1.0 PRODUCT DESCRIPTION
TheLBC-HDMI-T/R-WPtransmitter and receiverisa high performance,
lowcost,miniature,LinkBridgeTMHDBaseTHDMITransmissionSystem.
It carries one (1) unidirectional HDMI video with embedded audio. This
uniqueCAT-5e/6 transmissionsystem letsyourdigitalflat panel display
extendupto 70m (230ft)at 4K2KandWUXGA(1920x1200 @60Hz)or
720p/1080i/1080pHDTV videoresolution.
LBC-HDMI-T/R-WP is a 1 gang single-input Decora style wall plate
transmitterandreceiver.When the HDMIwith activesignalisconnected,
thesignalwillbesent to the compatibleHDBaseTreceiver automatically.
Inaddition,theLBC-HDMI-T/R-WPsupportsPoH(PoweroverHDBaseT)
where they can be powered by a remote Matrix, a compatible receiver/
transmitter or local DC adapter.
In addition, the LBC-HDMI-T/R-WP transmitter and receiver are
compatible with our Designer and Standard (LBH & LBC model) Series
transmittersandreceivers.Thismakes both CAT-5e/6transmission and
HDMI/DVI/VGA/YPbPrIconversioninonesinglesystemsetup.Theunits
are easily monitored by a power/ link LED indicator. Figures 1-1, and
1-2 illustrate the front and rear panels of the LBC-HDMI-T/R-WP unit.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
6
Front Panel (Wall Plate)
1. Link:Soildredwhen power up.Blinkingred/amberwhen HDBT
connectwithoutvideosignal.Solidamberwhenvideoconnection
established.
2. HDMI In: Connect to HDMI source for Tx unit and connect to
display for Rx unit.
Figure 1-1
LBC-HDMI-T/R-WP Front Panel

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 7
Rear Panel (Wall Plate)
1. Power: Connect to 24V DC adapter here to power up device.
2. HDBaseT: Connect RJ45 category cable from HDBaseT
transmitter to receiver.
Figure 1-2
LBC-HDMI-T/R-WP Rear Panel

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
8
2.0 SETUP
The BCI LBC HDBaseT Extender Series units are used in pairs. One
LBC-HDMI-T-WP transmitter unit is located at the near-end (source)
andconnectedthrough a singlecategorycable, to theLBC-HDMI-T-WP
receiver shown below and located at the far-end (sink) of the link.
Figure2-1 depictsa typical installation forthe LBC-HDMI-T/R-WPpair.
2.1 Mounting
Beforeinstalling theunits into your housing, make sure there is
enoughspacetopullandconnectboththeelectricalandcategory
cables without stressing them beyond the manufacturer’s
limitations (also known as the minimum bend radius).
2.2 Cabling and Connectors
In order to setup the LBC-HDMI-T/R-WP properly, make sure
toobserve thefollowing instructionswhen installingthe proper
cables. The LBC-HDMI-T/R-WP requires two parts to the
cablingsetup,thevideosignalandthetransmission connections.
Figure 2-1
LBC-HDMI-T-WP with LBC-HDMI-R-WP Transmission Pair

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 9
2.3 HDMI Video Interface
The HDMI video connection is the HDMI plug connectors for
video input port. Use the following instructions to properly
connect your component video as illustrated in Figure 2-2.
Connectthe LBC-HDMI-T/R-WP(Transmitter/Receiver) unit’s
HDMI video source and video output to the user’s display with
the appropriate HDMI cables.
Figure 2-2
Video Connection User’s HDMI Video Source and Display

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
10
2.4 CAT-5e/6 Transmission Connection
Select an appropriate terminated shielded CAT 5e/6 cable.
Each unit’s RJ45 ports in the system are specified for use with
RJ45connectors. Follow the ensuing instructionson installing
andconnecting theHDBaseT links:
1. Ensurethepower is offbefore proceeding withtheCAT-5e/6
cableinstallation.
2. Connect thecable from one unit to the other connecting the
near end LBC-HDMI-T-WP unit’s RJ45 port and to the far
end of the LBC-HDMI-R-WP (use any compatible LBC or
LBH series receiver) unit’s RJ45 RX port as illustrated in
Figure 2-3.
Figure 2-3
CAT-5e/6 Connection

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 11
3.0 DC POWER CONNECTION
Congratulations!Youare nowreadytopoweruptheLBC-HDMI-T/R-WP
and set up your network connection. In order to make sure that you
have a proper installation, please observe the following:
1. Your AC jack has power.
2. The 24VDC power supply is working.
3. Yourelectrical systemhas proper grounding(this ensuresthat
your power supply does not suffer from voltage variations).
4. Power Surge Protection. This is optional, but highly
recommended.A UPS system provides voltage regularity as
well as prevents spikes from occurring, thus protecting your
LBH-HDMI-T/R-WPfrom sensitive voltage conditions.
TheLBC-HDMI-T/R-WP derivespower froman external 24VDC power
supply or via PoH (Power over HDBaseT). This power supply is a wall
mountedAC/DCadapter,100-240 VAC,50-60 Hz,at 1.0A.This power
supply comes standard for the LBC-HDMI-T/R-WP unless otherwise
specified. To provide power to the LBC-H/V-T-WP, simply connect the
power cord, already provided with the units, and connect it to the wall
jack. (You will find one power cord per unit). Once the power cord has
beenconnected tothe wall jack,connect 24VDCto the unitand theunit
should power up immediately. If you have any problems or concerns,
regarding the installation, make sure that you have taken the proper
steps to ensure a proper power connection. Otherwise, feel free to
contact us for any questions you may have.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
12
3.1 In-Wall Power/CAT-5e/6 Wiring Instruction
The in-wall power/CAT-5e/6 installation for the
LBC-HDMI-T/R-WP wall plate must confirm national and local
electricalcodes, e.g., ULjunction boxes shall be usedand DC
power source shall not exceed product rated range (+24VDC
@ 1A). Follow the following steps for power/CAT5e/6
installation:
1. FeedbothCAT-5e/6and power cables throughthe opening
of the wall box, and secure the cables with cable clamps
to provide strain relief.
2. Terminated CAT-5e/6 with RJ45 connector to be directly
plugged into the RJ45 connector port of the
LBC-HDMI-T/R-WP unit.
3. Before connecting power wire to the LBC-HDMI-T/R-WP
unit, make sure power supply is off. Prepare the Positive
(+24V)and chassis ground(CHASSIS toearth ground) tip
of the power wire as shown in Figure 3-1 to be directly
plugged into the captive screw +24VDC connector of the
LBC-HDMI-T/R-WP unit. Make sure the polarity of the
connection is correct. Insulate any exposed wire shields
to prevent short circuits.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 13
Note 1: During installation, the installer may need to connect
the power supply output to an appropriate Listed NEC type
cablebefore it isrouted behind awall. Simply routingthe power
supply output cable behind a wall will most likely not comply
with applicable installation requirements. Unit should only be
powered by a power source that is Listed (NEC) Class 2 or a
ListedITEPowerSupplymarked/ratedasLPSorLimited Power
Source.
Note2:Theinstallationshallbeinaccordancewiththeapplicable
provisionsoftheNationalElectrical CodeANSI/NFPA70,Article
725 and the Canadian Electrical Code, Part 1, Section 16.
Note3: Thepower supplyshall notbe permanentlyfixed tothe
building structure or similar structures.
Note 4: The power supply shall not be located within
environmental air handling spaces or within the wall cavity.
Note 5: The power supply is to be located within the same
vicinityastheA/Vprocessingequipmentinan ordinary location,
Pollution Degree 2, secured to the equipment rack within the
dedicated closet, podium or desk.
Figure 3-1
Power Connection

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
14
4.0 MAINTENANCE AND TROUBLESHOOTING
4.1 Maintenance
Thereis nooperator maintenanceother then keeping the units
clean. However, observethe followinglight indicatorsto make
sure that the unit is working properly:
4.2 Troubleshooting
If the LBC-HDMI-T/R-WP units do not operate properly after
installation,checkforpossible cable breaks,looseconnections,
and incorrect cable connections. If problems persist that may
be fiber related, contact BCI at 1-800-214-0222 for further
assistance.
For electrical problems, perform the following troubleshooting
procedures:
1. If the POWER indicator is OFF, check for the following:
a. The line cord is plugged into the unit and your outlet
has power.
2. If the POWER indicator is ON, but the Link indicator is
OFF, check for the following:
a. Make sure the appropriate cables are being used.
b. Cable and cable connectors are not broken.
c. For each unit, the transmit (TX) cable is connected to
the other unit’s receiver (RX).
3. If the POWER indicator and Link indicator are ON, but
the channels are not operating, then:
a. Checktoseethattheattacheduserequipmentis turned
on.
b. Bothendsofthelinkareconnectedtothecorresponding
equipmentandtothesamecorrespondingchannelport.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 15
c. Cable connections at both channels are securely
fastened to each connector. Turn the power off, then
back on to reset the link.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
16
5.0 SPECIFICATIONS
Video
Resolution Up to 4K2K and 1080p @ 60Hz
or 1920x1200 @ 60Hz
Connector HDMIFemale Plug
Protocol DDC/EDID/HDCPCompatible
Transmission
Cable Type Single CAT 5e/6
Number of cables 1
Connector RJ45
MaxDistance 70m (230 ft)
Physical
Dimension (H x W x D) 2.62" x 1.31" x .071" Wall Plate
Power Level (max.) +24VDC @ 1A
LED Indicator Power/Link
OperatingTemperature 0 to +55oC
Humidity 5 to 95% RH, non-condensing

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 17
6.0 SERVICE PROCEDURE
6.1 Replacement Policy
Standard products found defective on arrival (DOA) will be
replaced,based onavailability,within 24 to48 hoursanywhere
in the U.S. Please call Customer Service at 800-214-0222 for
information.
6.2 Return/Repair Service
TheLBC-HDMI-T/R-WP Systemcontains no user serviceable
components.If youhaveaproblemwithyourunit,please contact
the Customer Service Department. To facilitate our return/
repair processing please contact Broadata Communications,
Inc. to obtain a Return MaterialAuthorization (RMA). Please
includethe followinginformation:
• Productmodel number
• SerialNumber
• Complete description of problem
• Hardwareinstallation description
BroadataCommunications, Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone] (Facsimile)
e-mail:[email protected]
Website: www.broadatacom.com

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
18
7.0 LIMITED WARRANTY
Broadata Communications, Inc. (BCI) warrants, for a period of one
yearfromdate ofshipment,each productsoldshall be freefrom defects
in material and workmanship. BCI will correct, either by repair, or at
BCI’s election, by replacement, any said products that in our sole
discretion prove to be defective and are returned to the manufacturing
location within 30 days after such defect is ascertained. All warranties
are limited to defects arising under normal use and do not include
malfunctionsorfailureresultingfrommisuse,abuse, neglect, alterations,
electrical power problems, usage not in accordance with product
instructions, improper installation, or damage determined by BCI to
havebeen causedby the Buyer or repairmade by athird party. Limited
warrantiesgranted onproducts are to the initialcustomer end-userand
arenot transferable. OUR LIABILITYUNDERTHISWARRANTYSHALL
IN ANY CASE BE LIMITED TO THE INVOICE VALUE OF THE
PRODUCTSOLDANDBCISHALLNOTBELIABLETOANYONEFOR
CONSEQUENTIALORINCIDENTALDAMAGESARISINGFROMTHE
USE OF ITS PRODUCTS OR THE SALE THEREOF. We make NO
WARRANTYAS TO THE MERCHANTABILITY OF ANY GOODS, OR
THAT THEY ARE FIT FOR ANY PARTICULAR PURPOSE OR END
APPLICATION NOR DO WE MAKEANY WARRANTY, EXPRESSED
OR IMPLIED OTHER THANAS STATEDABOVE.

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMI WallPlateHDBaseTTransmissionSystem
Broadata Technical Support, [email protected] 19

LBC-HDMI-T/R-WPUser’sManual
LinkBridgeTM HDMIWallPlate HDBaseTTransmissionSystem
Broadata Technical Support, [phone]
20

BroadataCommunications, Inc.
2545 West 237th Street, Suite K
Torrance, CA 90505
1-800-214-0222
[phone]
[phone] (Facsimile)
e-mail:[email protected]
Website: www.broadatacom.com
60000-LBC-HDMI-T/R-WP
