BRINKS ARRAY smart deadbolt User manual

Installation Instructions
999-00451
Simply Smart Security.™
Smart Deadbolt
Secure control from anywhere.™

999-00451
Installation Instructions
Box Contents
Mounting Screws (2) ---------
Mounting Plate Screw (1) ------------------
Latch & Strike Screws (4) ---------------------------
Interior Housing Screw (1) -------------------------
Battery Compartment Screws (2) ----------------------
Reinforcement Screws (2) ---
Exterior
Assembly
Interior
Assembly
Need help? Download the ARRAY™app or visit www.arraylock.com
for installation videos or call 1-800-850-LOCK (5625).
Rechargeable
Battery
Interior Mounting
Plate
Reinforcement
Plate
Strike
Plate
Dust Box
(Optional)
Drive-in
Collar
USB Cable
Wall Adapter
Square Corner
Face Plate
1
Latch
Screw
Cover
Battery Charging Cradle
Key (2)
Gasket

Tools you will need: Tools you may need:
Compatible Devices:
IMPORTANT INSTALLATION NOTES. PLEASE READ:
• Remove the battery from the battery compartment and charge it in the
Charging Cradle until the LED turns green.
• The ARRAY™lock has a built-in solar panel that will charge the battery if
positioned in direct sunlight. If unable to position the lock in direct
sunlight, you may need to charge the battery more frequently. You will see
the battery status on the app.
• Do not attempt to disassemble any internal components of the lockset.
You will void the warranty.
• Do not install the battery until you’ve installed the lock and downloaded
the app. Follow the instructions in order.
• Do NOT use a power drill to install the lock. A power drill should only be
used for door preparation.
• Make sure your door is properly aligned and can be closed without
pushing, pulling or lifting the door.
Note: New devices will continue to be added to enhance your experience with
the ARRAY™lock. Please visit our website www.arraylock.com for a complete
list of compatible devices.
2

Installation Overview
MOUNTING
SCREWS (AA)
KEY (A)
LATCH (G)
BATTERY COVER (L)
INTERIOR MOUNTING PLATE (H)
INTERIOR HOUSING
SCREW (CC)
ANTENNA
COVER (K)
MOUNTING PLATE
SCREW (BB)
BATTERY COMPARTMENT
SCREWS (DD)
RECHARGEABLE
BATTERY (J)
INTERIOR
ASSEMBLY (I)
STRIKE PLATE (N)
REINFORCEMENT PLATE (O)
REINFORCEMENT
SCREWS (FF)
DUST BOX (P)
LATCH & STRIKE SCREWS (EE)
EXTERIOR ASSEMBLY (B)
SCREW COVER (Q)
TAILPIECE
RECEIVER (M)
Part Description
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
Key
Exterior Assembly
Cylinder
Tailpiece
Power Cable
Gasket
Latch
Interior Mounting Plate
Interior Assembly
Rechargeable Battery
Antenna Cover
Battery Cover
Tailpiece Receiver
Strike Plate
Reinforcement Plate
Dust Box
Screw Cover
3
GASKET (F)
TAILPIECE (D)
POWER CABLE (E)
2-1/16" (52 mm) Mounting Screws (2) ---
1-1/4" ( 32 mm) Mounting Plate Screw (1) ------------
13/16" (20.3 mm) Interior Housing Screw (1) -----------------
5/16" (7.9 mm) Battery Compartment Screws (2) -----------------
3/4" (19.2 mm) Latch & Strike Screws (4) --------------------
3" (76.2) Reinforcement Screws (2) ----
AA
BB
CC
DD
EE
FF
Part Description
CYLINDER (C)

4. Install Latch and Strike Plate
Install Strike Plate (N) in the Door Frame
Strike plate (N)
Dust box (P)
Door Jamb
3/4" Strike Screws (EE)
3" Reinforcement Screws (FF)
Reinforcement plate (O)
2. Watch the Installation Video
1. Charge Battery
3. Prep the Door
Pre-Installation Instructions
b.
a. Remove the Battery Cover (L), Rechargeable
Battery (J), Battery Charging Cradle, USB Cable
and Wall Adapter. Remove the plastic tab on the
Battery (J). Slide the Battery (J) into the Charging
Cradle from the side. Charge the Battery (J) until
the LED Light turns from red to green.
b. Carefully remove the Antenna
Cover (K) by gently pulling the
edges outward slightly and lifting.
Antenna Cover (K)
Pull edge slightly
outward
4
a. If replacing an existing deadbolt. Remove the old hardware and begin at STEP 4.
b. If installing ARRAY™on a new door, follow the door preparation instructions on PAGE 9
and use the template provided on PAGE 10.
•FITS DOORS 1-3/8"(35 mm) TO 1-3/4"(45 mm) THICK •
Rechargeable
Battery (J)
USB Cable
Battery
Charging
Cradle
Wall Adapter
LED Light
a.
Slide
The ARRAY™lock is compatible with either iOSor Android™devices. Search for
“ARRAY™Lock” at the App Store or Play Store to download the free app. Once the
app is downloaded, register your lock and watch the installation video. Install your
ARRAY™ lock (Steps 3 – 5) and then follow the instructions to add a lock or visit
www.arraylock.com/pages/installation.

Set the Latch Backset
Install the Latch
The distance from the center of the bore hole to the edge of the door is called the backset. If the backset of your
door is 2-3/8", you don’t need to adjust the latch. The backset is preset for 2-3/8".
If the backset of your door is 2-3/4, you’ll need to adjust the latch as shown.
OR
2-3/8 (60 mm)
2
3
/
8
2
3
/
4
2-3/4 (70 mm)
b.
a.
180º
c.
3/4" Latch Screws (EE)
Wood Block
Option 1 Option 2
CAUTION: Be sure the latch is in the upright position.
Mortise on door edge chiseled:
Door edge not chiseled:
Square corner faceplate
Drive-in collar option
Drive-in collar
Round corner faceplate
Determine the Proper Faceplate
a
c
b
a.
c.
b.
OR
4. Install Latch and Strike Plate (Continued)
5

Apply Gasket
D.
Tailpiece (C)
Power
Cable (E)
Exterior
Assembly (B)
B.
C.
Mounting Plate
Mounting Plate
Remove Mounting Plate Screw
Use a wrench and in a counter-clockwise motion,
remove the Mounting Plate Screw (BB).
Slide keypad cover up.
Apply Gasket (F).
Slide keypad cover down.
Use a flathead screwdriver to remove the Mounting Plate.
B. Remove Mounting Plate C.
Mounting
Plate
Screw (BB)
Exterior
Assembly (B)
Exterior
Assembly (B)
5. Install Lock Assemblies
A. A.
Deadbolt Installation Instructions
For door with bore hole 2-1/8" diameter
proceed to STEP D.
For door with bore hole 1-1/2" diameter follow Steps B
and C for Mounting Plate Screw (BB) and Mounting Plate
removal.
Bore Hole
2-1/8"
diameter
Door Bore Hole Options
Bore Hole
1-1/2"
diameter
OR
Mounting
Plate
Screw (BB)
Mounting
Plate
Option 1 Option 2
6
A.
Latch bolt MUST
be in the retracted
position.
IMPORTANT:
2
3
2
2
3
Gasket (F)
Gasket
(F)
Gasket
(F)

F.
Door
Interior
Mounting Plate (H)
Tailpiece (D)
Power
Cable (E)
Exterior
Assembly (B)
Bulged part of the Interior Mounting Plate (H)
must be toward the door.
Power Cable (E) goes underneath the latch. Insert
Tailpiece (D) horizontally.
E.
Tailpiece
(C)
Power
Cable (E)
E.
F.
EXTERIOR VIEW
5. Install Lock Assemblies (Continued)
Exterior
Assembly (B)
7
H. Install the Power Cable (E) firmly into the Connector Port. I. Secure the Power Cable (E) onto the
Interior Mounting Plate (H) as shown.
G.
Interior Mounting
Plate (H)
Mounting
Screws (AA)
Feed Power Cable (E) through Interior Mounting Plate (H) as shown. Insert Mounting Screws (AA) and
Mounting Plate Screw (BB) as shown and tighten.
Power
Cable (E)
Tailpiece (D)
Mounting Plate
Screw (BB)
Power
Cable (E)
Interior
Mounting Plate (H)
INTERIOR VIEW
Tailpiece (D)
H.
Power
Cable (E)
Connector
Port
INTERIOR VIEW
H.
Power
Cable (E)
Interior
Mounting
Plate (H)
I.
G.

K.
J.
J.
L.
K. Insert the two Battery Compartment Screws (DD)
and tighten. Insert the Interior Housing Screw (CC)
and tighten.
L. Re-install the Antenna Cover (K) by gently separating
both sides of the Cover (K) and snapping the Cover
(K) onto the side ridges of the Interior Assembly (I).
Apply Screw Cover (Q).
Battery
Compartment
Screws (DD)
Interior
Housing
Screw (CC)
Antenna
Cover (K)
Screw
Cover (Q)
Pull edge
slightly outward
Interior
Assembly (I)
Side Ridge
5. Install Lock Assemblies (Continued)
6. Return to the app and follow the instructions to Add a Lock
Interior
Assembly (I)
INTERIOR VIEW
Tailpiece (D)
Power
Cable (E)
J. Align the Tailpiece Receiver (M) of the Interior Assembly (I) into the Tailpiece (D).
8
Tailpiece Receiver (M)
Interior
Assembly (I)
Take care not to damage the antenna when
inserting the Battery Compartment Screws (DD).
CAUTION:

a,b c
1"
25.4 mm
2 "
54 mm
8
1
44"
1120 mm
DOOR JAMB
Drill Holes
d.
Mark latch screw holes and drill two 1/8" (3 mm)
pilot holes for the Latch Screws.
a.
Drill a 2-1/8" (54 mm) hole on the door face from
both sides to avoid splitting wood.
b.
a.
a.
b.
b.
Drill a 1" (25.4 mm) hole in the door edge for the
latch.
c.
Insert latch into hole, mark outline of faceplate, and
chisel 1/8" (3 mm) deep or until the faceplate is
flush with the door edge.
Prepare Door Jamb for Strike Plate
Mark centerline on the door jamb exactly opposite
the latch hole in the door edge. Make sure that the
mark is correct so that the latch bolt will enter the
strike plate without intereference when the deadbolt
is locked.
ab
c
d
44"
1120 mm
5½"
140mm
a.
b.
c.
d.
Mark the centerline for the deadbolt about 44"
(1120 mm) from the floor, or about 5-1/2" (140 mm)
above the center of an existing knob or lever.
Apply the template to the door with the dotted
fold line on the door edge.
Select the 2-3/8" (60 mm) or 2-3/4" (70 mm)
backset and mark the center for the hole for the
deadbolt on the door face. (Most residential doors
have a 2-3/8" backset.)
Mark the center for the latch hole on the door edge
according to the thickness of your door.
Mark Door with Template
Using the strike plate as a pattern, drill the latch and
screw holes, and chisel out a mortise until the strike
plate fits flush.
Door Jamb Hole Dimension
A.
B.
C.
Strike Plate Dimension
D.
E.
F.
1-9/16" (40 mm)
5/32" (4 mm)
2-3/4" (70 mm)
1-1/8" (28 mm)
1-3/16" (30 mm)
1" (25 mm)
C
B
F
E
AD
3/4" Strike Screws (EE)
3" Reinforcement
Screws (FF)
Strike plate
Reinforcement plate
Dust box
Door Jamb
9
Door Preparation Instructions for New Doors
If installing ARRAY™on a new door, follow the door preparation
instructions and use the template on Page 10.

45mm 40mm 35mm
For backset 2-3/4" (70mm) For backset 2-3/8" (60mm) Fits 2-1/8" (54mm) cylinder hole
Fold on dotted line and t on door edge
Make a 1" (25.4mm) hole at center of door edge
C
LC
LC
L
1-3/4" 1-9/16" 1-3/8"
TEMPLATE
This line should be 3 inches. Measure it before using this template. If the line is not 3 inches when measured, print this instruction out, full scale on paper that is 8.5" x 11" and measure again.
3"
10

50 Icon, Foothill Ranch, CA 92610-3000 USA
email: [e-mail]
www.arraylock.com | 1-800-850-5625
Made in Taiwan
©2017 Hampton Products International Corp.
999-00451E_REVA 10/17
BRINKS HOME SECURITY and all related logos are
trademarks or registered trademarks of Brink’s
Network, Inc., and are used with permission.
WARRANTY – Full Lifetime mechanical & finish warranty and limited one-year electronics warranty.
Subject to the terms and conditions of this warranty, Hampton Products Int’l Corp. (“Hampton”) extends a full lifetime mechanical and finish warranty and a
limited one-year electronics warranty to the original residential user (“Original User”) of this product (“Product”) against defects in material and workmanship
as long as the Original User occupies the residential premises upon which the Product was originally installed. This warranty only applies to the Original User
of Product. This Warranty is not transferable. Upon pre-authorized return of defective Product to Hampton, Hampton may repair or replace the Product with
a new or refurbished product at Hampton’s sole discretion.
What is NOT covered: The following costs, expenses and damages are not covered by the provisions of this limited warranty: (1) labor costs including, but not
limited to, such costs for the removal and reinstallation of Product; (2) shipping and freight expenses required to return Product to Hampton; (3) failures,
defects, or damage (including, but not limited to, any security failure or loss of data), caused by any third party product, service, or system connected or used
in conjunction with the Product, and; (4) any other incidental, consequential, indirect, special and/or punitive damages, whether based on contract, warranty,
tort (including, but not limited to, strict liability or negligence), patent infringement, or otherwise, even if advised of the possibility of such damages. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so the above exclusion or limitation may not apply to you. This warranty
give you specific legal rights and you may also have other rights that vary from state to state.
The provisions of this Warranty do not apply to Product: (i) used in commercial applications; (ii) used in common area applications; (iii) used for purposes for
which they are not designed or intended; (iv) which have been subjected to alteration, abuse, misuse negligence or accident; (v) which have been improperly
stored, installed, maintained or operated; (vi) which have been used in violation of written instructions provided by Hampton; (vii) which have been subjected
to improper temperature, humidity or other environmental conditions; (viii) which, based on Hampton’s examination, do not disclose to Hampton’s satisfaction
non-conformance to the warranty. Additionally, the limited lifetime warranty DOES NOT COVER scratches, abrasions, or deterioration due to the use of paints,
solvents or other chemicals, abuse, misuse, or Product used in commercial applications.
Additional terms: Hampton does not authorize any person to create for it any obligation or liability in connection with the Product. Hampton’s maximum
liability is limited to the original purchase price of the Product. No action arising out of any claimed breach of this warranty by Hampton may be brought by
the Original User more than one (1) year after the cause of action has arisen.
Exclusions: Tuscan Bronzefinish is designed to improve over time and change in appearance, creating a living finish through daily use and, thus, finish
discoloration is not applicable to the above warranty.
For assistance or specific warranty details and limitations information, please call 1-800-850-5625 in the U.S and Canada, or visit www.arraylock.com.
•
Misusing the battery may cause it to get hot, explode, or ignite and cause injury. Follow the safety rules listed below:
oDo not place battery in fire or heat the battery.
oDo not penetrate the battery with nails, strike the battery with a hammer, step on the battery, or otherwise subject it to
strong impacts or shocks.
o
Do Not Open, Crush, Heat Above 60°C (140°F), or Incinerate.
oDo not solder directly onto the battery.
•Do not disassemble or modify the battery. The battery contains safety and protection devices which, if damaged, may cause the
battery to generate heat, explode, or ignite.
•Do not place the battery on or near fires, stoves, or other high-temperature locations.
oDo not place the battery in direct sun or use or store the battery inside hot conditions.
Doing so may cause the battery to generate heat, explode, or ignite.
•Immediately discontinue use of the battery if, while using, charging, or storing the battery, it emits an unusual smell, feels hot, or
appears abnormal in any other way.
•In the event that the battery leaks and the fluid gets into one’s eye, do not rub the eye. Rinse well with water and immediately
seek medical care. If left untreated, the battery fluid could cause damage to the eye.
•The temperature range for using the battery is -10°C to 60°C (14°F to 140°F). Use of the battery outside of this temperature
range may damage the performance of the battery or may reduce its life expectancy.
•Do not use the battery in any device except the BRINKS HOME SECURITY ARRAY™Smart Deadbolt.
ARRAY™BATTERY MANUFACTURER’S INSTRUCTIONS
WARNING:
FCC GENERAL STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna, or increase the separation between the equipment and receiver.
• Connect the receiver to a dierent outlet.
• Consult Hampton Products International Corporation or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment (i.e. any changes or modification that may influence the specification of radio frequency relating to the Wi-Fi®is prohibited).
FCC ID Number: 2ANTYA2350X
Wi-Fi®is a registered trademark of Wi-Fi Alliance®.
