintenance
S_hedulei_ _ Maintenancesection).
djust ent
....: T_ea_uretor on this engineis low emission. It is equipped
Wh a non-adjustable idle mixture valve.Top speedhas been
.........at the factory, if adjustment is required,seea Briggs &
Stratton authorized dealer.
,_ CAUTION Excessively high operating speeds could
result in minor injury and/or generator damage.
Excessively low speeds impose a heavy load.
•DO NOTtamper with governor spring, links or other partsto
increase enginespeed. Generatorsupplies correct rated
frequency and voltage when running at governed speed.
•DO NOTmodify generator in any way.
.
3. Removefour screwsthat attachsparkarresterscreen(C).
Inspect screenand obtain a replacementif torn,
perforated or otherwise damaged. DONOTusea
defective screen.If screen is not damaged,clean it with
commercial solvent.
4. Reattachscreen and muffler guard.
18 BRIGGSandSTRATTON.C01Vl

Storage
Thegenerator should be started at least once every seven
days and allowed to run at least 30 minutes, if this cannot be
done and you must store the unit for morethan 30 days,use
the following guidelinesto prepare it for storage.
GeneratorStorage
•Cleanthe generator as outlined in Cleaningin the
Maintenancesection.
•Checkthat cooling air slots and openingson generator
are open and unobstructed.
LongTerm Storage Instructions
Fuelcan becomestale when stored over 30 days.Stalefuel
causesacid and gum deposits to form in the fuel system or
on essentialcarburetor parts. To keepfuel fresh, use Briggs
& Stratton FRESHSTART® fuel stabilizer, availableasa
liquid additive or a drip concentrate cartridge.
Thereis no needto drain gasolinefrom the engine if a fuel
stabilizer is added according to instructions. Runthe engine
for 2 minutesto circulate the stabilizerthroughout the fuel
system. The engine andfuel canthen be stored up to
24 months.
ChangeOil
While engine is still warm, drain oil from crankcase.Refill
with recommendedgrade.See ChangingEngine Oilin Engine
Maintenance.
Other Storage Tips
1. DONOTstore fuel from one seasonto another unless it
has beentreated as described in Long TermStorage
Instructions.
2. Replacefuel can if it starts to rust. Contaminatedfuel
will cause engine problems.
3. if possible,store unit indoors and cover it to give
protection from dust and dirt.
4. Cover unit with a suitable protective cover that does not
retain moisture.
,i_ WARNING Storagecovers could causea fire
resulting in death, serious injury and/or property
damage.
•DONOTplacea storagecoverovera hotgenerator.
• Letequipmentcoolfor a sufficienttime beforeplacingthe
coverontheequipment. .....
_ _tore
....... generatoria e!e_aidry area.
If gasoline in the engine hasnot beentreated with a fuel
stabilizer, it must be drained into an approvedcontainer. Ru ...........
the engine until it stops from lack of fuel. The useof ............
stabilizer in the storage container is
maintain freshness.... ....
A WARNING Fueland its vapors are
_,_ ,,andexplosivewhich coul8 Caus_bSrns,
J[d_ _ fire or explosionresulting in death,
m.,m, _r "_: seriousinjury and/orproperty damage.
WHENSTORINGFUELOREQUIPMENTWITHFUELIN
Storeawayfromfurnaces,stoves,waterheaters,clothes_iye_
or otherappliancesthathavepilotlightor otherignitio__GU_:::
becausetheycouldignitefuelvapors.
WHENDRAININGFUEL ....
*TurngeneratorengineOFFandJetit _olat:e_i _ _ihutes
beforeremovingfuelcap.Loosencapslowly_Qrelievepressure
intank.
*Drain fuel tank outdoors.
*Keepfuel awayfrom sparks, open flames, pilot lights,heat,and
other ignition sources.
*Checkfuel lines,tank, cap and fittings frequently for cracks or
leaks.Replaceif necessary.
.DO NOTlighta cigarette or smoke.
19

20 BRIGGSandSTRATTON.COM
