BroadLink SC4R1 User manual

User Manual
Lights Remote Control | SC4R1
www.ibroadlink.com
Email: [e-mail]
| Overview
Front
Back
Battery Cover
* Requires 2x AAA batteries (not included in package)
* Works with FastCon BLE lights
| Button Description
Button
Function
Description
ON
All ON
OFF
All OFF
Bri+
Brighten
Press shortly to brighten/dim 1 level;
Press and hold to brighten/dim continuously
Bri-
Dim
K+
Cooler Color
Press shortly to tune color temperature
cooler/warmer 1 level;
Press and hold to tune color temperature
continuously;
K-
Warmer Color
Group 1/2/3 ON
Group ON / Pair
Press and hold to pair lights (in pairing
mode) to specific group;
Quickly press 5x to unpair lights (in pairing
mode) from group
Group 1/2/3 OFF
Group OFF

RGB
Change Color
Press to change color between Red, Green
and Blue (under same brightness)
CW
Change Color Temp
Press to change color temperature between
Cool White, Warm White and Neutral (under
same brightness)
* Dimming (Bri+/-) and color temperature tuning (K+/-) are effective to All or Group 1/2/3
according to last ON/OFF target
| Pair Lights
Power up the lights (if they are already powered up, switch them off and on just once)
to enable pairing mode. The pairing mode will last for 10s.
Press and hold ON button of group 1/2/3 during lights pairing mode. The lights will
be automatically paired to the group if they flash twice.
| Unpair Lights from Group
Switch the lights off and on just once to enable pairing mode.
Quickly press 5 times of OFF button of the group during lights pairing mode to unpair
lights from group
| Important Notices
The battery can last for 2 years for typical use. If the LED doesn't light up when
pressing, the battery might be used up and changing a new battery is required.
The use of remote control DOES NOT require App. If you want to use App control,
please follow the user manual in specific lighting product to pair lights in App. Pairing
lights in App doesn’t affect use of remote control.
| FCC Radiation Exposure Statement
FCC ID: 2ATEV-SC4R1
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
RF exposure statement
This equipment complies with the FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

NOTE 1: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
