Briggs & Stratton 20320 Setup guide

Model No. 020320 (3000 PSI (206.8 BARS) Pressure Washer) Manual No. 203768A Revision B (08/02/2007)
BRIGGS & STRATTON POWER PRODUCTS GROUP, LLC
JEFFERSON, WISCONSIN, U.S.A.
Questions? Help is just a moment away!
Call: Pressure Washer Helpline
1-800-743-4115 M-F 8-5 CT
Illustrated Parts List

2BRIGGSandSTRATTON.COM
Exploded View and Parts List — Main Unit
Item Part # Description
1 203081GS ASSY, Base
2 Y201499GS HANDLE
3 203082GS KIT, Billboard, w/Decals & Clips
195964GS Clips, Tree
30809GS Grommet
4 192131GS KIT, Pump Mounting Hardware
5 198347GS ASSY, Pump
194298GS Valve, Thermal Relief
23139DGS Key
6 203083GS KIT, Wheel
200520GS Hubcap
192050GS E-Ring
7 202017GS HOSE
8 200595GS EXTENSION
9 192553GS KIT, Vibration Mount
10 199990GS GUN
11 202182GS KIT, Nozzle
201580RGS Nozzle, QC, Project Pro, Yellow
201580XGS Nozzle, QC, Project Pro, Orange
201580AAGS Nozzle, QC, Project Pro, Red
198841GS Nozzle, Plastic, Soap
12 B2203GS KIT, Handle Fastening
13 192134GS KIT, Engine Mounting Hardware
900 § ENGINE
Items Not Illustrated:
203768GS MANUAL, Operator’s
202494GS DECAL, Engine
202495GS DECAL, Cover Air Cleaner
200658GS DECAL, Recoil
87815GS GOGGLES
201314GS AXLE
BB3061BGS OIL BOTTLE
695755 KNOB, Throttle
194256GS KIT, Hang Tag, Warning
Optional Accessories
6048 KIT, O-Ring
6039 PUMP SAVER
§ - Contact Engine Manufacturer
Copyright © 2007 Briggs & Stratton Power Products Group, LLC. All rights reserved. No part of this material may be
reproduced or transmitted in any form by any means without the express written permission of Briggs & Stratton Power
Products Group, LLC.

3
Exploded View and Parts List — Pump
Item Part # Description
19 190571GS CAP, Oil
28 198102GS MANIFOLD
45 190578GS PIN
62 190581GS CAP, 1/8
76 194298GS THERMAL RELIEF
A 190594GS KIT, UNLOADER
B 190670GS KIT, WATER INLET
C 190669GS KIT, BREATHER TUBE
D 193808GS KIT, HEAD BRASS
E 193806GS KIT, CHECK VALVES
F 190592GS KIT, INLET CHECK
G 190593GS KIT, CHEMICAL INJECTION
Item Part # Description
H 193807GS KIT, SEAL SET
J 189971GS KIT, CHEMICAL HOSE
K 193971GS KIT, PIPE FITTING
L 193972GS KIT, UNLOADER SEAT
Parts Not Illustrated
190585GS OIL BOTTLE
B2384GS FILTER, Inlet
NOTE: Item letters A - L are service kits and include all parts
shown within the box.
