Britax XTENSAFIX User manual

1. Open the harness buckle 21 (press red button)
2. Press the adjusting button 26 and at the same time pull both
shoulder belts 08 forwards. Do not pull on the shoulder
pads 19 .
3. Have your child sit down in the child seat.
21
26
08
19
4. Guide the two buckle latches 20
together and engage them befo-
re putting them into the harness
buckle 21 - this should make a
clicking noise.
Pull on the adjusting strap 09 until the harness lies at and is
close against your child‘s body.
CAUTION! Pull out the adjusting strap to the front.
CAUTION! The hip straps 27 must be positioned as low
as possible over your child‘s hips.
20 21
09
27
7. Push the child seat towards the backrest applying rm, even
pressure on both sides.
8. Shake the child safety seat to make sure it is safely attached
and re-check to the green safety buttons 04 to make sure
that both of them are completely green.
9. Take the Top Tether 13 and press the metal tongue 16 away
from the strap to lengthen the strap and pull the Top Tether
13 by the snap hook 17 until it makes a V-shape.
10. Guide the Top Tether 13 on the left and right-hand sides
past the headrest.
To remove the child seat follow the steps in section 10
11. Hook the snap hook 17 into the Top Tether anchoring point
recommended in your vehicle owner‘s guide.
CAUTION! Be sure not to use the luggage hook instead of
the Top Tether point. Check your vehicle and look for this
sign:
5. Place the child seat facing in the direction of travel on the
vehicle seat.
6. Pull the vehicle belt 22 out and guide it through the belt
guides 23 of the child seat. Make sure that the belt is not
twisted.
7. Engage the buckle tongue in the vehicle seat buckle 29
CLICK!
8. On the side opposite the car seat belt buckle, swivel
clamping lever 24 down and insert diagonal belt in belt
lock-off 25 .
9. Apply your body weight to the child seat (kneel into the
seat). At the same time pull the diagonal belt strongly to
tighten (hold tension) and swivel the clamping lever 24
upwards until it engages.
10. To re-tension pull the diagonal belt whilst the belt lock-off
25 is closed.
1. Make sure that the child seats 5-point harness is installed
correctly (see section 9)
2. Make sure that the child seats metal plate is in the right
position (see section 9 step 7)
3. Follow the steps in section 6.2
4. Take the Top Tether 13 from the stow-pocket 14 and lay it
over the child seat.
11. Take the Top Tether 13 and press the metal tongue 16
away from the strap to lengthen the strap and pull the Top
Tether 13 by the snap hook 17 until it makes a V-shape.
12. Guide the Top Tether 13 on the left and right-hand sides
past the headrest.
13. Hook the snap hook 17 into the Top Tether anchoring point
recommended in your vehicle owner‘s guide.
CAUTION! Be sure not to use the luggage hook instead of
the Top Tether point. Check your vehicle and look for this
sign:
14. Tension the strap of the Top Tether 13 until the tension
indicator 18 turns green and the Top Tether 13 is tightly
tensioned.
15. Follow the steps in section [securing your child with 5-point
harness].
5. Push both ISOFIT locking arms 15 into the insert guides
02 , until the ISOFIT locking arms engage on both sides.
„CLICK!“
CAUTION! The locking arms are only correctly engaged if
both of the green safety buttons 04 are completely green.
1. Make sure that the child seats 5-point harness is removed
correctly (see section 8)
2. Follow the steps in section 6.1
3. Follow the steps in section 6.3
4. Place the child seat facing in the direction of travel on the
vehicle seat.
6. Push the child seat towards the backrest applying rm, even
pressure on both sides.
7. Shake the child safety seat to make sure it is safely attached
and re-check to the green safety buttons 04 to make sure
that both of them are completely green
8. Have your child sit down in the child seat.
9. Pull out the vehicle seat belt and guide it in front of your child
to the vehicle seat buckle 29 .
CAUTION! Do not twist the belt.
10. Engage the buckle tongue in the vehicle seat buckle 29
CLICK!
11. Place the diagonal seat belt section 11 and lap belt secti-
on 28 on the side of the vehicle seatbelt buckle 29 under
the armrest and into the light red belt guide 23 of the seat
cushion.
12. CAUTION! The vehicle seatbelt buckle 29 must not
be positioned between the light red belt guide 23 and the
armrest.
13. Place the lap belt section 28 on the other side of the seat
cushion in the light red belt guide 23 .
CAUTION! The lap belt section 28 must lie as low as
possible over your child‘s hips on both sides
14. Guide the diagonal seat belt section 11 into the dark red
belt holder 30 of the headrest 07 until it lies completely in
the belt holder 30 and is not twisted.
Tip! If the backrest 31 conceals the belt holder 30 , you can
adjust the headrest 07 upwards. The diagonal seat belt secti-
on 11 can now be easily inserted. Now return the
headrest 07 to the proper height.
15. Make sure that the diagonal seat belt section 11 runs over
your child‘s shoulder bone, and not in front of his or her
neck.
Tip! You can still adjust the height of the headrest 07 again
here in the vehicle.
CAUTION! The diagonal seat belt section 11 must run
diagonally backward. You can adjust the course of the belt with
your vehicle‘s adjustable belt deector.
CAUTION! The diagonal seat belt section 11 must never
lead forward to the vehicle‘s belt deector.
In this case, only use the child seat on the rear seat.
For the safety of your child, before every journey in the car check that...
►the child safety seat is engaged on both sides with the ISOFIT locking arms 15
in the ISOFIT attachment points 01 and that both green safety buttons 04 are
completely green;
►the child safety seat is securely fastened;
►the lap belt section 28 runs through the light red belt guides 23 on both sides of
the seat cushion,
►the diagonal seat belt section 11 on the side of the vehicle seatbelt buckle 29 also
runs through the light red belt guide 23 of the seat cushion,
►the diagonal seat belt section 11 runs through the dark red belt holder 30 of the
headrest,
►the diagonal seat belt section 11 runs diagonally backward,
►the straps are tight and not twisted,
►the vehicle seatbelt buckle 29 is not positioned between the light red belt guide 23
and the armrest of the seat cushion.
Caution: If your child attempts to open the ISOFIT safety buttons 04 or the
harness buckle 21 , make sure to stop at the earliest opportunity. Check that the
child safety seat is correctly attached and make sure that your child is properly
secured. Teach your child about the dangers involved.
1. Make sure that the child seats 5-point harness is removed
correctly (see section 8)
2. Follow the steps in section 6.3
3. Pull out the vehicle seat belt and guide it in front of your child
to the vehicle seat buckle 29 .
CAUTION! Do not twist the belt.
4. Engage the buckle tongue in the vehicle seat buckle 29 .
CLICK!
5. Place the diagonal seat belt section 11 and lap belt section
28 on the side of the vehicle seatbelt buckle 29 under
the armrest and into the light red belt guide 23 of the seat
cushion.
CAUTION! The vehicle seatbelt buckle 29 must not be
positioned between the light red belt guide 23 and the
armrest.
6. Place the lap belt section 28 on the other side of the seat
cushion in the light red belt guide 23 .
CAUTION! The lap belt section 28 must lie as low as
possible over your child‘s hips on both sides.
7. Guide the diagonal seat belt section 11 into the dark red
belt holder 30 of the headrest 07 until it lies completely in
the belt holder 30 and is not twisted.Tip! If the backrest 31
conceals the belt holder 30 , you can adjust the headrest
07 upwards. The diagonal seat belt section 11 can now
be easily inserted. Now return the headrest 07 to the
proper height.
8. Make sure that the diagonal seat belt section 11 runs over
your child‘s shoulder bone, and not in front of his or her
neck. Tip! You can still adjust the height of the headrest 07
again here in the vehicle.
CAUTION! The diagonal seat belt section 11 must run
diagonally backward. You can adjust the course of the belt
with your vehicle‘s adjustable belt deector.
CAUTION! The diagonal seat belt section 11 must
never lead forward to the vehicle‘s belt deector. In this
case, only use the child seat on the rear seat
12. Tension the strap of the Top Tether 13 until the tension
indicator 18 turns green and the Top Tether 13 is tightly
tensioned.
13. Follow the steps in section [securing your child with 5-point
harness].
6. Grasp the child seat with both hands and slide the two
locking arms 15 rmly into the insert guides 02 until the
locking arms engage with a clicking noise on both sides.
The green ISOFIX safety button 04 must now be visible
on both sides.
CAUTION! The locking arms are only correctly engaged if
both of the ISOFIX safety buttons 04 are completely green.
1. Make sure that the child seats 5-point harness is installed
correctly (see section 9).
2. Follow the steps in section 6.1
3. Follow the steps in section 6.2
4. Take the Top Tether 13 from the stow-pocket 14 and lay it
over the child seat.
5. Place the child seat facing in the direction of travel on the
vehicle seat.
GROUP 1 (9-18 kg)
With ISOFIX + Top Tether + 5-point harness
A1
For the safety of your child, before every journey in the car check that...
►the child safety seat is engaged on both sides with the ISOFIX locking arms 15
in the ISOFIX attachment points 01 and that both green safety buttons 04 are
completely green;
►the child seat is securely fastened;
►the Top Tether 13 is tightly tensioned over the backrest of the car seat and the
tension indicator 18 is green;
►the straps of the child safety seat are close to the body without constricting the
child;
►the shoulder belts 08 are correctly adjusted and the straps are not twisted;
►the shoulder pads 19 are in the right position on your child‘s body;
►the buckle latches 20 are engaged in the harness buckle 21 .
Caution: If your child attempts to open the green ISOFIX safety buttons 04 or the
harness buckle 21 , make sure to stop at the earliest opportunity. Check that the
child safety seat is correctly attached and make sure that your child is properly
secured. Teach your child about the dangers involved.
GROUP 2 (15-25 kg) - EXTENDED HARNESS
With vehicle belt + Top Tether + 5-point harness
B1
For the safety of your child, before every journey in the car check that...
►the child seat is rmly installed in the vehicle.
►the belt is not twisted.
►the tongue and the buckle of the vehicle seat belt are not positioned in the belt
guides of the child seat.
►the Top Tether 13 is tightly tensioned over the backrest of the car seat and the
tension indicator 18 is green;
►the diagonal belt is only clamped by the lock-off which is located on the opposite
side from the car seat belt buckle.
►the straps of the child safety seat are close to the body without constricting the
child;
►the shoulder belts 08 are correctly adjusted and the straps are not twisted;
►the shoulder pads 19 are in the right position on your child‘s body;
►the buckle latches 20 are engaged in the harness buckle 21 .
CAUTION! If your child attempts to open the harness buckle 21 , make sure to
stop at the earliest opportunity. Check that the child safety seat is correctly atta-
ched and make sure that your child is properly secured. Teach your child about
the dangers involved.
GROUP 2 (15-25 kg) &
GROUP 3 (22-36 kg)
With vehicle belt
C2
A correctly adjusted headrest 07 ensures optimal protection
for your child in the safety seat:
The headrest 07 must be adjusted so that the shoulder belts
08 are at the same level as your child’s shoulders or slightly
above.
CAUTION! The shoulder belts 08 must not run behind
the back of the child or at ear height or above the ears.
The shoulder belts are adjusted as follows:
1. Loosen the 5 point harness 38 of the child seat as much
as possible.
Backside of the child seat:
2. Press the button of the shoulder belt height adjuster 10 at
the rear of the seat shell and tilt the shoulder belt height
adjuster 10 towards you.
3. Slide the shoulder belt height adjuster 10 to select the
correct height of the shoulder belts 08 and engage it in
the positon that ts for your child by releasing the button.
A correctly adjusted headrest 07 ensures that the diagonal
seat belt section 11 is optimally positioned, and gives your
child the optimal protection.
The headrest 07 must be adjusted so that there is a space
two ngers wide between the headrest 07 and your child‘s
shoulders.
To adjust the height of the headrest to t your child:
1. Reach into the adjustment handle 12 on the back of the
headrest 07 and pull it towards you.
This unlocks the headrest.
2. You can now move the unlocked headrest 07 to the desi-
red height. As soon as you release the adjustment handle
12 the headrest 07 will lock into place.
3. Place the child seat on the vehicle seat.
4. Have your child sit down in the child seat and check the
height.Repeat this process unti the headrest 07 is at the
optimal height.
6.3. Adjusting the headrest
1. If your vehicle is not equipped with the ISOFIX insert
guides as standard, clip the two insert guides 02 which
are included with the seat* with the cut-out facing
upwards onto the two ISOFIX attachment points 01 of
your vehicle.
TIP: The ISOFIX attachment points are located between the
surface and the backrest of the vehicle seat.
2. Move the head restraint on the vehicle seat to the
upper position.
3. Pull the grey fabric loop 03 to pull out both locking arms
15 until you hear a clicking sound which indicates they
are fully engaged.
4. On both sides of the seat squeeze the green safety button
04 and the red release button 05 together and remove
the connector protection 06 .
* The insert guides make it easier to install the child safety seat with the aid of the ISOFIX attach-
ment points and prevent damage to the seat covering. When not in use, they should be removed
and stored in a safe place. On vehicles with a folding backrest the insert guides must be removed
before the backrest is folded.
Any problems which occur are usually caused by dirt or foreign objects on the insert guides and
on the hooks. Clean off any dirt or foreign objects to remedy this type of problem.
6. PREPARATORY WORK
6.1 Prepare ISOFIX
6.2 Adjusting the headrest with 5-point harness
GROUP 2 (15-25 kg) &
GROUP 3 (22-36 kg)
With ISOFIT + vehicle belt
C1
For the safety of your child, before every journey in the car check that...
►the child safety seat is securely fastened;
►the lap belt section 28 runs through the light red belt guides 23 on both sides of
the seat cushion,
►the diagonal seat belt section 11 on the side of the vehicle seatbelt buckle 29 also
runs through the light red belt guide 23 of the seat cushion,
►the diagonal seat belt section 11 runs through the dark red belt holder 30 of the
headrest,
►the diagonal seat belt section 11 runs diagonally backward,
►the straps are tight and not twisted,
►the vehicle seatbelt buckle 29 is not positioned between the light red belt guide 23
and the armrest of the seat cushion.
CAUTION! If your child attempts to open the harness buckle 21 , make sure to
stop at the earliest opportunity. Check that the child safety seat is correctly atta-
ched and make sure that your child is properly secured. Teach your child about
the dangers involved.
To remove the child seat follow the steps in section 10
To remove the child seat follow the steps in section 10
To remove the child seat follow the steps in section 10
02
01
7. INSTALLATION
Please read the chapter with your desired installation method in chapter 7 rst.
03
15
0405
06
07
08
10
07
11
12
SECURING YOUR CHILD WITH 5-POINT HARNESS
4. Guide the two buckle latches 20
together and engage them befo-
re putting them into the harness
buckle 21 - this should make a
clicking noise.
Pull on the adjusting strap 09 until the harness lies at and is
close against your child‘s body.
CAUTION! Pull out the adjusting strap to the front.
CAUTION! The hip straps 27 must be positioned as low
as possible over your child‘s hips.
1. Open the harness buckle 21 (press red button)
2. Press the adjusting button 26 and at the same time pull both
shoulder belts 08 forwards. Do not pull on the shoulder
pads 19 .
3. Have your child sit down in the child seat.
SECURING YOUR CHILD WITH 5-POINT HARNESS
21
26
08
19
20 21
09
27
1 cm
13
14
15
04
17
16
17
18
13
14
22
23
24
25
25
17
16
15
04
29
29
1 cm
18
17
11
28
23
28 23
11
30 07
11 07
11 07
11 30 07
28
23
29
38
11
28
23

XTENSAFIX
9 – 36 kg
9 m ~ 12 y
User instructions
GB
5. CARE AND MAINTENANCE
Care for the harness buckle
It is vital for the safety of your child that the harness buckle works correctly. Malfun-
ctions of the harness buckle are usually caused by accumulations of dirt or foreign
bodies. Malfunctions are as follows:
• The buckle latches are ejected only slowly when the red release button is pressed.
• The buckle latches will no longer lock home (i.e. they are ejected again if you try to
push them in).
• The buckle latches engage without an audible „click“.
• The buckle latches are difcult to insert (you feel resistance).
• The buckle only opens if extreme force is applied.
Remedy
wash out the harness buckle so that it functions properly once again:
Cleaning the harness buckle
1. Open the harness buckle 21 (press the red button).
2. Open the Velcro fastener on the crotch pad 32 and take off the crotch pad from the
cover.
3. Put the seat shell into the recline position
4. Grasp the metal plate 33 from underneath and turn it into a vertical position
5. Slide the metal plate 33 through the slot 34
6. Remove the harness buckle 21
7. Soak the harness buckle 21 in warm water with dishwashing liquid for at least an
hour. Then rinse and dry it thoroughly.
Cleaning
Please be sure to use only genuine Britax/RÖMER replacement seat covers, as the
seat cover is an integral part of the child safety seat which plays an important role in
ensuring that the system works properly. Replacement seat covers are available from
your retailer.
2. USE IN THE VEHICLE
Please observe the instructions on the use of child restraint systems described
in your vehicle owner’s manual.
The seat may be used in all vehicles equipped with the ISOFIX and Top Tether
anchoring systems or 3-point belt. Please consult your vehicle owner’s manual
for information about the ISOFIX &Top Tether anchoring points or the installa-
tion with 3-point belt. Also check your vehicle owner’s manual for seats which
are approved for child safety seats in the weight classes 9-18 kg, 15-25 kg,
22-36 kg.
You can use your child car seat asfollows:
In the direction of travel Yes
Against the direction of travel No 1)
with 2-point belt (vehicle belt) NO
with 3-point belt (vehicle belt) Yes 2)
On seats featuring:
ISOFIX attachments (between seat surface and
backrest) and Top Tether anchoring points (for
example on the parcel shelf, on the oor or behind
the backrest)
Yes 3)
(Please observe the applicable regulations in your country)
1) Use is permitted on a rearward-facing vehicle seat (e.g. in a van or minibus) only if
the vehicle seat is also approved for use by adults. The seat must not be positioned
anywhere where it is in range of an airbag which is being deployed.
2) The safety belt must be approved to ECE R 16 or a comparable standard (see test
label on belt with an “E” or “e” in a circle).
3) If there is a front airbag: Slide the passenger seat a long way back and refer to any
instructions in vehicle owner’s manual. BRITAX RÖMER
Kindersicherheit GmbH
Blaubeurer Straße 71
D-89077 Ulm
Germany
t: [phone]/-299
f: [phone]
e: [email protected]
www.roemer.eu
BRITAX EXCELSIOR LIMITED
1 Churchill Way West
Andover
Hampshire SP10 3UW
United Kingdom
t: [phone]
f: [phone]
e: [email protected]
www.britax.eu
1. GENERAL SAFETY NOTES
Take the time to carefully read through these instructions, and always
keep them ready to hand in the designated pocket on the child seat.
For the protection of all vehicle occupants
In the case of an emergency stop or an accident, persons or objects which
are not properly secured in the car can cause injury to other vehicle occu-
pants. For this reason, please always check that...
• the backrests of the vehicle seats are locked (e.g. that the latch on a fol-
ding rear seat bench is engaged).
• all heavy or sharp-edged objects in the vehicle (e.g. on the parcel shelf)
are secured.
• all persons in the vehicle have their seatbelts fastened.
• the child safety seat is always secured in the car via the ISOFIX anchoring
and the Top Tether or the 3-point belt (vehicle belt), even when there is no
child in the seat.
For the protection of your child
• The more snugly the harness ts over your child‘s body, the safer your
child will be.
• Please do not ever leave your child unattended in the child safety seat in
the vehicle.
• Use on the rear seat:
Move the front seat forward far enough that you child‘s feet cannot hit the
backrest of the front seat (to prevent risk of injury).
• The child safety seat can get hot in direct sunshine. Caution: Children‘s
skin is delicate and could be injured as a result. Protect the child
seat against intensive direct sunlight when it is not currently in use.
• Only allow your child to enter and exit the vehicle on the pavement side.
• Make stops during longer journeys to give your child an opportunity to run
about and play.
To protect your vehicle
Some vehicle seat coverings made of more delicate materials (e.g. velour,
leather, etc.) may develop wear marks when child seats are used. For opti-
mum protection of your seat covers, we recommend using the BRITAX RÖ-
MER Car Seat Protector, which is available from our range of accessories.
3. APPROVAL
BRITAX RÖMER
child safety seat
Tested and certied ac-
cording to ECE* R 44/04
Group Body weight
XTENSAFIX 1 9 to 18 kg
2 15 to 25 kg
3 22 to 36 kg
The child safety seat has been designed, tested and certied according to the require-
ments of the European Standard for Child Safety Equipment (ECE R 44/04). The test
mark E (in a circle) and the certication number are located on the orange certication
sticker (sticker on the child safety seat).
• This certication will be invalidated if you make any modications to the child safety
seat.
• The XTENSAFIX child safety seat must only be used to secure your child in the
vehicle. It must never be used as a seat or toy in the home.
Risk of injury due to unauthorised modications!
Unauthorised technical modi ations may reduce or entirely void the seat’s protective
properties.
• Do not make any technical modi cations to the baby seat.
• Use the baby seat only as described in these user instructions.
The XTESAFIX offers a variety of mounting options, the following table indicates the
types of installation for the respective groups:
Group Installation method Child installation User Guide
chapter
1(9-18 kg) ISOFIX + TopTether with 5-point harness A1
2(15-25 kg) Vehicle belt + Top Tether with 5-point harness B1
2(15-25 kg) ISOFIT vehicle belt C1
2(15-25 kg) Vehicle belt vehicle belt C2
3(22-36 kg) ISOFIT + vehicle belt vehicle belt C1
3(22-36 kg) Vehicle belt vehicle belt C2
• The child seat must not be used without its cover.
• The cover can be removed and washed with a mild detergent using the
washing machine‘s cycle for delicate items (30 °C). Please observe the
instructions on the washing label of the cover.
• The plastic parts can be cleaned using soapy water. Do not use harsh
cleaning agents (such as solvents).
• The harnesses can be washed in lukewarm soapy water.
Caution: Never remove the buckle latches 20 from the straps.
• The shoulder pads can be washed in lukewarm soapy water.
Removing the cover
A) Headrest
1. Move the headrest of the child seat to the upper position.
2. Take the elastic seam of the cover 35 from the hooks at the backside of the head-
rest and remove the cover of the headrest.
B) Cover
1. Undo the hooks on the bottom side.
2. Undo the hooks located on the upper backside.
3. Undo the elastic loop on both sides of the belt guides.
4. Open the two plastic fasteners on the backside of the cover.
5. Remove the cover.
Re-tting the Cover:
Simply follow the steps in the opposite order.
CAUTION! Never use the child seat without a correct installed buckle. Make sure
that the metal plate 33 is correctly attached.
CAUTION! Check that the harness straps are not twisted and that they
have been correctly inserted in the belt slots on the cover.
www.britax.eu
10. REMOVAL OF THE CHILD SEAT
Caution: Remove the child seat from the vehicle. The child seat must never be
transported in the car if it is not properly secured.
Group 1 (ISOFIX & Top Tether)
1. To release the ISOFIX fastening, squeeze the green safety button and the red
release button together,rst on one side, then on the other.
2. To release the TopTether anchoring loosen the belt by lifting the metal tongue of the
adjuster away from the belt. Then take the spring hook out of the anchoring point.
3. Put the connector protection on the ISOFIX.
Group 2 (3-Point-Belt & Top Tether)
1. Open the buckle of the vehicle seat belt and take the diagonal belt with a short pull
out of the belt lock-off. This countermovement releases the interior clamping of
the belt lock-off and the clamping lever is now easy to open.
2. To release the TopTether anchoring loosen the belt by lifting the metal tongue of the
adjuster away from the belt. Then take the spring hook out of the anchoring point.
Group 3A (ISOFIT)
1. To release the ISOFIT fastening, squeeze the green safety button and the red
release button together,rst on one side, then on the other.
2. Put the connector protection on the ISOFIX.
Group 3B (3-Point-Belt)
1. Unbuckle the vehicle seat belt.
4. CARE INSTRUCTIONS
To ensure the full protective effect of the child safety seat:
►In the event of an accident with an impact speed above 10 km/h it is possible that
the child safety seat may have been damaged, but that the damage may not be
immediately obvious. In this case the child safety seat must be replaced.
Please dispose of it properly.
►Regularly check all important parts for damage. Make sure that the mechanical
components in particular are all in perfect working order.
►To prevent damage, ensure that the child safety seat does not become jammed
between hard objects (car door, seat runners etc.).
►Always have the child safety seat checked if it has been damaged (e.g. if it is
dropped).
►Never lubricate or oil parts of the child seat.
►In order to properly protect your baby, it is imperative that you install and use the
XTENSAFIX exactly as described in this manual.
Disposal of packaging Container for cardboard
Cover Residual waste, thermal utilisation
Plastic parts In accordance with the labelling in the
designated container
Metal parts Container for metals
Harness straps Container for polyester
Buckle & latch Residual waste
33
34
21 32
35
1. Reach into the adjustment handle 12 on the back of the headrest 07 and push
the headrest into the lowest position.
2. Lift the upper part of the headrest cover.
3. Open the left and right buttons on the lower part of the cover 43 and lay the
cover piece on the seating area.
4. Take the shoulder belts 08 and the buckle latches 20 from the storage compart-
ment 47 and unroll the shoulder belts.
5. Fold back the two cover pieces and close the left and right poppers 42 on the
lower part of the cover.
Should the child seat not be in the most reclined position:
Press the recline handle so that the seat is in its most upright position.
6. Take the harness buckle 21 and the shoulder pads 19 from the stow-pocket 14 on
the backside of the seat.
7. Retting buckle and belly pad: pull the elastic strip 44 in the seating area towards
you. Group 1 (9-18 kg) use the belt slot closest to the backrest a, for Group 2
(15-25 kg) use the one furthest away b.
8. Take the harness buckle 21 and hold the metal plate 33 verticaly. Push it with the
narrow side upwards through the belt slot aor binto the seat shell.
9. Ensure that the metal plate 33 is in a horizontal position and check the correct
tting of the metal plate by pulling up on the crotch pad 32 several times.
10. Guide the two buckle latches 20 together and engage them before putting them
into the harness buckle 21 - this should make a cklicking noise.
CAUTION! The lap belts must not be twisted or swapped.
11. Pull the shoulder pads 19 onto the shoulder belts 08 ensuring there are no twists.
Allign the two loops of the shoulder belts 08 and strap loops of the shoulder pads
19 .
12. Pull the shoulder belts 08 and the strap loops of the shoulder pads 19 through
the slots 40 .
Tip: Fold up the rear cover part.
13. Pull the strap loops of the shoulder pads 19 onto the plastic extensions 41 of the
shoulder belt height adjuster 10 .Tip: the strap loops of the shoulder pads should
be the lower loop.
14. Fold the upper part of the cover downwards.
CAUTION! The shoulder belts 08 must not be twisted or swapped.
15. Take the connecting piece 39 from the provided storage on the backside of the
child seat.
16. Hook the shoulder belts 08 back onto the connecting piece 39 . The left loop on
the left arm of the connecting piece and the right loop on the right arm.
17. Pull slowly on the adjustment strap 09 and at the same time push the connecting
piece 39 between backrest and the provided storage of the connecting piece.
1. Put the stow-pocket 14 forward over the seat.
2. Loosen the 5 point harness 38 of the child seat as much as possible.
Backside of the childseat:
3. Press the button of the shoulder belt height adjuster 10 at the rear of the seat shell
and tilt the shoulder belt height adjuster 10 toward you.
4. Move the shoulder belt height adjuster 10 in the top position and x the position
by releasing the button of the shoulder belt height adjuster.
5. Loosen the 5-point harness 38 of the child seat as much as possible. Unhook the
shoulder belts 08 on the backside of the childseat from the connecting piece 39 .
6. Put the connecting piece 39 in the provided storage.
7. Pull below both, the shoulder pads 19 and the two shoulder belts 08 to the front
through the Slots 40 . (Frontside of the childseat)
8. Slide the belt loops off of the plastic extensions 41 of the shoulder belt height
adjuster 10 .
Frontside of the childseat:
9. Pull out the adjustment strap 09 as far as possible.
10. Store the adjustment strap in the case of the adjusting button 26 .
11. Pull the shoulder pads 19 through the slots 40 to the front.
12. Remove the shoulder pads 19 from the shoulder belts 08 and put them in the
stow-pocket on the backside of the seat.
13. Open the harness buckle 21 (press the red release button)
14. Fold the upper part of the rear cover to the top.
15. Open the left and right poppers 42 on the lower part of the cover 43 and lift the
cover piece to the front. Slide the buckle latches 20 down into the appropriate
slots.
16. Roll the shoulder belts 08 together and place them also into the storage compart-
ment.
17. Fold the two cover parts to the rear and lock the poppers 42 on the left and right
side of the cover backside.
18. Pull the recline handle while pressing into the recline position (forward position).
19. Pull the elastic strip 44 over the harness buckle 21 .
20. Grasp the metal plate 33 from underneath and turn it into a vertical position.
21. Push upwards and slide the metal plate 33 through the slot 34 .
22. Remove the harness buckle 21 with the crotch pad 32 and store it in the
stow-pocket 14 .
8. REMOVING THE 5 POINT HARNESS
9. REFITTING THE 5 POINT HARNESS
38
10
39
08
39
19
08
40
41 10 26
09
40
19
08
21
42
43 08
42
12
07
42
43
33
34
44
21
32
21
14
20
08
47
42
32
21
14
44
21
a
b
21
33 32
20
21
19
08
08 40
19
19
41
10
39 39
09
08
EDV-NR.: 2000009868
