BM818Operation Manual 1/34
BM818
Operation manual_V1.4
Important Statements
Copyright Notice
All right reserved：ShangHai broad mobi Communication
Technology Co LTD
This material and contains all of the content belong to
ShangHai broad mobi Communication Technology Co
LTD, and it is protected by Chinese law and any relevant
copyright from international convention. anyone who
donothave the authorization in written form by
ShangHai broad mobi Communication Technology Co
LTD cannot copy, spread, modify or other methods to
use part or all of content, the offender will be
investigated and affixed legal liability。

BM818Operation Manual 2/34
Unguaranteed Statements
Shanghai broad mobi Communication Technology Co LTD
does not make express or implied statement or
guarantee for any details from this document, and also
not be responsible for Specific purpose of marketability
and applicability or any indirect, special, or jointly any
loss .
Confidential Statements
The information from this document include any
attachment is confidential information. The receiver
must know this document is classified，only use to the
prescriptive purpose, and cannot leak out this document
to any third party.
Disclaimer Statements
The company does not undertake any property or
personal injury caused by inappropriate operation.
Please must follow technical specifications and reference
design from the manual. Before the statement, the
company has right to make changes according the

BM818Operation Manual 3/34
development of technological, and version change
without prior notice.
Contents
1. Introduction ………………………………………………………………….……………..6
1.1. Purpose .…………………………………………………………........................6
1.2. General view ..……………………………..…………….…………………………..6
2. Brief introduction …..…………………………………………….……………………..6
2.1. Necessaryequipment .…………………………………….…...................7
3. Set up and Install ...………………………………………………………..…….……...8
3.1. The Construct of Hardware Environment ………………………..……..8
3.1.1. How put in or out SIM/USIM card ..………………………………8
3.1.2. How to link module ..………………………………………..…….....11
3.1.3. How to link main antenna ..……………………………..……..….12
3.1.4. How to link diversity antenna …..…………………………….….14
3.1.5. How to link USB cable..…………………………......................16
3.1.6. How to power on ..………………………………………..…….……..17
3.1.7. How to power off ...…………………………………………………….17
3.2. The Construct of Software Environment ....…………………………..17
3.2.1. How to install driver …………………………………………………..17
3.2.2. How to upgrade firmware.……….……..………………………..22
4. Debugging and Testing .………………………………………………………………24

BM818Operation Manual 4/34
4.1. How to use USB cable to communicate ………………………………..24
4.2. How to make data connection …………………………………………..…25
4.3. How to make voice call out ………………………………..…………………30
4.4. How to check module information and SIM card status ……….31
4.5. How to set airplane mode …………………………….……………………..32
5. CAUTION..………………………………………………………………………………….33

BM818Operation Manual 5/34
1. Introduction
BM818 EVB use for testing the function and performance of
BM818module ，and provide relevant assessment to help
customer develop application.
1.1 Purpose
This document detailed describes the basic function of BM818
and point out the main feature is data transmission.
1.2 General view
Chapter 2, Main introduction the Development
environment and list of equipment for BM818
Chapter 3, in detail describe the construct of software
environment for BM818
Chapter 4, in detail describe the methods of data
transmission and common business for BM818
2. Brief Introduction
BM818 EVB is development and evaluation board that for
customer to test the performance and function of
BM818modul.This EVB board is module adapter PCBA board，

BM818Operation Manual 6/34
it has USB interface, SIM card interface, MINI PCI-E port
3 ports.
2.1 Necessary equipment
The chart 1 detailed describe the necessary
equipment for testing environment BM818.
Chart 1：EVB Kit List
Equipment
EVB kit whether or
not Include
Description
EVB Board
Yes
Use for BM818test

BM818Operation Manual 7/34
USB Cable
Yes
Standard USB
Antenna
Yes
Antenna has two parts：
1）diversity antenna and
main antenna
2）antenna patch cord
BM818 Board
Not
SIM/USIM
Not
Need a SIM/USIM Card have
balance
Chart 2 Antenna Gain
Frequency (MHz)
Gain （dBi）
700
3.08
711
2.24
781
1.44
791
1.14
824
2.80
896
0.78
960
0.14
1710
1.7
1805
2.3
1880
3.25
1950
3.1
2150
2.28
2300
1.3
2400
1.78
2500
2.04
2690
0.94
3. Set up and Install
EVB construct divide by hardware environment and software
environment：

BM818Operation Manual 8/34
1) The Construct of Hardware Environment
How put in or out SIM/USIM card
How to link module
How to link main antenna
How to link diversity antenna
How to link USB cable
How to power on
How to power off
2) The Construct of Software Environment
How to install driver
How to upgrade firmware
3.1．The Construct of Hardware Environment
3.1.1. How put in or out SIM/USIM card
Need a SIM/USIM Card havebalance.
The step for put in SIM/USIM:
1)Put EVB upwards, hold the yellow button, and pull out the
SIM Card slot. See Picture 1 and 2.

BM818Operation Manual 9/34
(Picture 1)
（Picture 2）
2)Put SIM Card into the slot, make sure SIM chip upwards, put
into the SIM slot on EVB Boar. See Picture 3 and 4.

BM818Operation Manual 10/34
（Picture 3）
（Picture 4）
3.1.2. How to link module
Put module into development board after finish install SIM

BM818Operation Manual 11/34
card:
1) Put EVB Board right side up, and put module into Mini
PCI-E connector. See Picture 5 and 6.

BM818Operation Manual 12/34

BM818Operation Manual 13/34
（Picture 5）
（picture 6）
2) Put module into Mini PCI-E with screw fixation. See Picture
7。

BM818Operation Manual 14/34
（Picture 7）
3.1.3. How to link main antenna
Before the link antenna, need finish put in SIM card and
Module.
1) Antenna interface located on top right of module with sign
“M”. See Picture 8.
（Picture 8)

BM818Operation Manual 15/34
2) Spike RF Patch cord into module connector smoothly. See
Picture 9。
（Picture 9）
3) Tightening antenna SMA contact and RF patch cord SMA
contact. See Picture 10。
（Picture 10）

BM818Operation Manual 16/34
3.1.4. How to link diversity antenna
Before link diversity antenna, need finish put SIM Card and
module in, and link the main antenna
1) The antenna interface is located on the top left of module
with sign “D”. See Picture 11.
(Picture 11)
2) Spike RF Patch cord into module connector smoothly. See
Picture 12.

BM818Operation Manual 17/34
（Picture 12）
3) Tightening antenna SMA contact and RF patch cord SMA
contact. See Picture 13
（Picture 13）
3.1.5．How to link USB cable
Follow the step to link USB cable:

BM818Operation Manual 18/34
1) Put EVB Board right side up;
2) Put the port B of USB Cable into the USB slot on the EVB
Board.
3) Put the port A of USB cable into the USB interface of
PC.See Picture14.
（Picture 14）
3.1.6．How to power on
BM818 only support electrify power on, all need just put the
port A of USB cable into PC, and module will auto power
on.
3.1.7．How to power off
BM818 support outage shutdown, module will shut down
when VBAT blackout.
A
B

BM818Operation Manual 19/34
3.2 The Construct of Software Environment
3.2.1．How to install driver
1）First use USB cable to connect PC and module,
power module on, Windows will popup new
equipment window, choose“No, not this time”, then
click”Next”
Picture 15: find new hardware
2）Choose “Install from a list or specific location
(Advanced)”, click“Next”

BM818Operation Manual 20/34
Picture 16: choose the method for install driver
BM818 choose the path that driver file is located,
and click “Yes”;
3）Click“Next”
Picture 18: Choose driver file path 2 in XP
