Instructions for Installation & Use - Series No. BS4000A-020133 1
Instructions for Installation & Use
Series No. BS4000A-020133
IMPORTANT:
KEEP THIS BOOKLET IN THE PLACE PROVIDED ON
THE CHILD RESTRAINT
CAR BOOSTER SEAT
FORWARD
FACING
4 years to
6-8 years
(approx).

Instructions for Installation & Use - Series No. BS4000A-020133
2
SEATBELT QUICK SETUP
1
5
3
4
6
2

Instructions for Installation & Use - Series No. BS4000A-020133 3
SEATBELT QUICK SETUP
8
9
7

Instructions for Installation & Use - Series No. BS4000A-020133
4
To be used with a lap-sash seatbelt by a child whose shoulders are above the
lower shoulder height marker (approximately 4 years of age) until the child’s
shoulders reach the upper shoulder height marker (approximately 6 to 8 years of
age).
Can also be used with child harness that is approved for use with this booster
seat.
Continue to use this booster seat until the child reaches this limit. Children are
safest in a booster seat until their shoulders reach the upper shoulder height
marker of the booster seat.
Do not use this booster seat until child’s shoulders are above the lower shoulder
height marker.
If the knees do not bend in front of the vehicle seat cushion continue to use a
booster seat.
Just using a seatbelt is not recommended for children that have outgrown this
seat. Use a larger booster seat.

864


 




INTRODUCTION
用于肩膀超过靠下的肩高标记的儿童（大约4岁的儿童），配安全腰带一起使
用，直到儿童的肩膀达到靠上的肩高标记（约6-8岁的儿童）。
也可以和该垫高椅匹配的儿童安全带一起使用。
在儿童达到垫高椅上限之前必须使用垫高椅。在儿童肩膀达到垫高椅靠上的肩
高标记之前最安全的做法是使用垫高椅。
在儿童肩膀未超过靠下的肩高标记时不得使用此垫高椅。
如果儿童在车辆弹性座垫前无法自然屈膝则需要继续使用垫高椅。
不建议个子比该座椅大的儿童只使用安全带，要使用较大的垫高椅。

Instructions for Installation & Use - Series No. BS4000A-020133 5
INTRODUCTION
Da usare con una cintura di sicurezza fasciante da un bambino le cui spalle
superano il marcatore di altezza inferiore (circa 4 anni di età) fino a quando
le spalle del bambino raggiungono il marcatore di altezza della spalla
superiore (circa 6 a 8 anni di età).
Con questo seggiolino, può essere utilizzato anche con un'imbracatura per
bambini approvata per l'uso.
Continuare a utilizzare questo seggiolino fino a quando il bambino
raggiunge questo limite. I bambini sono più sicuri su un seggiolino finchè le
loro spalle raggiungono il marcatore di altezza superiore del seggiolino.
Non utilizzare il seggiolino fino a quando le spalle del bambino sono al di
sopra del marcatore altezza inferiore.
Se le ginocchia non si piegano al limite del sedile del veicolo continuare ad
utilizzare un seggiolino.
Usare soltanto la cintura di sicurezza non è raccomandato per i bambini che
sono troppo grandi per questo sedile. Utilizzare un seggiolino più grande.
    -               
   ( 4    )                 
  ( 6  8    )
                     
                      
                
                       

                 
                      
         

Instructions for Installation & Use - Series No. BS4000A-020133
6
INTRODUCTION
Được sử dụng với dây nịt an toàn quàng qua vai của em có vai ở trên vạch
ghi độ cao của vai ở dưới cùng (khoảng 4 tuổi) cho đến khi vai em cao tới
vạch ghi độ cao của vai ở trên cùng (khoảng 6-8 tuổi).
Cũng có thể được sử dụng với đai nịt trẻ em được chấp thuận sử dụng với
ghế trẻ em (booster) này.
Hãy tiếp tục sử dụng ghế trẻ em (booster) này cho đến khi em cao tới giới
hạn này. Trẻ em được an toàn nhất trong ghế trẻ em (booster) cho đến khi
vai của em đạt tới vạch ghi độ cao của vai ở trên cùng của ghế trẻ em.
Không sử dụng ghế trẻ em (booster) này cho đến khi vai của em ở trên vạch
ghi độ cao của vai ở dưới cùng.
Nếu đầu gối không co lại đằng trước đệm ghế của xe, hãy tiếp tục sử dụng
ghế trẻ em (booster).
Chỉ sử dụng dây nịt an toàn nào không được đề nghị cho các em lớn hơn
ghế này. Hãy sử dụng ghế trẻ em rộng hơn.
應與安全腰帶一同使用，適用於肩膀超過靠下的肩高標記的孩子（大約4歲
大），直至其肩膀達到靠上的肩高標記（大約6至8歲大）。
也可同與此墊高椅匹配的兒童安全背帶一並使用。
讓您的孩子一直乘坐墊高椅，直至其達到墊高椅的上限。在孩子肩膀達到墊高
椅靠上的肩高度標記之前，使用墊高椅是最安全的做法。
在孩子肩膀超過靠下的肩高標記前，切勿使用此墊高椅。
若孩子在汽車座椅邊無法自然曲膝，請繼續使用墊高椅。
孩子因長大超出墊高椅的上限時，不推薦僅僅使用安全帶。請使用更大尺寸
的墊高椅。
Debe utilizarse con un cinturón de seguridad de tres puntos para
un niño cuyos hombros sobrepasen el marcador de altura inferior
(aproximadamente a los 4 años de edad) hasta que los hombros del niño
alcancen el marcador de altura superior (aproximadamente de 6 a 8 años
de edad).
También se puede utilizar con un arnés para niños cuyo uso con este
asiento elevador esté aprobado.
Siga utilizando este asiento elevador hasta que el niño alcance dicho límite.
El niño estará más seguro en un asiento elevador hasta que sus hombros
alcancen el marcador de altura superior del asiento elevador.
No utilice este asiento elevador hasta que los hombros del niño sobrepasen
el marcador inferior.
Si las rodillas del niño no se doblan en la parte delantera del cojín del
asiento del vehículo siga utilizando un asiento elevador.
No se recomienda utilizar sólo un cinturón de seguridad para el niño que ya
no quepa en este asiento. Utilice un asiento elevador más grande.

Instructions for Installation & Use - Series No. BS4000A-020133 7
INTRODUCTION
Να χρησιμοποιείται με ζώνη ασφαλείας τριών σημείων από ένα παιδί
του οποίου οι ώμοι είναι πάνω από τον χαμηλότερο δείκτη ύψους ώμου
(περίπου 4 ετών) μέχρι οι ώμοι του παιδιού να φτάνουν στον ανώτερο δείκτη
ύψους ώμου (περίπου 6 έως 8 ετών).
Μπορεί επίσης να χρησιμοποιηθεί με τον παιδικό ιμάντα που έχει εγκριθεί
για χρήση με αυτό το βοηθητικό κάθισμα.
Συνεχίστε να χρησιμοποιείτε αυτό το βοηθητικό κάθισμα μέχρι το παιδί να
φτάσει σε αυτό το όριο. Τα παιδιά είναι ασφαλέστερα σε ένα βοηθητικό
κάθισμα μέχρι οι ώμοι τους να φθάνουν στον ανώτερο δείκτη ύψους ώμου
του βοηθητικού καθίσματος.
Μην χρησιμοποιείτε αυτό το βοηθητικό κάθισμα μέχρι οι ώμοι του παιδιού
να είναι πάνω από τον χαμηλότερο δείκτη ύψους ώμων.
Αν τα γόνατα δεν λυγίζουν μπροστά από το μαξιλάρι καθίσματος του
οχήματος, συνεχίστε να χρησιμοποιείτε ένα βοηθητικό κάθισμα.
Η χρήση μόνον μιας ζώνης ασφαλείας δεν συνιστάται για παιδιά που έχουν
ξεπεράσει σε ύψος αυτό το κάθισμα. Χρησιμοποιήστε ένα μεγαλύτερο
βοηθητικό κάθισμα.
Gamitin kasama ang isang lap-sash na seatbelt ng isang bata na ang
mga balikat ay lampas na sa ibabang marka ng taas ng balikat (humigit-
kumulang 4 na taong gulang) hanggang sa maabot ngmga balikat ng bata
ang itaas na marka ng taas sa balikat (humigit-kumulang 6-8 taong gulang).
Maaari ring gamitan ng guwarnisyon ng bata na naaprubahang gamitin
kasama ang upuang booster na ito.
Patuloy na gamitin ang upuang booster na ito hanggang sa maabot ng bata
ang limitasyong ito. Ang mga bata ay pinakaligtas sa isang upuang booster
hanggang sa maabot ng kanilang mga balikat ang itaas na marka ng taas
ng balikat ng upuang booster.
Huwag gamitin ang upuan booster na ito hanggang sa ang mga balikat ng
bata ay lumampas sa ibabang marka ng taas ng balikat.
Kung ang mga tuhod ay hindi makaliko sa harap ng kutson ng upuan ng
sasakyan ay patuloy na gamitin ang upuang booster.
Ang paggamit lamang ng seatbelt ay hindi inirerekomenda para sa mga
bata na nakalakhan na ang upuang ito. Gumamit ng mas malaking upuang
booster.

Instructions for Installation & Use - Series No. BS4000A-020133
8
INTRODUCTION
Carefully read all the instructions for installation. If in doubt about the method of
installation, consult Britax Childcare or agent or a child restraint fitter or, in New
Zealand, consult the agent for the vehicle.
There is no requirement to attach this booster seat to the car's child restraint
upper anchorage fitting.
THIS RESTRAINT MUST BE USED IN CARS WITH FORWARD FACING
SEATS WITH A LAP-SASH SEATBELT OR WITH A SEATBELT AND CHILD
HARNESS. When used with a Child Harness either lap only seatbelt or lap-
sash seatbelt may be used.
This booster seat should be use in the rear seating position wherever
possible as this is a safer position.
Suitable for use with the following child harness:
Safe-n-Sound Protecta PLUS™Child Harness Series 220/2013.
No child restraint can guarantee absolute protection from injury in every crash.
However, to ensure that your child gets all the protection designed into the
restraint PLEASE READ AND FOLLOW THESE INSTRUCTIONS EXACTLY.
This child restraint is not suitable for use on an aircraft.
Always store the instruction book in the pocket provided on the side of the
headrest.

Instructions for Installation & Use - Series No. BS4000A-020133 9
INDEX
INTRODUCTION
WARNINGS
SHOULDER HEIGHT MARKERS AND A GROWING CHILD
SHOULDER HEIGHT MARKERS
SHOULDER HEIGHT MARKERS AND THE NEXT STEP
SPECIAL FEATURES
HOW TO SETUP
HOW TO USE
HOW TO USE WITH A CHILD HARNESS
TO REMOVE CHILD
CARE & MAINTENANCE
HOW TO CLEAN
IN CASE OF ACCIDENT
WARRANTY
8
12
13
14
15
16
18
10
24
34
36
35
37
40
PAGE

Instructions for Installation & Use - Series No. BS4000A-020133
10
• Use the restraint exactly as shown in the instructions.
• Supervision of children is needed because they may be able to undo the
buckles and/or special features.
• DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR.
• Do not alter or modify this restraint. Use only recommended parts and
accessories.
• Repairs must only be done by the manufacturers or agent.
• Do not allow the restraint to come into contact with polishes, oils, bleach and
other chemicals.
• Destroy the restraint if it has been in a severe crash, even if no damage is
visible.
• DO NOT USE THIS RESTRAINT WITHOUT THE COVER.
• DO NOT USE WITH JUST A LAP BELT. You must use with lap-sash seat belt,
or with a seat belt and child harness.
• The lap part of the seat belt must be firmly across the thighs and the sash
straps fitted diagonally across the chest and on the shoulder.
• If used with a child harness, the lap belt must be adjusted firmly first, and
then the harness, so that the lap-belt is not lifted off the child’s lap when the
harness is adjusted.
• Regularly check the restraint components, straps and other fitments for correct
function, cracking & condition. Seek immediate repair.
• IF AN AIRBAG IS FITTED IN THE SEATING POSITION WHERE
THE CHILD RESTRAINT IS TO BE FITTED, FOLLOW THE VEHICLE
MANUFACTURER’S WARNINGS AND INSTRUCTIONS.
• The lap belt on the abdomen is dangerous. The lap belt positioning anti
submarining device SecureGuard™ must always be used.
• This child restraint is not approved for use with any connectors that connect to
the car's ISOFIX low anchorages.

Instructions for Installation & Use - Series No. BS4000A-020133 11
• Seatbelt extenders are not recommended to be used if the seatbelt is not long
enough to secure the child restraint. If seatbelts are too short then seek advice
from a child restraint fitter and consider their recommendations before using a
seatbelt extender. If you use a seatbelt extender then ensure that the seatbelt
buckle does not contact the child.
• Do not use in a front seat, unless your child is over 4 years of age or in
accordance with the applicable Road Rules in your region. Research shows
that children under 12 years old are at a greater risk of serious injury when
travelling in the front seat.
• Do not use on any vehicle seat which faces sideways or rearwards.
• Use of aftermarket accessories (i.e. items not provided in the box with the
child restraint), can reduce the safety provided by the child restraint and may
cause injury or death.
• Use a towel or seat protector (messy mat) to protect the vehicle seat.
Protection of both underneath and behind the booster seat may be required.
• Do not store in hot places or underneath heavy objects. The plastic may
distort.
• The restraint should not be purchased or sold as a second hand item. It is
recommended not to use child restraints older than 10 years as the protection
in an accident may be reduced.
IMPORTANT :

Instructions for Installation & Use - Series No. BS4000A-020133
12
SHOULDER HEIGHT MARKERS AND
A GROWING CHILD
SMALLER CHILD
Shoulders must not be below the Lower
Shoulder Height Marker.
From approximately 4 years of age.
TALLER CHILD
Shoulders must not be above the Upper
Shoulder Height Marker.
To approximately 6 to 8 years of age.
Height label will be behind the child’s neck.
Front of Vehicle
Marker B
NOTE: These heights also apply if you are
using a Child Harness with the booster seat.
Marker B
Marker A
Marker A

Instructions for Installation & Use - Series No. BS4000A-020133 13
IMPORTANT: Follow this advice.
MARKER A: LOWER SHOULDER HEIGHT MARKER
The child’s shoulders must be in-line or above this marker. Approximately 4 years
of age. If the child’s shoulders are below then the child should remain in their
previous child restraint.
MARKER B: UPPER SHOULDER HEIGHT MARKER
When the child’s shoulders reach this upper marker, or the child no longer fits
in the child restraint, approximately 6 to 8 years of age, then the child must be
moved to the next form of child restraint, see next page.
SHOULDER HEIGHT MARKERS
The child restraint is unsuitable for the occupant when the shoulders are below
the lower marker or above the upper height marker.

Instructions for Installation & Use - Series No. BS4000A-020133
14
Or the car's lap-sash seatbelt if the lower
leg is able to hang over the edge of the seat
cushion.
Next type of restraint that can be used in the car for your
child.
When your child has outgrown the this booster seat, you can then use either
restraint methods as follows:
A larger booster seat suitable for children up to 8-10 years
of age.
Safe-n-Sound recommends the Encore 10 for children who
have outgrown this booster seat.
Safe-n-Sound recommend to keep your child in the appropriate restraint suitable
for their age and size, only moving to the car's lap-sash seatbelt setup when they
no longer fits a dedicated child restraint.
SHOULDER HEIGHT MARKERS AND
AND THE NEXT STEP

Instructions for Installation & Use - Series No. BS4000A-020133 15
SPECIAL FEATURES
Front of Vehicle
1
3
1. Padded Cover for Comfort
2. BOOSTER SEATBELT PATH label (each side, for lap belt)
3. SecureGuard™ Anti Submarining Device
4. Shoulder Height Markers
5. Sash guide
6. BOOSTER SEATBELT PATH label (each side, for sash belt)
7. Child harness slots
2
5
6
4
7

Instructions for Installation & Use - Series No. BS4000A-020133
16
HOW TO SETUP
ADJUSTING THE
SECUREGUARD™ DEVICE
The SecureGuard™ Device crotch strap must
be adjusted so that it fits the seatbelt correctly to
the child. The crotch strap length adjuster can be
found under the seat.
A. Underneath the base the length of the crotch
strap can be adjusted by threading webbing
through the adjuster in the direction of the
arrows shown below.
B. Adjust the crotch straps of the SecureGuard™
Device so that the Lap portion of the seatbelt
is positioned as low as possible on the child's
hips and thighs and the lap belt is prevented
from rising up the abdomen. Ensure the
SecureGuard™ Device does not push
into your child's thighs as this may cause
discomfort. Adjust the crotch strap to a shorter
length when using the seat with a smaller child.
TO SHORTEN
TO LENGTHEN
Bottom edge of
SecureGuard™
Device level
with top of legs
(with all slack
removed from
crotch straps).
2 Bar
Slide
2 Bar
Slide
The SecureGuard™ Device must always be setup to position the lap belt
correctly on the child's hips and thighs. The occupant may be injured in an
vehicle crash if the SecureGuard™ Device is set too high. DO NOT attempt to
remove or dismantle the crotch strap and SecureGuard™ Device.
DO NOT REMOVE 2 BAR SLIDE FROM SECUREGUARD™ STRAPS.
CAUTION:
ALWAYS USE THE SECUREGUARD™ DEVICE
Under booster seat
Adjuster
SecureGuard™ position
TOO HIGH
SecureGuard™ position
OK

Instructions for Installation & Use - Series No. BS4000A-020133 17
HOW TO SETUP
SETTING UP THE SASH GUIDE
The sash guide needs to be positioned to the same side as the sash belt route.
A. The Sash guide is found attached to
a strap at the back of the restraint.
B. Thread the sash guide through the
slot in the seat cover on the same
side as the sash belt is connected
to the car. Refit the seat cover to the
restraint if it was removed.
IMPORTANT:
ALWAYS USE THE SASH GUIDE

Instructions for Installation & Use - Series No. BS4000A-020133
18
HOW TO USE
A. Place the booster seat in the desired seating position.
B. Seat the child in the seat. The child's shoulders must be between the lower
and upper shoulder height markers.
C. Pull the seatbelt out and place the lap belt over the child's hips and thighs,
across the red BOOSTER SEATBELT PATH label, engage seatbelt
buckle and tongue, ensuring there are no twists in the belt. If the seatbelt
buckle is adjustable, adjust the buckle as low as possible away from the child.
BOOSTER
SEATBELT
PATH label

Instructions for Installation & Use - Series No. BS4000A-020133 19
HOW TO USE
D. Feed the sash-belt across the child's chest and through the sash guide. The
sash guide should be used to correctly position the sash portion of the seatbelt
over the child’s shoulder and across the chest.
IMPORTANT:
ALWAYS USE THE SASH GUIDE
Sash
guide

Instructions for Installation & Use - Series No. BS4000A-020133
20
HOW TO USE
CAUTION:
ALWAYS USE THE SECUREGUARD™ DEVICE
Engage
buckle
E. Hook the SecureGuard™ Device over the lap part of the seatbelt with the lap
belt positioning logo facing forward. The SecureGuard™ Device must be used
at all times to prevent the child slumping (sliding forward at base of seat) as
the lap belt on the abdomen is dangerous in the event of a crash.
F. Tighten the lap belt and the
sash belt if using an Inertia
reel retractor seatbelt, adjust
lap portion of the seatbelt
firmly around the child and
child booster seat, place the
sash belt through sash guide
where the red BOOSTER
SEATBELT PATH label is.
Allow the slack sash portion to
retract into the seatbelt.
Sash belt
across the
chest and
through the
sash guide
