Briteq BT-54L3 User manual

USER
MANUAL
Ver 1,0
LED MOVING WASH

ABLE OF CONTENTS
T
INTRO
INVERT
RANGE
SPECIAL
EDIT
EXTRA
CALIB
CODECHANGE
DEFAULT
PART1 PRODUCT(GENERAL)................................................................. 1.
1.1--PRODUCT INTRODUCTION........................................................................1.
1.2--PRODUCT FEATURES................................................................................1.
1.3--TECHNICAL SPECIFICATIONS...................................................................2.
1.4--PHOTOMETRIC DATA.................................................................................3.
1.5--SAFETY WARNING.....................................................................................4.
PART2 INSTALLATION........................................................................... 5.
2.1--MOUNTING................................................................................................5.
2.2-- ............................................................................... 6.
2.3--SETTING UP(STANDALONE).................................................................... 6.
2.4--SETTING UP(MASTER/SLAVE).................................................................. 7.
2.5--SETTING UP(DMX512 CONTROLLER).......................................................7.
PART3 DISPLAY PANEL OPERATION....................................................... 8.
3.1--BASIC........................................................................................................8.
3.2--MENU........................................................................................................8.
3.3-- .......................................................................................................10.
3.4-- ......................................................................................................11.
3.5-- ......................................................................................................12.
3.6-- ................................................................................................... 12.
3.7-- ..........................................................................................................13.
3.8-- .......................................................................................................13.
3.9-- .......................................................................................................14.
3.10-- ....................................................................................... 15.
3.11-- ................................................................................................ 15.
PART4 USINGADMX512 CONTROLLER...................................................16.
4.1--BASIC ADDRESSING.................................................................................16.
4.2--CHANNELASSIGNMENT............................................................................16.
4.3--BASIC INSTRUCTIONSFOR DMX512OPERATION .................................... 19.
PART5 APPENDIX................................................................................... 20.
5.1--TROUBLE SHOOTING................................................................................20.
5.2--MAINTENANCE..........................................................................................21.
FUSE REPLACEMENT

This product isdesigned for indoor use only. Suitable applications include wash or effect
lighting for architectural, stage or nightclub applications. Direct input of DMX512 signal
allows the fixtures to be controlled from any DMX512 controller. The fixture is fully
programmable with one custom program available and is supplied with two automatic
programs (all accessible from DMX512 controller). This product can be operated as a
single unit orwith multiple unitsfor large applications.
1.1 PRODUCTINTRODUCTION
RGBW Dimmer0-100%
Strobe
Automatic programs
Custom program(programmable)
Auto-colorsequence (variablespeed)
LCD display
Fan speedcontrol
DirectDMX512 input
1.2 PRODUCTFEATURES
No
1
2
3
4
5
6
7
8
9
10
11
12
13
14
ITEM
Head
Side arm
Handle
Menu
Enter
Down
Up
Switch
Power input
DMX 5-PIN signalinput
DMX 3-PIN signalinput
DMX 3-PIN signaloutput
DMX 5-PIN signaloutput
Safety lock
1 PRODUCT(GENERAL) 12008.7.31
1PRODUCT (GENERAL)

1.3 TECHNICALSPECIFICATIONS
100~240V...50/60Hz
280W
54pcs (14 X2W RED /14 X 3WGREEN
/ 14 X3W BLUE/12 X3W WHITE)
Forced air convection
390 x 320x 385mm
16Kg
Voltage
Rated Power
LED/Unit
Cooling
Dimensions
Weight
1 PRODUCT(GENERAL) 22008.7.31

1.4 PHOTOMETRICDATA
1 PRODUCT(GENERAL) 32008.7.31
WHITE
1
2
3
0
1
2
3
246810Distance(m)
6300 1550 694 404 277 LUX
15
RED
1
2
3
0
1
2
3
246810Distance(m)
5140 1373 620 350 238 LUX
15
GREEN
1
2
3
0
1
2
3
246810Distance(m)
9360 2320 1055 602 398 LUX
15
BLUE
1
2
3
0
1
2
3
246810Distance(m)
1710 420 192 110 73 LUX
15
RGB
1
2
3
0
1
2
3
246810Distance(m)
16050 3920 1765 1010 670 LUX
15
RGB+WHITE
1
2
3
0
1
2
3
246810Distance(m)
20200 5400 2430 1400 950 LUX
15

1.5 SAFETYWARNING
IMPORTANT
ALWAYSREAD THEUSER MANUALBEFORE OPERATION.
PLEASE CONFIRMTHATTHE POWERSUPPLYSTATED ONTHE
PRODUCT IS THESAME AS THE MAINS POWERSUPPLY IN YOUR AREA.
This productmust beinstalled bya qualifiedprofessional.
Always operatethe equipmentas describedin theuser manual.
A minimum distance of 0.5m must be maintained between the equipment and
combustible surface.
The productmust alwaysbe placedin awell ventilatedarea.
Always makesure thatthe equipmentis installedsecurely.
DO NOT stand close to the equipment and stare directly into the LED light
source.
Always disconnectthe powersupply beforeattempting andmaintenance.
Always make sure that the supporting structure is solid and can support the
combined weight ofthe products.
The earthwire mustalways beconnected tothe ground.
Do not touchthe power cablesif your handsare wet.
ATTENTION
This product leftthe place ofmanufacture in perfectcondition. In orderto
maintain thiscondition andfor safeoperation, theuser mustalways followthe
instructions andsafety warningsdescribed inthis usermanual.
Avoid shakingor strong impactsto any partof the equipment.
Make sure thatall parts ofthe equipment arekept clean andfree of dust.
Always makesure thatthe powerconnections areconnected correctand
secure.
If thereis anymalfunction ofthe equipment,contact yourdistributor
immediately.
When transferringthe product,it isadvisable touse theoriginal packagingin
which the productleft thefactory.
Shields, lenses orultraviolet screens shallbe changed ifthey have become
damaged tosuch anextent thattheir effectivenessis impaired.
The lamp(LED) shallbe changedif ithas becomedamaged orthermally
deformed.
1 PRODUCT(GENERAL) 42008.7.31

2.1 MOUNTING
5
2 INSTALLATION 2008.7.31
The LED fixture can be operated in any position at any angle. When mounted on a flat
surface, thesurface mustbe strongenough tosupport 10times theweight ofthe fixtureand
stable so thatthe will beno damage causedto the fixtureor surrounding peopleor objects
because ofmovements ofthe fixtureon thesurface.
When the unit is mounted in a hanging position, the fixture is attached using the mounting
brackets and a standard truss clamp or other clamping device. The mounting brackets
supplied aremounted usingquick-release locksallowing simplemounting orremoval.
UPRIGHT HANGING
IMPORTANT SAFETYNOTE!!
Always use asafety cable wheninstalling this unit!!
Be surethat thesafety cableis connectedto asolid load-bearingstructure.
2INSTALLATION

F
I
I
Remove thesafety cap by ascrewdriver.
etch theold fusefrom safetycap.
nstall anew fuse.
nstall thesafety cap.
Safety Cap
Fuse
2.2 FUSE REPLACEMENT
6
2 INSTALLATION 2008.7.31
The LED fixture can be used as a stand alone unit. The stand alone functions AUTO 1,
AUTO 2, CUSTOM can be activated without the need to connect to any controller or
connecting to anyother equipment.
Simply, access the <operation> menu from the DISPLAY and select the target program to
activate.
2.3 SETTING UP(STANDALONE)

When unitsare connectedin seriesusing DMX512signal cable connect theunits asshown
in thediagram below
Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin
connector ofthe first(MASTER) fixture.
Connect the end of the cable coming from the MASTER fixture which will have a (female) 3
pin connector to the input connector of the next fixture consisting of a (male) 3 pin
connector.
Then proceed toconnect from the output asstated above tothe input ofthe following fixture
and soon.
Set the first unit in the series to one of the STAND ALONE modes as described in section
2.2
All otherunits inthe seriesshould beset to<SLAVE>from the<operation> menu.
MASTER SLAVE SLAVE
When units areconnected in seriesto a DMX512controller and otherDMX512 equipment,
connect theequipment asshown inthe diagrambelow.
Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin
connector ofthe controller.
Connect the end of the cable coming from the controller which will have a (female) 3 pin
connector tothe inputconnector ofthe nextfixture consistingof a(male) 3pin connector.
Then proceed toconnect from the output asstated above tothe input ofthe following fixture
and soon.
If over32pcs fixturesconnected ,theamplifier isneeded.
DMX512
CONTROLLER
7
2 INSTALLATION 2008.7.31
2.4 SETTING UP(MASTER/SLAVE)
2.5 SETTING UP(DMX512 CONTROLLER)

MENU 1.2 Reset
1.5 Channels
1.6 Display
1 Intro 1.1Address
1.3 Fans
1.4 Operation
1.7 Info
2.4 Use
2.3 Dimmer
2.2 Tilt
2 Invert 2.1 Pan
Yes
No
High
Normal
Low
Auto
Auto1
Auto2
Slave
Test
DMX512
(001~512)
60 close
Bright
Edition
Basic
Advanced
Normal
Reverse
Normal
Reverse
Normal
Reverse
No
Yes
Custom
DOWN
ENTER UPMENU
3.1 BASIC
The LED fixtureis mounted witha LCD displayand 4 controlbuttons.
MENU Scroll throughthe mainmenu orexit fromthe currentsub-menu
ENTER Enter thecurrently selectedmenu orconfirm thecurrent functionvalue
DOWN Scroll 'DOWN'through themenu listor decreasethe valueof thecurrent function
UP Scroll 'UP'through themenu listor increasethe valueof thecurrent function
3.2 MENU
3 DISPLAY PANEL OPERATION 2008.7.31
3DISPLAY PANEL OPERATION
8

3 DISPLAY PANEL OPERATION 2008.7.31
5 EDIT 5.1STEP
5.2pan
5.4speed
5.3tilt
5.5 red
5.6 green
5.7 blue
5.8 white
5.9 strobe
5.11 time
5.12 Use
(001~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
No
Yes
3.1P/start
3.2P/Finish
3.3T/start
3.4T/Finish
3.5 Use
3 Range
4.1 BlackDelay
4 Special
4.2Reset
4.3 Dimmer
4.4 RGB
4.5 Fan
6.2password
0000
0000
6 Extra 6.1User-key
(000~255)
No
Yes
(000~255)
(000~255)
(000~255)
No
Yes
DMX
System
Normal
Special
No
Yes
DMX
System
7 Calib
7.2 W2:3400K
7.3 W3:4200K
7.2 RED
7.2 GREEN
7.2 BLUE
7.3 RED
7.3 GREEN
7.3 BLUE
7.1 W1:3200K
7.1 RED
7.1 GREEN
7.1 BLUE
7.4 W4:4900K
7.4 RED
7.4 GREEN
7.4 BLUE
7.5 W5:5600K
7.5 RED
7.5 GREEN
7.5 BLUE
7.6 W6:5900K
7.6 RED
7.6 GREEN
7.6 BLUE
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
5.10 dim-speed
9

10
3 DISPLAY PANEL OPERATION 2008.7.31
MENU 1.2 Reset
1.5 Channels
1.6 Display
1 Intro 1.1Address
1.3 Fans
1.4 Operation
1.7 Info
Yes
No
High
Normal
Low
Auto
Auto1
Auto2
Slave
Test
DMX512
(001~512)
60 close
Bright
Edition
Basic
Advanced
Custom
3.3 INTRO
7.7 W7:6500K
7.7 RED
7.7 GREEN
7.7 BLUE
7.8 W8:7200K
7.8 RED
7.8 GREEN
7.8 BLUE
7.9 W9:8000K
7.9 RED
7.9 GREEN
7.9 BLUE
7.10 W10:8500K
7.10 RED
7.10 GREEN
7.10 BLUE
7.11W11:10000K
7.11 RED
7.11 GREEN
7.11 BLUE
7.12 RGB W
7.12 RED
7.12 GREEN
7.12 BLUE
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
0000
8 CodeChange
8.1 User-key
10.1 Default
10 Default
MENU Yes
No

1.2 Reset
1.2 Reset
1.3 Fans
1.3 Fans High
Normal Low Auto
1.4 Operation
1.4 Operation DMAX512 Auto1
Auto2 Custom Slave Test
1.5 Channels
1.5 Channels Basic Advanced .
1.6 Display
1.6 Display
1.7 Info
1.7 Info
1.1 Address
Enter 1.1 Address to setthe DMXAddress,which isfrom (001-512)
In order torest custom modestto default, select
Enter to select theworking mode offan: is for fast;
is for normal; is for slow; is forAuto
Enter to selectthe operationmode: ; ;
;;;
Enter to select theDMX channel modes: ;
Enter to selectthe lighting time ofthe LCDdisplay panel.
Enter to seethe versionof thesoftware.
11
3 DISPLAY PANEL OPERATION 2008.7.31
2.4 Use
2.3 Dimmer
2.2 Tilt
2 Invert 2.1 Pan Normal
Reverse
Normal
Reverse
Normal
Reverse
No
Yes
MENU
3.4 INVERT
2.3 Dimmer Normal Reverse
2.4 Use Yes
2 Invert
Select 2.1 Pan /2.2 Tilt / to set or
Enter and set to runthe newsetting

3.1P/start
3.2P/Finish
3.3T/start
3.4T/Finish
3.5 Use
3 Range (000~255)
No
Yes
(000~255)
(000~255)
(000~255)
MENU
3.5 RANGE
3.1P/start
3.2P/Finish
3.3T/start
3.4T/Finish
3.5 Use
3.5 Use Yes
Set panstart value 000~255
Set panfinish value 000~255
Set Tilt startvalue 000~255
Set Tilt finishvalue 000~255
Enter and select to openthe operationof X/Yangle
12
3 DISPLAY PANEL OPERATION 2008.7.31
4.1 BlackDelay
4 Special
4.2Reset
4.3 Dimmer
4.4 RGB
4.5 Fan
No
Yes
DMX
System
Normal
Special
No
Yes
DMX
System
MENU
3.6 SPECIAL
4.1 BlackDelay
4.1 BlackDelay No Yes
4.2Reset
4.2Reset DMX System
4.3 Dimmer
When DIMMERis setto NORMAL,then RGBWand MASTERDIMMER arelinear
CURRENT Vs.DMX. WhenDIMMER isset toSPECIAL, thenthe dimmingis not
linear
4.4 RGB
When RGBTO WHITEis set to Yes , thenwhen RGB= 255,255,255then thecolor
is perfect whiteas the actualRGB values areadjusted to makewhite. When RGB
TO WHITEis set to No , thenwhen RGB= 255,255,255,the RGBvalues arenot
adjusted andthe outputis mostpowerful
4.5 Fan
C DMX System
Enter to choose without delayor 3seconds
delay
Enter to choose DMX control resetor DMX
cannot controlreset
hoose DMX tocontrol fanor DMX cannotcontrol fan

5.1STEP
5.2pan
5.4speed
5.3tilt
5.5 red
5.6 green
5.7 blue
5.8 white
5.9 strobe
5.11 time
5.10 dim-speed
5.12 Use
(001~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
No
Yes
5 EDIT
MENU
3.7 EDIT
13
3 DISPLAY PANEL OPERATION 2008.7.31
6.2password
0000
1111
6 Extra 6.1User-key
MENU
3.8 EXTRA
6.1User-key
When the userinputs 6.1User-key ,the hiddenmenu 7 Cablid ,
8 CodeChange ,9 default will appearon displaypanel, and the useris
able toreset the DEFAULT values of allfunctions.
The User-keeycan bechanged at 8 codechange , thedefault accesscode is
0000 .
6.2password
When theuser inputsthe 6.2password ,the useris ableto resetthe DEFAULT
values andget theadministrator rightsThe password can bechanged at
8 CodeChange , thedefault accesscode is 1111
5 EDIT
Enter the 5 EDIT mode toedit thecustom programsby adjustingthe
value of 5.1STEP ,5.2pan ,5.3tilt ,5.4speed ,5.5 red ,5.6 green ,
5.7 blue ,5.8 white ,5.9 strobe ,5.10 dim-speed ,5.11time
5.12 Use Yes
5.11time
5.11time 5.12 Use
5.11time 5.12 Use
5.11time 5.12 Use
Enter and select to runthe stepsuser need.
Note: if userwant tocirculate thecreated steps,please setthe laststep s
as 0
For example,there are3 steps,the settingshould belike belowed:
Step 1 = 4 = Yes
Step 2 = 5 = Yes
Step 3 = 0 = Yes

14
3 DISPLAY PANEL OPERATION 2008.7.31
7 Calib
7.2 W2:3400K
7.3 W3:4200K
7.2 RED
7.2 GREEN
7.2 BLUE
7.3 RED
7.3 GREEN
7.3 BLUE
7.1 W1:3200K
7.1 RED
7.1 GREEN
7.1 BLUE
7.4 W4:4900K
7.4 RED
7.4 GREEN
7.4 BLUE
7.5 W5:5600K
7.5 RED
7.5 GREEN
7.5 BLUE
7.6 W6:5900K
7.6 RED
7.6 GREEN
7.6 BLUE
7.7 W7:6500K
7.7 RED
7.7 GREEN
7.7 BLUE
7.8 W8:7200K
7.8 RED
7.8 GREEN
7.8 BLUE
7.9 W9:8000K
7.9 RED
7.9 GREEN
7.9 BLUE
7.10 W10:8500K
7.10 RED
7.10 GREEN
7.10 BLUE
7.11W11:10000K
7.11 RED
7.11 GREEN
7.11 BLUE
7.12 RGB W
7.12 RED
7.12 GREEN
7.12 BLUE
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
(000~255)
MENU
3.9 CALIB
7 Calib
Enter the 7 Calib to select white colorof differentcolor temperature.
There are11pre-programmed Whitecolors plusRGB TOWHITE andcan beedited
by using Red , Green & Blue .

MENU
9.1 Default
9 Default
Yes
No
MENU
3.10 CODECHANGE
8 CodeChange
S 8.1 User-key
S 8.2 Password
8.2 Password
elect to setthe password
elect to setthe password.
Note: will notappear onlywhen 6.2 password is activated.
3.11 DEFAULT
9 Default
This functionswill resetall settingto theoriginal factorysetting
15
3 DISPLAY PANEL OPERATION 2008.7.31
****
8 CodeChange
8.1 User-key
8.2password
****

1
2
3
4
5From fast toslow
6
7
8
9
CHANNEL VALUE FUNCTION
PAN
PAN FINE
TILT
TILT FINE
Clockwise rotate 0~ 054
Fine control of panmovement 0~3
Anti-clockwise rotate 0~270
Fine control of tiltmovement 0~3
PAN/TILTSPEED
RED
GREEN
BLUE
WHITE
0 255
0 255
0 255
0 255
0 255
0 255
0 255
0 255
0 255
Note: This product havetwo DMX512 channel configuration: ADVANCED and BASIC .
4.1 BASICADDRESSING
Connect all of the unitsin series using standard DMX512signal cable .
Set theDMX512 addressin the DMX menu.
It ispossible tohave thesame DMXaddress orindependent addressesfor eachfixture.
4.2 CHANNELASSIGNMENT
ADVANCED
16
4 USINGA DMX512CONTROLLER 2008.7.31
4USING ADMX512 CONTROLLER

14
0 19
20 39
40 59
60 79
80 99
100 119
120 139
140 149
150 159
160 169
170 179
180 189
190 199
200 219
220 255
CONTROL
10
11
12
13
CHANNEL VALUE FUNCTION
DIMMER
STROBE
COLOR/WHITE MACRO
0 5
251 255
6 25
26 45
46 65
66 85
86 105
106 125
126 145
146 165
166 180
181 190
191 200
201 205
206 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
0 255
0 255
17
4 USINGA DMX512CONTROLLER 2008.7.31
DIMMER SPEED
0
6 5 255 NO FUNCTION
Fast to Slow
No function
Pan/tilt black activated
Pan/tilt black deactivated
Fan auto
Fan slow
Fan normal
Fan fast
No function
Auto1 (activated after 3secs)
Auto2 (activated after 3secs)
Test (activatedafter 3 secs)
Custom (activated after 3secs)
No function
Reset (activated after 3secs)
No function
NO FUNCTION
RED UP/GREEN0%/BLUE 100%
RED 100%/GREENUP/BLUE DOWN
RED DOWN/GREEN100%/BLUE0%
RED 0%/GREEN DOWN/BLUEUP
RED UP/GREEN 0%/BLUE DOWN
RED DOWN /GREEN UP/BLUE0%
RED UP /GREEN 100% /BLUE 0%
RED DOWN /GREEN DOWN/ BLUEUP
NO FUNCTION
NO FUNCTION
NO FUNCTION
WHITE 1:3200K
WHITE 2:3400K
WHITE 3:4200K
WHITE 4:4900K
WHITE 5:5600K
WHITE 6:5900K
WHITE 7:6500K
WHITE 8:7200K
WHITE 9:8000K
WHITE 10: 8500K
WHITE 11:10000K

1
2
3
4
5
6
7
8
9
10
CHANNEL VALUE FUNCTION
PAN
TILT
Clockwise rotate 0~ 054
Anti-clockwise rotate 0~270
RED
GREEN
BLUE
WHITE
DIMMER
STROBE
COLOR/WHITE MACRO
NO FUNCTION
RED UP/GREEN0%/BLUE 100%
RED 100%/GREENUP/BLUE DOWN
RED DOWN/GREEN100%/BLUE0%
RED 0%/GREEN DOWN/BLUEUP
RED UP/GREEN 0%/BLUE DOWN
RED DOWN /GREEN UP/BLUE0%
RED UP /GREEN 100% /BLUE 0%
RED DOWN /GREEN DOWN/ BLUEUP
NO FUNCTION
NO FUNCTION
NO FUNCTION
WHITE 1:3200K
WHITE 2:3400K
WHITE 3:4200K
WHITE 4:4900K
WHITE 5:5600K
WHITE 6:5900K
WHITE 7:6500K
WHITE 8:7200K
WHITE 9:8000K
WHITE 10: 8500K
WHITE 11:10000K
0 255
0 255
0 255
0 255
0 255
0 255
0 5
251 255
6 25
26 45
46 65
66 85
86 105
106 125
126 145
146 165
166 180
181 190
191 200
201 205
206 210
211 215
216 220
221 225
226 230
231 235
236 240
241 245
246 250
0 255
0 255
0 19
20 39
40 59
60 79
80 99
100 119
120 139
140 149
150 159
160 169
170 179
180 189
190 199
200 219
220 255
CONTROL
BASIC
18
4 USINGA DMX512CONTROLLER 2008.7.31
No function
Pan/tilt black activated
Pan/tilt black deactivated
Fan auto
Fan slow
Fan normal
Fan fast
No function
Auto1 (activated after 3secs)
Auto2 (activated after 3secs)
Test (activatedafter 3 secs)
Custom (activated after 3secs)
No function
Reset (activated after 3secs)
No function
