Broadcom WICED Sense User manual

Broadcom®August 6, 2014 • MMPWICED-Smart-DQSG100-R
WICED Sense Kit
Quick Start
Broadcom Corporation
5300 California Avenue
Irvine, CA 92617
© 2014 by Broadcom Corporation
All rights reserved
Printed in the U.S.A.
Broadcom®, the pulse logo, Connecting everything®, and the Connecting everything
logo are among the trademarks of Broadcom Corporation and/or its affiliates in the
United States, certain other countries and/or the EU. Any other trademarks or trade
names mentioned are the property of their respective owners.
Broadcom®Corporation reserves the right to make changes without further
notice to any products or data herein to improve reliability, function, or design.
Information furnished by Broadcom Corporation is believed to be accurate
and reliable. However, Broadcom Corporation does not assume any liability
arising out of the application or use of this information, nor the application or
use of any product or circuit described herein, neither does it convey any
license under its patent rights nor the rights of others.

Broadcom®August 6, 2014 • MMPWICED-Smart-DQSG100-R
Introduction
The WICED Sense TAG is made up of the BCM20737S
Bluetooth Low Energy SoC and five ST Microelectronics
sensors: gyroscope, accelerometer, eCompass, pressure,
and humidity/temperature. The BCM20737S connects directly
to the sensors without the need for an external micro-
processor. The WICED Sense smartphone application
receives and displays real-time data from the sensors.
Kit Contents
1. One WICED Sense TAG
2. One USB to Micro USB cable
3. This document, which contains information about how to
download all required software, including the:
• WICED Sense sample application for iOS.
• WICED Smart Software Development Kit 2.X
Setup
Pair the WICED Sense TAG and an iPhone
1. From the iPhone 4S (or greater):
• Go to the iTunes App Store.
• Search for and download the WICED Sense app.
2. When the download is complete, start the WICED Sense
app.
3. On the WICED Sense TAG:
• Remove the plastic shipping strip in the battery
compartment (pull the tab).
• Press the Wake button. See the WICED Sense TAG
illustration for the location of the Wake button.
4. On the phone, the app will display the WICED Sense kits
that are ready to pair. Tap the desired kit to complete
pairing.
Tap the information icon ("i") in the lower-left corner of the
iPhone screen for application information.
Kit Components
Humidity
Sensor
USB Port
(Not Visible)
Wake
Button
App
Button
USB Cable
Sense Tag iPhone App UI
Buzzer On
the Back
For additional information and/or to download the WICED
Smart SDK visit:
http://www.broadcom.com/wicedsense
For additional support and/or to download the WICED Sense
reference design package, visit:
http://community.broadcom.com/community/wiced-smart
Note
ST Microelectronics Devices used in the WICED Smart Kit
(http://www.st.com/web/en/catalog/sense_power/...):
• Gyroscope (L3GD20) – ...FM89/SC1288/PF252443
• Accelerometer (LIS3DSH) – ...FM89/FM89/SC444/PF252716
• eCompass (LSM303D) – ...FM89/SC1449/PF253884
• Pressure sensor (LPS25H) – ...FM89/SC1316/PF255230
• Humidity Temperature sensor (HTS221) – ...FM89/SC1718/PF260067

Regulatory Statement
Broadcom BCM9WICED_SENSE
1. USA—Federal Communications Commission (FCC)
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
INFORMATION TO USER:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy. If not installed and used in
accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the equipment off and on, the
user is encouraged to try and correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna
-Increase the distance between the equipment and the receiver.
-Connect the equipment to outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2. Canada - Industry Canada (IC)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
French:
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s) .
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit
pas provoquer d'interférences et ( 2) cet appareil doit accepter toute interférence , y
compris celles pouvant causer un mauvais fonctionnement de l'appareil.
