Britex DVR User manual

MELBOURNE
Britex Place Mirra Crt
Bundoora VIC 3083
t(03) 9466 9000
e[email protected]om.au
SYDNEY
16 Northumberland Drv
Taren Point NSW 2229
t(02) 9531 2100
[e-mail]
PERTH
Unit 1/8 Principal Link
Malaga WA 6090
t(08) 9249 5464
[e-mail]
BRISBANE
19 Manilla St
East Brisbane QLD 4169
t(07) 3363 2400
e[email protected]om.au
ADELAIDE
The Britex Group
SA State Office
t1300 764 744
e[email protected]om.au
Installation
Guide
360
20 350
Removable Panel
355
M4 Button Head
Screws
220
320
Trap Not Supplied
DVR
Vandal Resistant Drinking Fountain
A3
SHEET 1 OF 2
SCALE:1:5
TITLE:
DO NOT SCALE DRAWING
DATE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
APPV'D
CHK'D
DRAWN
REVISION
Britex Metal Products Co. Pty Ltd.
ACN: 004 309 737
2 Mirra Ct, Bundoora Victoria 3083
P: 03 9466 9000 F: 03 9466 9044
britex.com.au [email protected]
Drawing:
db
26/06/18
B
SD-2838.1
Sign
Date
Approval For Manufacture
DVR
Vandal Resistant
Drinking Fountain
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023

Australia’s Finest Stainless | britex.com.au
About
Preparation and Completion Notes
The BRITEX Stainless Steel Vandal Resistant Drinking Fountain provides great value for
money in projects that require a drinking bubbler highly resistant to vandalism. Easily
installed and fabricated from heavy duty S.S., all plumbing connections are housed
within the carcass of the fountain preventing them from being broken or tampered with.
Maintenance can be carried out by removing the access panel concealed underneath the
base. Supplied complete with heavy duty push button Drink Safe™ lead safe bubbler, wall
bracket and waste outlet.
Contractors please note: Ideally, stainless steel drinking fountain should be installed after all
other building activities that could cause contamination to the surface of the stainless steel
have been completed.
These activities include:
Using proprietary building mortar removers containing hydrochloric acid. Welding, cutting and
grinding that may ‘spray’ carbon steel and iron particles onto the stainless-steel surface.
1. Remove drinking fountain from box packaging and inspect for any damage before beginning
installation process.
2. Confirm all requested details are correct.
3. If drinking fountain is damaged in transit or if any details are not as requested, do not install
it. Notify Britex immediately within 24 hours of receipting the product.
2
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORISED SERVICE PERSON
Installation of this unit must be in accordance with AS/NZS 3500.1, AS/NZS 3500.2, the PCA
and the local regulatory requirements. Water and/or electrical supply conditions must comply to
national or state requirements and standards. Failure to comply shall void the product warranty
and may affect the performance of the product. For further support and after-sales care, please
contact Britex.
WARNING
WHEN INSTALLATION IS COMPLETE, ENSURE THESE INSTRUCTIONS REMAIN INSIDE
THE PLASTIC BAG PROVIDED WITH THE UNIT FOR FUTURE REFERENCE

Australia’s Finest Stainless | britex.com.au
DVR Drawing
3
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023
360
20 350
Removable Panel
355
175
M4 Button Head
Screws
40mm
Waste
220
320
333
6
44
6
Trap Not Supplied
DVR
Vandal Resistant Drinking Fountain - Installation
A3
SHEET 2 OF 5
SCALE:1:5
TITLE:
DO NOT SCALE DRAWING
DATE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
APPV'D
CHK'D
DRAWN
REVISION
Britex Metal Products Co. Pty Ltd.
ACN: 004 309 737
2 Mirra Ct, Bundoora Victoria 3083
P: 03 9466 9000 F: 03 9466 9044
britex.com.au [email protected]
Drawing:
db
26/06/18
B
SD-2838.5
Sign
Date
Approval For Manufacture
360
20 350
Removable Panel
355
175
M4 Button Head
Screws
40mm
Waste
220
320
333
6
44
6
Trap Not Supplied
DVR
Vandal Resistant Drinking Fountain - Installation
A3
SHEET 2 OF 5
SCALE:1:5
TITLE:
DO NOT SCALE DRAWING
DATE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
APPV'D
CHK'D
DRAWN
REVISION
Britex Metal Products Co. Pty Ltd.
ACN: 004 309 737
2 Mirra Ct, Bundoora Victoria 3083
P: 03 9466 9000 F: 03 9466 9044
britex.com.au [email protected]
Drawing:
db
26/06/18
B
SD-2838.5
Sign
Date
Approval For Manufacture
360
20 350
Removable Panel
355
175
M4 Button Head
Screws
40mm
Waste
220
320
333
6
44
6
Trap Not Supplied
DVR
Vandal Resistant Drinking Fountain - Installation
A3
SHEET 2 OF 5
SCALE:1:5
TITLE:
DO NOT SCALE DRAWING
DATE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
APPV'D
CHK'D
DRAWN
REVISION
Britex Metal Products Co. Pty Ltd.
ACN: 004 309 737
2 Mirra Ct, Bundoora Victoria 3083
P: 03 9466 9000 F: 03 9466 9044
britex.com.au [email protected]
Drawing:
db
26/06/18
B
SD-2838.5
Sign
Date
Approval For Manufacture

Australia’s Finest Stainless | britex.com.au
Installation Instructions
DVR Assembly Diagram
1. Take the unit out of the box.
2. Remove the access panel on the bottom of the DVR.
3. Place the unit on the wall where you want to fix it and mark the top of it.
4. Measure where the joggle on the wall will go and mark out the holes for that. Drill those
holes and fix the joggle to the wall. (Fixings are provided)
5. Place the DVR drinking fountain on the joggle, ensuring it is flush with the wall.
6. Mark the bottom fixing of the DVR and attached two appropriate fixings. (These are not
supplied)
7. Once the unit is fixed to the wall, the waste trap can be installed, this is not supplied.
Plumb up the bubbler/bottle filler according to the PCA or relevant Australian Standard.
Ensure it is working to the desired degree.
8. Reinstall the access plate to the bottom of the unit.
Note: No need for any special tools to carry out this job.
4
DVR
Assembly Drawing
A3
SHEET 3 OF 3
SCALE:1:5
TITLE:
DO NOT SCALE DRAWING
DATE
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
APPV'D
CHK'D
DRAWN
REVISION
Britex Metal Products Co. Pty Ltd.
ACN: 004 309 737
2 Mirra Ct, Bundoora Victoria 3083
P: 03 9466 9000 F: 03 9466 9044
britex.com.au [email protected]
Drawing:
db
26/06/18
B
SD-2838.3
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023

Australia’s Finest Stainless | britex.com.au 5
Technical Parameters
Inlet Connection 1/2” BSP Male
Recommended Inlet Pressure 350 kPa
Maximum Inlet Pressure 500 kPa
Working Temperature Range (°C) Min 5; Max 60
Nominal Flow Rate (LPM) 1.95
Finish Chrome
Troubleshooting Drinking Fountain
SYMPTOM CAUSES ACTION
No Water Water supply Check main supply
Leaking waste pipe Crack in pipe Contact plumber
Inconsistent flow Blocked top assembly Remove top assembly and clean
Button hard to press The mains pressure may be too
great Reduce to below 500kPa (70PSI).
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023

Australia’s Finest Stainless | britex.com.au
6
Spare Parts
74-08-0106
Battery Pack 6V DC with 6mm Dia. 2 Pin Plug (suits electronic button and
Solenoid unit)
TW-BF-HF
Hob Mounted Lead Safe Fixed Spout Gooseneck Bottle Filler -
Manufactured using high quality DZR solid brass with less than 0.25% lead
content*
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023

Australia’s Finest Stainless | britex.com.au
Warranty
The BRITEX product is backed by our manufacturer’s warranty available for download
from our website at www.britex.com.au. We expressly warrant that the product is free from
operational defects in workmanship and materials for the warranty period indicated on the
schedule in the manufacturer’s warranty. During the warranty period, BRITEX will repair or
replace any defective products manufactured by BRITEX at no charge, provided that the
terms of the manufacturer’s warranty are followed.
This warranty is the only warranty given by BRITEX, and we expressly disclaim all other
warranties, including but not limited to implied warranties of merchantability and fitness
for a particular purpose. This warranty represents the sole and exclusive remedy for breach
of warranty, and BRITEX shall not be liable for any incidental, special, or consequential
damages, including lost profits, labor charges, delays, vandalism, negligence, fouling
caused by foreign material, damage from adverse water conditions, chemical, electrical or
any other circumstances beyond BRITEX’s control.
This warranty shall be void if the product is abused, misused, improperly installed,
maintained, or altered. By purchasing our product, you agree to these terms and
conditions. We appreciate your business and look forward to providing you with high-
quality products and services.
7
Care and Maintenance
Stainless steel products should be kept clean at all times. The secret to stainless steel’s
ability to maintain a high-quality finish and promises of a long-life expectancy is the
invisible chromium-oxide film that sits on the surface and protects the steel beneath. To
maintain this film, it is essential that the surface remains clean and in constant contact
with oxygen. If this film is penetrated (either by abrasion or chemically) and dirt, liquid,
grime contaminants embed themselves in these micro chasms for an extended period,
the chromium oxide film will not be able to regenerate and the steel below will eventually
become damaged and discoloured.
What we recommend for general cleaning and maintenance:
Cleaning Materials:
• A soft cloth
• A soft-bristled brush
• A natural or artificial sponge
Cleaning Solutions:
• Hand washing soap / soft water solution
• Mild soap / soft water solution
White vinegar / soft water solution
It is recommended that general cleaning of stainless-steel surfaces be carried out weekly, or
as soon as a build-up of surface media has been observed. To clean, simply wash stainless
steel surfaces with, warm, diluted, mild soapy water using a cloth or soft bristled brush. Once
all dirt, oil and grime is removed, rinse thoroughly with clean water and wipe dry.
DVR Installation Guide | QID 2.1 | Rev 3 | 17 Oct 2023
