Brink Air Control Ventilation Reference guide

BrinkClimateSystemsB.V. WethouderWassebaliestraat8 7951SN Staphorst P.O.Box11 NL-7950AA Staphorst
T. [phone] F. [phone] [email protected] www.brinkclimatesystems.nl
Modications reserved
Art.nr.: 614884-C
1 - Brink Air Control - Ventilation
2 - Brink Air Control - Allure
The Allure manual starts after page 32 of the Ventilation manual
STORE NEAR THE APPLIANCE

Brink Air Control- Ventilation
English
Installation regulations

Contents
1 User manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Descripon Brink Air Control- Venlaon. . . . . . . . 3
1.2 Symbols used. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Technical specicaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 General product specicaon. . . . . . . . . . . . . . . . . . 4
2.2 Environment inuences. . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Overview operaonal controls. . . . . . . . . . . . . . . . . 5
2.4 Overview display version main screen. . . . . . . . . . . 5
2.5 Venlaon modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Precauonary measures and safety instrucons. . . . . . . 7
3.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 During placement. . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 During use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.4 During maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 For the environment. . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Assembly and installaon (to be performed by the
installer). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1.1 Disconnecng the operaonal module from the
wall bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1.2 Mounng the wall bracket. . . . . . . . . . . . . . . . . 9
4.1.3 Electrical connecon. . . . . . . . . . . . . . . . . . . . 10
4.1.4 Replacing the operaonal module in the wall
bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.2 Installaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2.1 Seng language. . . . . . . . . . . . . . . . . . . . . . . . 11
4.2.2 Seng me. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2.3 Seng date. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.2.4 Selecng a device connected to the Brink Air
Control- Venlaon . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Descripon of operaon; manner of use. . . . . . . . . . . . 15
5.1 Navigaon: general descripon. . . . . . . . . . . . . . . . 15
5.2 Selecng a device connected to the Brink Air
Control- Venlaon. . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.3 Weekly programmes P1, P2 and P3. . . . . . . . . . . . 16
5.3.1 Standard sengs P1, P2 and P3. . . . . . . . . . . 16
5.3.2 Creang a P1 program. . . . . . . . . . . . . . . . . . . 17
5.3.3 Creang a P2 program. . . . . . . . . . . . . . . . . . . 18
5.3.4 Creang a P3 program. . . . . . . . . . . . . . . . . . . 19
5.4 Acvang program type (P1, P2 or P3). . . . . . . . . . 20
5.5 Temperarily overriding program. . . . . . . . . . . . . . . 20
5.6 Overriding program for a longer period of me. . 20
5.7 Seng venlaon mode values. . . . . . . . . . . . . . . 21
5.8 Retrieving sengs. . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.9 Factory seng connected device. . . . . . . . . . . . . . 22
6 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.1 General maintenance. . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 Cleaning or replacing lter. . . . . . . . . . . . . . . . . . . . 23
6.2.1 Filter nocaon. . . . . . . . . . . . . . . . . . . . . . . 23
6.2.2 Removing, cleaning or replacing. . . . . . . . . . . 23
6.2.3 Re-seng lter nocaon. . . . . . . . . . . . . . . 24
7 Dismanteling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8 Repair. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9 Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
10 Troubleshoong and guarantee. . . . . . . . . . . . . . . . . . . 28
10.1 Troubleshoong. . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10.2 Guarantee. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
11 Appendix: Standard sengs weekly programs. . . . . . 29
11.1 Standard program P1. . . . . . . . . . . . . . . . . . . . . . . 29
11.2 Standard program P2. . . . . . . . . . . . . . . . . . . . . . . 30
11.3 Standard program P3. . . . . . . . . . . . . . . . . . . . . . . 31

1 User manual
Dear client,
Thank you for buying the Brink Air Control- Ventilation. This user’s manual contains all required information to
quickly become familiar with the product. We kindly request you to carefully go through this information before
using the product. This user’s manual is intended for the Brink Air Control- Ventilation installer and end user. You
can retrieve the required information from the user’s manual via the table of contents.
This is an extended user’s manual. A Quick Start Guide is available, in addition to this user’s manual. Take good
care of this user’s manual! For more information or ordering manuals, please contact:
Brink Climate Systems B.V.
Mailbox 11
NL-7950 AA, Staphorst, The Netherlands
T: [phone]
F. [phone]
E. [e-mail]
www.brinkclimatesystems.com
1.1 Description Brink Air Control- Ventilation
Intended and unintended use
The Brink Air Control- Ventilation should be used in combination with products that have been approved by Brink
Climate Systems B.V.
Brink Climate Systems B.V. cannot be held responsible for possible damage caused by improper, incorrect or
unwise use. It is important that one understands this user’s manual completely.
Working with other devices
The Brink Air Control- Ventilation is connected to other devices. The HRU (Heat Recovery Unit) is co-dependent
on these devices’ operation for its proper functioning. These devices’ presence and proper functioning are
prerequisites for using the Brink Air Control- Ventilation.
1.2 Symbols used
Warning!
The user can (seriously) injure himself or seriously damage the product. A warning is indicave of a risk of damage
to the user or product, if the user does not execute the procedures carefully.
Careful!
The product can be endangered. “Careful” is indicave of a risk of damage to the product, if the user does not
execute the procedures carefully.
Take note!
A remark with supplementary informaon for the user. A remark draws the user’s aenon to possible problems.
Brink Air Control- Ventilation 614884-B Brink / 3

2 Technical specification
2.1 General product specification
Product description
Name: Brink Air Control- Ventilation
Technical product specifications
Electricity: 15 to 24 Volt
Power consumption: 1,5 Watt
Protection class: IP30
Power reserve: > 48 hours
Ambient conditions
Ambient temperature: 0 °C to 50 °C
Storage temperature: -20 °C to 60 °C
Humidity: 10% to 90%
Other: Exclusively for indoor use
2.2 Environment influences
The Brink Air Control- Ventilation should be placed and used in a space with the correct ambient conditions for
proper operation. The Brink Air Control- Ventilation may only be mounted on the indoors, but not on the vicinity of
a heat source, a radiator, in a draft or in a humid environment. The Brink Air Control- Ventilation may also not be
exposed to direct radiation heat (sun light). The Brink Air Control- Ventilation may also not be mounted in the
vicinity of a magnetic field. This could damage internal components.
Brink Air Control- Ventilation 614884-B

2.3 Overview operational controls
The Brink Air Control- Ventilation has a number of buttons with which the device can be operated:
1
2
3
4
5
=
=
=
=
=
Setting knob
Return key
Setting & activating timer programme
Manual control key
Bypassing the timer programme
2.4 Overview display version main screen
1
2
3
4
5
6
7
8
=
=
=
=
=
=
=
=
Flow rate indicator
eBus connection indicator
Fan indicator
Fault symbol
Filter message
Current time block
Current time
Current date (day/ month/ year)
Brink Air Control- Ventilation 614884-B Brink / 5

2.5 Ventilation modes
The Brink Air Control- Ventilation has four ventilation modes. You can
activate a ventilation mode yourself (for more information see ®
Description of operation; manner of use page 15 ). You can adjust
every ventilation mode yourself (for more information ®Setting
ventilation mode values page 21 ). You can retrieve the set values at
the Device information menu (see below).
Venlaon modes
1
2
3
=
=
=
Device information
HRU-appliance
Information HRU ventilation
Brink Air Control- Ventilation 614884-B

3 Precautionary measures and
safety instructions
3.1 General
Warning!
The installation and assembly activities required to commission your Brink Air Control-
Ventilation should be performed by an installer approved by Brink Climate Systems B.V.
Immediately remove the power from your Brink Air Control- Ventilation by removing the
connected device’s plug from the socket, if:
▪Parts of the Brink Air Control- Ventilation lie open, are pierced or had fallen hard;
▪The power cable is damaged;
▪The screen is cracked or broken.
Then contact Brink Climate Systems B.V. or you supplier.
Take note!
▪Never use parts other than original parts.
▪Only use the Brink Air Control- Ventilation indoors, at temperatures between 0 °C and 50 °C
and with a relative humidity between 0% and 90%.
▪All settings (excluding the filter message) will be lost if the Brink Air Control- Ventilation
breaks down or if the factory settings are reset. There is no backup available.
3.2 During placement
Take note!
Assembly and installation should be performed by an installer approved by Brink Climate
Systems B.V. The following requirements should be taken into account during placement:
▪The Brink Air Control- Ventilation should be placed at a height of approximately 1.65 meters
above the floor;
▪The Brink Air Control- Ventilation may not be covered, for example, by a curtain or a cabinet;
▪Consult paragraph ®Environment influences page 4 for environmental requirements.
3.3 During use
Take note!
Settings, which have not been described in this user’s manual, are intended for installers
approved by Brink Climate Systems B.V.
Do not change these by yourself.
Brink Air Control- Ventilation 614884-B Brink / 7

3.4 During maintenance
Careful!
Clean the screen with a soft cloth.
Never apply water and/or (cleaning) liquid to the screen.
3.5 For the environment
Take note!
The Brink Air Control- Ventilation may not be removed as unsorted urban waste, but should be
treated separately.
Make enquiries within your own region, where the Brink Air Control- Ventilation can be handed
in when use has been terminated. Do not throw away electrical devices or parts, but check if
(parts of) the Brink Air Control- Ventilation cannot be handed in, recycled or re-used.
Brink Air Control- Ventilation 614884-B

4 Assembly and installation (to be
performed by the installer)
Assembly and installation should be performed by an installer approved by Brink Climate Systems B.V.
4.1 Assembly
You should perform the steps, described in paragraph (®Disconnecting the operational module from the wall
bracket page 9)through paragraph (®Replacing the operational module in the wall bracket page 10), one by
one, to assemble the Brink Air Control- Ventilation.
4.1.1 Disconnecting the operational module from the wall bracket
Disconnect the operational module from the wall bracket. Perform the following actions :
▪Slide the control unit upward over the two guide
profiles of the wall bracket until the control unit
can be taken off.
4.1.2 Mounting the wall bracket
The wall bracket can be attached to a wall box (Ø 55 mm) or can be directly mounted on the wall with screws and
plugs.
▪Screw the wall bracket onto the wall in the correct
position. Here one must use the mounting holes in
the wall bracket.
Take note!
Consult ( ®During placement page 7) for more information on placing the Brink Air Control-
Ventilation.
Brink Air Control- Ventilation 614884-B Brink / 9

4.1.3 Electrical connection
The following actions should be performed to
connect the Brink Air Control- Ventilation
electrically:
▪Feed the two-core wire (from the device to be
connected) through via opening at the back of
the wall bracket.
▪Check that the cables’ ends have been stripped
in the correct manner. If this is not the case, do
so.
▪Screw the cable to the terminal No. 1 and No.
2. Consult the installation instructions of the
device to be connected, for more information
on the correct connection.
4.1.4 Replacing the operational module in the wall bracket
Place the operational in the wall bracket mounted on the wall. Perform the following actions for this :
▪Slide the control unit downward over
the two guide profiles. Make sure the
guide profiles of the wall bracket fit
snugly in the cutouts of the control
unit provided for that purpose.
1 = ± 25 seconds
2 = HRU venlaon
Take note!
The operational module should click onto the wall bracket. Only then is a proper electrical
connection established.
At power on the device determines which type of device is connected either a Heat Recovery
Unit or an Air Heating Unit followed by an second start-up cycle!
Brink Air Control- Ventilation 614884-B

4.2 Installation
4.2.1 Setting language
You can set the language in which the menus are presented.
Perform the following actions to set the language:
▪Press returnkey "2" as many times as
necessary to get to the main screen,
▪Press setting knob "1"; ‘Main Menu’ opens,
▪Select ‘Basic Settings’ by turning setting knob
"1",
▪Press setting knob "1";‘Basic Settings’ opens,
▪Select ‘Language’ by turning setting knob "1",
▪Press setting knob "1"; ‘Language’ opens,
▪Select the desired language by turning setting
knob "1",
▪Press setting knob "1" to set the selected
language,
▪Press return key "2" as many times as
necessary to get to the main screen.
1
2
3
=
=
=
Basic settings
Language
Englisch
Take note!
The names of the described menu items will not correspond with this user manual’s menu
items if the Brink Air Control- Ventilation is set to a language other than Dutch.
Brink Air Control- Ventilation 614884-B Brink / 11

4.2.2 Setting time
You can set the time. The time is visible on the main screen. The Brink Air Control- Ventilation only has 24 hour
representation.
Perform the following actions to set the time :
▪Press returnkey "2"as many times as necessary to
get to the main screen,
▪Press setting knob "1"; ‘Main Menu’ opens,
▪Select ‘Basic Settings’ by turning setting knob "1",
▪Press setting knob "1"; ‘Basic Settings’ opens,
▪Select ‘Clock’ by turning setting knob "1",
▪Press setting knob "1"; ‘Clock’ opens,
▪Change the time by turning setting knob "1",
▪Press setting knob "1" to confirm the time,
▪Repeat the previous two steps for both the
minutes and seconds,
▪Press returnkey "2" as many times as necessary
to get to the main screen.
Brink Air Control- Ventilation 614884-B

4.2.3 Setting date
You can set the date. The date is visible on the main screen.
Perform the following actions to set the date:
▪Press returnkey "2" as many times as necessary to
get to the main screen
▪Press setting knob "1"; ‘Main Menu’ opens
▪Select ‘Basic Settings’ by turning setting knob "1"
▪Press setting knob "1"; ‘Basic Settings’ opens
▪Select ‘Date’ by turning setting knob "1"
▪Press setting knob "1" ‘Date’ opens
▪Change the day by turning setting knob "1"
▪Repeat the previous two steps for both the months
and the year
▪Press returnkey "2" as many times as necessary to
get to the main screen
1 = Flow rate indicator
2 = eBus connection indicator
3 = Fan indicator
4 = Fault symbol
5 = Filter message
6 = Current time block
7 = Current time
8 = Current date
Brink Air Control- Ventilation 614884-B Brink / 13

4.2.4 Selecting a device connected to the Brink Air Control- Ventilation
You can choose the device you want to regulate with the control if multiple devices are connected to Brink Air
Control- Ventilation.
Proceed as follows to set the appliance selection:
▪Press return key "2" as many times as necessary to get to
the main screen,
▪Press setting knob "1"; ‘Main Menu’ opens,,
▪Select ‘Installer’ by turning setting knob "1",
▪Press setting knob "1";‘Installer’ opens,
▪Select ‘Device’ by turning setting knob "1",
▪Press setting knob "1" to confirm selected device.If only one
appliance is connected, no choice is offered and only Heat
Recovery Unit appliance is displayed.
1 = Installer
2 = HRU-appliance
3 = Device settings
4 = Please wait: Loading data
5 = Airflow-mode 1
6 = Airflow 30 m
3
/h
7 = Factory setting
8 = Yes
9 = Settings are reset to factory setting
Brink Air Control- Ventilation 614884-B

5 Description of operation; manner
of use
You can increase or decrease the ventilation mode with the Brink Air Control- Ventilation. You can do this by
setting a program. You can temporarily override the program while it is running.
5.1 Navigation: general description
Navigating through menus
The Brink Air Control- Ventilation has menus that you can navigate
through. For this you use setting knob "1" . You scroll through the
menus by turning the setting knob "1". You can open a selected
menu-item by pressing the setting knob "1".
1 = Main menu
2 = Device informaon
3 = Basic sengs
4 = Installer
Return to the main screen
The main screen is the Brink Air Control- Ventilation
start screen.
You can always return to the main screen by pressing
on the return key "2" a few times. The number of
times you need to press return depends on how deep
you have gone into the menu. U need not be afraid of
pressing return too frequently.
Brink Air Control- Ventilation 614884-B Brink / 15

5.2 Selecting a device connected to the Brink Air Control- Ventilation
You can choose the device you want to regulate with the control if multiple devices are connected to Brink Air
Control- Ventilation ( ® Selecting a device connected to the Brink Air Control- Ventilation page 14 ).
5.3 Weekly programmes P1, P2 and P3
You can programme the regulation of the ventilation mode in a weekly program. You can choose from programs
P1, P2 and P3.
Program P1
With this you create a day program for every day of the week.
Program P2
With this you create two day programs.
One day program for weekdays ‘mo-fri’ and one day program for the weekend ‘sa-su’.
Program P3
With this you create seven day programs.
Separately for every day of the week.
5.3.1 Standard settings P1, P2 and P3
The Brink Air Control- Ventilation has standard set weekly programmes. You can find these settings in appendix
(®Appendix: Standard settings weekly programs page 29).
Brink Air Control- Ventilation 614884-B

5.3.2 Creating a P1 program
▪Press returnkey "2" as many times as necessary
to get to the main screen,
▪Press setting & activating time program knob "3";
‘Setting & activating timer programme’ opens,
▪Select ‘P1: week’ by turning setting knob "1",
▪Press setting knob "1"; ‘P1: week’ opens.
You have a choice from ‘Period 1’, ‘Period 2’, ‘Period 3’, ‘Period 4’, ‘Period 5’ and ‘Period 6’. Every period is a part
of the day in which you can set a ventilation position. Perform the following actions to set period 1:
▪Select ‘P1’ by turning setting knob "1",
▪Press setting knob "1";‘Period 1’ opens,
▪Select ‘Start Time’ by turning setting knob "1",
▪Press setting knob "1"; ‘Start Time’ opens,
▪Change the start time by turning setting knob "1",
▪You have a range of between 3.00u and 2.59u.
If in a period the time is turned back so far that lines appear, that period and the one above it
will be deleted.
▪Press setting knob "1" to confirm the start time
Now set the ventilation mode for period 1. Perform the following actions for this:
▪Select ‘Ventilatiestand’ by turning "1",
▪Press "1" , ‘Ventilatiestand’ opens,
▪Set the ventilation mode for period 1 by turning "1",
▪Press "1" to confirm the ventilation mode for period 1.
You have set the ventilation mode for period 1. You can set period 2 through 6 in the same manner. A period ends
when a new one starts.
Brink Air Control- Ventilation 614884-B Brink / 17

5.3.3 Creating a P2 program
▪Press returnkey "2" as many times as necessary to get to
the main screen,
▪Press setting & activating time program knob "3";
‘Setting & activating timer programme’ opens,
▪Select ‘P2: week/weekend’ by turning setting knob "1",
▪Press setting knob "1"; ‘P1: week/weekend’ opens.
You can choose between ‘Week’ and ‘Weekend’. With ‘Week’ you can set a day program for Monday through
Friday. With ‘Weekend’ you can set a day program for Saturday and Sunday.
Week
▪Select ‘Week’ by turning setting knob "1",
▪Press setting knob "1"; ‘Week’ opens,
(*) You have a choice from ‘Period 1’, ‘Period 2’, ‘Period 3’, ‘Period 4’, ‘Period 5’ and ‘Period 6’. Every period
is a part of the day in which you can set a ventilation mode.
Perform the following actions to set period 1:
▪Select ‘Period 1’ by turning setting knob "1",
▪Press setting knob "1"; ‘Period 1’ opens,
▪Select ‘start time’ by turning setting knob "1",
▪Press setting knob "1"; ‘start time’ opens,
▪Change ‘start time’ by turning setting knob "1"; You have a range of between 3.00 hrs and 2.59 hrs,
▪Press setting knob "1" to confirm start time.
Now set the ventilation mode for period 1. Perform the following actions for this:
▪Select ‘Ventilatiestand’ by turning setting knob "1"
▪Press setting knob "1";‘Ventilatiestand’ opens
▪Set the ventilation mode for period 1 by turning setting knob "1"
▪Press setting knob "1" to confirm the airflow for period 1
You have set the ventilation mode for period 1 You can set period 2 through 6 in the same manner. A period ends
when a new one starts.
Weekend
▪Follow the steps from paragraph 5.3.3, until you have a choice between ‘Week’ and ‘Weekend’
▪Select ‘Weekend’ by turning setting knob "1"
▪Press setting knob "1"; ‘Weekend’ opens
▪Continue the steps from paragraph 5.3.3 at (*)
Brink Air Control- Ventilation 614884-B
