Briggs & Stratton 20223 Setup guide

Model No. 020223 (2400 PSI (165 BARS) Pressure Washer) Manual No. 203761A Revision - (06/26/2007)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Call: Pressure Washer Helpline
1-800-743-4115 M-F 8-5 CT
Illustrated Parts List

2BRIGGSandSTRATTON.COM
Exploded View and Parts List — Main Unit
Item Part # Description
1 195339GS BASE
2 B194718GS HANDLE
3 195052GS ASSY, Billboard w/Decal
4 196006GS HOSE
5 192529GS KIT, Pump Mounting Hardware
6 199735GS ASSY, Pump
194298GS Valve, Thermal Relief
23139GS Key
7 192309GS KIT, Hook, Base
8 194264GS KIT, Hook, Handle
9 193482GS GUN
10 188792HGS WAND, Adjustable Nozzle
11 21760GS ORIFICE
12 192310GS KIT, Vibration Mount
13 B2203GS KIT, Handle Connector
14 194255GS KIT, Wheel
192006GS Axle
192050GS E-Ring
900 § ENGINE
Items Not Illustrated:
203761GS MANUAL, Operator’s
MS6847 MANUAL, Engine
95456GS QUICK CONNECT, Male
96016GS QUICK CONNECT, Female
195347GS KIT, Tag, Warning with Clip
192014GS FITTING, Hose, 1/2
192015GS FITTING, Hose, 3/4
6048 KIT, O-Ring Maintenance
Optional Accessories
6039 PUMP SAVER
§ - Contact Engine Manufacturer
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.

3
Exploded View and Parts List — Pump
Item Part # Description
19 190571GS CAP, Oil
28 190627GS MANIFOLD
45 190578GS PIN
62 190581GS CAP, 1/8
76 194298GS THERMO RELIEF
A 190594GS KIT, UNLOADER STEM
B 190632GS KIT, WATER INLET, ALUM
C 190634GS KIT, OUTLET, ALUM
D 199708GS KIT, HEAD ALUM
E 193806GS KIT, CHECK VALVES
F 190592GS KIT, INLET CHECK
Item Part # Description
G 190593GS KIT, CHEMICAL INJECTION
H 193807GS KIT, SEAL SET
J 189971GS KIT, CHEMICAL HOSE
K 193971GS KIT, PIPE FITTING
L 193972GS KIT, UNLOADER SEAT
Parts Not Illustrated
B2384GS FILTER, Inlet
NOTE: Item letters A - L are service kits and include all parts
shown within the box.
