Britpart DA4512 User manual

2

Ty r e P r e s s u r e M o i t o r i g S y s t e m
Co te ts
Thank you choosing the Britpart Tyre Pressure Monitoring System.
This system is an advanced monitoring & a ert system of tyre conditions. It monitors tyre pressure and temperature and re ays the
state of each tyre to a disp ay unit. When any abnorma ities are detected, the system wi disp ay the status of the affected tyre and
sound an a arm to ensure you take action to remedy the prob em. Keeping your tyres in good condition at the right pressure can
extend the ife of your tyres and reduce fue consumption.
P ease read this manua carefu y before using our product.
Index
Notification 4
Genera Insta ation Diagram 4
Working Princip e 5
Components 5
Technica Specifications 6
Insta ation
Sensor Insta ation 7
Disp ay and Receiver Insta ation 8
Operation
System Operation 9
System A arm 10
Function Setting
Interface Setting 11
Temperature Unit Setting 12
Pressure Unit Setting 13
Set Reference Pressure 14
ID Exchange 15
Learn New ID 16
Learn ID By Low Frequency 17
Appendix 18
3

This system app ies to 4 whee ed vehic es with meridian tyre (vacuum tyre) and co d tyre pressure (22ºC) ower than 2.8 bar
(280KPa/40.6psi/2.86*104kgf/m2). It shou d be insta ed by a qua ified professiona according to this manua . This system is an
e ectronic device that measures and disp ays the inside air pressure and temperature of the tyres and gives a warning signa when
an abnorma ity is detected. The system has no contro ing function so the driver shou d rectify and detected prob ems as soon as
possib e. The performance of the sensors cou d be affected by chemica materia s. Preset pressure from the manufacturer is 2.40
Bar (240KPa/34.8psi/2.45*104kgf/m2). P ease set it to your vehic es recommended pressures after the initia insta ation (see
detai s on page 14). This system is to be used as a monitoring aid on y and Britpart wi take no responsibi ity after the kit is insta ed
and the user must ensure tyres are inf ated to the vehic e manufacturers recommendations.
Notificatio
Ge eral I stallatio Diagram
No. 2 Tyre Sensor No. 3 Tyre Sensor
No. 1 Tyre Sensor No. 4 Tyre Sensor
Disp ay
Receiver
B ack wire to ground
White wire to ACC ON
Red wire to +12v power
4

This system consists of 4 sensors and LCD disp ay. The sensor monitors the tyre inner pressure and temperature then transmits
the signa , the disp ay unit wi then show the signa and give an a arm if appropriate.
Worki g Pri ciple
Compo e ts
Ty r e P r e s s u r e M o i t o r i g S y s t e m 5
1234567
Code Name of Compo e t Qua tity
1Disp ay 1
2Receiver 1
3Tyre Sensor 4
4Disp ay Bracket - 1 2
5Disp ay Bracket - 2 1
63M Sticker 2
7Instruction Manua 1

Tech ical Specificatio s
6
Tyre Se sor
Worki g Voltage Ra ge DC 2.1 – 3.6v - High-powered battery inside
Worki g Curre t 0.6uA - Standby / 9mA - Transmission status
Worki g Temperature Ra ge -40–125ºC
Tra smitti g Freque cy 433.92MHz
Tra smitti g Power >5dBm
Modulati g Method FSK
Measurable Pressure 0–3.5bar (0–350KPa/0–50.8psi/0–3.58*104kgf/m2)
Measurable Temperature -40–+120ºC
Battery Life 5 years +
Size 76 x 56 x 22mm
Weight <38g - no va ve weight
Display Receiver
Worki g Voltage Ra ge Receiver Supp y 5v DC 9–15v DC
Receivi g Se sitivity N/A <-100dBm
Receivi g Freque cy N/A 433.92MHz
Size 83 x 41 x 18mm 75 x 55 x 17mm
Weight 70g 35g
Worki g Curre t Standby - <30mA / A arm - <80mA
Worki g Temperature Ra ge -30 – +80ºC

Sensor Insta ation
> Discharge the whee , press the tyre around the va ve by too to fix the sensor.
> Remove the origina air va ve.
> Insta the sensor - the ho e for air must not be jammed.
> Fix the sensors to the corresponding whee -
No. 1 is fro t left wheel; No. 2 is fro t right wheel; No. 3 is rear right wheel a d No. 4 is rear left wheel
> Insta the tyre and charge it with air to norma pressure, then turn it to ba ance it.
> Insta the whee .
I stallatio
Remove the origina
air va ve.
Ty r e P r e s s u r e M o i t o r i g S y s t e m 7
Fix the sensor.
Charge the tyre to
standard pressure
then ba ance the
whee .
Tighten the screw in
the sensor according
to c ockwise direction
by screwp ate.

I stallatio - co ti ued
8
Recommended
Insta the
disp ay on the
heater vent.
C ip the
bracket
appropriate y if
it is too ong.
Hide and fix
the receiver in
drivers
footwe .
Receiving
antenna
Disp ay bracket - 1 Disp ay bracket - 2
ACC. ON
Recommended
Insta the
disp ay in front
of the
dashboard.
Recommended
Insta the
disp ay in an
easy to see
p ace.
> Connect the red wire to +12 power supp y, white wire to the ACC. ON, b ack wire to ground.
Disp ay and Receiver Insta ation
> Fix the disp ay on a suitab e position with the bracket or 3M sticker.
3M sticker

Operatio
Ty r e P r e s s u r e M o i t o r i g S y s t e m 9
System Operation
The system enters into working status after insta ation. With ACC ON the system starts se f-test then disp ays the inside pressure
and temperature of each tyre for 2 seconds. If a tyres are in good condition, the disp ay wi go off automatica y, the status
indicator (LED) turns green. Otherwise the buzzer wi sound 3 times with the indicator in orange or red and the disp ay wi show the
re evant information, the buzzer wi sound 3 times every 3 minutes unti the prob em is rectified.
Press SCAN to read the data of each tyre.
Press SET 3 seconds to convert the temperature units - ºC to ºF
When the ACC ON cut off the power supp y, the system is sti in monitoring state but wi not a arm
Front right whee Power Sensor signa High temperature Temperature Temperature unit
Rear right whee Air eakage Tyre pressure Pressure unit Status indicator
Front eft
whee
Rear eft
whee
Scan
Set

System A arm
Examp e - when reference pressure is 2.4 bar.
Operatio - co ti ued
10
15% ower than
reference pressure
20% ower than
reference pressure
20% higher than
reference pressure
25% higher than
reference pressure
Temperature higher
than 70ºC
Temperature higher
than 80ºC
Air eaking
No signa
Fau ty sensor
Low battery - sensor

Interface Setting
Fu ctio Setti g
Ty r e P r e s s u r e M o i t o r i g S y s t e m 11
(a) Temperature setting (b) Pressure unit setting (c) Reference pressure setting
(d) ID exchange
(g) Quit setup mode
(e) Learn new ID (d) Learn ID by LF
E ter i to setup mode:
> Switch to ACC ON, press SET unti you hear the sound of ‘Bi” to enter setup
mode. Press SCAN to choose amongst the interfaces of (a) to (g), press SET
again to enter into the setup mode.
Quit setup mode:
>Press SCAN and se ect the interface (g). Then press SET to quit setup mode.
The system wi quit setup mode automatica y when the power supp y is shut off.

Temperature Unit Setting
P ease fo ow the steps be ow for unit change
Fu ctio Setti g - co ti ued
12
(a) Enter setup mode and se ect the
interface of Temperature Unit
Setting.
(b) Press SET to enter the
Temperature Unit Setting, the
present temperature unit wi be
disp ayed.
(c) Press SCAN, you can shift
between ºC and ºF.
(d) Press SET to confirm the
temperature unit. The system wi quit
setup mode of temperature unit in
case of no operation in 10 seconds,
the origina setting wi be kept
unchanged. The system wi enter into
next setup interface automatica y
after setting or automatic quitting.

Pressure Unit Setting
P ease fo ow the steps be ow for unit change
Fu ctio Setti g - co ti ued
Ty r e P r e s s u r e M o i t o r i g S y s t e m 13
(a) Enter setup mode and se ect the
interface of Pressure Unit Setting.
(b) Press SET to enter the Pressure
Unit Setting, the present pressure
unit wi be disp ayed.
(c) Press SCAN, you can shift
between Bar and PSI.
(d) Press SET to confirm the setting of
new pressure unit. The system wi quit
the pressure unit setting mode in case
of no operation in 10 seconds, the
origina pressure unit setting wi not
be changed. The system wi enter into
next setup interface automatica y
after setting or automatic quitting.

Fu ctio Setti g - co ti ued
14
Set Reference Pressure - the preset pressure – 2.4 Bar
To reset reference pressure for different types of cars, fo ow the steps be ow.
1 standard air pressure - 1bar = 1000Kpa = 14.5psi = 1.02*104kgf/m2.
(a) Enter setup mode and se ect the
interface of Set Reference Pressure
(b) Press SET to enter the interface
of the setup mode of Reference
Pressure, the system shows the
present reference pressure.
(c) Press SCAN, the pressure wi
increase by 0.1bar or 1psi and wi
cyc e among 0.5–2.8bar or 7–41psi
(d) Press SET after confirming the
new reference pressure.
(e) The system wi enter into the
reference pressure setting of back
tyres automatica y after setting
front tyres pressure and show the
current reference pressure. Set the
new reference pressure step (c) and
(d).
(f) The system wi quit reference
pressure setting mode automatica y
in case of no operation in 10
seconds. The origina reference
pressure wi keep unchanged. The
system wi enter into next interface
after setting or automatic quitting.

Fu ctio Setti g - co ti ued
Ty r e P r e s s u r e M o i t o r i g S y s t e m 15
ID Exchange
After some period of time in use, the tyres shou d be exchanged to pro ong their ives. The ID positions of the sensors shou d be
exchanged according y. For examp e the front right whee changes with the back right whee .
(a) Enter setup mode and se ect the
interface of ID exchange.
(b) Press SET to enter the ID
Exchange mode. It wi show the
position of the front eft whee and
its ID.
(c) Press SCAN, se ect the front
right whee then press SET to
confirm.
(d) Press SCAN se ect the back right
whee (indicator of se ected tyre wi
be kept unchanged).
(e) Press SET to finish the ID
Exchange. The system wi quit ID
exchange mode automatica y in
case of no operation in 10 seconds,
the ID wi not be exchanged. The
system wi enter into next setup
interface after setting or automatic
quitting.
Repeat the steps to
exchange other ID.

Fu ctio Setti g - co ti ued
16
(a) Enter setup mode and se ect the
interface of Learn New ID’.
(b) Press SET to enter the Learn
New ID mode. It wi show position of
front whee and its ID
(c) Press SCAN, se ect the front
right whee then press SET to
confirm.
(d) Waiting for transmitting and
receiving.
(e) Keep the sensor into the range
of 10cm from the disp ay.
Repeat the steps to
earn other ID.
(f) The origina ID wi be rep aced
when the system receives a new
one, the setting is finished. The
system wi quit Learn New ID mode
automatica y in case of no operation
in 1 minute, the ID wi not be
exchanged. The system wi enter
into next setup interface after
setting or automatic quitting.
Learn New ID
When a sensor is rep aced, fo ow the steps be ow to earn new ID. For examp e earn new ID for front right whee .

Fu ctio Setti g - co ti ued
Ty r e P r e s s u r e M o i t o r i g S y s t e m 17
Learn ID by Low Frequency
This function is on y supported by the ID Reading Contro er by our company. Otherwise, ID earning by ow frequency wi not be
rea ised.
(c) Use the Reading Contro er to
read out ID of a whee s needed to
be insta ed or updated and then
send out the data.
(d) The origina ID wi be rep aced
when the system received a the
new data, the setting is finished.
Press SCAN to quit the setting
mode and keep the origina setting
unchanged. The system wi enter
into next setup interface after
setting or automatic quitting.
(b) Press SET to enter the LF Learn
ID mode, the system wi indicate the
position of a the whee s, waiting for
the data from the Reading
Contro er.
(a) Enter setup mode and se ect the
interface of LF Learn ID.

Conversion tab e of pressure units
Appe dix
18
(N/m2)Pa kgf/m2kgf/cm2bar atm mmH2OmmHg (lb/i 2) psi
(N/m2)Pa 1 0.101972 10.1972*10-6 1*10-5 0.986923*10-5 0.101972 7.50062*10-3 145.038-10-6
kgf/m29.80665 1 1*10-4 9.80665*10-5 9.67841*10-5 1*10-8 0.0735559 0.00142233
kgf/cm298.0665*1031*1041 0.980665 0.967841 10*103735.559 14.2233
bar 1*10510197.2 1.01972 1 0.986923 10.1972*103750.061 14.5038
atm 1.01325*10510332.3 1.03323 1.01325 1 10.3323*103760 14.6959
mmH2O0.101972 1*105-8 1*10-4 9.80665*10-5 9.67841*10-5 173.5559*10-3 1.42233*10-3
mmHg 133.322 13.5951 0.00135951 0.00133322 0.00131579 13.5951 1 0.0193368
(lb/i 2) psi 6.89476*103703.072 0.0703072 0.0689476 0.0680462 703.072 51.7151 1
Conversion tab e of temperature units - ºF = ºC*9/5+32
ºC ºF ºC ºF ºC ºF ºC ºF ºC ºF
-50 -58 -10 14 30 86 70 158 110 230
-40 -40 0 32 40 104 80 176 120 248
-30 -22 10 50 50 122 90 194 130 268
-20 -4 20 68 60 140 100 212 140 284

Ty r e P r e s s u r e M o i t o r i g S y s t e m 19
